NISSAN NOTE 2016 Service Repair Manual

DLK-112
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
SYMPTOM DIAGNOSIS
DOOR DOES NOT LOCK/UNLOCK WI
TH DOOR LOCK AND UNLOCK
SWITCH
ALL DOOR
ALL DOOR : DescriptionINFOID:0000000012430051
All doors do not lock/unlock using door lock and unlock switch.
ALL DOOR : Diagnosis ProcedureINFOID:0000000012430052
1.CHECK DOOR LOCK AND UNLOCK SWITCH
Check door lock and unlock switch.
Refer to DLK-89, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK DOOR LOCK ACTUATOR
Check front door lock assembly LH.
Refer to DLK-79, "
DRIVER SIDE : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000012430053
Driver side door does not lock/unlock using door lock and unlock switch.
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000012430054
1.CHECK DOOR LOCK ACTUATOR
Check front door lock assembly LH.
Refer to DLK-79, "
DRIVER SIDE : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
PASSENGER SIDE
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
DLK-113
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PASSENGER SIDE : DescriptionINFOID:0000000012430055
Passenger side door does not lock/unloc k using door lock and unlock switch.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000012430056
1.CHECK DOOR LOCK ACTUATOR
Check front door lock actuator RH.
Refer to DLK-80, "
PASSENGER SIDE : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
REAR LH
REAR LH : DescriptionINFOID:0000000012430057
Rear LH side door does not lock/unlock using door lock and unlock switch.
REAR LH : Diagnosis ProcedureINFOID:0000000012430058
1.CHECK DOOR LOCK ACTUATOR
Check rear door lock actuator LH.
Refer to DLK-81, "
REAR LH : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
REAR RH
REAR RH : DescriptionINFOID:0000000012430059
Rear RH side door does not lock/unlock using door lock and unlock switch.
REAR RH : Diagnosis ProcedureINFOID:0000000012430060
1.CHECK DOOR LOCK ACTUATOR
Check rear door lock actuator RH.
Refer to DLK-82, "
REAR RH : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-114
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to
GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR DOES NOT LOCK/UNLOCK WITH DRIVER SIDE DOOR LOCK KNOB OR
DOOR KEY CYLINDER
DLK-115
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR DOES NOT LOCK/UNLOCK WITH DRIVER SIDE DOOR LOCK
KNOB OR DOOR KEY CYLINDER
Diagnosis ProcedureINFOID:0000000012430061
1.CHECK POWER DOOR LOCK OPERATION
Check power door lock operation.
Does door lock/unlock with door lock and unlock switch?
YES >> GO TO 2.
NO >> Refer to DLK-112, "
ALL DOOR : Diagnosis Procedure".
2.CHECK UNLOCK SENSOR
Check unlock sensor.
Refer to DLK-92, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-116
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DOOR DOES NOT LOCK/UNLOCK
WITH DOOR REQUEST SWITCH
ALL DOOR REQUEST SWITCHES
ALL DOOR REQUEST SWITCHES : DescriptionINFOID:0000000012430062
All doors do not lock/unlock using all door request switches.
ALL DOOR REQUEST SWITCHES : Diagnosis ProcedureINFOID:0000000012430063
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent Key button?
YES >> GO TO 2.
NO >> Refer to DLK-22, "
INTELLIGENT KEY SYSTEM : System Description".
2.CHECK LOCK/UNLOCK BY I-KEY SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “LOCK/UNLOCK BY I-KEY” in “Work support”.
3. Check “LOCK/UNLOCK BY I-KEY” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “ON” in “LOCK/UNLOCK BY I-KEY”.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
• Instrument center: Refer to DLK-65, "
DTC Logic".
• Console: Refer to DLK-67, "
DTC Logic".
• Trunk room: Refer to DLK-69, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna.
• LH side: Refer to DLK-73, "
DTC Logic".
• RH side: Refer to DLK-71, "
DTC Logic".
• Rear bumper: Refer to DLK-75, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
DRIVER SIDE DOOR REQUEST SWITCH
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-117
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DRIVER SIDE DOOR REQU EST SWITCH : DescriptionINFOID:0000000012430064
All doors do not lock/unlock using door request switch LH.
DRIVER SIDE DOOR REQUEST SW ITCH : Diagnosis ProcedureINFOID:0000000012430065
1.CHECK DOOR REQUEST SWITCH LH
Check door request switch LH.
Refer to DLK-94, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna LH.
Refer to DLK-73, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
PASSENGER SIDE DOOR REQUEST SWITCH
PASSENGER SIDE DOOR REQUEST SWITCH : DescriptionINFOID:0000000012430066
All doors do not lock/unlock using door request switch RH.
PASSENGER SIDE DOOR REQUEST SWITCH : Diagnosis ProcedureINFOID:0000000012430067
1.CHECK DOOR REQUEST SWITCH RH
Check door request switch RH.
Refer to DLK-94, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna RH.
Refer to DLK-71, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-118
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH INTELLIGENT KEY
DOOR DOES NOT LOCK/UNLOC
K WITH INTELLIGENT KEY
Diagnosis ProcedureINFOID:0000000012430068
1.CHECK POWER DOOR LOCK OPERATION
Check power door lock operation.
Does door lock/unlock with door lock and unlock switch?
YES >> GO TO 2.
NO >> Refer to DLK-112, "
ALL DOOR : Diagnosis Procedure".
2.CHECK REMOTE KEYLESS ENTRY RECEIVER
Check remote keyless entry receiver.
Refer to DLK-106, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK INTELLIGENT KEY
Check Intelligent Key.
Refer to DLK-104, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

IGNITION POSITION WARNING FUNCTION DOES NOT OPERATE
DLK-119
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
IGNITION POSITION WARNING FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430069
1.CHECK POWER DOOR LOCK OPERATION
Check power door lock operation.
Does door lock/unlock with driver side door lock knob and door key cylinder?
YES >> GO TO 2.
NO >> Refer to DLK-115, "
Diagnosis Procedure".
2.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-120
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
AUTO DOOR LOCK OPERATIO
N DOES NOT OPERATE
AUTO DOOR LOCK OPERATION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430070
1.CHECK AUTO LOCK SET SE TTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “AUTO LOCK SET” in “Work support”.
3. Check “AUTO LOCK SET” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “MODE 2”, “MODE 3”, “MODE 4”, “MODE 5”, “MODE 6” or “MODE 7” in “AUTO LOCK SET”.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

VEHICLE SPEED SENSING AUTO LOCK OPERATION DOES NOT OPERATE
DLK-121
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
VEHICLE SPEED SENSING AUTO LOCK OPERATION DOES NOT OPER-
AT E
Diagnosis ProcedureINFOID:0000000012430071
1.CHECK AUTOMATIC LOCK/UNLOCK SELE CT SETTING IN WORK SUPPORT
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “AUTOMATIC LOCK/UNLOCK SELECT” in “Work support”.
3. Check “AUTOMATIC LOCK/UNLOCK SELECT” setting in “Work support”. Refer to BCS-18, "
DOOR LOCK : CONSULT Function (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “Lock Only” or “Lock/Unlock” in “Work support”.
2.CHECK AUTOMATIC DOOR LOCK SELECT SETTING IN WORK SUPPORT
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “AUTOMATIC DOOR LOCK SELECT” in “Work support”.
3. Check “AUTOMATIC DOOR LOCK SELECT” setting in “Work support”. Refer to BCS-18, "
DOOR LOCK : CONSULT Function (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “VH SPD” in “AUTOMATIC DOOR LOCK SELECT”.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com
