NISSAN NOTE 2016 Service Repair Manual

DLK-82
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and rear door lock actuator LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between rear door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
REAR RH
REAR RH : Component Function CheckINFOID:0000000012430018
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “DOOR LOCK” in “Active Test”.
3. Touch “ALL LOCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-82, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000012430019
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock actuator RH connector.
3. Check voltage between rear door lock actuator RH harness connector and ground.
BCM Rear door lock actuator LH
Continuity
Connector TerminalConnector Terminal
M99 65
D205 1
Ye s
55 2
BCM GroundContinuity
Connector Terminal
M99 65
No
55
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M99 65
Ground Door lock and unlock switch Lock
Battery voltage
55 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK ACTUATORDLK-83
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace rear door lock actuator RH. Refer to DLK-172, "Exploded View".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and rear door lock actuator RH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between rear door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
BACK DOOR
BACK DOOR : DescriptionINFOID:0000000012430020
Locks/unlocks the door with the signal from BCM.
BACK DOOR : Component Function CheckINFOID:0000000012430021
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
(+)
(–) Condition Vo l ta g e
(Approx.)
Rear door lock actuator RH
Connector Terminal
D305 2
Ground Door lock and unlock switch Lock
Battery voltage
1 Unlock
BCMRear door lock actuator RH
Continuity
Connector TerminalConnector Terminal
M99 65
D305 2
Ye s
55 1
BCM GroundContinuity
Connector Terminal
M99 65
No
55
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M99 65
Ground Door lock and unlock switch Lock
Battery voltage
55 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-84
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
YES >> Back door lock actuator is OK.
NO >> Refer to
DLK-84, "
BACK DOOR : Diagnosis Procedure".
BACK DOOR : Diagnosis ProcedureINFOID:0000000012430022
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK BACK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect back door lock actuator connector.
3. Check voltage between back door lock actuator harness connector and ground.
Is the inspection result normal?
YES >> Replace back door lock actuator. Refer to DLK-176, "BACK DOOR LOCK : Removal and Installa-
tion".
NO-1 >> GO TO 2 (lock signal).
NO-2 >> GO TO 3 (unlock signal).
2.CHECK BACK DOOR LOCK ACTUATOR LOCK CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connecto r and back door lock actuator harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK BACK DOOR LOCK ACTUATOR UNLOCK CIRCUIT
1. Disconnect back door lock actuator relay connector.
2. Check continuity between back door lock actuator relay harness connector and back door lock actuator
harness connector.
3. Check continuity between BCM harness connector and ground.
(+)
(–) Condition Voltage (V)
(Approx.)
Back door lock actuator
Connector Terminal
D505 1
Ground Door lock and unlock switch Unlock
Battery voltage
2L ock
BCM Back door lock actuator
Continuity
Connector TerminalConnector Terminal
M99 65D505 2Yes
BCM GroundContinuity
Connector Terminal
M99 65 No
Back door lock actuator relayBack door lock actuator
Continuity
Connector TerminalConnector Terminal
M41 3D505 1Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK ACTUATORDLK-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to GI-42, "
Intermittent Incident"
>> Inspection End.
Back door lock actuator relay
GroundContinuity
Connector Terminal
M41 3 No
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-86
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BACK DOOR LOCK ACTUATOR RELAY
BACK DOOR LOCK ACTUATOR RELAY
DescriptionINFOID:0000000012430023
Controls back door lock actuator lock/unlock operation.
Component Function CheckINFOID:0000000012430024
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Back door lock actuator relay is OK.
NO >> Refer to DLK-86, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430025
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 10 A fuse, No. 8, located in fuse block (J/B).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK BACK DOOR LOCK ACTUATOR RELAY POWER CIRCUIT
1. Remove back door lock actuator relay.
2. Check voltage between back door lock actuator relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BACK DOOR LOCK ACTUATOR RELAY CIRCUIT 1
1. Install the back door lock actuator relay.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO-1 (when voltage is fixed at 12V)>>Replace BCM. Refer to BCS-74, "
Removal and Installation".
NO-2 (when voltage is fixed at 0V)>>GO TO 4.
(+)
(–)Voltage (V)
(Approx.)
Back door lock actuator relay
Connector Terminal
M41 1
Ground Battery voltage
5
(+)
(–) Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M100 50GroundDoor lock and un-
lock switch LOCK Battery voltage
UNLOCK 0
Revision: August 2015 2016 Versa Note

cardiagn.com

BACK DOOR LOCK ACTUATOR RELAYDLK-87
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
4.CHECK BACK DOOR LOCK ACTUATOR RELAY CIRCUIT 1
1. Disconnect BCM connector.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> GO TO 5.
5.CHECK BACK DOOR LOCK ACTUATOR RELAY CIRCUIT 2
1. Remove back door lock actuator relay.
2. Check continuity between BCM harness connector and back door lock actuator relay harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace back door lock actuator relay.
NO >> Repair or replace harness.
6.CHECK BACK DOOR LOCK ACTUATOR RELAY GROUND CIRCUIT
Check continuity between back door lock actuator relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK BACK DOOR LOCK ACTUATOR RELAY
Check back door lock actuator relay.Refer to DLK-87, "
Component Inspection"
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace back door lock actuator relay.
8.CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to GI-42, "
Intermittent Incident"
>> Inspection End.
Component InspectionINFOID:0000000012430026
1.CHECK BACK DOOR LOCK ACTUATOR RELAY
(+)
(–)Voltage (V)
(Approx.)
BCM
Connector Terminal
M100 50GroundBattery voltage
Back door lock actuator relay BCM
Continuity
Connector Terminal Connector Terminal
M41 2 M100 50Yes
Back door lock actuator relay GroundContinuity
Connector Terminal
M41 2 No
Back door lock actuator relay
GroundContinuity
Connector Terminal
M41 4 Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-88
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BACK DOOR LOCK ACTUATOR RELAY
1. Turn ignition switch OFF.
2. Remove back door lock actuator relay.
3. Check continuity between back door
lock actuator relay terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace back door lock actuator relay.
Back door lock actuator relay Condition Continuity
Te r m i n a l
3 4
12 V direct current supply between terminals 1 and 2
No
No current supply Yes
5 12 V direct current supply between terminals 1 and 2
Yes
No current supply No
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK AND UNLOCK SWITCHDLK-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK AND UNLOCK SWITCH
Component Function CheckINFOID:0000000012430027
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “CDL LOCK SW”, “CDL UNLOCK SW” in “Data Monitor”.
3. Check that the function operates normall y according to the following conditions:
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Refer to DLK-89, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430028
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK DOOR LOCK AND UNLOCK SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch connector.
3. Check signal between main power window and door lock/unlock switch harness connector and ground
using oscilloscope.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connecto r and main power window and door lock/unlock switch
harness connector.
Monitor item Condition Status
CDL LOCK SW Main power window and door
lock/unlock switch LOCK
ON
UNLOCK OFF
CDL UNLOCK SW LOCK
OFF
UNLOCK ON
(+)
(–)Signal
(Reference value)
Main power window and door lock/unlock switch
Connector Terminal
D7 6
Ground 1.0 - 1.5 V
D8
18
JPMIA0012GB
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK DOOR LOCK AND UNLOCK SWITCH GROUND
Check continuity between main power window and door lock/unlock switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK DOOR LOCK AND UNLOCK SWITCH
Refer to DLK-90, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-55, "
Removal and Instal-
lation".
5.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430029
1.CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch connector.
3. Check continuity between main power window and door lock/unlock switch terminals.
Is the inspection result normal?
YES >> Inspection End
BCM Main power window and door lock/unlock switch
Continuity
Connector TerminalConnector Terminal
M97 12
D8 18
Ye s
13 D7 6
BCM GroundContinuity
Connector Terminal
M97 12
No
13
Main power window and door lock/unlock switch
GroundContinuity
Connector Terminal
D8 17 Yes
Main power window and door lock/unlock switch
Condition Continuity
Te r m i n a l
6 17Main power window
and door lock/ unlock
switch LOCK
No
UNLOCK Yes
18 LOCK
Yes
UNLOCK No
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK AND UNLOCK SWITCHDLK-91
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-55, "Removal and Instal-
lation".
Revision: August 2015 2016 Versa Note

cardiagn.com
