NISSAN NOTE 2016 Service Repair Manual

DLK-232
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR SWITCH
DOOR SWITCH
DescriptionINFOID:0000000012430182
Detects door open/close condition.
Component Function CheckINFOID:0000000012430183
1.CHECK FUNCTION
With CONSULT
Check door switches “DOOR SW-DR”, “DOOR SW-AS”, “DOOR SW-RL”, “DOOR SW-RR” in “Data Monitor”.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-232, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430184
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscilloscope.
Monitor item Condition
DOOR SW-DR
CLOSE → OPEN: OFF → ON
DOOR SW-AS
DOOR SW-RL
DOOR SW-RR
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR SWITCHDLK-233
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector and door switch connector.
2. Check continuity between BCM connector and door switch connector.
Te r m i n a l s
Door condition Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M20 60
Ground Front RH
OPEN
0
CLOSE
57 Rear RHOPEN
0
CLOSE
59 Front LHOPEN
0
CLOSE
58 Rear LHOPEN
0
CLOSE
PKIB4960J
PKIB4960J
PKIB4960J
PKIB4960J
BCM connector Terminal Door switch
connector Terminal Continuity
M20 60
B16 (Front RH)
3Yes
57
B17 (Rear RH)
59 B8 (Front LH)
58 B6 (Rear LH)
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-234
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR SWITCH
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Refer to DLK-234, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace malfunctioning door switch.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430185
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect door switch connector.
3. Check door switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunctioning door switch.
BCM connector Terminal
GroundContinuity
M20 60
No
57
59
58
Te r m i n a l
Door switch condition Continuity
Door switch
3 Ground part of door switch Pressed
No
Released Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK AND UNLOCK SWITCHDLK-235
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK AND UNLOCK SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000012430186
Transmits door lock/unlock operation to BCM.
DRIVER SIDE : Comp onent Function CheckINFOID:0000000012430187
1.CHECK FUNCTION
With CONSULT
Check “CDL LOCK SW”, “CDL UNLOCK SW” in “Data Monitor”.
Is the inspection result normal?
YES >> Door lock and unlock switch is OK.
NO >> Refer to DLK-235, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diag nosis ProcedureINFOID:0000000012430188
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK POWER WINDOW SWITCH OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage at the main power window and door lock /unlock switch connector when the switch (driver
side) is turned to “LOCK” or “UNLOCK”.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK POWER WINDOW SWITCH GROUND
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch connector.
3. Check continuity between main power window and door lock/unlock switch connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK POWER WINDOW SWITCH
Monitor item Condition
CDL LOCK SW LOCK
: ON
UNLOCK : OFF
CDL UNLOCK SW LOCK
: OFF
UNLOCK : ON
ConnectorMain power window and door lock/unlock
switch state Te r m i n a lVoltage
(Approx.)
D7 Neutral → Unlock 6
Ground Battery voltage → 0
D8 Neutral → Lock 18
Main power window and door lock/unlock switch
connector Terminal
Continuity
D8 17Ground Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-236
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
Check continuity between main power window and door lock/unlock switch terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace main power window and door lock/unlock switch. Refer to
PWC-55, "
Removal and Instal-
lation".
4.CHECK POWER WINDOW SWITCH CIRCUITS
1. Disconnect BCM connector.
2. Check continuity between BCM connector and main power window and door lock/unlock switch connec- tor.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000012430189
Transmits door lock/unlock operation to BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000012430190
1.CHECK FUNCTION
With CONSULT
Check “CDL LOCK SW”, “CDL UNLOCK SW” in “Data Monitor”.
Main power window and door lock/unlock switch state TerminalsContinuity
Lock 17 - 18
Ye s
Unlock 6 - 17
Neutral/Lock 6 - 17
No
Neutral/Unlock 17 - 18
BCM connectorTerminalMain power window and door lock/unlock
switch connector Terminal Continuity
M18 12
D8 18
Ye s
13 D7 6
BCM connector TerminalContinuity
M18 12
Ground No
13
Monitor item Condition
CDL LOCK SW LOCK
: ON
UNLOCK : OFF
CDL UNLOCK SW LOCK
: OFF
UNLOCK : ON
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK AND UNLOCK SWITCHDLK-237
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Door lock and unlock switch is OK.
NO >> Refer to DLK-237, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Dia gnosis ProcedureINFOID:0000000012430191
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK POWER WINDOW SWITCH OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage at the power window and door lock/unl ock switch RH connector when the switch (passen-
ger side) is turned to “LOCK” or “UNLOCK”.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK POWER WINDOW SWITCH GROUND
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH connector.
3. Check continuity between power window and door lock/unlock switch RH connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK POWER WINDOW SWITCH
Check continuity between power window and door lock/unlock switch RH terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace power window and door lock/unlock switch RH. Refer to PWC-56, "
Removal and Installa-
tion".
4.CHECK POWER WINDOW SWITCH CIRCUITS
1. Disconnect BCM connector.
2. Check continuity between BCM connector and power window and door lock/unlock switch RH connector.
Connector Power window and door lock/unlock
switch RH state Te r m i n a lVoltage
(Approx.)
D105 Neutral
→ Lock 1
Ground Battery voltage → 0
Neutral → Unlock 2
Power window and door lock/unlock switch RH con-
nector Terminal
Continuity
D105 3Ground Yes
Power window and door lock/unlock switch RH state TerminalsContinuity
Lock 1 - 3
Ye s
Unlock 2 - 3
Neutral/Unlock 1 - 3
No
Neutral/Lock 2 - 3
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-238
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
BCM connector TerminalPower window and door lock/unlock
switch RH connector Terminal
Continuity
M18 12
D105 1
Ye s
13 2
BCM connectorTerminalContinuity
M18 12
Ground No
13
Revision: August 2015 2016 Versa Note

cardiagn.com

KEY CYLINDER SWITCHDLK-239
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY CYLINDER SWITCH
DescriptionINFOID:0000000012430192
When the mechanical key is inserted and turned into the front door lock key cylinder switch LH, the switch
transmits the LOCK or UNLOCK signal directly to the BCM.
Component Function CheckINFOID:0000000012430193
1.CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL
Check “KEY CYL UN-SW”, “KEY CYL UN-SW” in “Dat a Monitor” of “POWER DOOR LOCK SYSTEM” with
CONSULT. Refer to BCS-90, "
DOOR LOCK : CONSULT Func tion (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> Key cylinder switch is OK.
NO >> Refer to DLK-239, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430194
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> Front door lock key cylinder switch LH is OK.
NO >> GO TO 2.
2.CHECK DOOR KEY CYLINDE R SWITCH GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front door lock key cylinder switch LH connector.
3. Check continuity between front door lock key cylinder switch LH connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
Monitor item Condition
KEY CYL LK-SW Lock
: ON
Neutral / Unlock : OFF
KEY CYL UN-SW Unlock
: ON
Neutral / Lock : OFF
Te r m i n a l s
Key positionVoltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M18 8
Ground Lock
0
Neutral / Unlock 7.0 - 8.0
7 Unlock
0
Neutral / Lock 7.0 - 8.0
Front door lock key cylinder switch LH connector Terminal
GroundContinuity
D14 4 Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-240
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEY CYLINDER SWITCH
NO >> Repair or replace harness.
3.CHECK DOOR KEY CYLINDER SIGNAL CIRCUIT
1. Disconnect BCM connector M18.
2. Check continuity between front door lock key cylinder switch LH connector and BCM connector M18.
3. Check continuity between front door lock key cylinder switch LH connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK DOOR KEY CYLINDER SWITCH
Check door key cylinder switch.
Refer to DLK-240, "
Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Replace front door lock key cylinder switch LH. Refer to DLK-295, "
DOOR LOCK : Removal and
Installation".
Component InspectionINFOID:0000000012430195
COMPONENT INSPECTION
1.CHECK DOOR KEY CYLINDER SWITCH
Check front door lock key cylinder switch LH.
Is the inspection result normal?
YES >> Key cylinder switch is OK.
NO >> Replace front door lock key cylinder switch LH. Refer to DLK-295, "
DOOR LOCK : Removal and
Installation".
Front door lock key cylinder switch LH con-
nector Terminal
BCM connector Terminal Continuity
D14 6
M18 8
Ye s
57
Front door lock key cylinder switch LH connector Te r m i n a l
GroundContinuity
D14 6
No
5
Te r m i n a l Key position Continuity
Front door lock key cylinder switch LH connector
6 4 Lock
Yes
Neutral / Unlock No
5 Unlock
Yes
Neutral / Lock No
Revision: August 2015 2016 Versa Note

cardiagn.com

KEY SWITCH (BCM INPUT)DLK-241
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY SWITCH (BCM INPUT)
Diagnosis ProcedureINFOID:0000000012430196
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK KEY SWITCH INPUT SIGNAL
With CONSULT
Check key switch “KEY ON SW” in “Data Monitor”. Refer to BCS-90, "
DOOR LOCK : CONSULT Function
(BCM - DOOR LOCK)".
• When key is inserted to ignition key cylinder:
• When key is removed from ignition key cylinder:
Without CONSULT
Check voltage between BCM connector M18 terminal 37 and ground.
Is the inspection result normal?
YES >> Key switch (insert) circuit is OK.
NO >> GO TO 2.
2.CHECK KEY SWITCH (INSERT)
1. Turn ignition switch OFF.
2. Disconnect key switch connector.
3. Check continuity between key switch terminals.
Is the inspection result normal?
YES >> Repair or replace harness or fuse.
NO >> Replace key switch. KEY ON SW : ON
KEY ON SW : OFF
Connector
Te r m i n a l
Condition Voltage (V)
(Approx.)
(+) (–)
M18 37Ground Key is inserted.
Battery voltage
Key is removed. 0
Terminals Condition Continuity
1 – 2 Key is inserted.
Yes
Key is removed. No
Revision: August 2015 2016 Versa Note

cardiagn.com
