NISSAN NOTE 2016 Service Repair Manual

DLK-252
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
HORN FUNCTION
HORN FUNCTION
DescriptionINFOID:0000000012430215
Perform answer-back for each operation with horn.
Component Function CheckINFOID:0000000012430216
1.CHECK FUNCTION
1. Select “HORN” in “Active Test” using CONSULT.
2. Check the horn operation.
Is the operation normal?
YES >> Inspection End.
NO >> Refer to DLK-252, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000012430217
Regarding Wiring Diagram information, refer to DLK-216, "Wiring Diagram".
1.CHECK HORN FUNCTION
Check horn function with horn switch.
Does the horn sound?
YES >> GO TO 2.
NO >> Refer to HRN-3, "
Wiring Diagram".
2.CHECK HORN RELAY POWER SUPPLY
1. Turn ignition switch ON.
2. Perform “Active Test”“HORN” using CONSULT.
3. Using an oscilloscope or analog voltmeter to check voltage between IPDM E/R connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace IPDM E/R. Refer to PCS-30, "
Removal and Installation".
3.CHECK HORN RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R har ness connector and horn relay harness connector.
4. Check continuity between IP DM E/R harness connector and ground.
Test item Description
HORN ON Horn relay ON (for 20 ms)
IPDM E/R
Ground Test item Voltage (V)
(Approx.)
Connector Terminal
E46 73Ground HORN ON
Battery voltage → 0 → Battery voltage
Other than above Battery voltage
IPDM E/R Horn relay
Continuity
Connector TerminalConnector Terminal
E46 73E39 1Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

HORN FUNCTIONDLK-253
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace the malfunctioning part.
IPDM E/R GroundContinuity
Connector Terminal
E46 73Ground No
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-254
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
WARNING CHIME FUNCTION
WARNING CHIME FUNCTION
DescriptionINFOID:0000000012430218
Performs operation method guide and warning with buzzer.
Component Function CheckINFOID:0000000012430219
1.CHECK FUNCTION
With CONSULT
1. Check the operation of “BUZZER” in “Active Test”.
2. Touch “IGN KEY WARN ALM”, “SEAT BELT WARN TEST”or “LIGHT WARN ALM”on screen.
Is the inspection result normal?
YES >> Warning buzzer into combination meter is OK.
NO >> Refer to DLK-254, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430220
1.CHECK METER BUZZER CIRCUIT
Operate the hazard lights by turni ng ON the hazard warning switch.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (Type A) or MWI-115,
"Removal and Installation" (Type B).
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

HAZARD FUNCTIONDLK-255
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD FUNCTION
DescriptionINFOID:0000000012430221
Perform answer-back for each oper ation with number of blinks.
Component Function CheckINFOID:0000000012430222
1.CHECK FUNCTION
Check hazard warning lamp “FLASHER” in “Active Test”.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-255, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430223
1.CHECK HAZARD SWITCH CIRCUIT
Operate the hazard lights by turni ng ON the hazard warning switch.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace hazard warning switch circuit. Refer to EXL-108, "
Removal and Installation".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-256
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB ID SET UP WITH CONSULT
KEYFOB ID SET UP WITH CONSULT
ID Code Entry ProcedureINFOID:0000000012430224
KEYFOB ID SET UP WITH CONSULT
NOTE:
•
If a keyfob is lost, the ID code of the lost keyfob must be erased to prevent unauthorized use. A spe-
cific ID code can be erased with CONSULT. However, when the ID code of a lost keyfob is not known,
all controller ID codes should be erased. After all ID codes are erased, the ID codes of all remaining
and/or new keyfobs must be re-registered.
• When registering an additional keyfob, the existing ID codes in memory may or may not be erased. If
five ID codes are stored in memory when an additi onal code is registered, only the oldest code is
erased. If less than five codes are stored in memory when an additional code is registered, the new
ID code is added and no ID codes are erased.
• Entry of a maximum of five ID codes is allowed. Wh en more than five codes are entered, the oldest ID
code will be erased.
• Even if the same ID code that is already in memory is input, the same ID code can be entered. The
code is counted as an additional code.
1. Turn ignition switch ON.
2. Select “BCM”.
3. Select “MULTI REMOTE ENT”.
4. Select “Work support”.
5. You can register, erase or confirm a keyfob ID code. To register a new code, select the following option
and follow CONSULT instructions:
• REMO CONT ID REGIST Use this mode to register a keyfob ID code.
NOTE:
Register the ID code when keyfob or BCM is re placed, or when additional keyfob is required.
• REMO CONT ID ERASUR Use this mode to erase a keyfob ID code.
• REMO CONT ID CONFIR
Use this mode to confirm if a ke yfob ID code is registered or not.
Revision: August 2015 2016 Versa Note

cardiagn.com

KEYFOB ID SET UP WITHOUT CONSULTDLK-257
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEYFOB ID SET UP WITHOUT CONSULT
ID Code Entry ProcedureINFOID:0000000012430225
KEYFOB ID SET UP WITHOUT CONSULT
NOTE:
• If a keyfob is lost, the ID code of the lost keyfob must be erased to prevent unaut horized use. A specific ID
code can be erased with CONSULT. However, when the ID code of a lost keyfob is not known, all controller
ALKIA2029GB
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-258
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB ID SET UP WITHOUT CONSULT
ID codes should be erased. After all ID codes are eras
ed, the ID codes of all remaining and/or new keyfobs
must be re-registered.
To erase all ID codes in memory, register one ID code (keyfob) five times. After all ID codes are erased, the
ID codes of all remaining and/or new keyfobs must be re-registered.
• When registering an additional keyfob, the existing ID codes in memory may or may not be erased. If five ID
codes are stored in memory, when an additional code is registered, only the oldest code is erased. If less
than five ID codes are stored in memory, when an additi onal ID code is registered, the new ID code is added
and no ID codes are erased.
• If you need to activate more than two additional new keyfobs, repeat the procedure “Additional ID code
entry” for each new keyfob DLK-256, "
ID Code Entry Procedure" (with CONSULT), DLK-257, "ID Code Entry
Procedure" (without CONSULT).
• A maximum amount of five ID codes is allowed. W hen more than five ID codes are entered, the oldest ID
code will be erased.
• Even if same ID code that is already in the memory is input, the same ID code can be entered. The code is
counted as an additional code.
Revision: August 2015 2016 Versa Note

cardiagn.com

POWER DOOR LOCK SYSTEM SYMPTOMSDLK-259
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SYMPTOM DIAGNOSIS
POWER DOOR LOCK SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012430226
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to DLK-225, "
Work
Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• If the following symptoms are detec ted, check systems shown in the “Diagnosis/service procedure” column
in this order.
Symptom Diagnosis/service procedure Reference page
Key reminder door function does not operate
properly. 1. Check door switch.
DLK-232
2. Check key switch.DLK-241
3. Check Intermittent Incident. GI-42
Power door lock does not operate with door
lock and unlock switch on main power window
and door lock/unlock switch or power window
and door lock/unlock switch RH.1. Check BCM power supply and ground circuit.
BCS-1292. Check main power window and door lock and unlock switch. DLK-235
3. Check power window and door lock and unlock switch RH.DLK-236
4. Check Intermittent Incident. GI-42
Specific door lock actuator does not operate.1. Check door lock actuator.Front LH
DLK-242
Front RHDLK-243
Rear LHDLK-244
Rear RHDLK-245
2. Check Intermittent Incident. GI-42
Power door locks do not operate with front
door lock key cylinder switch LH.1. Check key cylinder switch.
DLK-239
2. Replace BCM.BCS-137
Vehicle speed sensing auto door LOCK oper-
ation does not operate.1. Ensure automatic door lock/unlock function (lock operation)
is enabled. DLK-196
2. Check combination meter vehicle speed signal. MWI-40
(Type
A)
MWI-95
(Type
B)
3. Check intermittent incident. GI-42
Ignition OFF interlock auto door UNLOCK
function does not operate.1. Ensure automatic door lock/unlock function (unlock opera-
tion) is enabled. DLK-196
2. Check BCM for DTCs.
BCS-115
3. Check intermittent incident. GI-42
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-260
< SYMPTOM DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
REMOTE KEYLESS ENTRY SYSTEM SYMPTOMS
REMOTE KEYLESS ENTR
Y SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012430227
REMOTE KEYLESS ENTRY SYSTEM
Symptom Diagnoses/service procedureReference
page
All functions of remote keyless entry system do not
operate. 1. Keyfob battery and function check (use Remote Keyless Entry
Tester [- (J-43241)] or Signal
Tech II Tool [- (J-50190)]).
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning. DLK-250
2. Check BCM and remote keyless entry receiver.
DLK-247
The new ID of keyfob cannot be entered.1. Keyfob battery and function check (use Remote Keyless Entry
Tester [- (J-43241)] or Signal
Tech II Tool [- (J-50190)]).
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning. DLK-250
2. Door switch check.
DLK-232
3. Replace BCM.BCS-137
Door lock or unlock does not function.
(If the power door lock system does not operate
manually, check power door lock system)1. Keyfob battery and function check (use Remote Keyless Entry
Tester [- (J-43241)] or Signal
Tech II Tool [- (J-50190)]).
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning. DLK-250
2. Replace BCM.
BCS-137
Hazard and horn reminder does not activate properly
when pressing lock or unlock button of keyfob.1. Check hazard and horn reminder mode with CONSULT
NOTE:
Hazard and horn reminder mode can be changed.
First check the hazard and horn reminder mode setting.
DLK-199
2. Door switch check
DLK-232
3. Replace BCM.BCS-137
Hazard reminder does not activate properly when
pressing lock or unlock button of keyfob.
(Horn reminder OK)1. Check hazard reminder mode with CONSULT
NOTE:
Hazard reminder mode can be changed.
First check the hazard reminder mode setting.
DLK-199
2. Check hazard function with hazard switch
—
3. Replace BCM. BCS-137
Horn reminder does not activate properly when
pressing lock or unlock button of keyfob.
(Hazard reminder OK)1. Check horn reminde
r mode with CONSULT
NOTE:
Horn reminder mode can be changed.
First check the horn reminder mode setting. DLK-199
2. Check horn function with horn switch
—
3. IPDM E/R operation check PCS-10
4. Replace BCM.BCS-137
Room lamp illumination does not operate properly.1. Room lamp operation check
INL-72. Door switch checkDLK-232
3. Replace BCM.BCS-137
Panic alarm (horn and headlamp) does not activate
when panic alarm button is continuously pressed.1. Keyfob battery and function check (use Remote Keyless Entry
Tester [- (J-43241)] or Signal
Tech II Tool [- (J-50190)]).
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning. DLK-250
2. Replace BCM.
BCS-137
Revision: August 2015 2016 Versa Note

cardiagn.com

REMOTE KEYLESS ENTRY SYSTEM SYMPTOMSDLK-261
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Auto door lock operation does not activate properly.
(All other remote keyless entry functions OK.) 1. Check auto door lock operation mode with CONSULT
NOTE:
Auto door lock operation mode can be changed.
First check the auto door lock operation mode setting.
DLK-196
2. Replace BCM.
BCS-137
SymptomDiagnoses/service procedureReference
page
Revision: August 2015 2016 Versa Note

cardiagn.com
