< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000012430197
Locks/unlocks the door with the signal from BCM.
DRIVER SIDE : Component Function CheckINFOID:0000000012430198
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-242, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000012430199
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock actuator LH connector.
3. Check voltage between front door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator LH. Refer to DLK-295, "DOOR LOCK : Removal and Installa-
tion".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and front door lock actuator LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
(+) (–) Condition Vo l ta g e
(Approx.)
Front door lock actuator
LH
Connector Terminal
D14 1
Ground Door lock and unlock switch Lock
Battery voltage
2 Unlock
BCMFront door lock actuator LH
Continuity
Connector TerminalConnector Terminal
M19 54
D14 1
Ye s
41 2
BCM GroundContinuity
Connector Terminal
M19 54
No
41
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK ACTUATORDLK-243
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between front door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000012430200
Locks/unlocks the door with the signal from BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000012430201
1.CHECK FUNCTION
1. Perform “DOOR LOCK”“Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-243, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Dia gnosis ProcedureINFOID:0000000012430202
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock actuator RH connector.
3. Check voltage between front door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator RH. Refer to DLK-295, "DOOR LOCK : Removal and Installa-
tion".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuators.
2. Check continuity between BCM harness connector and front door lock actuator RH harness connector.
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
41 Unlock
(+)
(–) Condition Vo l ta g e
(Approx.)
Front door lock actuator
RH
Connector Terminal
D114 2
Ground Door lock and unlock switch Lock
Battery voltage
1 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-244
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
3. Check continuity between
BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between front door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
REAR LH
REAR LH : DescriptionINFOID:0000000012430203
Locks/unlocks the door with the signal from BCM.
REAR LH : Component Function CheckINFOID:0000000012430204
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-244, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000012430205
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock actuator LH connector.
3. Check voltage between rear door lock actuator LH harness connector and ground.
BCM Front door lock actuator RH
Continuity
Connector TerminalConnector Terminal
M19 54
D114 2
Ye s
53 1
BCM GroundContinuity
Connector Terminal
M19 54
No
53
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
53 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK ACTUATORDLK-245
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Replace rear door lock actuator LH. Refer to DLK-299, "DOOR LOCK : Removal and Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and rear door lock actuator LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between rear door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
REAR RH
REAR RH : DescriptionINFOID:0000000012430206
Locks/unlocks the door with the signal from BCM.
REAR RH : Component Function CheckINFOID:0000000012430207
1.CHECK FUNCTION
1. Perform “DOOR LOCK” in “Active Test” using CONSULT.
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
(+)
(–) Condition Vo l ta g e
(Approx.)
Rear door lock actuator LH
Connector Terminal
D205 1
Ground Door lock and unlock switch Lock
Battery voltage
2 Unlock
BCMRear door lock actuator LH
Continuity
Connector TerminalConnector Terminal
M19 54
D205 1
Ye s
53 2
BCM GroundContinuity
Connector Terminal
M19 54
No
53
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
53 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-246
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
YES >> Door lock actuator is OK.
NO >> Refer to
DLK-246, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000012430208
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock actuator RH connector.
3. Check voltage between rear door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear door lock actuator RH. Refer to DLK-299, "DOOR LOCK : Removal and Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and rear door lock actuator RH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between rear door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
(+)
(–) Condition Vo l ta g e
(Approx.)
Rear door lock actuator RH
Connector Terminal
D305 2
Ground Door lock and unlock switch Lock
Battery voltage
1 Unlock
BCMRear door lock actuator RH
Continuity
Connector TerminalConnector Terminal
M19 54
D305 2
Ye s
53 1
BCM GroundContinuity
Connector Terminal
M19 54
No
53
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M19 54
Ground Door lock and unlock switch Lock
Battery voltage
53 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com

REMOTE KEYLESS ENTRY RECEIVERDLK-247
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY RECEIVER
DescriptionINFOID:0000000012430209
Receives keyfob operation and transmits to BCM.
Component Function CheckINFOID:0000000012430210
1.CHECK FUNCTION
With CONSULT
Check remote keyless entry receiver “KEYLESS LOCK”, “KEYLESS UNLOCK”, and “KEYLESS PANIC” in
“Data Monitor”.
Is the inspection result normal?
YES >> Remote keyless entry receiver is OK.
NO >> Refer to DLK-247, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430211
Regarding Wiring Diagram information, refer to DLK-216, "Wiring Diagram".
1.CHECK REMOTE KEYLESS ENTRY RECEIVER OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between remote keyless entry receiver connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 2.
Monitor item Condition
KEYLESS LOCK Checks whether value changes from “Off” to “On” when operating keyfob lock button.
KEYLESS UNLOCK Checks whether value changes from “Off” to “On” when operating keyfob unlock button.
KEYLESS PANIC Checks whether value changes from “Off” to “On” when operating keyfob panic button.
Te r m i n a l s
ConditionSignal
(Reference value)
(+)
(–)
Remote keyless entry re-
ceiver connector Te r m i n a l
M23 2 Ground Waiting
(All doors closed)
When signal is received (All doors closed)
PIIB7728J
PIIB7729J
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-248
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
REMOTE KEYLESS ENTRY RECEIVER
2.CHECK REMOTE KEYLESS ENTRY RECEIVER POWER SUPPLY
1. Disconnect remote keyless entry receiver connector.
2. Check signal between remote keyless entry receiver connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK REMOTE K EYLESS ENTRY RECEIVER CIRCUIT 1
1. Disconnect BCM connector.
2. Check continuity between BCM connector and remote keyless entry receiver connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Reconnect BCM, GO TO 4.
NO >> Repair or replace harness between BCM and remote keyless entry receiver.
4.CHECK REMOTE KEYL ESS ENTRY RECEIVER GROUND CIRCUIT
Check continuity between remote keyless entry receiver connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK REMOTE K EYLESS ENTRY RECEIVER CIRCUIT 2
Check continuity between BCM connector and remote keyless entry receiver connector.
Is the inspection result normal?
YES >> GO TO 7.
Te r m i n a l s
Signal
(Reference value)
(+)
(–)
Remote keyless entry receiver
connector Te r m i n a l
M23 4Ground
JPMIA0338JP
BCM connector TerminalRemote keyless entry receiver
connector Terminal
Continuity
M18 19 M23 4Yes
BCM connector Terminal
GroundContinuity
M18 19 No
Remote keyless entry receiver
connector Te r m i n a l
GroundContinuity
M23 1 Yes
BCM
connector Te r m i n a lRemote keyless entry receiver
connector Terminal
Continuity
M18 18 M23 1Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

REMOTE KEYLESS ENTRY RECEIVERDLK-249
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Repair or replace harness between BCM and remote keyless entry receiver.
6.CHECK REMOTE KEYLESS EN TRY RECEIVER CIRCUIT 3
1. Check continuity between BCM connector and remote keyless entry receiver connector.
2. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness between BCM and remote keyless entry.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
BCM
connector Te r m i n a l
Remote keyless entry receiver
connector Terminal
Continuity
M18 20 M23 2Yes
BCM connector Terminal
GroundContinuity
M18 20 No
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-250
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB BATTERY AND FUNCTION
KEYFOB BATTERY AND FUNCTION
DescriptionINFOID:0000000012430212
The following functions are available when having and carrying the keyfob:
• Door lock/unlock
• Panic mode (horn and head-lamp operation)
Remote control entry function and panic alarm functi
on are available when operating the remote buttons.
Component Function CheckINFOID:0000000012430213
NOTE:
The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions: Refer to the Signal Tech II
User Guide for additional information.
• Check keyfob relative signal strength.
• Confirm vehicle antenna signal strength.
1.CHECK FUNCTION
With CONSULT
Check remote keyless entry receiver “KEYLESS LOCK”, “KEYLESS UNLOCK”, and “KEYLESS PANIC” in
“Data Monitor”.
Is the inspection result normal?
YES >> Keyfob is OK.
NO >> Refer to DLK-250, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430214
NOTE:
The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions: Refer to the Signal Tech II
User Guide for additional information.
• Check keyfob relative signal strength.
• Confirm vehicle antenna signal strength.
1.CHECK KEYFOB FUNCTION
Check keyfob function using Signal Tech II Tool [- (J-50190)] or
Remote Keyless Entry Tester [- (J-43241)] (shown).
Does the test pass?
YES >> Keyfob is OK.
NO >> GO TO 2.
2. CHECK KEYFOB COMPONENTS
Monitor item Condition
KEYLESS LOCK Checks whether value changes from “Off” to “On” when operating keyfob lock button.
KEYLESS UNLOCK Checks whether value changes from “Off” to “On” when operating keyfob unlock button.
KEYLESS PANIC Checks whether value changes from “Off” to “On” when operating keyfob panic button.
ALKIA2300ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

KEYFOB BATTERY AND FUNCTIONDLK-251
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Remove the screw (A).
2. Insert a small screwdriver into the slit of the corner (B) and twist it to separate the upper part from the power part. Use a cloth to
protect the casing.
CAUTION:
• Do not touch the circuit board or battery terminal.
• The keyfob is water-resistant. However, if it does get wet,
immediately wipe it dry.
3. Remove the keyfob battery.
CAUTION:
• Keep dirt, grease, and other fo reign materials off the elec-
trode contact area.
4. Visually inspect keyfob internal components.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK KEYFOB BATTERY
Check by connecting a resistance (approximately 300 Ω) so that the
current value becomes about 10 mA.
Is the measurement val ue within specification?
YES >> Keyfob battery is OK. Check remote keyless entry
receiver. Refer to DLK-247,
"ComponentFunctionCheck".
NO >> GO TO 4.
4. REPLACE KEYFOB BATTERY
1. Replace the keyfob battery with a new one. CAUTION:
• When replacing battery, keep dirt, grease, and other for-eign materials off the electrode contact area.
• Make sure that the + side faces the bottom of the case.
2. Align the tips of the upper and lower parts, and then push them
together until it is securely closed.
3. After replacing the battery, check that all keyfob functions work properly.
Is the inspection result normal?
YES >> Keyfob is OK.
NO >> Check remote keyless entry receiver. Refer to DLK-247,
"ComponentFunctionCheck".
ALKIA2301ZZ
Standard : Approx. 2.5 - 3.0V
OCC0607D
ALKIA2302ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
