NISSAN TEANA 2008 Service Manual

AV
REAR VIEW MONITOR SYSTEM
AV-57
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PREDICTED COURSE LINE OPERATION PRINCIPLE
Detection Of Steering Rotation Direction
Camera control unit detects the rotation direction of steering according to the phase difference of two pairs of
pulse signals (sensor signal 1 and sensor signal 2) input from steering angle sensor.
Detection Of Steering Neutral Position
The sensor signal 3 input from steering angle sensor is generated at 1 pulse per 1 rotation of the steering
wheel. Camera control unit detects the steering neutral position from this pulse.
Correction Of Steering Neutral Position
Camera control unit corrects the steering neutral position during driving according to the vehicle speed signal
and sensor signal.
JSNIA0708GB

AV-58
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
REAR VIEW MONITOR SYSTEM
Component Parts Location
INFOID:0000000003885182
1. Front squawker RH 2. Front squawker LH 3. Front door speaker LH
4. Rear door speaker LH 5. Rear control switch 6. Rear view camera
7. Camera control unit 8. Antenna amp. 9. Rear door speaker RH
10. Front door speaker RH 11. Steering angle sensor 12. Steering switch
13. AV control unit 14. Auxiliary input jacks 15. Preset switch
16. Multifunction switch 17. Display unit
A. Trunk room side RH B. Within rear pillar finisher RH C. Spiral cable part
D. In center console
JSNIA1433ZZ

AV
REAR VIEW MONITOR SYSTEM
AV-59
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Component DescriptionINFOID:0000000003885184
Part name Description
AV CONTROL UNIT Image on display is transmitted to rear view monitor image by serial communi-
cation between AV control unit and display unit.
 AV control unit recognizes the presence of camera system with camera con-
nection recognition signal.
DISPLAY UNIT Camera image signal is input from AV control unit.
 Rear view monitor image is changed by serial communication from AV control
unit.
CAMERA CONTROL UNIT Camera image signal is input from rear view camera. Camera image signal is
output to AV control unit.
 Power supply is transmitted to rear view camera.
 Superimposes the guiding line and predicted course line to the camera image
that outputs to AV control unit.
 Inputs the sensor signal from steering angle sensor, and then controls the pre-
dicted course line.
 Camera control unit is connected via AV communication.
REAR VIEW CAMERA The image of vehicle rear view is transmitted to camera control unit.
 It receives power supply from camera control unit and operates.
STEERING ANGLE SENSORSteering signal necessary for predicted course line control is transmitted to cam-
era control unit.

AV-60
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Diagnosis DescriptionINFOID:0000000003882711
MULTIFUNCTION SWITCH AND PRESET SWITCH SELF-DIAGNOSIS FUNCTION
The ON/OFF operation (continuity) of each switch in the multifunction switch and preset switch can be
checked.
Self-diagnosis Mode
 Press the “BACK” switch and the “UP” switch of the 4-direction
switches within 10 seconds after turning the ignition switch from
OFF to ACC and hold them for 3 seconds or more. Then the
buzzer sounds, all indicators of the preset switch illuminate, and
the self-diagnosis mode starts.
 The continuity of each switch at the ON position can be checked
by pressing the switch. The buzzer sounds if the switch is normal.
NOTE:
The hazard switch and disk eject switch cannot be checked.
Finishing Self-diagnosis Mode
Self-diagnosis mode is canceled when turning the ignition switch OFF.
MULTI AV SYSTEM ON BOARD DIAGNOSIS FUNCTION
 The AV control unit diagnosis function starts up with multifunction switch operation and the AV control unit
performs a diagnosis for each unit in the system during the on board diagnosis.
 Perform a CONSULT-III diagnosis if the on board diagnosis does not start, e.g., the screen does not display
anything, the multifunction switch does not function, etc.
ON BOARD DIAGNOSIS
Description
 The trouble diagnosis function has a self-diagnosis mode for conducting trouble diagnosis automatically and
a confirmation/adjustment mode for operating manually.
 Self-diagnosis mode performs the AV control unit diagnosis and the connection diagnosis between each of
the units that make up the system, and it indicates the results to the display.
 The confirmation/adjustment mode allows the technician to check, modify or adjust the vehicle signals and
set values, as well as to monitor the system error records and system communication status. The check,
modify or adjust actions generally require human intervention and judgment (the system cannot make judg-
ment automatically).
On Board Diagnosis Item
JSNIA1284GB
Mode Description
Self Diagnosis AV control unit diagnosis.
 Diagnoses the connections across system components.

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-61
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
*:On-board self-diagnosis is not supported. Only CONSULT-III is supported.
STARTING PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pressing the “SETTING” button, turn the volume control
dial clockwise or counterclockwise for 40 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
 Shifting from current screen to previous screen is performed
by pressing “BACK” button.
4. The trouble diagnosis initial screen is displayed, and then the
items of “Self Diagnosis” and “Confirmation/Adjustment” can be
selected.
SELF-DIAGNOSIS MODE
1. Start the self-diagnosis function and select “Self Diagnosis”.
- Self-diagnosis subdivision screen is displayed, and the self-diagnosis mode starts.
- The bar graph visible on the center of the self-diagnosis subdivision screen indicates progress of the trou-
ble diagnosis.
Confirmation/
AdjustmentDisplay DiagnosisThe following check functions are available: color tone check by color
bar display, light and shade check by grey scale display and touch panel
calibration response check.
Vehicle SignalsDiagnosis of signals can be performed for vehicle speed, parking brake,
lights, ignition switch, and reverse.
Speaker Test The connection of a speaker can be confirmed by test tone.
Climate Control
*Not used.
Error HistoryThe system malfunction and the frequency when occurred in the past are
displayed. When the malfunctioning item is selected, the time and place
that the selected malfunction last occurred are displayed.
Camera Cont.It can perform the confirmation of a signal connection to the camera con-
trol unit, the calibration of each camera, Correct Draw Line of Camera
Image, and Fine Tuning of Birds-Eye View.
Refer to AV- 6 0 , "
Diagnosis Description".
Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored.
AV COMM DiagnosisThe communication condition of each unit of Multi AV system can be
monitored.
Delete Unit Connection Log Erase the connection history of unit and error history.
Initialize Settings Initializes the AV control unit memory.Mode Description
JSNIA1285GB
JSNIA0138GB

AV-62
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
2. Diagnosis results are displayed after the self-diagnosis is com-
pleted. The unit names and the connection lines are color-coded
according to the diagnostic results.
NOTE:
 Only the control unit (AV control unit) is displayed in red.
 Replace AV control unit if “Self-Diagnosis did not run because of a control unit malfunction” is indicated.
The symptom is AV control unit internal error. Refer to AV-170, "
Removal and Installation".
- If multiple errors occur at the same time for a single unit, the screen switch colors are determined accord-
ing to the following order of priority: red > yellow > gray.
- The comments of the self-diagnosis results can be viewed with a
component in the diagnosis result screen.
SELF-DIAGNOSIS RESULTS
 The self-diagnosis mode allows the technician to diagnose the connection in the communication line
between AV control unit and each unit and the internal operation of the AV control unit.
 Because the start condition of diagnosis function is a switch operation, the on board diagnosis function can-
not be started up if any malfunction is detected in the communication circuit between AV control unit and
multifunction switch.
 Check the applicable display in the following table, and then repair the malfunctioning parts.
Self-diagnosis Result Chart
Diagnosis results UnitCon-
nection
line
Normal Green Green
Connection malfunction Gray Yellow
Unit malfunction
NoteRed GreenJSNIA1435GB
JSNIA0141GB
Area with yellow connection lines DescriptionPossible malfunction location / Action
to take
NOTE:
When a control unit malfunction is detected (red in
unit display), connection malfunctions with other
connection unit may be displayed.Malfunction is detected in AV control
unit power supply and ground circuitsCheck AV control unit power supply
and ground circuits. When detecting
no malfunction in those components,
replace AV control unit.
“Self-Diagnosis did not run because of a control unit
malfunction”
JSNIA1436GB

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-63
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
CONFIRMATION/ADJUSTMENT MODE
1. Start the diagnosis function and select “Confirmation/Adjustment”. The confirmation/adjustment mode
indicates where each item can be checked or adjusted.
2. Select each switch on the “Confirmation/Adjustment Mode”
screen to display the relevant trouble diagnosis screen. Press
the “BACK” switch to return to the initial Confirmation/Adjust-
ment Mode screen.
Display Diagnosis
Malfunction is detected in camera con-
nection recognition signal circuit.Camera connection recognition signal
circuit.
When either one of the following
items is detected:
 rear control switch power supply and
ground circuits are malfunctioning.
 AV communication signal between
AV control unit and rear control
switch is malfunctioning.
 malfunction is detected in AV com-
munication circuits between AV con-
trol unit and multifunction switch. Rear control switch power supply
and ground circuits.
 AV communication circuits between
AV control unit and multifunction
switch. Area with yellow connection lines DescriptionPossible malfunction location / Action
to take
JSNIA1437GB
JSNIA1438GB
JSNIA0147GB
JSNIA0688GB

AV-64
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
The tint of the color bar indication is as per the following list if RGB signal error is detected.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and
the signals recognized by the system.
Speaker Test
Select “SPEAKER DIAGNOSIS” to display the Speaker Diagnosis
screen. Press “START and NEXT” to generate a test tone in a
speaker. Press “Start” to generate a test tone in the next speaker.
Press “End” to stop the test tones.
NOTE:
The frequency of test tone emitted from each speaker is as follows.
Climate Control
On-board self-diagnosis is not supported. Only CONSULT-III is supported.
Refer to HAC-156, "
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : CONSULT-III Function"for
details.
Camera Cont.
Refer to AV-56, "System Description".
Error History
R (red) signal error : Light blue (Cyan) tint
G (green) signal error : Purple (Magenta) tint
B (blue) signal error : Yellow tint
JSNIA0149GB
Diagnosis item Display Vehicle status Remarks
Vehicle speedON Vehicle speed > 0 km/h (0 MPH)
Changes in indication may be delayed by approximately
1.5 seconds. This is normal. OFF Vehicle speed = 0 km/h (0 MPH)
Parking brakeON Parking brake is applied.
OFF Parking brake is released.
LightsON Light switch ON
Block the light beam from the auto light optical sensor.
OFF Light switch OFF
IgnitionON Ignition switch ON
—
OFF Ignition switch in ACC position
ReverseONShift the selector lever to “R” posi-
tion
Changes in indication may be delayed by approximately
1.5 seconds. This is normal.
OFFShift the selector lever other than
“R” position
Squawker : 3 kHz
Front speaker : 300 Hz
Rear speaker : 1 kHz
JSNIA0150GB

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-65
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
The self-diagnosis results are judged depending on whether any error occurs from when “Self-diagnosis” is
selected until the self-diagnosis results are displayed.
However, the diagnosis results are judged normal if an error has occurred before the ignition switch is turned
ON and then no error has occurred until the self-diagnosis start. Check the “Error Record” to detect any error
that may have occurred before the self-diagnosis start because of this situation.
The error record displays the time and place of the most recent occurrence of that error. However, take note of
the following points.
 Place of the error occurrence is represented by the position of the current location mark at the time an error
occurred. If current location mark has deviated from the correct position, then the place of the error occur-
rence cannot be located correctly.
 The frequency of occurrence is displayed in a count up manner. The actual count up method differs depend-
ing on the error item.
Count up method A
 The counter resets to 0 if an error occurs when IGN switch is turned ON. The counter increases by 1 if the
condition is normal at a next IGN ON cycle.
 The counter upper limit is 39. Any counts exceeding 39 are ignored.“ The counter can be reset (no error
record display) with the “Delete log” switch or CONSULT-III.
Count up method B
 The counter increases by 1 if an error occurs when IGN switch is ON. The counter will not decrease even if
the condition is normal at the next IGN ON cycle.
 The counter upper limit is 50. Any counts exceeding 50 are ignored. “ The counter can be reset (no error
record display) with the “Delete log” switch or CONSULT-III.
Error item
Some error items may be displayed simultaneously according to the cause. If some error items are displayed
simultaneously, the detection of the cause can be performed by the combination of display items
Display type of occur-
rence frequencyError history display item
Count up method A CAN communication line, control unit (CAN), AV communication line, control unit (AV communication)
Count up method B Other than the above
JSNIA0151GB
Error item Description Possible malfunction factor/Action to take
CAN COMM CIRCUITCAN communication malfunction is detect-
ed.Perform diagnosis with CONSULT-III, and
then repair the malfunctioning parts accord-
ing to the diagnosis results.

AV-66
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
CONTROL UNIT (CAN)CAN initial diagnosis malfunction is detect-
ed.
Replace the AV control unit. CONTROL UNIT (AV)AV communication circuit initial diagnosis
malfunction is detected.
FLASH-ROM Error Of Control Unit
AV control unit malfunction is detected.
CAN Controller Memory Error
Front Display Connection ErrorWhen either one of the following items is
detected:
 display unit power supply and ground cir-
cuits are malfunctioning.
 serial communication circuits between
display unit and AV control unit are mal-
functioning.
 serial communication signal between
display unit and AV control unit is mal-
functioning. Display unit power supply and ground
circuits
 Serial communication circuits between
display unit and AV control unit
Camera Cont. Unit Connection ErrorCamera connection recognition signal cir-
cuits malfunction is detected.Camera connection recognition signal cir-
cuit
AV COMM CIRCUITRear control switch power supply and
ground circuits malfunction are detected.Rear control switch power supply and
ground circuits.
 AV COMM CIRCUIT
 Switches Connection ErrorWhen either one of the following items is
detected:
 multifunction switch power supply and
ground circuits are malfunctioning.
 AV communication circuits between AV
control unit and multifunction switch are
malfunctioning.
 AV communication signal between AV
control unit and multifunction switch is
malfunctioning. Multifunction switch power supply and
ground circuits
 AV communication circuits between AV
control unit and multifunction switch Error item Description Possible malfunction factor/Action to take
