NISSAN TEANA 2008 Service Manual

AV
RGB (G: GREEN) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
AV-87
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
RGB (G: GREEN) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY
UNIT)
DescriptionINFOID:0000000003882741
Transmit the image displayed with AV control unit or NAVI control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000003901207
1.CHECK CONTINUITY RGB (G: GREEN) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (G: GREEN) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 6 M129 39 Existed
Display unit
GroundContinuity
Connector Terminal
M49 6 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 6 GroundStart Confirmation / Adjustment
mode, and then display color bar
by selecting “Color Spectrum Bar”
on DISPLAY DIAGNOSIS screen.
SKIB2236J

AV-88
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
RGB (B: BLUE) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
RGB (B: BLUE) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
DescriptionINFOID:0000000003882743
Transmit the image displayed with AV control unit or NAVI control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000003901208
1.CHECK CONTINUITY RGB (B: BLUE) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (B: BLUE) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 18M12938 Existed
Display unit
GroundContinuity
Connector Terminal
M49 18 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 18 GroundStart Confirmation / Adjustment
mode, and then display color bar
by selecting “Color Spectrum Bar”
on DISPLAY DIAGNOSIS screen.
SKIB2237J

AV
RGB SYNCHRONIZING SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY
UNIT)
AV-89
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
RGB SYNCHRONIZING SIGNAL CIRCUIT (AV CONTROL UNIT TO DIS-
PLAY UNIT)
DescriptionINFOID:0000000003882745
Transmit the RGB synchronizing signal to the display unit so as to synchronize the RGB image displayed with
AV control unit or NAVI control unit.
Diagnosis ProcedureINFOID:0000000003901209
1.CHECK CONTINUITY RGB SYNCHRONIZING SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB SYNCHRONIZING SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 19M12941 Existed
Display unit
GroundContinuity
Connector Terminal
M49 19 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 19 Ground —
SKIB3603E

AV-90
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
RGB AREA (YS) SIGNAL CIRCUIT
RGB AREA (YS) SIGNAL CIRCUIT
DescriptionINFOID:0000000003882747
Transmits the display area of RGB image displayed by AV control unit or NAVI control unit with RGB area (YS)
signal to display unit.
Diagnosis ProcedureINFOID:0000000003901210
1.CHECK CONTINUITY RGB AREA (YS) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector terminal 9 and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB SYNCHRONIZING SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 9 M129 43 Existed
Display unit
GroundContinuity
Connector Terminal
M49 9 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 9 GroundWhen RGB image is displayed. Approx. 5 V
When AUX image is displayed.
PKIB4948J

AV
HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
AV-91
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
DescriptionINFOID:0000000003882749
In composite image (AUX image, camera image), transmit the vertical synchronizing (VP) signal and horizon-
tal synchronizing (HP) signal from display unit to AV control unit so as to synchronize the RGB images dis-
played with AV control unit such as the image quality adjusting menu, etc.
Diagnosis ProcedureINFOID:0000000003901211
1.CHECK CONTINUITY HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HORIZONTAL SYNCHRONIZING (HP) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
NO >> Replace display unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 8 M129 45 Existed
Display unit
GroundContinuity
Connector Terminal
M49 8 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 8 Ground —
SKIB3601E

AV-92
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
VERTICAL SYNCHRONIZING (VP) SIGNAL CIRCUIT
VERTICAL SYNCHRONIZING (VP) SIGNAL CIRCUIT
DescriptionINFOID:0000000003882751
In composite image (AUX image, camera image), transmit the vertical synchronizing (VP) signal and horizon-
tal synchronizing (HP) signal from display unit to AV control unit so as to synchronize the RGB images dis-
played with AV control unit such as the image quality adjusting menu, etc.
Diagnosis ProcedureINFOID:0000000003901212
1.CHECK CONTINUITY VERTICAL SYNCHRONIZING (VP) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK VERTICAL SYNCHRONIZING (VP) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
NO >> Replace display unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 20M12957 Existed
Display unit
GroundContinuity
Connector Terminal
M49 20 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 20 Ground —
SKIB3598E

AV
AUX IMAGE SIGNAL CIRCUIT
AV-93
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
AUX IMAGE SIGNAL CIRCUIT
DescriptionINFOID:0000000003882753
Transmits the image signal of external device from auxiliary input jacks to AV control unit.
Diagnosis ProcedureINFOID:0000000003882754
1.CHECK CONTINUITY AUX IMAGE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect auxiliary input jacks connector and AV control unit connector.
3. Check continuity between auxiliary input jacks harness connector and AV control unit harness connector.
4. Check continuity between auxiliary input jacks harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK AUX IMAGE SIGNAL
1. Connect auxiliary input jacks connector and AV control unit connector.
2. Turn ignition switch ON.
3. Make AUX image signal being input.
4. Check signal between auxiliary input jacks harness connector using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
NO >> Check that there is no malfunction in the external device.
Auxiliary input jacks AV control unit
Continuity
Connector Terminals Connector Terminals
M2537
M13066
Existed
874
Auxiliary input jacks
GroundContinuity
Connector Terminal
M253 7 Not existed
(+) (−)
Condition Reference value Auxiliary input jacks Auxiliary input jacks
Connector Terminal Connector Terminal
M253 7 M253 8 When AUX image is displayed.
SKIB2251J

AV-94
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DISK EJECT SIGNAL CIRCUIT
DISK EJECT SIGNAL CIRCUIT
DescriptionINFOID:0000000003882755
The eject signal is output to AV control unit when the eject switch of multifunction switch is pressed.
Diagnosis ProcedureINFOID:0000000003901213
1.CHECK CONTINUITY DISK EJECT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect multifunction switch connector and AV control unit connector.
3. Check continuity between multifunction switch harness connector and AV control unit harness connector.
4. Check continuity between multifunction switch harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Connect multifunction switch connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check voltage between AV control unit harness connector and ground.
Is inspection result normal?
YES >> Replace preset switch.
NO >> Replace AV control unit.
Multifunction switch AV control unit
Continuity
Connector Terminal Connector Terminal
M125 14 M131 103 Existed
Multifunction switch
GroundContinuity
Connector Terminal
M125 14 Not existed
(+)
(−) Condition Reference value AV control unit
Connector Terminal
M131 103 GroundPressing the eject switch. 0 V
Except for above. 3.3 V

AV
REAR VIEW CAMERA POWER SUPPLY
AV-95
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
REAR VIEW CAMERA POWER SUPPLY
DescriptionINFOID:0000000003882757
 Camera control unit outputs camera ON signal to rear view camera and inputs rear view camera image sig-
nal from rear view camera when the reverse signal is input.
 The camera control unit that inputs the camera image signal transmits the camera image signal to the AV
control unit.
Diagnosis ProcedureINFOID:0000000003901214
1.CHECK CONTINUITY CAMERA ON SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect camera control unit connector and rear view camera connector.
3. Check continuity between camera control unit harness connector and rear view camera harness connec-
tor.
4. Check continuity between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK VOLTAGE CAMERA ON SIGNAL
1. Connect camera control unit connector and rear view camera connector.
2. Turn ignition switch ON.
3. Check signal between camera control unit harness connector and ground.
Is inspection result normal?
YES >> Replace rear view camera.
NO >> Replace camera control unit.
Camera control unit Rear view camera
Continuity
Connector Terminal Connector Terminal
B2518T1031Existed
Camera control unit
GroundContinuity
Connector Terminal
B251 8 Not existed
(+)
(−) ConditionVo l ta g e
(Approx.) Camera control unit
Connector Terminal
B251 8 GroundSelector le-
ver in R posi-
tion. 6.0 V
Other than
selector le-
ver in R posi-
tion. 0 V

AV-96
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
CAMERA IMAGE SIGNAL CIRCUIT
CAMERA IMAGE SIGNAL CIRCUIT
DescriptionINFOID:0000000003882759
 Camera control unit outputs camera ON signal to rear view camera and inputs rear view camera image sig-
nal from rear view camera when the reverse signal is input.
 The camera control unit that inputs the camera image signal transmits the camera image signal to the dis-
play unit.
Diagnosis ProcedureINFOID:0000000003901215
1.CHECK CONTINUITY CAMERA IMAGE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect camera control unit connector and AV control unit connector.
3. Check continuity between camera control unit harness connector and AV control unit harness connector.
4. Check continuity between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK CAMERA IMAGE SIGNAL
1. Connect camera control unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between camera control unit harness connector using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
NO >> Replace camera control unit.
Camera control unit AV control unit
Continuity
Connector Terminals Connector Terminals
B25111
M13064
Existed
12 65
Camera control unit
GroundContinuity
Connector Terminal
B251 12 Not existed
(+)
(−) Condition Reference value Camera control unit
Connector Terminal
B251 12 GroundWhen rear view camera
image is displayed.
SKIB2251J
