U1243 DISPLAY UNIT
DescriptionINFOID:0000000003882725
DTC LogicINFOID:0000000003882726
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003901200
1.CHECK DISPLAY UNIT POWER SUPPLY AND GROUND CIRCUIT
Check display unit power supply and ground circuit. Refer to AV-82, "
DISPLAY UNIT : Diagnosis Procedure".
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair malfunctioning parts.
2.CHECK CONTINUITY COMMUNICATION CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
Part name Description
DISPLAY UNIT Display image is controlled by the serial communication from AV control unit.
 It receives the power (signal VCC and inverter VCC) from the AV control unit
and operates.
 RGB image signal is input from AV control unit (RGB, RGB area and RGB syn-
chronizing).
 Composite image (DVD, AUX and camera images) signal is input from AV con-
trol unit.
 Synchronize signal (HP, VP) is output to AV control unit.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Possible causes
U1243FRONT DISP CONN
[U1243]When either one of the following items is detected:
 display unit power supply and ground circuits are mal-
functioning.
 serial communication circuits between display unit and
AV control unit are malfunctioning.
 serial communication signal between display unit and
AV control unit is malfunctioning. Display unit power supply and
ground circuits.
 Serial communication circuits be-
tween display unit and AV control
unit
Display unit AV control unit
Continuity
Connector Terminals Connector Terminals
M4911
M12956
Existed
22 44
Display unit
GroundContinuity
Connector Terminals
M4911
Not existed
22

AV-78
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
U1243 DISPLAY UNIT
3.CHECK COMMUNICATION SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> GO TO 4.
NO >> Replace AV control unit.
4.CHECK COMMUNICATION SIGNAL
Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace display unit.
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 11 GroundWhen adjusting display bright-
ness.
PKIB5039J
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 22 GroundWhen adjusting display bright-
ness.
PKIB5039J

AV
U1250 CAMERA CONTROL UNIT
AV-79
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
U1250 CAMERA CONTROL UNIT
DescriptionINFOID:0000000003882728
DTC LogicINFOID:0000000003882729
Diagnosis ProcedureINFOID:0000000003901201
1.CHECK CONTINUITY RECOGNITION SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and camera control unit connector.
3. Check continuity between AV control unit harness connector and camera control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Connect AV control unit connector and camera control unit connector.
2. Turn ignition switch ON.
3. Check signal between AV control unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
Part name Description
CAMERA CONTROL UNIT Camera image signal is input from rear view camera. Camera image signal
output to AV control unit.
 Power supply is transmitted to rear view camera.
 AV control unit recognizes the presence of camera system with camera con-
nection recognition signal.
 Camera control unit is connected via AV communication.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Possible causes
U1250CAMERA CONT. CONN
[U1250]Malfunction is detected in camera connection recogni-
tion signal circuit.Camera connection recognition sig-
nal circuit.
AV control unit Camera control unit
Continuity
Connector Terminals Connector Terminals
M130 68 B251 14 Existed
AV control unit
GroundContinuity
Connector Terminals
M130 68 Not existed
(+)
(−) ConditionVo l ta g e
(Approx.) AV control unit
Connector Terminal
M130 68 GroundConnected camera
control unit connector0 V
Disconnect camera
control unit connector5 V

AV-80
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
U1250 CAMERA CONTROL UNIT
NO >> Replace camera control unit.

AV
U1300 AV COMM CIRCUIT
AV-81
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
U1300 AV COMM CIRCUIT
DescriptionINFOID:0000000003882731
U1300 is indicated when malfunction occurs in communication signal of multi AV system. Indicated simulta-
neously, without fail, with the malfunction of control units connected to AV control unit with communication line.
Determine the possible malfunction cause from the table below.
Self-diagnosis results display item
DTCDisplay contents of
CONSULT-IIIDescriptionPossible malfunction factor/Action to
take
U1300
U1240 AV COMM CIRCUIT
[U1300]
 SWITCH CONN
[U1240]When either one of the following items is detected:
 multifunction switch power supply and ground circuits
are malfunctioning.
 AV communication circuits between AV control unit and
multifunction switch are malfunctioning.
 AV communication signal between AV control unit and
multifunction switch is malfunctioning. Multifunction switch power supply
and ground circuits
Refer toAV- 8 3 , "
MULTIFUNCTION
SWITCH : Diagnosis Procedure".
 AV communication circuits be-
tween AV control unit and multi-
function switch
U1300
U1252 AV COMM CIRCUIT
[U1300]
 REAR-CAMERA LAN
CONN [U1252]With rear control switch
When either one of the following items is detected:
 camera control unit power supply and ground circuits
are malfunctioning.
 AV communication signal between AV control unit and
camera control unit is malfunctioning.
 AV communication circuits between multifunction
switch and rear control switch are malfunctioning.
 AV communication circuits between rear control switch
and camera control unit are malfunctioning. Camera control unit power supply
and ground circuits
Refer to AV- 8 4 , "
CAMERA CON-
TROL UNIT : Diagnosis Proce-
dure".
 AV communication circuits be-
tween multifunction switch and rear
control switch
 AV communication circuits be-
tween rear control switch and cam-
era control unit
Without rear control switch
When either one of the following items is detected:
 camera control unit power supply and ground circuits
are malfunctioning.
 malfunction is detected in AV communication circuits
between multifunction switch and camera control unit.
 AV communication signal between AV control unit and
multifunction switch is malfunctioning. Camera control unit power supply
and ground circuits
Refer to AV- 8 4 , "
CAMERA CON-
TROL UNIT : Diagnosis Proce-
dure".
 AV communication circuits be-
tween multifunction switch and
camera control unit
U1300
U1240
U1252 AV COMM CIRCUIT
[U1300]
 SWITCH CONN
[U1240]
 REAR-CAMERA LAN
CONN [U1252]When either one of the following items is detected:
 AV communication circuits between AV control unit and
multifunction switch are malfunctioning.
 AV communication signal between AV control unit and
multifunction switch is malfunctioning.AV communication circuits between
AV control unit and multifunction
switch

AV-82
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
AV CONTROL UNIT
AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003901202
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between AV control unit harness connectors and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between AV control unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connectors.
3. Check continuity between AV control unit harness connectors and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
DISPLAY UNIT
DISPLAY UNIT : Diagnosis ProcedureINFOID:0000000003901446
1.CHECK POWER SUPPLY CIRCUIT (DISPLAY SIDE)
Check voltage between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
Power source Fuse No.
Battery 31
Ignition switch ACC or ON 19
Ignition switch ON or START 4
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Battery power supply
M12719 OFF
Battery voltage ACC power supply 7 ACC
Ignition signal M131 104 ON
Signal name Connector No. Terminal No. Ignition switch position Continuity
GroundM127 20
OFF Existed
M131 85
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Inverter VCC
M492
ACC 9 V
Signal VCC 3

AV
POWER SUPPLY AND GROUND CIRCUIT
AV-83
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the harness connector between display unit and AV control unit.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK POWER SUPPLY CIRCUIT (AV CONTROL UNIT SIDE)
1. Connect the AV control unit harness connector.
2. Turn ignition switch ACC.
3. Check voltage between AV control unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTED END.
NO >> Replace AV control unit.
4.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector.
3. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTED END.
NO >> Repair harness or connector.
MULTIFUNCTION SWITCH
MULTIFUNCTION SWITCH : Diagnosis ProcedureINFOID:0000000003901204
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
Signal nameDisplay unit AV control unit
Continuity
Connector No. Terminal No. Connector No. Terminal No.
Ground M492
M12959
Existed
347
Signal nameDisplay unit
GroundContinuity
Connector No. Terminal No.
Inverter VCC
M492
Not existed
Signal VCC 3
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Inverter VCC
M12959
ACC 9 V
Signal VCC 47
Signal nameDisplay unit
GroundContinuity
Connector No. Terminal No.
Ground M49 1 Existed
Power source Fuse No.
Ignition switch ACC or ON 19

AV-84
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between multifunction switch harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between multifunction switch and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect multifunction switch connector.
3. Check continuity between multifunction switch harness connector and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
CAMERA CONTROL UNIT
CAMERA CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003901205
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUITS
Check voltage between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between camera control unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect camera control unit connector.
3. Check continuity between camera control unit harness connector and ground.
Is inspection result normal?
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
ACC power supply M125 3 ACC Battery voltage
Signal name Connector No. Terminal No. Ignition switch position Continuity
Ground M125 1 OFF Existed
Power source Fuse No.
Battery 31
Ignition switch ACC 19
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Battery power supply
B25132 OFF
Battery voltage
ACC power supply 30 ACC
Signal name Connector No. Terminal No. Ignition switch position Continuity
Ground B251 31 OFF Existed

AV
POWER SUPPLY AND GROUND CIRCUIT
AV-85
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
YES >> INSPECTION END
NO >> Repair harness or connector.

AV-86
< COMPONENT DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
RGB (R: RED) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
RGB (R: RED) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
DescriptionINFOID:0000000003882739
Transmit the image displayed with AV control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000003901206
1.CHECK CONTINUITY RGB (R: RED) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (R: RED) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 17M12940 Existed
Display unit
GroundContinuity
Connector Terminal
M49 17 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 17 GroundStart Confirmation / Adjustment
mode, and then display color bar
by selecting “Color Spectrum Bar”
on DISPLAY DIAGNOSIS screen.
SKIB2238J
