NISSAN TEANA 2008 Service Manual

EXL-182
< ON-VEHICLE REPAIR >[XENON TYPE]
FRONT COMBINATION LAMP
1. Remove the relay box cover*. Refer to PCS-34, "Exploded View".
*: When replace a left
2. Rotate the bulb socket counterclockwise and unlock it.
3. Remove the bulb from the front turn signal lamp bulb socket.
Disassembly and AssemblyINFOID:0000000003773622
DISASSEMBLY
1. Rotate the resin cap counterclockwise and unlock it.
2. Disconnect the xenon bulb socket ground line.
3. Rotate the xenon bulb socket counterclockwise and unlock it.
4. Unlock the retaining spring. And then remove the xenon bulb from the headlamp housing.
5. Rotate the halogen bulb (HI) socket counterclockwise and unlock it.
6. Remove the halogen bulb (HI) from the headlamp housing.
7. Remove the HID control unit installation screw.
8. Remove the screw. And then disconnect the connector from HID control unit.
9. Remove the xenon bulb socket from the headlamp housing.
10. Rotate the parking lamp bulb socket counterclockwise and unlock it.
11. Remove the bulb from the parking lamp bulb socket.
12. Rotate the front turn signal lamp bulb socket counterclockwise and unlock it.
13. Remove the bulb from the front turn signal lamp bulb socket.
ASSEMBLY
Assemble in the reverse order of disassembly.
CAUTION:
 Install HID control unit securely.
 After installing the bulb, install the resin cap and the bulb socket securely for watertightness.

FRONT FOG LAMP
EXL-183
< ON-VEHICLE REPAIR >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
FRONT FOG LAMP
Exploded ViewINFOID:0000000003773623
Removal and InstallationINFOID:0000000003773624
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
REMOVAL
1. Remove the front fender protector. Keep a service area. Refer to EXT-22, "FENDER PROTECTOR :
Exploded View".
2. Remove the front fog lamp connector.
3. Remove the mounting nuts. And then remove the front fog lamp.
NOTE:
Never remove a front fog lamp bracket, when the front fog lamp is replaced.
INSTALLATION
Installation is the reverse order of removal.
NOTE:
After installation, perform aiming adjustment. Refer to EXL-178, "
Description".
ReplacementINFOID:0000000003773625
CAUTION:
 Disconnect the battery negative terminal or remove the fuse.
 Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
 Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
FRONT FOG LAMP BULB
1. Remove the front fender protector. Keep a service area. Refer to EXT-22, "FENDER PROTECTOR :
Exploded View".
1. Front fog lamp bracket 2. Front fog lamp
JPLIA1090ZZ

EXL-184
< ON-VEHICLE REPAIR >[XENON TYPE]
FRONT FOG LAMP
2. Remove the front fog lamp bulb connector (1).
3. Rotate the bulb (2) counterclockwise and unlock it.
JPLIA1091ZZ

OPTICAL SENSOR
EXL-185
< ON-VEHICLE REPAIR >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
OPTICAL SENSOR
Exploded ViewINFOID:0000000003773626
Removal and InstallationINFOID:0000000003773627
REMOVAL
1. Insert an appropriate tool between the optical sensor and the speaker grille (RH). Pull out the optical sen-
sor upward.
2. Disconnect the optical sensor connector. And then remove the optical sensor.
INSTALLATION
Install in the reverse order of removal.
1. Optical sensor
JPLIA1092ZZ

EXL-186
< ON-VEHICLE REPAIR >[XENON TYPE]
LIGHTING & TURN SIGNAL SWITCH
LIGHTING & TURN SIGNAL SWITCH
Exploded ViewINFOID:0000000003773628
Removal and InstallationINFOID:0000000003773629
Lighting & turn signal switch is integrated in the combination switch. Refer to BCS-79, "Exploded View".

HAZARD SWITCH
EXL-187
< ON-VEHICLE REPAIR >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
HAZARD SWITCH
Exploded ViewINFOID:0000000003773630
Removal and InstallationINFOID:0000000003773631
REMOVAL
1. Remove the cluster lid D. Refer to IP-11, "Exploded View".
2. Disengage the pawls. And then remove the hazard switch.
INSTALLATION
Install in the reverse order of removal.
1. Hazard switch 2. Cluster lid D
A. Pawls
JPLIA1093ZZ

EXL-188
< ON-VEHICLE REPAIR >[XENON TYPE]
SIDE TURN SIGNAL LAMP
SIDE TURN SIGNAL LAMP
Exploded ViewINFOID:0000000003816250
Removal and InstallationINFOID:0000000003816251
CAUTION:
Disconnect battery negative terminal or remove the fuse.
REMOVAL
1. Remove the door mirror glass. Refer to MIR-18, "GLASS MIRROR : Exploded View".
2. Remove the door mirror outer cover. Refer to MIR-19, "
DOOR MIRROR COVER : Exploded View".
3. Remove the door mirror actuator mounting screws (A) and (B).
And then remove the side turn signal lamp mounting screw (C).
4. Remove the door mirror under cover. Refer to MIR-19, "
DOOR MIRROR COVER : Exploded View".
5. Remove the screws (A) and connector (1). And then remove the
side turn signal lamp (2).
INSTALLATION
1. Side turn signal lamp 2. Door mirror under cover
JPLIA1094ZZ
JPLIA1095ZZ
JPLIA1096ZZ

SIDE TURN SIGNAL LAMP
EXL-189
< ON-VEHICLE REPAIR >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Install in the reverse order of removal.

EXL-190
< ON-VEHICLE REPAIR >[XENON TYPE]
AUTO LEVELIZER CONTROL UNIT
AUTO LEVELIZER CONTROL UNIT
Exploded ViewINFOID:0000000003774377
Removal and InstallationINFOID:0000000003774378
Removal
1. Remove the auto levelizer control unit bolt.
2. Remove the sensor lever link bracket bolt.
3. Disconnect the auto levelizer control unit connector.
4. Remove the auto levelizer control unit.
Installation
Install in the reverse order of removal.
CAUTION:
 Be sure to perform sensor initialization if auto levelizer control unit is removed. Refer to EXL-10,
"SENSOR INITIALIZE : Special Repair Requirement (HEADLAMP AIMING CONTROL SYSTEM)".
 Be sure to perform “WRITE CONFIGURATION” with CONSULT-III when replacing the auto levelizer
control unit. Refer to EXL-9, "
CONFIGURATION (HEADLAMP LEVELIZER) : Special Repair Require-
ment".
1. Auto levelizer control unit
A. Auto levelizer control unit bolt B. Sensor lever link bracket bolt
JPLIA1147ZZ

REAR COMBINATION LAMP
EXL-191
< ON-VEHICLE REPAIR >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR COMBINATION LAMP
Exploded ViewINFOID:0000000003773634
REMOVAL
DISASSEMBLY
Removal and InstallationINFOID:0000000003773635
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
REMOVAL
1. Remove the rear combination lamp finisher.
2. Remove the rear combination lamp mounting bolts.
3. Pull the rear combination lamp toward outside of the vehicle. And then remove the rear combination lamp.
4. Disconnect the rear combination lamp connector.
INSTALLATION
Install in the reverse order of removal.
1. Rear combination lamp 2. Rear combination lamp finisher
JPLIA1097ZZ
1. Back-up lamp bulb 2. Back-up lamp bulb socket 3. Rear turn signal lamp bulb socket
4. Rear turn signal lamp bulb
JPLIA1098ZZ
