NISSAN TEANA 2008 Service Manual

EXL-162
< ECU DIAGNOSIS >[XENON TYPE]
AUTO LEVELIZER CONTROL UNIT
DTC Inspection Priority Chart
INFOID:0000000003805625
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
B2082: SENSOR OUT OF
RANGEAfter engine start
[Less than 5 seconds after ig-
nition switch ON and vehicle
speed less than 4 km/h (2.5
MPH)]Fix with the light axis facing
downward
When sensor signal returns to
normal range
While driving
[5 seconds or more after igni-
tion switch ON or vehicle
speed 4 km/h (2.5 MPH) or
more]Maintain the light axis at the
time of DTC detection
B2083: SEN SIG NOT PLAU-
SIBLE Maintain the aiming motor drive signal output at the time of
DTC detection
 Maintain the light axis at the time of DTC detectionIgnition switch OFF
B2084: VOLTAGE UNDER
LIMITAfter engine start
[Less than 5 seconds after ig-
nition switch ON and vehicle
speed less than 4 km/h (2.5
MPH)]Fix with the light axis facing
downward
Ignition switch OFF
While driving
[5 seconds or more after igni-
tion switch ON or vehicle
speed 4 km/h (2.5 MPH) or
more]Maintain the light axis at the
time of DTC detection
B2085: LOWBEAM SIG
OPEN LINEAfter engine start
[Less than 5 seconds after ig-
nition switch ON and vehicle
speed less than 4 km/h (2.5
MPH)]Fix with the light axis facing
downward
Ignition switch OFF
While driving
[5 seconds or more after igni-
tion switch ON or vehicle
speed 4 km/h (2.5 MPH) or
more]Maintain the light axis at the
time of DTC detection
B2086: FRQ. OVER LIMITAfter engine start
[Less than 5 seconds after ig-
nition switch ON and vehicle
speed less than 4 km/h (2.5
MPH)]Fix with the light axis facing
downward
Ignition switch OFF
While driving
[5 seconds or more after igni-
tion switch ON or vehicle
speed 4 km/h (2.5 MPH) or
more]Maintain the light axis at the
time of DTC detection
B2087: SHORT TO GROUND Maintain the light axis at the time of DTC detection Ignition switch OFF
B2088: SHORT TO BATTERY Maintain the light axis at the time of DTC detection Ignition switch OFF
B208A: PARA NOT PROG Fix aiming motor drive signal output to approximately 0 VWrite configuration is complet-
ed DTC Fail-safe Cancellation
Priority DTC
1 B2080: ECU TROUBLE
 B208A: PARA NOT PROG

AUTO LEVELIZER CONTROL UNIT
EXL-163
< ECU DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
DTC IndexINFOID:0000000003805626
2  B2081: INITIAL NOT DONE
3 B2082: SENSOR OUT OF RANGE
 B2083: SEN SIG NOT PLAUSIBLE
 B2084: VOLTAGE UNDER LIMIT
 B2085: LOWBEAM SIG OPEN LINE
 B2086: FRQ. OVER LIMIT
 B2087: SHORT TO GROUND
 B2088: SHORT TO BATTERY Priority DTC
DTC Fail-safe Refer to
B2080: ECU TROUBLE×EXL-38, "
Description"
B2081: INITIAL NOT DONE×EXL-39, "DTC Logic"
B2082: SENSOR OUT OF RANGE×EXL-40, "DTC Logic"
B2083: SEN SIG NOT PLAUSIBLE×EXL-41, "DTC Logic"
B2084: VOLTAGE UNDER LIMIT×EXL-42, "DTC Logic"
B2085: LOWBEAM SIG OPEN LINE×EXL-43, "Description"
B2086: FRQ. OVER LIMIT×EXL-45, "Description"
B2087: SHORT TO GROUND×EXL-47, "DTC Logic"
B2088: SHORT TO BATTERY×EXL-48, "DTC Logic"
B208A: PARA NOT PROG×EXL-49, "DTC Logic"

EXL-164
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Symptom TableINFOID:0000000003774367
CAUTION:
Perform the self-diagnosis with CONSULT-III before the symptom diagnosis. Perform the trouble diag-
nosis if any DTC is detected.
Symptom Possible cause Inspection item
Headlamp (HI) is not
turned ON.One sideFuse
 Halogen bulb (HI)
 Harness between IPDM E/R
and the headlamp high
 IPDM E/RHeadlamp (HI) circuit
Refer to EXL-54
.
Both sides
Symptom diagnosis
“BOTH SIDE HEADLAMPS (HI) ARE NOT TURNED ON”
Refer to EXL-168
.
Headlamp (HI) is not
turned OFF.When ignition switch is
turned ON.
When ignition switch is
turned OFF.IPDM E/R —
High beam indicator lamp is not turned ON.
[Headlamp (HI) is turned ON.]Combination meter Combination meter
Data monitor “HI-BEAM IND”
 BCM (HEAD LAMP)
Active test “HEADLAMP”
Headlamp (LO) is not
turned ON.One sideFuse
 Xenon bulb (LO)
 Harness between IPDM E/R
and the front combination lamp
 IPDM E/RHeadlamp (LO) circuit
Refer to EXL-56
.
Both sides
Symptom diagnosis
“BOTH SIDE HEADLAMPS (LO) ARE NOT TURNED ON”
Refer to EXL-169
.
Headlamp (LO) is not
turned OFF.When ignition switch is
turned ON.
When ignition switch is
turned OFF.IPDM E/R —
Each lamps are not turned ON/OFF with lighting
switch AUTO. Combination switch
 Harness between the combina-
tion switch and BCM
BCMCombination switch
Refer to BCS-76
.
 Optical sensor
 Harness between the optical
sensor and BCM
BCMOptical sensor circuit
Refer to EXL-69
.
Front fog lamp is not
turned ON.One side Front fog lamp bulb
 Harness between IPDM E/R
and the front fog lamp
 Front fog lamp
 IPDM E/RFront fog lamp circuit
Refer to EXL-62
.
Both sidesSymptom diagnosis
“BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON”
Refer to EXL-171
. Front fog lamp is not turned ON.
Front fog lamp indicator is not turned ON.
(Front fog lamp is turned ON.)Combination meter Combination meter
Data monitor “FR FOG IND”
 BCM (HEAD LAMP)
Active test “FR FOG LAMP”

EXTERIOR LIGHTING SYSTEM SYMPTOMS
EXL-165
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Parking lamp is not turned ON. Parking lamp bulb
 Harness between IPDM E/R
and the front combination lamp
 Front combination lamp
 IPDM E/RParking lamp circuit
Refer to EXL-64.
Tail lamp is not turned ON. Harness between IPDM E/R
and the rear combination lamp
 Rear combination lampTail lamp circuit
Refer to EXL-74
.
License plate lamp is not turned ON. License plate lamp bulb
 Harness between IPDM E/R
and the license plate lamp
 License plate lampLicense plate lamp circuit
Refer to EXL-76
.
Tail lamp and the license plate lamp are not turned
ON.Fuse
 Harness between IPDM E/R
and the rear combination lamp
 IPDM E/RLicense plate lamp circuit
Refer to EXL-76
.
 Parking lamp, the tail lamp and the license plate
lamp are not turned ON.
 Parking lamp, the tail lamp and the license plate
lamp are not turned OFF.
(Each illumination is turned ON/OFF.)Symptom diagnosis
“PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED
ON”
Refer to EXL-170
.
Tail lamp indicator is not turned ON.
(Parking, tail lamps are turned ON.)Combination meter Combination meter
Data monitor “LIGHT IND”
 BCM (HEAD LAMP)
Active test “TAIL LAMP”
Turn signal lamp does not
blink.Indicator lamp is nor-
mal.
(Applicable side per-
forms the high flasher
activation.) Harness between BCM and
each turn signal lamp
 Turn signal lamp bulbTurn signal circuit
Refer to EXL-66
.
Indicator lamp is includ-
ed. Combination switch
 Harness between the combina-
tion switch and BCM
BCMCombination switch
Refer to BCS-76
.
Turn signal indicator lamp
does not blink.
(Turn signal indicator
lamp is normal.)One side Combination meter —
Both sides
(Always) Turn signal indicator lamp sig-
nal
-BCM
 Combination meter Combination meter
Data monitor “TURN IND”
 BCM (FLASHER)
Active test “FLASHER”
Both sides
(Only when activating
hazard warning lamp
with the ignition switch
OFF) Combination meter power sup-
ply and the ground circuit
 Combination meterCombination meter
Power supply and the ground circuit
Refer to MWI-42
.
 Hazard warning lamp does not activate.
 Hazard warning lamp continues activating.
(Turn signal is normal.) Hazard switch
 Harness between the hazard
switch and BCM
BCMHazard switch
Refer to EXL-72
.
Rear fog lamp is not
turned ON.Rear fog lamp indicator
lamp is normal. Harness between BCM and the
rear fog lamp
 Rear fog lamp bulb
BCMRear fog lamp circuit
Refer to EXL-77
.
Rear fog lamp indicator
lamp is included. Combination switch
 Harness between the combina-
tion switch and BCM
BCMCombination switch
Refer to BCS-76
. Symptom Possible cause Inspection item

EXL-166
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Rear fog lamp indicator lamp is not turn ON.
(Rear fog lamp turns ON) Rear fog lamp status signal
-BCM
 Combination meter Combination meter
Data monitor “RR FOG IND”
 BCM (HEAD LAMP)
Active test “RR FOG LAMP”
Headlamp auto aiming does not activate. Harness between the auto lev-
elizer control unit and the aim-
ing motor.
 Front combination lamp (Aiming
motor)
 Auto levelizer control unitHeadlamp levelizer circuit
Refer to EXL-60
. Symptom Possible cause Inspection item

NORMAL OPERATING CONDITION
EXL-167
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003774368
XENON HEADLAMP
 Brightness and the color of light may change slightly immediately after turning the headlamp ON until the
xenon bulb becomes stable. This is normal.
 Illumination time lag may occur between right and left. This is normal.
AUTO LIGHT SYSTEM
The headlamp may not be turned ON/OFF immediately after passing dark area or bright area (short tunnel,
sky bridge, shadowed area etc.) while using the auto light system. This causes for the control difference. This
is normal.

EXL-168
< SYMPTOM DIAGNOSIS >[XENON TYPE]
BOTH SIDE HEADLAMPS (HI) ARE NOT TURNED ON
BOTH SIDE HEADLAMPS (HI) ARE NOT TURNED ON
DescriptionINFOID:0000000003774369
Both side headlamps (HI) are not turned ON when setting to the lighting switch HI or PASS.
Diagnosis ProcedureINFOID:0000000003774370
1.COMBINATION SWITCH INSPECTION
Check the combination switch. Refer to BCS-76, "
Symptom Table".
Is the combination switch normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning part.
2.CHECK HEADLAMP (HI) REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select “HL HI REQ” of IPDM E/R data monitor item.
2. With operating the lighting switch, check the monitor status.
Is the item status normal?
YES >> GO TO 3.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
3.HEADLAMP (HI) CIRCUIT INSPECTION
Check the headlamp (HI) circuit. Refer to EXL-54, "
Component Function Check".
Is the headlamp (HI) circuit normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace the malfunctioning part.
Monitor item Condition Monitor status
HL HI REQLighting switch
(2ND)HI or PASS On
LO Off

BOTH SIDE HEADLAMPS (LO) ARE NOT TURNED ON
EXL-169
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
BOTH SIDE HEADLAMPS (LO) ARE NOT TURNED ON
DescriptionINFOID:0000000003774371
Both side headlamps (LO) are not turned ON in any condition.
Diagnosis ProcedureINFOID:0000000003774372
1.CHECK COMBINATION SWITCH
Check the combination switch. Refer to BCS-76, "
Symptom Table".
Is the combination switch normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning part.
2.CHECK HEADLAMP (LO) REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select “HL LO REQ” of IPDM E/R data monitor item.
2. With operating the lighting switch, check the monitor status.
Is the item status normal?
YES >> GO TO 3.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
3.HEADLAMP (LO) CIRCUIT INSPECTION
Check the headlamp (LO) circuit. Refer to EXL-56, "
Component Function Check".
Is the headlamp (LO) circuit normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace the malfunctioning part.
Monitor item Condition Monitor status
HL LO REQ Lighting switch2ND On
OFF Off

EXL-170
< SYMPTOM DIAGNOSIS >[XENON TYPE]
PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON
PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON
DescriptionINFOID:0000000003773608
The parking, license plate, tail lamps and each illumination are not turned ON in any condition.
Diagnosis ProcedureINFOID:0000000003773609
1.CHECK FUSE
Check that the following fuse is fusing.
Is the fuse fusing?
YES >> Repair the applicable circuit. And then replace the fuse.
NO >> GO TO 2.
2.COMBINATION SWITCH INSPECTION
Check the combination switch. Refer to BCS-76, "
Symptom Table".
Is the combination switch normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning part.
3.CHECK TAIL LAMP RELAY REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select “TAIL & CLR REQ” of IPDM E/R data monitor item.
2. With operating the lighting switch, check the monitor status.
Is the item status normal?
YES >> GO TO 4.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
4.TAIL LAMP CIRCUIT INSPECTION
Check the tail lamp circuit. Refer to EXL-74, "
Component Function Check".
Is the tail lamp circuit normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace the malfunctioning part.
Unit Location Fuse No. Capacity
Parking lamp
IPDM E/R#52 10 A
Tail lamp
 License plate lamp#53 10 A
Monitor item Condition Monitor status
TAIL & CLR
REQLighting switch1ST On
OFF Off

BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON
EXL-171
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON
DescriptionINFOID:0000000003773610
The front fog lamps are not turned ON in any condition.
Diagnosis ProcedureINFOID:0000000003773611
1.CHECK FUSE
Check that the following fuse is fusing.
Is the fuse fusing?
YES >> Repair the applicable circuit. And then replace the fuse.
NO >> GO TO 2.
2.COMBINATION SWITCH INSPECTION
Check the combination switch. Refer to BCS-76, "
Symptom Table".
Is the combination switch normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning part.
3.CHECK FRONT FOG LAMP REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select “FR FOG REQ” of IPDM E/R data monitor item.
2. With operating the front fog lamp switch, check the monitor status.
Is the item status normal?
YES >> GO TO 4.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
4.FRONT FOG LAMP CIRCUIT INSPECTION
Check the front fog lamp circuit. Refer to EXL-62, "
Component Function Check".
Is the front fog lamp circuit normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace the malfunctioning part.
Unit Location Fuse No. Capacity
Front fog lamp IPDM E/R #58 15 A
Monitor item Condition Monitor status
FR FOG REQFront fog lamp switch
(With lighting switch 1ST)ON On
OFF Off
