SIDE TURN SIGNAL LAMP
SIDE TURN SIGNAL LAMP
Exploded ViewINFOID:0000000003894369
Removal and InstallationINFOID:0000000003894370
CAUTION:
Disconnect battery negative terminal or remove the fuse.
REMOVAL
1. Remove the door mirror glass. Refer to MIR-18, "GLASS MIRROR : Exploded View".
2. Remove the door mirror outer cover. Refer to MIR-19, "
DOOR MIRROR COVER : Exploded View".
3. Remove the door mirror actuator mounting screws (A) and (B).
And then remove the side turn signal lamp mounting screw (C).
4. Remove the door mirror under cover. Refer to MIR-19, "
DOOR MIRROR COVER : Exploded View".
5. Remove the screws (A) and connector (1). And then remove the
side turn signal lamp (2).
INSTALLATION
1. Side turn signal lamp 2. Door mirror under cover
JPLIA1094ZZ
JPLIA1095ZZ
JPLIA1096ZZ

SIDE TURN SIGNAL LAMP
EXL-353
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Install in the reverse order of removal.

EXL-354
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
REAR COMBINATION LAMP
REAR COMBINATION LAMP
Exploded ViewINFOID:0000000003894373
REMOVAL
DISASSEMBLY
Removal and InstallationINFOID:0000000003894374
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
REMOVAL
1. Remove the rear combination lamp finisher.
2. Remove the rear combination lamp mounting bolts.
3. Pull the rear combination lamp toward outside of the vehicle. And then remove the rear combination lamp.
4. Disconnect the rear combination lamp connector.
INSTALLATION
Install in the reverse order of removal.
1. Rear combination lamp 2. Rear combination lamp finisher
JPLIA1097ZZ
1. Back-up lamp bulb 2. Back-up lamp bulb socket 3. Rear turn signal lamp bulb socket
4. Rear turn signal lamp bulb
JPLIA1098ZZ

REAR COMBINATION LAMP
EXL-355
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
ReplacementINFOID:0000000003894375
CAUTION:
 Disconnect the battery negative terminal or remove the fuse.
 Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
 Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
STOP/TAIL LAMP
Replacement integral with rear combination lamp. Refer to EXL-354, "Exploded View".
REAR TURN SIGNAL LAMP BULB
1. Remove the rear combination lamp. Refer to EXL-354, "Exploded View".
2. Rotate the rear turn signal lamp bulb socket counterclockwise, and unlock it.
3. Remove the bulb from the rear turn signal lamp bulb socket.
BACK-UP LAMP BULB
1. Remove the rear combination lamp. Refer to EXL-354, "Exploded View".
2. Rotate the back-up lamp bulb socket counterclockwise, and unlock it.
3. Remove the bulb from the back-up lamp bulb socket.

EXL-356
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
HIGH-MOUNTED STOP LAMP
HIGH-MOUNTED STOP LAMP
Exploded ViewINFOID:0000000003894376
Removal and InstallationINFOID:0000000003894377
CAUTION:
Disconnect battery negative terminal or remove the fuse.
REMOVAL
1. Remove the rear parcel shelf finisher. Refer to INT-43, "Exploded View".
2. Remove the screw. And then disconnect the connector.
3. Remove the high-mounted stop lamp.
INSTALLATION
Install in the reverse order of removal.
1. High-mounted stop lamp 2. Rear parcel shelf finisher
JPLIA1099ZZ

REAR FOG LAMP
EXL-357
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR FOG LAMP
Exploded ViewINFOID:0000000003894378
Removal and InstallationINFOID:0000000003894379
CAUTION:
Disconnect battery negative terminal or remove the fuse.
REMOVAL
1. Disconnect the rear fog lamp connector.
2. Remove the nuts. And then remove the rear fog lamp rim.
3. Remove the screw. And then remove the rear fog lamp from the rear fog lamp rim.
INSTALLATION
Installation is the reverse order of removal.
ReplacementINFOID:0000000003894380
CAUTION:
 Disconnect the battery negative terminal or remove the fuse.
 Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
 Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
REAR FOG LAMP BULB
1. Turn the bulb socket (1) counterclockwise and unlock it.
2. Remove the bulb (2) from the rear fog lamp bulb socket.
1. Rear fog lamp 2. Rear fog lamp bracket 3. Rear fog lamp finisher
JPLIA1102ZZ
JPLIA1103ZZ

EXL-358
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
LICENSE PLATE LAMP
LICENSE PLATE LAMP
Exploded ViewINFOID:0000000003894381
Removal and InstallationINFOID:0000000003894382
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
REMOVAL
1. Remove the trunk lid finisher inner. Refer to INT-59, "Exploded View".
2. Remove the trunk lid finisher outer. Refer to INT-59, "
Exploded View".
3. Remove the license plate lamp while pushing a resin clip.
4. Disconnect the license plate lamp connector.
INSTALLATION
Install in the reverse order of removal.
ReplacementINFOID:0000000003894383
CAUTION:
 Disconnect the battery negative terminal or remove the fuse.
 Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
 Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
LICENSE PLATE LAMP BULB
1. Remove the trunk lid finisher inner. Refer to INT-59, "Exploded View".
1. License plate lamp
A. Resin clip
JPLIA1100ZZ

LICENSE PLATE LAMP
EXL-359
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
2. Turn the license plate lamp bulb socket (1) counterclockwise
and unlock it.
3. Remove the bulb (2) from the license plate lamp bulb socket.
JPLIA1101ZZ

EXL-360
< SERVICE DATA AND SPECIFICATIONS (SDS) [HALOGEN TYPE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Bulb SpecificationsINFOID:0000000003773752
Item Type Wattage (W)
Front combination lampHeadlamp (HI) H9 65
Headlamp (LO) H11 55
Parking Lamp W5W 5
Front turn signal WY21W (Amber) 21
Front fog lamp H11 55
Front side turn signal lamp (integrated into the door mirror) LED —
Rear combination lampStop/tail lamp LED —
Rear turn signal lamp S25 (Amber) 21
Back-up lamp W16W 16
License plate lamp W5W 5
High-mounted stop lamp LED —
Rear fog lamp W21W 21
