NISSAN TEANA 2008 Service Manual

EXT-22
< ON-VEHICLE REPAIR >
FENDER PROTECTOR
FENDER PROTECTOR
FENDER PROTECTOR
FENDER PROTECTOR : Exploded ViewINFOID:0000000003819537
FENDER PROTECTOR : Removal and InstallationINFOID:0000000003819538
REMOVAL
1. Remove splash guard fixing clips (A), and then remove splash
guard (1).
1. Front splash guard 2. Fender protector 3. U-nut
4. Front fender 5. Fender clip
JMKIA2530ZZ
JMKIA2531ZZ

FENDER PROTECTOR
EXT-23
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
2. Remove front fender protector fixing screws (A) and clips (B)
from underside.
3. Remove front fender rear part fixing clips (A) and screw (B).
4. Remove front fender protector upper fixing clips.
5. Remove front fender clips from fender arch, and then remove the front fender protector.
INSTALLATION
Install in the reverse order of removal.
REAR WHEEL HOUSE PROTECTOR
JMKIA2532ZZ
JMKIA2533ZZ

EXT-24
< ON-VEHICLE REPAIR >
FENDER PROTECTOR
REAR WHEEL HOUSE PROTECTOR : Exploded View
INFOID:0000000003819539
REAR WHEEL HOUSE PROTECTOR : Removal and InstallationINFOID:0000000003819540
REMOVAL
1. Remove clip (A) of rear wheel house protector front end.
2. Remove tires with power tool.
1. Rear wheel house protector
JMKIA2534ZZ
JMKIA2535ZZ

FENDER PROTECTOR
EXT-25
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
3. Remove clips (A) of rear wheel house protector rear end.
4. Remove rear wheel house protector fixing clips, and then remove rear wheel house protector.
INSTALLATION
Install in the reverse order of removal.
JMKIA2543ZZ

EXT-26
< ON-VEHICLE REPAIR >
CENTER MUD GUARD
CENTER MUD GUARD
Exploded ViewINFOID:0000000003819541
Removal and InstallationINFOID:0000000003819542
REMOVAL
1. Remove center mud guard front end fixing clip (A) and screw
(B).
1. Center mud guard
JMKIA2544ZZ
JMKIA2545ZZ

CENTER MUD GUARD
EXT-27
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
2. Remove center mud guard rear end fixing clips (A) and screw
(B).
3. Remove center mud guard underside fixing clips and screws.
4. Fully open front door and rear door.
5. Remove center mud guard fixing clips from back side using remover tool.
6. Remove center mud guard from body side.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
 When installing, visually check the center mud guard and the clips, then replace them with new parts
if they are damaged.
 When installing center mud guard, check that clips are securely fitted in panel holes on body, and
then press them in.
JMKIA2546ZZ

EXT-28
< ON-VEHICLE REPAIR >
FLOOR SIDE FAIRING
FLOOR SIDE FAIRING
Exploded ViewINFOID:0000000003819543
Removal and InstallationINFOID:0000000003819544
REMOVAL
ENGINE UNDER COVER
1. Remove engine under cover fixing clips.
2. Remove engine under cover.
INSTALLATION
Install in the reverse order of removal.
1. Engine under cover seal 2. Engine under cover
JMKIA2630ZZ

ROOF SIDE MOLDING
EXT-29
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
ROOF SIDE MOLDING
Exploded ViewINFOID:0000000003819545
Removal and InstallationINFOID:0000000003819546
REMOVAL
1. Remove front fender cover (LH/RH). Refer to DLK-199, "Removal and Installation".
2. Disengage clips while pinching molding from roof rear end to
front end.
1. Roof side molding 2. Roof side molding clip 3. Front windshield
4. Body side panel 5. Roof panel
: Clip
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2614GB
: Clip
JMKIA2615ZZ

EXT-30
< ON-VEHICLE REPAIR >
ROOF SIDE MOLDING
3. Remove roof side molding after sliding it in the backward direc-
tion of the vehicle.
CAUTION:
The position of roof side molding front end fixing clip moves when removing roof side molding.
Before removing the roof side molding, always check and mark the position of roof side molding front
end fixing clip. Put matching marks between the molding and the roof side molding and the body side
panel or the glass.
INSTALLATION
1. Reinstall roof side molding front end fixing clips that is removed from the vehicle to the matching mark
position of the molding.
2. Align the matching mark positions of the molding and vehicle, and install from the front end to rear end.
CAUTION:
When installing, visually check the roof side molding and the clips, then replace them with new parts if
they are damaged.
REMOVAL AND INSTALLATION OF ROOF SIDE MOLDING CLIP
Removal
1. Remove roof side molding. Refer to EXT-29, "Removal and Installation".
2. Heat adhesive tape interface using a dryer, and then peel roof side molding clips (body side) using long-
nose pliers.
CAUTION:
Be careful not to damage the body.
Installation
1. Clean tape removed surface with a shop cloth soaked in white gasoline or IPA.
2. Use two-part epoxy adhesive.
3. Apply adhesive evenly to clip tape surface.
4. Position applied parts to the proper location, and then sufficiently press-fit until the adhesive protrudes to
tape side.
5. Tape clips after press fit, and temporarily hold it for specified time based on the following.
6. Install from roof side molding rear end to front end in this order after temporarily holding.
CAUTION:
 Use double-faced adhesive tape after hardening for clips.
 Securely insert molding rear end cap onto roof rear end cutout (installation standard).
: Clip
JMKIA2616ZZ
Adhesive : 3M-weld DP–100 or equivalent
Thickness : Approximately 0.5 mm (0.020 in)
Press-fit limit : 19.6 N× 2 seconds
5 to 10°C (41 to 50°F) : 1 hour or more
11 t o 2 3°C (52 to 73°F) : 30 minutes or more
24°C or more (75°F or more) : 15 minutes or more

ROOF SIDE MOLDING
EXT-31
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
 When installing roof side molding of windshield portion, check that molding fastener is securely
inserted and then press in.
 Never wash the vehicle with in 24 hours so as to keep adhesive.
