NISSAN TEANA 2008 Service Manual

SRC-58
< COMPONENT DIAGNOSIS >
B1084 PRE-TEN FRONT RH
B1084 PRE-TEN FRONT RH
DescriptionINFOID:0000000003813996
For front RH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front RH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003813997
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-58, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813998
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1084 PRE-TEN FRONT RH
[SHORT]Front RH seat belt pre-tensioner circuit
are shorted to each other Disconnection of wiring harness and
short
 Malfunction in front RH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1084 PRE-TEN FRONT RH
SRC-59
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front RH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-58, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-58, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-60
< COMPONENT DIAGNOSIS >
B1086 PRE-TEN FRONT LH
B1086 PRE-TEN FRONT LH
DescriptionINFOID:0000000003813999
For front LH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front LH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003814000
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-60, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814001
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1086 PRE-TEN FRONT LH
[OPEN]Front LH seat belt pre-tensioner circuit
is open Disconnection of wiring harness and
open
 Malfunction in front LH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1086 PRE-TEN FRONT LH
SRC-61
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front LH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-60, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-60, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-62
< COMPONENT DIAGNOSIS >
B1087 PRE-TEN FRONT LH
B1087 PRE-TEN FRONT LH
DescriptionINFOID:0000000003814002
For front LH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front LH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003814003
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-62, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814004
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1087 PRE-TEN FRONT LH
[VB-SHORT]Front LH seat belt pre-tensioner circuit
is shorted to some power supply circuit Disconnection of wiring harness and
short
 Malfunction in front LH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1087 PRE-TEN FRONT LH
SRC-63
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front LH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-62, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-62, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-64
< COMPONENT DIAGNOSIS >
B1088 PRE-TEN FRONT LH
B1088 PRE-TEN FRONT LH
DescriptionINFOID:0000000003814005
For front LH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front LH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003814006
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-64, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814007
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1088 PRE-TEN FRONT LH
[GND-SHORT]Front LH seat belt pre-tensioner circuit
is shorted to ground Disconnection of wiring harness and
short
 Malfunction in front LH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1088 PRE-TEN FRONT LH
SRC-65
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front LH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-64, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-64, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-66
< COMPONENT DIAGNOSIS >
B1089 PRE-TEN FRONT LH
B1089 PRE-TEN FRONT LH
DescriptionINFOID:0000000003814008
For front LH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front LH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003814009
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-66, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814010
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1089 PRE-TEN FRONT LH
[SHORT]Front LH seat belt pre-tensioner circuit
are shorted to each other Disconnection of wiring harness and
short
 Malfunction in front LH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1089 PRE-TEN FRONT LH
SRC-67
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front LH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-66, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-66, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
