NISSAN TEANA 2008 Service Manual

SRC-48
< COMPONENT DIAGNOSIS >
B1068 ASSIST A/B MODULE
B1068 ASSIST A/B MODULE
DescriptionINFOID:0000000003813981
For front passenger air bag module, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
Front passenger air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
Front passenger air bag module is installed on the instrument panel with fixed bolts.
DTC LogicINFOID:0000000003813982
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-48, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813983
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1068 ASSIST A/B MODULE
[SHORT]Front passenger air bag module circuits
are shorted to each other Disconnection of wiring harness and
short
 Malfunction in front passenger air
bag module
 Malfunction in air bag diagnosis sen-
sor unit

B1068 ASSIST A/B MODULE
SRC-49
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE FRONT PASSENGER AIR BAG MODULE
1. Replace front passenger air bag module. Refer to SR-12, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-48, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-48, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-50
< COMPONENT DIAGNOSIS >
B1074, B1075, B1076, B1077, B1078, B1079 DIAGNOSIS SENSOR UNIT
B1074, B1075, B1076, B1077, B1078, B1079 DIAGNOSIS SENSOR UNIT
DescriptionINFOID:0000000003813984
Check the whole SRS and displays the malfunction either by illuminating or blinking the air bag warning lamp
in the combination meter. Malfunctioning part can be detected by on board self-diagnosis system and CON-
SULT-III.
OPERATION
It detects a shock that exceeds a specified level and monitors whether the driver and passenger air bags, front
side air bag, side curtain air bag and pre-tensioner seat belts operate normally.
STRUCTURE
It contains the “G” sensors for both frontal and side collisions and spare battery function in case of main bat-
tery damage in collision.
INSTALLATION
Air bag diagnosis sensor unit is installed under the center console with fixed bolts.
DTC LogicINFOID:0000000003813985
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-50, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813986
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1074
B1075
B1076
B1077
B1078
B1079CONTROL UNIT Air bag diagnosis sensor unit is mal-
functioning or out of the specification Malfunction in air bag diagnosis sen-
sor unit
 Configuration in air bag diagnosis
sensor unit dose not match to the ve-
hicles specification

B1074, B1075, B1076, B1077, B1078, B1079 DIAGNOSIS SENSOR UNIT
SRC-51
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-50, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-52
< COMPONENT DIAGNOSIS >
B1081 PRE-TEN FRONT RH
B1081 PRE-TEN FRONT RH
DescriptionINFOID:0000000003813987
For front RH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front RH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003813988
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-52, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813989
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1081 PRE-TEN FRONT RH
[OPEN]Front RH seat belt pre-tensioner circuit
is open Disconnection of wiring harness and
open
 Malfunction in front RH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1081 PRE-TEN FRONT RH
SRC-53
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front RH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-52, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-52, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-54
< COMPONENT DIAGNOSIS >
B1082 PRE-TEN FRONT RH
B1082 PRE-TEN FRONT RH
DescriptionINFOID:0000000003813990
For front RH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front RH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003813991
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-54, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813992
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1082 PRE-TEN FRONT RH
[VB-SHORT]Front RH seat belt pre-tensioner circuit
is shorted to some power supply circuit Disconnection of wiring harness and
short
 Malfunction in front RH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1082 PRE-TEN FRONT RH
SRC-55
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front RH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-54, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-54, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-56
< COMPONENT DIAGNOSIS >
B1083 PRE-TEN FRONT RH
B1083 PRE-TEN FRONT RH
DescriptionINFOID:0000000003813993
For front RH seat belt pre-tensioner, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In the case of a frontal collision that exceeds specified impact level, the air bag diagnosis sensor unit detects
the deceleration caused by collision. It restrains the passenger with seat belt easing the stress on passengers
chest with load limiter.
STRUCTURE
The restraint system for front seat occupant consists of the pre-tensioner mechanism and load limiter mecha-
nism.
INSTALLATION
Front RH seat belt pre-tensioner is installed on the underside of center pillar with fixed nuts.
DTC LogicINFOID:0000000003813994
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-56, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813995
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1083 PRE-TEN FRONT RH
[GND-SHORT]Front RH seat belt pre-tensioner circuit
is shorted to ground Disconnection of wiring harness and
short
 Malfunction in front RH seat belt pre-
tensioner
 Malfunction in air bag diagnosis sen-
sor unit

B1083 PRE-TEN FRONT RH
SRC-57
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SEAT BELT PRE-TENSIONER
1. Replace front RH seat belt pre-tensioner. Refer to SB-5, "
SEAT BELT RETRACTOR : Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-56, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-56, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
