NISSAN TEANA 2008 Service Manual

SRC-38
< COMPONENT DIAGNOSIS >
B1052 DRIVER AIRBAG MODULE
B1052 DRIVER AIRBAG MODULE
DescriptionINFOID:0000000003813966
For driver air bag module, crash is judged by main “G” sensor output signal and safing algorithm in front direc-
tion.
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
Driver air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
Driver air bag module is installed on the center of steering wheel with fixed bolts.
DTC LogicINFOID:0000000003813967
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-38, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813968
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1052 DRIVER AIRBAG MOD-
ULE
[SHORT]Driver air bag module circuit are shorted
to each other
(including the spiral cable) Disconnection of wiring harness
and short
 Malfunction in driver air bag module
 Malfunction in spiral cable
 Malfunction in air bag diagnosis sen-
sor unit

B1052 DRIVER AIRBAG MODULE
SRC-39
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.CHECK SPIRAL CABLE CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver air bag module harness connector and Combination switch (Spiral cable) harness con-
nector.
3. Check continuity between driver side air bag module harness connector and body side harness connec-
tor.
4. Check continuity between driver air bag module harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace spiral cable. Refer to SR-9, "
Exploded View".
4.REPLACE DRIVER AIR BAG MODULE
1. Replace driver air bag module. Refer to SR-6, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-38, "
DTC Logic".
Is DTC detected?
YES >> GO TO 5.
NO >> INSPECTION END
5.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-38, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Driver air bag module Combination switch (Spiral cable)
Continuity
Connector Terminal Connector Terminal
M35010
M3228
Existed
11 3 0
Driver air bag module
GroundContinuity
Connector Terminal
M35010
Not existed
11

SRC-40
< COMPONENT DIAGNOSIS >
B1058, B1059, B1060, B1061, B1062, B1063 DIAGNOSIS SENSOR UNIT
B1058, B1059, B1060, B1061, B1062, B1063 DIAGNOSIS SENSOR UNIT
DescriptionINFOID:0000000003813969
Check the whole SRS and displays the malfunction either by illuminating or blinking the air bag warning lamp
in the combination meter. Malfunctioning part can be detected by on board self-diagnosis system and CON-
SULT-III.
OPERATION
It detects a shock that exceeds a specified level and monitors whether the driver and passenger air bags, front
side air bag, side curtain air bag and pre-tensioner seat belts operate normally.
STRUCTURE
It contains the “G” sensors for both frontal and side collisions and spare battery function in case of main bat-
tery damage in collision.
INSTALLATION
Air bag diagnosis sensor unit is installed under the center console with fixed bolts.
DTC LogicINFOID:0000000003813970
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-40, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813971
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1058
B1059
B1060
B1061
B1062
B1063CONTROL UNIT Air bag diagnosis sensor unit is mal-
functioning or out of the specification Malfunction in air bag diagnosis sen-
sor unit
 Configuration in air bag diagnosis
sensor unit dose not match to the ve-
hicles specification

B1058, B1059, B1060, B1061, B1062, B1063 DIAGNOSIS SENSOR UNIT
SRC-41
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-40, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-42
< COMPONENT DIAGNOSIS >
B1065 ASSIST A/B MODULE
B1065 ASSIST A/B MODULE
DescriptionINFOID:0000000003813972
For front passenger air bag module, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
Front passenger air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
Front passenger air bag module is installed on the instrument panel with fixed bolts.
DTC LogicINFOID:0000000003813973
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-42, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813974
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1065 ASSIST A/B MODULE
[OPEN]Front passenger air bag module circuit
is open Disconnection of wiring harness and
open
 Malfunction in front passenger air
bag module
 Malfunction in air bag diagnosis sen-
sor unit

B1065 ASSIST A/B MODULE
SRC-43
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE FRONT PASSENGER AIR BAG MODULE
1. Replace front passenger air bag module. Refer to SR-12, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-42, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-42, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-44
< COMPONENT DIAGNOSIS >
B1066 ASSIST A/B MODULE
B1066 ASSIST A/B MODULE
DescriptionINFOID:0000000003813975
For front passenger air bag module, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
Front passenger air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
Front passenger air bag module is installed on the instrument panel with fixed bolts.
DTC LogicINFOID:0000000003813976
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-44, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813977
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1066 ASSIST A/B MODULE
[VB-SHORT]Front passenger air bag module circuit
is shorted to some power supply circuit Disconnection of wiring harness and
short
 Malfunction in front passenger air
bag module
 Malfunction in air bag diagnosis sen-
sor unit

B1066 ASSIST A/B MODULE
SRC-45
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE FRONT PASSENGER AIR BAG MODULE
1. Replace front passenger air bag module. Refer to SR-12, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END

SRC-46
< COMPONENT DIAGNOSIS >
B1067 ASSIST A/B MODULE
B1067 ASSIST A/B MODULE
DescriptionINFOID:0000000003813978
For front passenger air bag module, crash is judged by main “G” sensor output signal and safing algorithm in
front direction.
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
Front passenger air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
Front passenger air bag module is installed on the instrument panel with fixed bolts.
DTC LogicINFOID:0000000003813979
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-46, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003813980
WARNING:
 Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1067 ASSIST A/B MODULE
[GND-SHORT]Front passenger air bag module circuit
is shorted to ground Disconnection of wiring harness and
short
 Malfunction in front passenger air
bag module
 Malfunction in air bag diagnosis sen-
sor unit

B1067 ASSIST A/B MODULE
SRC-47
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE FRONT PASSENGER AIR BAG MODULE
1. Replace front passenger air bag module. Refer to SR-12, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-46, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-46, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
