DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-35
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable N POSI SIG
(On/Off) ––
×Neutral position (On/Off) judged by transmission
range switch signal.
P POSI SIG
(On/Off) ––
×Park position (On/Off) judged by transmission range
switch signal.
ACCEL POS SIG
(%) ×
– ×Throttle valve open/close status judged by CAN com-
munication signal is displayed.
SIDE G-SENSOR
(m/s
2) ×
– ×Transverse acceleration detected by side G-sensor is
displayed.
STR ANGLE SIG
(deg) ×
– ×Steering angle detected by steering angle sensor is
displayed.
PRESS SENSOR
(bar) ×
– ×Brake pressure detected by pressure sensor is dis-
played.
EBD SIGNAL
(On/Off) ––
×EBD operation (On/Off) status is displayed.
ABS SIGNAL
(On/Off) ––
×ABS operation (On/Off) status is displayed.
TCS SIGNAL
(On/Off) ––
×TCS operation (On/Off) status is displayed.
VDC SIGNAL
(On/Off) ––
×VDC operation (On/Off) status is displayed.
EBD FAIL SIG
(On/Off) ––
×EBD fail signal (On/Off) status is displayed.
ABS FAIL SIG
(On/Off) ––
×ABS fail signal (On/Off) status is displayed.
TCS FAIL SIG
(On/Off) ––
×TCS fail signal (On/Off) status is displayed.
VDC FAIL SIG
(On/Off) ––
×VDC fail signal (On/Off) status is displayed.
CRANKING SIG
(On/Off) ––
×The input state of the key SW START position signal
is displayed.
FLUID LEV SW
(On/Off) ×
– ×Brake fluid level switch (On/Off) status is displayed.
PARK BRAKE SW
(On/Off) ×
– ×Park brake switch (On/Off) status is displayed.
USV[FL-RR]
(On/Off) ——
×Primary side USV solenoid valve (On/Off) status is
displayed.
USV[FR-RL]
(On/Off) ——
×Secondary side USV solenoid valve (On/Off) status is
displayed.
HSV[FL-RR]
(On/Off) ——
×Primary side HSV solenoid valve (On/Off) status is
displayed.
HSV[FR-RL]
(On/Off) ——
×Secondary side HSV solenoid valve (On/Off) status is
displayed.
V/R OUTPUT
(On/Off) ——
×Valve relay operation signal (On/Off) status is dis-
played.
M/R OUTPUT
(On/Off) ——
×Motor relay operation signal (On/Off) status is dis-
played.
ENGINE RPM
(tr/min) ×
– ×Engine speed judged by CAN communication signal
is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-36
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
ACTIVE TEST
The active test is used to determine and identify details of a malfunction, based on self-diagnosis test results
and data obtained in the DATA MONITOR. In response to instructions from CONSULT, instead of those from
ABS actuator and electric unit (control unit) on the vehicle, a drive signal is sent to the actuator to check its
operation.
CAUTION:
• Never perform ACTIVE TEST while driving the vehicle.
• Always bleed air from brake system before active test.
• Never perform active test when system is malfunctioning.
NOTE:
• When active test is performed while depressing the pedal, the pedal depressing stroke may change. This is not a malfunction.
• “TEST IS STOPPED” is displayed approx. 10 seconds after operation start.
• When performing active test again after “TEST IS STOPPED” is displayed, select “BACK”.
• ABS warning lamp, brake warning lamp and VDC warning lamp may turn ON during active test. This is not a malfunction.
ABS IN Valve and ABS OUT Valve
When “Up”, “Keep” or “Down” is selected on display sc reen, the following items are displayed when system is
normal.
*: Immediately after being selected, status is “O n”. Status changes to “Off” after approx. 2 seconds.
ABS IN Valve (ACT) and ABS OUT Valve (ACT)
When “Up”, “ACT UP” or “ACT KEEP” is selected on di splay screen, the following items are displayed when
system is normal.
Test item Display Item Display
Up Keep Down
FR RH SOL FR RH IN SOL Off On* On*
FR RH OUT SOL Off Off On*
FR LH SOL FR LH IN SOL Off On* On*
FR LH OUT SOL Off Off On*
RR RH SOL RR RH IN SOL Off On* On*
RR RH OUT SOL Off Off On*
RR LH SOL RR LH IN SOL Off On* On*
RR LH OUT SOL Off Off On*
Test item Display Item Display
Up ACT UP ACT KEEP
FR RH SOLENOID
(ACT) FR RH IN SOL Off Off Off
FR RH OUT SOL Off Off Off
CV1 Off Off Off
CV2 Off On* On*
FR LH SOLENOID
(ACT) FR LH IN SOL Off Off Off
FR LH OUT SOL Off Off Off
CV1 Off On* On*
CV2 Off Off Off
RR RH SOLENOID
(ACT) RR RH IN SOL Off Off Off
RR RH OUT SOL Off Off Off
CV1 Off On* On*
CV2 Off Off Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-37
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
*: Immediately after being selected, status is “O n”. Status changes to “Off” after approx. 10 seconds.
ABS MOTOR
When “On” or “Off” is selected on display screen, the following items are displayed when system is normal.
NOTE:
Display occasionally changes On/Off for a moment after i gnition switch is turned ON. This is an operation for
checking purposes and is not a malfunction.
WORK SUPPORT
CONFIGURATION
Configuration includes the following functions.
CAUTION:
Use ‘‘Manual Configuration’’ only when ‘‘TYPE ID’’ of ABS actuator and electric unit (control unit) can-
not be read.
RR LH SOLENOID
(ACT) RR LH IN SOL Off On* Off
RR LH OUT SOL Off Off Off
CV1 Off Off Off
CV2 Off On* On*
Test item Display Item
Display
Up ACT UP ACT KEEP
Test item Display Item Display
On Off
ABS MOTOR MOTOR RELAY On Off
ACTUATOR RLY
(Note)On On
Conditions Description
ST ANGLE SENSOR ADJUSTMENT Steering angle sensor neutral position adjustment can be per-
formed. Refer to BRC-58, "Work Procedure"
.
DECEL G SEN CALIBRATION Perform decel G sensor calibration.
Function Description
Read/Write Configuration Before replacing ECU
Allows the reading of vehicle spec
ification (Type ID) written in ABS
actuator and electric unit (control unit) to store the specification in
CONSULT.
After replacing ECU Allows the writing of vehicle information (Type ID) stored in CON-
SULT into the ABS actuator and electric unit (control unit).
Manual Configuration Allows the writing of vehicle specification (Type ID) into the ABS
actuator and electric unit (control unit) by hand.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-38
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS INFORMATION
ABS ACTUATOR AND ELECTRIC
UNIT (CONTROL UNIT)
Reference ValueINFOID:0000000009463759
VALUES ON THE DIAGNOSIS TOOL
CAUTION:
The display shows the control unit calculation data, so a normal value might be displayed even in the
event the output circuit (harness) is open or short-circuited.
Monitor item Display content Data monitor
Condition Reference value in
normal operation
FR LH SENSOR Wheel speed 0 [km/h, mph] Vehicle stopped
Nearly matches the speed meter display
( ± 10% or less) Vehicle running
(Note 1)
FR RH SENSOR Wheel speed 0 [km/h, mph] Vehicle stopped
Nearly matches the speed meter display
( ± 10% or less) Vehicle running
(Note 1)
RR LH SENSOR Wheel speed 0 [km/h, mph] Vehicle stopped
Nearly matches the speed meter display
( ± 10% or less) Vehicle running
(Note 1)
RR RH SENSOR Wheel speed 0 [km/h, mph] Vehicle stopped
Nearly matches the speed meter display
( ± 10% or less) Vehicle running
(Note 1)
DECEL G-SEN Longitudinal acceleration detected by decel
G sensor Vehicle stopped Approx. 0 G
Vehicle running -1.7 to 1.7 G
FR RH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
FR RH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
FR LH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
FR LH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-39
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
RR RH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
RR RH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
RR LH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
RR LH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode) On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
EBD WARN LAMP EBD warning lamp
(Note 2) When EBD warning lamp is ON On
When EBD warning lamp is OFF Off
STOP LAMP SW Brake pedal operation When brake pedal is depressed On
When brake pedal is not depressed Off
MOTOR RELAY Motor and motor relay operation When the motor relay and motor are op-
erating On
When the motor relay and motor are not
operating Off
ACTUATOR RLY Actuator relay operation When the actuator relay is operating On
When the actuator relay is not operating Off
ABS WARN LAMP ABS warning lamp
(Note 2) When ABS warning lamp is ON On
When ABS warning lamp is OFF Off
OFF LAMP VDC OFF indicator lamp
(Note 2) When VDC OFF indicator lamp is ON On
When VDC OFF indicator lamp is OFF Off
SLIP/VDC LAMP SLIP indicator lamp
(Note 2) When SLIP indicator lamp is ON On
When SLIP indicator lamp is OFF Off
BATTERY VOLT Battery voltage supplied
to the ABS actuator
and electric unit (control unit) Ignition switch ON 10 – 16 V
GEAR Manual mode gear position determined by
TCM 1st gear
2nd gear
3rd gear
4th gear
5th gear 1
2
3
4
5
SLCT LVR POSI Selector lever position. Vehicle stopped N/P
YAW RATE SEN Yaw rate detected by yaw rate/side G sensor Vehicle stopped Approx. 0 d/s
Vehicle turning -75 to 75 d/s
Monitor item Display content
Data monitor
Condition Reference value in
normal operation
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-40
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
R POSI SIGTransmission range switch signal ON/OFF
condition CVT shift position = R position On
CVT shift position = other than R position Off
N POSI SIG Transmission range switch signal ON/OFF
condition CVT shift position = N position On
CVT shift position = other than N position Off
P POSI SIG Transmission range switch signal ON/OFF
condition CVT shift position = P position On
CVT shift position = other than P position Off
ACCEL POS SIG Throttle actuator opening/closing is dis-
played (linked with accelerator pedal) Accelerator pedal not depressed (ignition
switch is ON) 0 %
Depress accelerator pedal (ignition
switch is ON) 0 - 100 %
SIDE G-SENSOR Transverse G detected by side G sensor Vehicle stopped
Approx. 0 m/s
2
Vehicle turning rightNegative value
(m/s2)
Vehicle turning left Positive value
(m/s
2)
STR ANGLE SIG Steering angle detected by steering angle
sensor Straight-ahead Approx. 0
°
Steering wheel turned –720 to 720 °
PRESS SENSOR Brake fluid pressure detected by pressure
sensor With ignition switch turned ON and brake
pedal released Approx. 0 bar
With ignition switch turned ON and brake
pedal depressed –40 to 300 bar
EBD SIGNAL EBD operation EBD is active On
EBD is inactive Off
ABS SIGNAL ABS operation ABS is active On
ABS is inactive Off
TCS SIGNAL TCS operation TCS is active On
TCS is inactive Off
VDC SIGNAL VDC operation VDC is active On
VDC is inactive Off
EBD FAIL SIG EBD fail-safe signal In EBD fail-safe On
EBD is normal Off
ABS FAIL SIG ABS fail-safe signal In ABS fail-safe On
ABS is normal Off
TCS FAIL SIG TCS fail-safe signal In TCS fail-safe On
TCS is normal Off
VDC FAIL SIG VDC fail-safe signal In VDC fail-safe On
VDC is normal Off
CRANKING SIG Crank operation Crank is active On
Crank is inactive Off
FLUID LEV SW Brake fluid level switch When brake fluid level switch ON On
When brake fluid level switch OFF Off
PARK BRAKE SW Parking brake switch Parking brake switch is active On
Parking brake switch is inactive Off
Monitor item Display content
Data monitor
Condition Reference value in
normal operation
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-41
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Note 1: Confirm tire pressure is normal.
Note 2: On and off timing for warning lamps and indicator lamps.
•Refer to BRC-23, "VDC/TCS/ABS : VDC Function"
.
•Refer to BRC-25, "VDC/TCS/ABS : TCS Function"
.
•Refer to BRC-27, "VDC/TCS/ABS : ABS Function"
.
•Refer to BRC-28, "VDC/TCS/ABS : EBD Function"
.
Fail-safeINFOID:0000000009463760
VDC AND TCS FUNCTIONS
VDC warning lamp in combination meter turns ON when a malfunction occurs in system [ABS actuator and
electric unit (control unit)]. The control is su spended for VDC and TCS functions. However, ABS and EBD
functions operate normally.
USV[FL-RR] VDC switch-over valve When actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT) or
actuator relay is inactive (when in fail-
safe mode) On
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
USV[FR-RL] VDC switch-over valve When actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT) or
actuator relay is inactive (when in fail-
safe mode) On
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
HSV[FL-RR] VDC switch-over valve When actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT) or
actuator relay is inactive (when in fail-
safe mode) On
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
HSV[FR-RL] VDC switch-over valve When actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT) or
actuator relay is inactive (when in fail-
safe mode) On
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
V/R OUTPUT Solenoid valve relay activated When the solenoid valve relay is active
(when ignition switch OFF) On
When the solenoid valve relay is not ac-
tive (in the fail-safe mode) Off
M/R OUTPUT Actuator motor and motor relay activated When the actuator motor and motor relay
are active ( ″ACTIVE TEST” with CON-
SULT) On
When the actuator motor and motor relay
are inactive Off
ENGINE RPM With engine running With engine stopped 0 rpm
Engine running Almost in accor-
dance with tachome- ter display
Monitor item Display content
Data monitor
Condition Reference value in
normal operation
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-42
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ABS FUNCTION
ABS warning lamp and SLIP indicator lamp in combi
nation meter turn ON when a malfunction occurs in sys-
tem [ABS actuator and electric unit (control unit)]. The control is suspended for VDC, TCS and ABS functions.
However, EBD functions operate normally.
EBD FUNCTION
ABS warning lamp, brake warning lamp and SLIP indicator lamp in combination meter turn ON when a mal-
function occurs in system [ABS ac tuator and electric unit (control unit) ]. The control is suspended for VDC,
TCS, ABS and EBD functions.
DTC Malfunction detected condition Fail-safe condition
C1101 When an open circuit is detected in rear RH wheel sensor circuit.
The following functions are sus-
pended:
•VDC
•ABS
• EBD (only when both rear wheels are malfunctioning)
C1102 When an open circuit is detected in rear LH wheel sensor circuit.
C1103 When an open circuit is detected in front RH wheel sensor circuit.
C1104 When an open circuit is detected in front LH wheel sensor circuit.
C1105 • When a short circuit is detected in rear RH wheel sensor circuit.
• When power supply voltage of rear RH wheel sensor is in following state.
- Rear RH wheel sensor power supply voltage: 7.2 V ≥ Rear RH wheel sensor pow-
er supply voltage
• When distance between rear RH wheel sensor and rear RH wheel sensor rotor is
large.
• When installation of rear RH wheel sensor or rear RH wheel sensor rotor is not normal.
C1106 • When a short circuit is detected in rear LH wheel sensor circuit.
• When power supply voltage of rear LH wheel sensor is in following state.
- Rear LH wheel sensor power supply voltage: 7.2 V ≥ Rear LH wheel sensor power
supply voltage
• When distance between rear LH wheel sensor and rear LH wheel sensor rotor is large.
• When installation of rear LH wheel sensor or rear LH wheel sensor rotor is not nor-
mal.
C1107 • When a short circuit is detected in front RH wheel sensor circuit.
• When power supply voltage of front RH wheel sensor is in following state.
- Front RH wheel sensor power supply voltage: 7.2 V ≥ Front RH wheel sensor
power supply voltage
• When distance between front RH wheel sensor and front RH wheel sensor rotor is large.
• When installation of front RH wheel sensor or front RH wheel sensor rotor is not normal.
C1108 • When a short circuit is detected in front LH wheel sensor circuit.
• When power supply voltage of front LH wheel sensor is in following state.
- Front LH wheel sensor power supply voltage: 7.2 V ≥ Front LH wheel sensor pow-
er supply voltage
• When distance between front LH wheel sensor and front LH wheel sensor rotor is large.
• When installation of front LH wheel sensor or front LH wheel sensor rotor is not normal.
C1109 • When ignition power supply voltage is in following state.
- Ignition power supply voltage: 10 V ≥ Ignition power supply voltage.
- Ignition power supply voltage: 16 V ≤ Ignition power supply voltage. The following functions are sus-
pended:
•VDC
•TCS
•ABS
•EBD
C 111 0
When there is an internal malfunction in the ABS actuator and electric unit (control
unit).
C 1111 W h e n a m a l f u n c t i o n i s d e t e c t e d i n m o t o r o r m o t o r r e l a y. The following functions are sus-
pended:
•VDC
•TCS
•ABS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-43
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1113 When a malfunction is detected in longitudinal G signal. The following functions are sus-
pended:
•VDC
•TCS
C 111 5 When difference in wheel speed between any wheel and others is detected when
the vehicle is driven, because of installation of tires other than specified. The following functions are sus-
pended:
•VDC
•TCS
• ABS
• EBD
C1116 When stop lamp switch signal is not input when brake pedal operates. The following functions are sus-
pended:
•VDC
•TCS
C1120 When a malfunction is detec ted in front LH ABS IN valve.
The following functions are sus-
pended:
•VDC
•TCS
• ABS
• EBD
C1121 When a malfunction is detected in front LH ABS OUT valve.
C1122 When a malfunction is detected in front RH ABS IN valve.
C1123 When a malfunction is det ected in front RH ABS OUT valve.
C1124 When a malfunction is detected in rear LH ABS IN valve.
C1125 When a malfunction is detected in rear LH ABS OUT valve.
C1126 When a malfunction is det ected in rear RH ABS IN valve.
C1127 When a malfunction is detected in rear RH ABS OUT valve.
C1130 When a malfunction is detected in ECM system. The following functions are sus-
pended:
•VDC
•TCS
C1140 When a malfunction is detected in actuator relay. The following functions are sus-
pended:
•VDC
•TCS
• ABS
• EBD
C1142 When a malfunction is detected in VDC pressure sensor.
The following functions are sus-
pended:
•VDC
•TCS
C1143 When a malfunction is detected in steering angle sensor.
C1144 When neutral position adjustment of steering angle sensor is not complete.
C1145 When a malfunction is detected in yaw rate signal, or signal line of yaw rate/side/
decel G sensor is open or shorted.
C1146 When a malfunction is detected in side G signal, or signal line of yaw rate/side/decel
G sensor is open or shorted.
C1153 When ABS actuator and electric
unit (control unit) is malfunctioning. (Pressure in-
crease is too much or too little.) The following functions are sus-
pended:
•VDC
•TCS
• ABS
C1155 When brake fluid level low signal is detected. The following functions are sus-
pended:
•VDC
•TCS
C1160 When calibration of yaw rate/side/decel G sensor is not complete. The following functions are sus-
pended:
• VDC function
• TCS function
• Brake force distribution function
DTC Malfunction detected condition Fail-safe condition
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-44
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC Inspection Priority Chart
INFOID:0000000009463761
When multiple DTCs are displayed simultaneously, check each one using the following priority list.
C1164 When a malfunction is detected in cut valve 1. The following functions are sus- pended:
•VDC
•TCS
•ABS
•EBD
C1165 When a malfunction is detected in cut valve 2.
C1166 When a malfunction is detected in suction valve 1.
C1167 When a malfunction is detected in suction valve 2.
C1170 When the information in ABS actuator and electric unit (control unit) is not the same. The following functions are sus-
pended:
•VDC
•TCS
•ABS
C1197 When a malfunction is detected in vacuum sensor. Electrical vacuum assistance of
brake booster is suspended.
C1198 • When an open circuit is detected in vacuum sensor circuit.
• When a short circuit is detected in vacuum sensor circuit.
• When a malfunction is detected in vacuum sensor noise.
C1199 When brake booster vacuum is approx. 0 kPa (0 mmHg) during engine running. —
C119A When a malfunction is detected in supply power voltage of vacuum sensor. Electrical vacuum assistance of
brake booster is suspended.
U1000 When CAN communication signal is not continuously transmitted or received for 2
seconds or more. The following functions are sus-
pended:
•VDC
•TCS
U1002 When ABS actuator and electric unit (control unit) is not transmitting or receiving
CAN communication signal for 2 seconds or less.
DTC Malfunction detected condition Fail-safe condition
Priority Detected item (DTC)
1 • U1000 CAN COMM CIRCUIT
• U1002 SYSTEM COMM(CAN)
2 • C1110 CONTROLLER FAILURE
• C1153 EMERGENCY BRAKE
• C1170 VARIANT CORDING
3 • C1130 ENGINE SIGNAL 1
• C1144 ST ANG SEN SIGNAL
4 • C1109 BATTERY VOLTAGE [ABNORMAL]
• C 1111 P U M P M O T O R
•C1140 ACTUATOR RLY
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
