REAR DISC BRAKE
BRAKE CALIPER ASSEMBLY
BRAKE CALIPER ASSEMBLY : Exploded ViewINFOID:0000000009463724
BRAKE CALIPER ASSEMBLY : DisassemblyINFOID:0000000009463725
1. Remove the retaining ring from brake caliper using a suitable tool as shown. Discard the retaining ring.
CAUTION:
Do not reuse retaining ring.
1. Union bolt 2. Brake hose 3. Copper sealing washers
4. Cap 5. Bleeder valve 6. Lower sliding pin bolt
7. Upper sliding pin bolt 8. Upper sliding pin bushing 9. Brake caliper
10. Piston seal 11. Piston 12. Piston boot
13. Retaining ring 14. Sliding pin boot 15. Torque member bolt
16. Washers 17 Torque member A. Molykote AS-880N grease
B. Rubber grease
NOTE:
RH side caliper shown, LH side caliper similar.
AWFIA0937ZZ
SBR028A
Revision: November 20132014 Altima NAM

BR-46
< UNIT DISASSEMBLY AND ASSEMBLY >
REAR DISC BRAKE
2. Place a wooden block in the brake caliper as shown, and blowair into the union bolt hole to the remove piston and piston boot.
WARNING:
Do not get fingers caught be tween the piston and wooden
block.
3. Remove the piston seal from the brake caliper using a suitable tool. Discard the piston seal.
CAUTION:
• Be careful not to damage the cylinder inner wall.
• Do not reuse the piston seal.
BRAKE CALIPER ASSEMBLY : In spection After DisassemblyINFOID:0000000009463726
BRAKE CALIPER
Check the inner wall of the cylinder for corrosion, wear, and damage. Replace as necessary.
CAUTION:
Clean the brake caliper using new br ake fluid. Do not use mineral oils such as gasoline or kerosene.
TORQUE MEMBER
Check the torque member for wear, cr acks, and damage. Replace as necessary.
PISTON
Check the piston surface for corrosion, wear, and damage. Replace as necessary.
CAUTION:
The piston sliding surface is plated . Do not polish with sandpaper.
SLIDING PIN BOLT, SLIDING PIN BOOT
Check the sliding pin bolt and sliding pin boot fo r wear, damage, and cracks. Replace as necessary.
BRAKE CALIPER ASSEMBLY : AssemblyINFOID:0000000009463727
CAUTION:
Use NISSAN Rubber Grease during assembly.
1. Apply rubber grease to new piston seal (1), and install on brake caliper.
CAUTION:
Do not reuse piston seal.
BRD0041D
JPFIA0038ZZ
JPFIA0039ZZ
Revision: November 20132014 Altima NAM

REAR DISC BRAKEBR-47
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
G H
I
J
K L
M A
B
BR
N
O P
2. Apply rubber grease to new piston boot (1). Cover the piston (2) end with the new piston boot, and then install cylinder side lip on
new piston boot securely into a groove on brake caliper.
CAUTION:
Do not reuse piston boot.
3. Push piston (1) into caliper by hand and push piston boot (2) pis- ton side lip into the piston groove.
CAUTION:
Press the piston evenly and var y the pressing point to pre-
vent cylinder inner wall from being rubbed.
4. Using a suitable tool, secure piston boot with new retaining ring (1).
CAUTION:
• Make sure that boot is securely engaged in the groove on
brake caliper.
• Do not reuse retaining ring.
JPFIA0040ZZ
JPFIA0041ZZ
AWFIA0938ZZ
Revision: November 20132014 Altima NAM

BR-48
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationsINFOID:0000000009463728
Unit: mm (in)
Brake PedalINFOID:0000000009463729
Unit: mm (in)
Front brakeCylinder bore diameter 57.2 (2.252)
Pad length × width × thickness 114 × 47 × 10 (4.488 × 1.850 × 0.394)
Rotor outer diameter × thickness 296 × 26 (11.654 × 1.024)
Rear brake Cylinder bore diameter 34.93 (1.375)
Pad length × width × thickness 83 × 33 × 8.5 (3.268 × 1.299 × 0.335)
Rotor outer diameter × thickness 292 × 9 (11.496 × 0.354)
Master cylinder Cylinder bore diameter 25 (0.984)
Control valve Valve model Electric brake force distribution
Brake booster Diaphragm diameter 280 (11)
Recommended brake fluid DOT 3
Item Standard
Brake pedal height (H) (from dash lower panel top surface) 181.4 - 191.4 (7.1 - 7.5)
Brake pedal full stroke (S) 135.3 (5.3)
Clearance between stopper bracket (C
1) and threaded end of the stop lamp
switch and ASCD cancel switch (C
2) 0.74 - 1.96 (0.0291 - 0.0772)
AWFIA0913ZZ
Revision: November 20132014 Altima NAM

SERVICE DATA AND SPECIFICATIONS (SDS)BR-49
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D E
G H
I
J
K L
M A
B
BR
N
O P
Check ValveINFOID:0000000009463730
Brake BoosterINFOID:0000000009463731
Unit: mm (in)
Front Disc BrakeINFOID:0000000009463732
Unit: mm (in)
Rear Disc BrakeINFOID:0000000009463733
Unit: mm (in)
When suitable tool (A) is connected to the booster side (B) Vacuum should not decrease more than
3.3 kPa (25 mmHg, 0.98 inHg) for 15 sec-
onds under a vacuum of −26.6 ± 1.3 kPa ( −
500 ± 1.3 mmHg, −19.69 ± 0.04 inHg) at
room tempurature.
When suitable tool (A) is connected to the engine side (C) Vacuum should not exist.
JPFIA0024ZZ
Input rod installation standard dimension (B)
(1): Lock nut
(2): Input rod 125
± 0.5 (4.92 ± 0.02)
ALFIA0299ZZ
Brake pad Standard thickness (new) 11.0 (0.433)
Wear limit thickness 2.0 (0.079)
Disc rotor Standard thickness (new) 26.0 (1.024)
Wear limit thickness 24.0 (0.945)
Thickness variation (measured at 8 positions) 0.015 (0.0006)
Maximum runout (with it attached to the vehicle) 0.040 (0.0016)
Brake pad Standard thickness (new) 8.5 (0.335)
Wear limit thickness 1.0 (0.039)
Revision: November 20132014 Altima NAM

BR-50
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Disc rotorStandard thickness
(new) 9.0 (0.354)
Wear limit thickness 8.0 (0.315)
Thickness variation (measured at 8 positions) 0.015 (0.0006)
Maximum runout (with it attached to the vehicle) 0.05 (0.0020)
Revision: November 20132014 Altima NAM
