NISSAN TEANA 2014 Service Manual

C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-65
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
3.HARNESS AND CONNECTOR INSPECTION
1. Disconnect ABS actuator and electr ic unit (control unit) connector E54 and wheel sensor connector of
suspect wheel.
2. Check harness, connectors and terminals for corrosi on, deformation, disconnection, looseness or dam-
age.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace as necessary.
4.CHECK WHEEL SENSOR OUTPUT SIGNAL
1. Connect ABS active wheel sensor tester (J- 45741) to wheel sensor using appropriate adapter.
2. Turn on the ABS active wheel sensor tester power switch. NOTE:
The green POWER indicator should illuminate. If the POWER indicator does not illuminate, replace the
battery in the ABS active wheel sensor tester before proceeding.
3. Spin the wheel of the vehicle by hand and observe the red SENSOR indicator on the ABS active wheel
sensor tester. The red SENSOR indicator should flash on and off to indicate an output signal.
NOTE:
If the red SENSOR indicator illuminates but does not flash, reverse the polarity of the tester leads and
retest.
Does the ABS active wheel s ensor tester detect a signal?
YES >> GO TO 5.
NO >> Replace the wheel sensor. Refer to BRC-124, "Removal and Installation - Front Wheel Sensor"
or
BRC-125, "Removal and Installation - Rear Wheel Sensor"
.
5.CHECK WIRING HARNESS FOR SHORT TO VOLTAGE
1. Turn ignition switch ON.
2. Check voltage between wheel sensor harness c onnector terminals of suspect wheel and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair the circuit.
6.CHECK WIRING HARNESS FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Check continuity between wheel sensor harne ss connector terminals of suspect wheel and ground.
Wheel Sensor
Ground Voltage
Wheel Connector Terminal
Front LH E19 1
—0V
2
Front RH E41 1
2
Rear LH C2 1
2
Rear RH C3 1
2
Wheel Sensor Ground Continuity
Wheel Connector Terminal
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-66
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1101, C1102, C1103,
C1104 WHEEL SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair the circuit.
7.CHECK WIRING HARNESS FO R SHORT BETWEEN CIRCUITS
Check continuity between wheel sensor harness connector terminals of suspect wheel.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair the circuit.
8.CHECK WIRING HARNESS FOR OPEN CIRCUIT
Check continuity between ABS actuator and electric unit (control unit) connector E54 and wheel sensor con-
nector of wheel with DTC.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair the circuit.
9.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between ABS actuator and electric uni t (control unit) harness connector E54 terminal and
ground.
Front LH E19 1
—No
2
Front RH E11 1
2
Rear LH C2 1
2
Rear RH C3 1
2
Wheel Sensor (+) (-) Continuity
Wheel Connector Terminal Terminal
Front LH E19
12No
Front RH E41
Rear LH C2
Rear RH C3
Wheel sensor ABS actuator and electric unit (c
ontrol unit) Wheel sensor Continuity
Connector Terminal Connector Terminal
Ye s
Front LH
E548
E19 2
19 1
Front RH 4
E41 2
16 1
Rear LH 18
C2 2
31 1
Rear RH 29
C3 2
17 1
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-67
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 10.
NO >> Check the following:
• 10A fuse No. 49 located in the IPDM E/R
• Harness between ABS actuator and electr ic unit (control unit) and IPDM E/R
10.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between ABS actuator and elec tric unit (control unit) connector E54 terminals and
ground.
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace malfunctioning components.
11 .CHECK WHEEL SENSOR INPUT VOLTAGE
1. Connect ABS actuator and electric unit (control unit) connector E54.
2. Turn ignition switch ON.
3. Check voltage between suspect wheel sensor harness connector terminals.
Is the inspection result normal?
YES >> Replace wheel sensor. Refer to BRC-124, "Removal and Installation - Front Wheel Sensor" or
BRC-125, "Removal and Installation - Rear Wheel Sensor"
. Then, GO TO 12.
NO >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
12.CONFIRM REPAIR
With CONSULT
1. Clear all DTCs.
2. Perform DTC confirmation procedure. Refer to BRC-64, "DTC Logic"
.
Does DTC C1101, C1102, C1103 or C1104 reset?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Inspection End.
ABS actuator and electric unit
(control unit) Ground Condition Vo l ta g e
(Approx.)
Connector Terminal
E54 28 — Ignition switch ON Battery voltage
Ignition switch OFF 0V
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E54 13
Ground Yes
38
Wheel Sensor (+) (-) Voltage
(Approx.)
Wheel Connector Terminal Terminal
Front LH E19
1 2 Battery voltage
Front RH E41
Rear LH C2
Rear RH C3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-68
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107,
C1108 WHEEL SENSOR
C1105, C1106, C1107, C1108 WHEEL SENSOR
DTC LogicINFOID:0000000009463772
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Start engine and drive vehicle at approximately 21 km/h (13 MPH) or more for approximately 5 minutes.
2. Perform self diagnostic result.
Is DTC C1105, C1106, C1107 or C1108 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-68, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463773
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
CAUTION:
Do not check between wheel sensor terminals.
1.CONFIRM DTC
With CONSULT
1. Perform self-diagnostic result of ABS and record all active DTCs.
2. Clear all DTCs.
3. Perform DTC confirmation procedure. Refer to BRC-68, "DTC Logic"
.
Does DTC C1105, C1106, C1107 or C1108 reset?
YES >> GO TO 2.
NO >> Refer to GI-43, "Intermittent Incident"
.
2.CHECK TIRE PRESSURE AND TIRE WEAR
Check tires for excessive wear and proper inflation. Refer to WT-53, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace as necessary.
3.CHECK WHEEL SENSOR
DTC Display Item Malfunction detected condition Possible causes
C1105 RR RH SENSOR-2 • When distance between rear wheel sensor RH and
rear wheel sensor RH rotor is large.
• When installation of rear wheel sensor RH or rear wheel sensor RH rotor is not normal.
• Wheel sensor
• ABS actuator and electric unit
(control unit)
• Sensor rotor
C1106 RR LH SENSOR-2
• When distance between rear wheel sensor LH and
rear wheel sensor LH rotor is large.
• When installation of rear wheel sensor LH or rear wheel sensor LH rotor is not normal.
C1107 FR RH SENSOR-2 • When distance between front wheel sensor RH
and front wheel sensor RH rotor is large.
• When installation of front wheel sensor RH or front wheel sensor RH rotor is not normal.
C1108 FR LH SENSOR-2 • When distance between front wheel sensor LH and
front wheel sensor LH rotor is large.
• When installation of front wheel sensor LH or front wheel sensor LH rotor is not normal.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-69
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Check wheel sensor for the following:
• Proper installation
• Physical damage
• Contamination
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace as necessary.
4.CHECK SENSOR ROTOR
Check sensor rotor for the following:
• Contamination
• Physical damage (missing teeth, cracks, etc.)
• Foreign material
• Looseness
Is the inspection result normal?
YES >> Replace the wheel sensor. Refer to BRC-124, "Removal and Installation - Front Wheel Sensor" or
BRC-125, "Removal and Installation - Rear Wheel Sensor"
. Then, GO TO 5.
NO >> Repair or replace as necessary.
5.CONFIRM REPAIR
With CONSULT
1. Clear all DTCs.
2. Perform DTC confirmation procedure. Refer to BRC-68, "DTC Logic"
.
Does DTC C1105, C1106, C1107 or C1108 reset?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Inspection End.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-70
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1109 POWER AND GROUND SYSTEM
C1109 POWER AND GROUND SYSTEM
DTC LogicINFOID:0000000009463774
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn the ignition switch ON.
2. Perform self diagnostic result.
Is DTC C1109 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-70, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463775
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connectors.
3. Check connectors and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace as necessary.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CON TROL UNIT) IGNITION POWER SUPPLY CIRCUIT
Check voltage between ABS actuator and electric uni t (control unit) connector E54 terminal 28 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between ABS actuator and electric unit (control unit) connector E54 terminals 13, 38 and
ground.
DTC Display Item Malfunction detected condition Possible causes
C1109 BATTERY VOLTAGE
[ABNORMAL] • When ignition voltage is 10 V or less.
• When ignition voltage is 16 V or more. • Harness or connector
• ABS actuator and electric unit
(control unit)
•Fuse
• Ignition power supply system
• Battery
ABS actuator and electric unit (control unit) Ground Condition Voltage
Connector Terminal
E54 28 — Ignition switch ON Battery voltage
Ignition switch OFF 0V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

C1109 POWER AND GROUND SYSTEMBRC-71
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E54 13
Ground Yes
38
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-72
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1110, C1153, C1170 ABS ACTUATOR
AND ELECTRIC UNIT (CONTROL UNIT)
C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
DTC LogicINFOID:0000000009463776
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-72, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463777
1.REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
CAUTION:
Replace ABS actuator and electric unit (control uni t) when self diagnostic result shows items other
than those applicable.
>> Replace ABS actuator and electr ic unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
DTC Display item Malfunction detected condition Possible cause
C1110 CONTROLLER FAILURE When there is an internal malfunction in the ABS actuator
and electric unit (control unit). • ABS actuator and electric unit
(control unit)
C1153 EMERGENCY BRAKE When ABS actuator and electric unit (control unit) is mal-
functioning. (Pressure increase is too much or too little)
C1170 VARIANT CODING In a case wh ere VARIANT CODING is different.
Self-diagnosis results
CONTROLLER FAILURE EMERGENCY BRAKE VARIANT CODING
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

C1111 PUMP MOTORBRC-73
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1111 PUMP MOTOR
DTC LogicINFOID:0000000009463778
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch OFF.
2. Depress brake pedal 20 times or more.
3. Start the engine and wait for 3 minutes or more.
4. Perform self diagnostic result.
I s D T C C 1111 d e t e c t e d ?
YES >> Proceed to diagnosis procedure. Refer to BRC-73, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463779
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connectors.
3. Check connectors and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK ABS MOTOR AND MOTOR RELAY BATTERY POWER SUPPLY
Check voltage between ABS actuator and electric uni t (control unit) connector E54 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (contro l unit) connector E54 terminals 13, 38 and
ground.
DTC Display Item Malfunction detected condition Possible causes
C 1111 P U M P M O T O R • When a malfunction is detected in motor or motor
relay.
• When a low pressure malfunction is detected in ac- cumulator.
• When a malfunction is detected in accumulator
pressure sensor. • Harness or connector
• ABS actuator and electric unit
(control unit)
• Fusible link
• Battery power supply system
• Motor/accumulator assembly
ABS actuator and electric unit (control unit) —Voltage
Connector Terminal
E54 1 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-74
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1111 PUMP MOTOR
Is the inspection result normal?
YES >> Replace ABS actuator and electr
ic unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E54 13
Ground Yes
38
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
