NISSAN TEANA 2014 Service Manual

PRECAUTIONSBRC-5
< PRECAUTION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Precaution for Brake ControlINFOID:0000000009463736
• During ABS operation, the brake pedal may vibrate lightly and a mechanical noise may be heard. This is normal.
• Just after starting vehicle, the brake pedal may vibrate or a motor operating noise may be heard from engine
compartment. This is a normal status of operation check.
• Stopping distance may be longer than that of vehicles without ABS when vehicle drives on rough, gravel, or
snow-covered (fresh, deep snow) roads.
• When an error is indicated by ABS or another warning lamp, collect all necessary information from customer
(what symptoms are present under what conditions) and check for simple causes before starting diagnosis.
Besides electrical system inspection, check boos ter operation, brake fluid level, and fluid leaks.
• If incorrect tire sizes or types are installed on the vehicle or brake pads are not Genuine NISSAN parts, stop-
ping distance or steering stability may deteriorate.
• If there is a radio, antenna or related wiring near control module, ABS function may have a malfunction or
error.
• If aftermarket parts (car stereo, CD player, etc.) have been installed, check for incidents such as harness pinches, open circuits or improper wiring.
• If the following components are replaced with non-genuine components or modified, the VDC OFF indicator
lamp and SLIP indicator lamp may turn on or the VDC system may not operate properly. Components
related to suspension (shock absorbers, struts, springs , bushings, etc.), tires, wheels (exclude specified
size), components related to brake system (pads, roto rs, calipers, etc.), components related to engine (muf-
fler, ECM, etc.), components related to body reinforcement (roll bar, tower bar, etc.).
• Driving with broken or excessively worn suspensi on components, tires or brake system components may
cause the VDC OFF indicator lamp and the SLIP indicator lamp to turn on, and the VDC system may not
operate properly.
• When the TCS or VDC is activated by sudden acceleration or sudden turn, some noise may occur. The
noise is a result of the normal operation of the TCS and VDC.
• When driving on roads which have extreme slopes (such as mountainous roads) or high banks (such as sharp curves on a freeway), the VDC may not operate no rmally, or the VDC warning lamp and the SLIP indi-
cator lamp may turn on. This is not a problem if normal operation can be resumed after restarting the engine.
• Sudden turns (such as spin turns, acceleration turns), drifting, etc. with VDC turned off may cause the yaw rate/side/decel G sensor to indicate a problem. This is not a problem if normal operation can be resumed
after restarting the engine.
Precaution for CAN SystemINFOID:0000000009463737
• Do not apply voltage of 7.0V or higher to terminal to be measured.
• Maximum open terminal voltage of tester in use must be less than 7.0V.
• Before checking harnesses, turn ignition switch OFF and disconnect battery negative cable.
• Area to be repaired must be soldered and wrapped with tape. Make sure that fraying of twisted wire is within 110 mm (4.33 in).
PKIA0306E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-6
< PRECAUTION >[VDC/TCS/ABS]
PRECAUTIONS
• Do not make a bypass connection to repaired area. (If the circuit is
bypassed, characteristics of twisted wire will be lost.)
Precaution for WorkINFOID:0000000009463738
• When removing or disassembling each component, be careful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
PKIA0307E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PREPARATIONBRC-7
< PREPARATION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009463739
The actual shapes of the tools may differ from those illustrated here.
Commercial Service ToolINFOID:0000000009463740
Tool number
(TechMate No.)
Tool name Description
—
(J-45741)
ABS active wheel sensor tester Checking operation of ABS active wheel sen-
sor
WFIA0101E
Tool name Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-8
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000009463741
1. IPDM E/R 2. Fuse, fusible link and relay box
(stop lamp relay)3. ABS actuator and el
ectric unit (con-
trol unit)
4. Brake fluid level switch 5. Vacuum sensor (attached to lower side of brake booster)6. Front wheel sensor LH (RH similar)
ALFIA0301ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPONENT PARTSBRC-9
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000009463742
ABS Actuator and Electric Unit (Control Unit)INFOID:0000000009463743
Electric unit (control unit) is integrated with actuator and comprehensively controls VDC function, TCS func-
tion, ABS function and EBD function.
ELECTRIC UNIT (CONTROL UNIT)
• Brake fluid pressure is controlled according to signals from each sensor.
• If malfunction is detected, t he system enters fail-safe mode.
ACTUATOR
The following components are integrated with ABS actuator.
Pump
Returns the brake fluid reserved in reservoir to master cylinder by reducing pressure.
Motor
Activates the pump according to signals from ABS actuator and electric unit (control unit).
Motor Relay
Operates the motor ON/OFF according to signals fr om ABS actuator and electric unit (control unit).
Actuator Relay (Main Relay)
Operates each valve ON/OFF according to signals fr om ABS actuator and electric unit (control unit).
ABS IN Valve
Switches the fluid pressure line to increase or hold according to signals from control unit.
ABS OUT Valve
Switches the fluid pressure line to increase, hold or decrease according to signals from control unit.
Cut Valve 1, Cut Valve 2
Shuts off the ordinary brake line from master cylinder, when VDC function and TCS function are activated.
7. Rear wheel sensor LH (RH similar) 8. VDC OFF switch 9. Steering angle sensor
(view with steering wheel removed)
10. Parking brake switch 11. Stop lamp switch 12. Combination meter
Component Reference/Function
ABS actuator and electric unit (control unit) BRC-9, "ABS Actuator and Electric Unit (Control Unit)"
Wheel sensorBRC-10, "Wheel Sensor and Sensor Rotor"
Stop lamp switchBRC-10, "Stop Lamp Switch"
Steering angle sensorBRC-10, "Steering Angle Sensor"
Vacuum sensorBRC-10, "Vacuum Sensor"
VDC OFF switchBRC-11, "VDC OFF Switch"
Brake fluid level switchBRC-10, "Brake Fluid Level Switch"
Parking brake switchBRC-11, "Parking Brake Switch"
ABS warning lamp
BRC-12, "VDC/TCS/ABS : System Description"
Brake warning lamp
VDC OFF indicator lamp
SLIP indicator lamp
ECM Transmits the following signals to ABS actuator and electric unit (control unit) via CAN
communication.
• Accelerator pedal position signal
• Engine speed signal
• Target throttle position signal
TCM Transmits the current gear position signal
to ABS actuator and electric unit (control
unit) via CAN communication.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-10
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
COMPONENT PARTS
Suction Valve 1, Suction Valve 2
Supplies the brake fluid from master cylinder to t
he pump, when VDC function and TCS function are activated.
Return Check Valve
Returns the brake fluid from brake caliper and wheel cy linder to master cylinder by bypassing orifice of each
valve when brake is released.
Reservoir
Temporarily reserves the brake fluid drained from brake caliper, so that pressure efficiently decreases when
decreasing pressure of brake caliper and wheel cylinder.
Yaw rate/side/decel G sensor
Calculates the following information that affects the vehicle, and transmits a signal to ABS actuator and elec-
tric unit (control unit) via communication lines.
• Vehicle rotation angular velocity (yaw rate signal)
• Vehicle lateral acceleration (side G signal) and longitudinal acceleration (decel G signal)
Pressure Sensor
Detects the brake fluid pressure and transmits signal to ABS actuator and electric unit (control unit).
Wheel Sensor and Sensor RotorINFOID:0000000009463744
NOTE:
• Wheel sensor of front wheel is installed on steering knuckle.
• Sensor rotor of front wheel is integrated in wheel hub assembly.
• Wheel sensor of rear wheel is installed on back plate of rear brake.
• Sensor rotor of rear wheel is installed on rear brake drum.
• Never measure resistance and voltage value using a tester because sensor is active sensor.
• Downsize and weight reduction is aimed. IC for detection portion and magnet for sensor rotor are adopted.
• Power supply is supplied to detection portion so that magnetic field line is read. Magnetic field that is detected is converted to current
signal.
• When sensor rotor rotates, magnetic field changes. Magnetic field change is converted to current signals (rectangular wave) and is
transmitted to ABS actuator and el ectric unit (control unit). Change
of magnetic field is proportional to wheel speed.
Stop Lamp SwitchINFOID:0000000009463745
Detects the operation status of brake pedal and transmits converted electric signal to ABS actuator and elec-
tric unit (control unit).
Steering Angle SensorINFOID:0000000009463746
Detects the following information and transmits steering angl e signal to ABS actuator and electric unit (control
unit) via CAN communication.
• Steering wheel rotation amount
• Steering wheel rotation angular velocity
• Steering wheel rotation direction
Brake Fluid Level SwitchINFOID:0000000009463747
Detects the brake fluid level in reservoir tank and transmi ts converted electric signal from combination meter to
ABS actuator and electric unit (control unit) via CAN communication.
Vacuum SensorINFOID:0000000009463748
Detects the vacuum in brake booster and transmits conver ted electric signal to ABS actuator and electric unit
(control unit).
JPFIC0131GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPONENT PARTSBRC-11
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Parking Brake SwitchINFOID:0000000009463749
Detects the operation status of parking brake switch and transmits converted electric signal from combination
meter to ABS actuator and electric uni t (control unit) via CAN communication.
VDC OFF SwitchINFOID:0000000009463750
• Non-operational status or standby status of VDC and TCS functions can be selected using VDC OFF switch.
VDC OFF indicator lamp indicates the operation stat us of function. (ON: Non-operational status, OFF:
Standby status)
• VDC OFF indicator lamp turns OFF (standby status) when the engine is started again after it is stopped once while VDC OFF indicator lamp is ON (non-operational status).
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-12
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
SYSTEM
SYSTEM
VDC/TCS/ABS
VDC/TCS/ABS : System DiagramINFOID:0000000009463751
VDC/TCS/ABS : System DescriptionINFOID:0000000009463752
• The system switches fluid pressure of each brake caliper to increase, to hold, or to decrease according to
signals from control unit in ABS actuator and electric unit (control unit). This control system is applied to
VDC, TCS, ABS and EBD functions.
• Fail-safe function is available for each function and is activated by each function when system malfunction
occurs.
INPUT SIGNAL AND OUTPUT SIGNAL
Major signal transmission between each unit via communication lines is shown in the following table.
ALFIA0294GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SYSTEMBRC-13
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
VALVE OPERATION (VDC AND TCS FUNCTIONS)
The control unit built in the ABS actuator and electric unit (control unit) controls fluid pressure of the brake cal-
ipers by operating each valve.
VDC and TCS Functions are Operating (Pressure Increases)
Component Signal description
Steering angle sensor Transmits the steering an
gle sensor signal to ABS actuator an d electric unit (control unit) via
CAN communication.
ECM Transmits the following signals to ABS actuator and electric unit (control unit) via CAN commu-
nication.
• Accelerator pedal position signal
• Engine speed signal
• Target throttle position signal
TCM Transmits the current gear positi
on signal to ABS actuator and electric unit (control unit) via
CAN communication.
Combination meter Transmits the following signals to ABS actuator and electric unit (control unit) via CAN commu-
nication.
• Brake fluid level switch signal
• Parking brake switch signal
Receives the foll owing signals from ABS actuator and elec tric unit (control unit) via CAN com-
munication.
• ABS warning lamp signal
• Brake warning lamp signal
• VDC OFF indicator lamp signal
• SLIP indicator lamp signal
ALFIA0309GB
Name Not activated Pressure increases
Cut valve 1 Power supply is not supplied (open) Power supply is supplied (close)
Cut valve 2 Power supply is not supplied (open) Power supply is supplied (close)
Suction valve 1 Power supply is not supplied (close) Power supply is supplied (open)
Suction valve 2 Power supply is not supplied (close) Power supply is supplied (open)
ABS IN valve Power supp ly is not supplied (open) Power supp ly is not supplied (open)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BRC-14
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
SYSTEM
Front RH brake caliper• Brake fluid is conveyed to the pump from the master
cylinder through suction valve 1 and is pressurized by
the pump operation. The pressurized brake fluid is s upplied to the front RH brake caliper through the ABS IN
valve. For the left caliper, brake fluid pressure is maintained because the pressurization is unnecessary. The
pressurization for the left caliper is controlled separately from the right caliper.
Front LH brake caliper
• Brake fluid is conveyed to the pump from the master cylinder through suction valve 2 and is pressurized by
the pump operation. The pressurized brake fluid is supp lied to the front LH brake caliper through the ABS IN
valve. For the right caliper, brake fluid pressure is maintained because the pressurization is unnecessary.
The pressurization for the right caliper is controlled separately from the left caliper.
Rear RH brake caliper
• Brake fluid is conveyed to the pump from the master cylinder through suction valve 2 and is pressurized by
the pump operation. The pressurized brake fluid is s upplied to the rear RH brake caliper through the ABS IN
valve. For the left caliper, brake fluid pressure is maintained because the pressurization is unnecessary. The
pressurization for the left caliper is controlled separately from the right caliper.
Rear LH brake caliper• Brake fluid is conveyed to the pump from the master cylinder through suction valve 1 and is pressurized by
the pump operation. The pressurized brake fluid is suppl ied to the rear LH brake caliper through the ABS IN
valve. For the right caliper, brake fluid pressure is maintained because the pressurization is unnecessary.
The pressurization for the right caliper is controlled separately from the left caliper.
VDC and TCS Functions Start Operating (Pressure Holds)
ABS OUT valve Power supply is not supplied (close) Power supply is not supplied (close)
Each brake caliper (fluid pressure) — Pressure increases Name Not activated Pressure increases
ALFIA0310GB
Name Not activated Pressure holds
Cut valve 1 Power supply is not supplied (open) Power supply is supplied (close)
Cut valve 2 Power supply is not supplied (open) Power supply is supplied (close)
Suction valve 1 Power supply is not supplied (close) Power supply is not supplied (close)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
