NISSAN TEANA 2014 Service Manual
Manufacturer: NISSAN, Model Year: 2014, Model line: TEANA, Model: NISSAN TEANA 2014Pages: 4801, PDF Size: 51.2 MB
Page 241 of 4801
![NISSAN TEANA 2014 Service Manual
C1160 DECEL G SEN SETBRC-95
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1160 DECEL G SEN SET
DTC LogicINFOID:0000000009463807
DTC DETECTION LOGIC
DTC CONFIRMATION PR NISSAN TEANA 2014 Service Manual
C1160 DECEL G SEN SETBRC-95
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1160 DECEL G SEN SET
DTC LogicINFOID:0000000009463807
DTC DETECTION LOGIC
DTC CONFIRMATION PR](/img/5/57390/w960_57390-240.png)
C1160 DECEL G SEN SETBRC-95
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1160 DECEL G SEN SET
DTC LogicINFOID:0000000009463807
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch OFF to ON.
2. Perform self-diagnostic result.
Is DTC C1160 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-95, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463808
1.DECEL G SENSOR CALIBRATION
Perform decel G sensor calibration. Refer to BRC-60, "Work Procedure"
.
>> GO TO 2.
2.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT.
Perform self-diagnostic result.
Is DTC C1160 detected?
YES >> GO TO 3.
NO >> Inspection End.
3.CHECK YAW RATE/SIDE/DECEL G SENSOR SYSTEM
Check yaw rate/side/decel G sensor system. Refer to BRC-75, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
DTC Display Item Malfunction detected condition Possible causes
C1160 DECEL G SEN SET When calibration of yaw rate/side/decel G sensor is
not complete. • Yaw rate/side/decel G sensor
• Harness or connector
• ABS actuator and electric unit (control unit)
• Decel G sensor calibration is
not performed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 242 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-96
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1164, C1165, C1166
, C1167 CV/SV SYSTEM
C1164, C1165, C1166, C1167 CV/SV SYSTEM
DTC LogicINFOID:0000000009463809
DTC DETECTION LOGIC
DTC CONFIRMATION P NISSAN TEANA 2014 Service Manual
BRC-96
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1164, C1165, C1166
, C1167 CV/SV SYSTEM
C1164, C1165, C1166, C1167 CV/SV SYSTEM
DTC LogicINFOID:0000000009463809
DTC DETECTION LOGIC
DTC CONFIRMATION P](/img/5/57390/w960_57390-241.png)
BRC-96
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1164, C1165, C1166
, C1167 CV/SV SYSTEM
C1164, C1165, C1166, C1167 CV/SV SYSTEM
DTC LogicINFOID:0000000009463809
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch OFF to ON.
2. Perform self diagnostic result.
Is DTC C1164, C1165, C1166 or C1167 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-96, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463810
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check connector and terminals for defo rmation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY
Check voltage between ABS actuator and electric uni t (control unit) connector E54 terminal 25 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control unit) connector E54 terminals 13, 38 and
ground.
DTC Display Item Malfunction detected condition Possible causes
C1164 CV 1 When a malfunction is detected in cut valve 1. • Harness or connector
• ABS actuator and electric unit (control unit)
• Fusible link
• Battery power supply system
C1165 CV 2 When a malfunction is detected in cut valve 2.
C1166 SV 1 When a malfunction is detected in suction valve 1.
C1167 SV 2 When a malfunction is detected in suction valve 2.
ABS actuator and electric unit (control unit) —Vo l ta g e
(Approx.)
Connector Terminal
E54 25 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E54 13
Ground Yes
38
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 243 of 4801
![NISSAN TEANA 2014 Service Manual
C1164, C1165, C1166, C1167 CV/SV SYSTEM
BRC-97
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Replace ABS actuator and electric un NISSAN TEANA 2014 Service Manual
C1164, C1165, C1166, C1167 CV/SV SYSTEM
BRC-97
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Replace ABS actuator and electric un](/img/5/57390/w960_57390-242.png)
C1164, C1165, C1166, C1167 CV/SV SYSTEM
BRC-97
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 244 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-98
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1197 VACUUM SENSOR
C1197 VACUUM SENSOR
DTC LogicINFOID:0000000009463811
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
NISSAN TEANA 2014 Service Manual
BRC-98
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1197 VACUUM SENSOR
C1197 VACUUM SENSOR
DTC LogicINFOID:0000000009463811
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT](/img/5/57390/w960_57390-243.png)
BRC-98
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1197 VACUUM SENSOR
C1197 VACUUM SENSOR
DTC LogicINFOID:0000000009463811
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT.
1. Turn the ignition switch ON.
2. Perform self-diagnostic result.
Is DTC C1197 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-98, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463812
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CHECK BRAKE BOOSTER
1. Turn the ignition switch OFF.
2. Check brake booster. Refer to BR-10, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace brake booster. Refer to BR-28, "Removal and Installation - QR25DE"
or BR-29,
"Removal and Installation - VQ35DE".
2.CHECK VACUUM PIPING
Check vacuum piping. Refer to BR-28, "Exploded View"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace vacuum piping. Refer to BR-32, "Removal and Installation"
.
3.CHECK VACUUM SENSOR CIRCUIT
1. Disconnect vacuum sensor harness connector.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check continuity between vacuum sensor harness connector and ABS ac tuator and electric unit (control
unit) harness connector.
4. Check continuity between vacuum sensor harness connector and ground.
DTC Display Item Malfunction detected condition Possible causes
C1197 VACUUM SENSOR When a malfunction is detected in vacuum sensor. • Harness or connector
• Vacuum sensor (brake booster)
• Vacuum piping
• ABS actuator and electric unit (control unit)
Vacuum sensor ABS actuator and el ectric unit (control unit)
Continuity
Connector Terminal Connector Terminal
E27 1
E54 12
Ye s
224
35
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 245 of 4801
![NISSAN TEANA 2014 Service Manual
C1197 VACUUM SENSORBRC-99
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning componen NISSAN TEANA 2014 Service Manual
C1197 VACUUM SENSORBRC-99
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning componen](/img/5/57390/w960_57390-244.png)
C1197 VACUUM SENSORBRC-99
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning components.
4.CHECK TERMINAL
• Check vacuum sensor pin terminals for damage or loose connection with harness connector.
• Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning components.
5.REPLACE VACUUM SENSOR
With CONSULT
1. Connect ABS actuator and electric unit (control unit) harness connector.
2. Replace vacuum sensor. Refer to BR-28, "Exploded View"
.
CAUTION:
Always replace brake booster because vac uum sensor cannot be disassembled.
3. Erase self-diagnosis result for “ABS”.
4. Turn the ignition switch OFF.
5. Start engine.
6. Perform self-diagnosis for “ABS”.
Is DTC
“C1197” detected?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Inspection End.
Vacuum sensor —Continuity
Connector Terminal
E27 1
Ground No
2
3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 246 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-100
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1198 VACUUM SENSOR
C1198 VACUUM SENSOR
DTC LogicINFOID:0000000009463813
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
NISSAN TEANA 2014 Service Manual
BRC-100
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1198 VACUUM SENSOR
C1198 VACUUM SENSOR
DTC LogicINFOID:0000000009463813
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT](/img/5/57390/w960_57390-245.png)
BRC-100
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1198 VACUUM SENSOR
C1198 VACUUM SENSOR
DTC LogicINFOID:0000000009463813
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT.
1. Turn the ignition switch ON.
2. Perform self-diagnostic result.
Is DTC C1198 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-100, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463814
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CHECK VACUUM SENSOR CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect vacuum sensor harness connector.
3. Disconnect ABS actuator and electric unit (control unit) harness connector.
4. Check continuity between vacuum sensor harness connector and ABS ac tuator and electric unit (control
unit) harness connector.
5. Check continuity between vacuum sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning components.
2.CHECK TERMINAL
DTC Display Item Malfunction detected condition Possible causes
C1198 VACUUM SEN CIR • When an open circuit is detected in vacuum sensor
circuit.
• When a short circuit is detected in vacuum sensor circuit.
• When a malfunction is detected in vacuum sensor
noise. • Harness or connector
• Vacuum sensor (brake booster)
• ABS actuator and electric unit (control unit)
Vacuum sensor ABS actuator and electric unit (control unit) Continuity
Connector Terminal Connector Terminal
E27 1
E54 12
Ye s
224
35
Vacuum sensor —Continuity
Connector Terminal
E27 1
Ground No
2
3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 247 of 4801
![NISSAN TEANA 2014 Service Manual
C1198 VACUUM SENSORBRC-101
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
• Check vacuum sensor pin terminals for damage or loose connection with harness connector.
NISSAN TEANA 2014 Service Manual
C1198 VACUUM SENSORBRC-101
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
• Check vacuum sensor pin terminals for damage or loose connection with harness connector.](/img/5/57390/w960_57390-246.png)
C1198 VACUUM SENSORBRC-101
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
• Check vacuum sensor pin terminals for damage or loose connection with harness connector.
• Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.REPLACE VACUUM SENSOR
With CONSULT
1. Connect ABS actuator and electric unit (control unit) harness connector.
2. Replace vacuum sensor. Refer to BR-28, "Exploded View"
.
CAUTION:
Always replace brake booster because vac uum sensor cannot be disassembled.
3. Erase self-diagnosis result for “ABS”.
4. Turn the ignition switch OFF.
5. Start engine.
6. Perform self-diagnosis for “ABS”.
Is DTC
“C1198” detected?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Inspection End.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 248 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-102
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1199 BRAKE BOOSTER
C1199 BRAKE BOOSTER
DTC LogicINFOID:0000000009463815
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
NISSAN TEANA 2014 Service Manual
BRC-102
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1199 BRAKE BOOSTER
C1199 BRAKE BOOSTER
DTC LogicINFOID:0000000009463815
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT](/img/5/57390/w960_57390-247.png)
BRC-102
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1199 BRAKE BOOSTER
C1199 BRAKE BOOSTER
DTC LogicINFOID:0000000009463815
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT.
1. Turn the ignition switch ON.
2. Perform self-diagnostic result.
Is DTC C1199 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-102, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463816
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CHECK BRAKE BOOSTER
1. Turn the ignition switch OFF.
2. Check brake booster. Refer to BR-10, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace brake booster. Refer to BR-28, "Removal and Installation - QR25DE"
or BR-29,
"Removal and Installation - VQ35DE".
2.CHECK VACUUM PIPING
Check vacuum piping. Refer to BR-28, "Exploded View"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace vacuum piping. Refer to BR-32, "Removal and Installation"
.
3.CHECK VACUUM SENSOR CIRCUIT
1. Disconnect vacuum sensor harness connector.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check continuity between vacuum sensor harness connector and ABS ac tuator and electric unit (control
unit) harness connector.
4. Check continuity between vacuum sensor harness connector and ground.
DTC Display Item Malfunction detected condition Possible causes
C1199 BRAKE BOOSTER When brake booster vacuum is approx. 0 kPa (0 mm-
Hg) during engine running. • Harness or connector
• Vacuum sensor (brake booster)
• Vacuum piping
• ABS actuator and electric unit (control unit)
Vacuum sensor ABS actuator and el ectric unit (control unit)
Continuity
Connector Terminal Connector Terminal
E27 1
E54 12
Ye s
224
35
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 249 of 4801
![NISSAN TEANA 2014 Service Manual
C1199 BRAKE BOOSTERBRC-103
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning compone NISSAN TEANA 2014 Service Manual
C1199 BRAKE BOOSTERBRC-103
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning compone](/img/5/57390/w960_57390-248.png)
C1199 BRAKE BOOSTERBRC-103
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning components.
4.CHECK TERMINAL
• Check vacuum sensor pin terminals for damage or loose connection with harness connector.
• Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning components.
5.REPLACE VACUUM SENSOR
With CONSULT
1. Connect ABS actuator and electric unit (control unit) harness connector.
2. Replace vacuum sensor. Refer to BR-28, "Exploded View"
.
CAUTION:
Always replace brake booster because vac uum sensor cannot be disassembled.
3. Erase self-diagnosis result for “ABS”.
4. Turn the ignition switch OFF.
5. Start engine.
6. Perform self-diagnosis for “ABS”.
Is DTC
“C1199” detected?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Inspection End.
Vacuum sensor —Continuity
Connector Terminal
E27 1
Ground No
2
3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 250 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-104
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C119A VACUUM SENSOR
C119A VACUUM SENSOR
DTC LogicINFOID:0000000009463817
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
NISSAN TEANA 2014 Service Manual
BRC-104
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C119A VACUUM SENSOR
C119A VACUUM SENSOR
DTC LogicINFOID:0000000009463817
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT](/img/5/57390/w960_57390-249.png)
BRC-104
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C119A VACUUM SENSOR
C119A VACUUM SENSOR
DTC LogicINFOID:0000000009463817
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT.
1. Turn the ignition switch ON.
2. Perform self-diagnostic result.
Is DTC C119A detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-104, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463818
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CHECK VACUUM SENSOR POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect vacuum sensor harness connector.
3. Check voltage between vacuum sensor harness connector and ground.
4. Turn the ignition switch ON. CAUTION:
Never start engine.
5. Check voltage between vacuum sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK VACUUM SENSOR POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check continuity between vacuum sensor harness connector and ABS ac tuator and electric unit (control
unit) harness connector.
DTC Display Item Malfunction detected condition Possible causes
C119A VACUUM SEN VOLT When a malfunction is detected in supply power volt-
age of vacuum sensor. • Harness or connector
• Vacuum sensor (brake booster)
• ABS actuator and electric unit (control unit)
Vacuum sensor —Voltag e
(Approx.)
Connector Terminal
E27 3 Ground 0 V
Vacuum sensor —Vo l ta g e
(Approx.)
Connector Terminal
E27 3 Ground 4.75 V – 5.25 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
