HAC-92
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
ECV (ELECTRICAL CONTROL VALVE)
ECV (ELECTRICAL CONTROL VALVE)
Diagnosis ProcedureINFOID:0000000009463164
1.CHECK ECV (ELECTRICAL CONT
ROL VALVE) POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect compressor connector.
3. Turn ignition switch ON.
4. Check voltage between compressor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 10 A fuse [No. 30, located in fuse block (J/B)]. Refer to PG-70, "Terminal Arrangement"
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the affected circuit.
3.CHECK ECV POWER SUPPLY CIRCUIT FOR OPEN
1. Disconnect fuse block (J/B) connector.
2. Check continuity between compressor harness connector and fuse block (J/B) harness connector.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK ECV POWER SUPPLY CIRCUIT FOR SHORT
1. Disconnect A/C auto amp. connector and A/C switch assembly connector.
2. Check continuity between compressor harness connector and ground.
Is the inspection result normal?
YES >> Check ignition power supply circuit. Refer to PG-19, "Wiring Diagram — Ignition Power Supply —
".
NO >> Repair harness or connector.
5.CHECK ECV CONTROL SIGNAL CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between compressor harne ss connector and A/C auto amp. harness connector.
+
−Voltag e
Compressor
Connector Terminal F88 4 Ground Battery voltage
Compressor Fuse block (J/B) Continuity
Connector Terminal Connector Terminal
F88 4 E6 1M Yes
Compressor —Continuity
Connector Terminal
F88 4 Ground No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECV (ELECTRICAL CONTROL VALVE)
HAC-93
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK ECV CONTROL SIGNAL CIRCUIT FOR SHORT
Check continuity between compressor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair harness or connector.
7.CHECK ECV
Check ECV. Refer to HAC-93, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace compressor. Refer to HA-30, "COMPRESSOR : Removal and Installation"
.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
Component InspectionINFOID:0000000009463165
1.CHECK ECV (ELECTRICAL CONTROL VALVE)
1. Turn ignition switch OFF.
2. Disconnect compressor connector.
3. Check continuity between compressor connector F88 terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace compressor. Refer to HA-30, "COMPRESSOR : Removal and Installation"
.
Compressor A/C auto amp.
Continuity
Connector Terminal Connector Terminal
F88 3 M152 40 Yes
Compressor —Continuity
Connector Terminal
F88 3 Ground No
Te r m i n a l s Condition
Resistance (kΩ)
Temperature: °C ( °F)
3 4 20 (68) 10.1 – 11.1
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-94
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
HEATER AND AIR CONDITIONING
SYSTEM CONTROL SYMPTOMS
SYMPTOM DIAGNOSIS
HEATER AND AIR CONDITIONING SYSTEM CONTROL SYMPTOMS
Diagnosis Chart By SymptomINFOID:0000000009463166
NOTE:
Perform the self-diagnoses with CONSULT before perfo rming the symptom diagnosis. If DTC is detected, per-
form the corresponding diagnosis.
Symptom Corresponding malfunction part Reference
• Air conditioning does not activate.
• Air conditioning cannot be controlled.
• Operation status of air conditioning is not indicated on display. • A/C auto amp. ignition power supply
circuit
• Front A/C control (A/C auto amp.) HAC-78, "A/C AUTO AMP. : Diag-
nosis Procedure"
• Air outlet does not change.
• Mode door motor does not operate normally. • Circuit between mode door motor
and A/C auto amp.
• Mode door motor control linkage
• Mode door motor
• A/C auto amp. HAC-80, "MODE DOOR MOTOR :
Diagnosis Procedure"
• Discharge air temperature of driver side does not
change.
• Air mix door motor LH does not operate normally. • Circuit between air mix door motor
LH and A/C auto amp.
• Air mix door motor LH installation condition
• Air mix door motor LH
• A/C auto amp. HAC-78, "AIR MIX DOOR MOTOR
(DRIVER SIDE) : Diagnosis Proce-
dure"
• Discharge air temperature of passenger side does
not change.
• Air mix door motor RH does not operate normally. • Circuit between air mix door motor
RH and A/C auto amp.
• Air mix door motor RH installation condition
• Air mix door motor RH
• A/C auto amp. HAC-79, "AIR MIX DOOR MOTOR
(PASSENGER SIDE) : Diagnosis
Procedure"
• Intake door does not change.
• Intake door motor does not operate normally. • Circuit between intake door motor
and A/C auto amp.
• Intake door motor control linkage
• Intake door motor
• A/C auto amp. HAC-81, "INTAKE DOOR MOTOR :
Diagnosis Procedure"
All door motors do not operate normally.
• Each door motor power supply and
ground circuit
• A/C auto amp. HAC-89, "Diagnosis Procedure"
Blower motor operation is malfunctioning. • Power supply system of front blower
motor
• Circuit between front blower motor
and A/C auto amp.
• Front blower motor
• A/C auto amp. HAC-84, "Diagnosis Procedure"
Compressor does not operate. • Circuit between magnet clutch and
IPDM E/R
• Magnet clutch
• IPDM E/R (A/C relay)
• Circuit between ECM and refriger- ant pressure sensor
• Refrigerant pressure sensor
• CAN communication circuit
• A/C auto amp. HAC-87, "Diagnosis Procedure"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HEATER AND AIR CONDITIONING SYSTEM CONTROL SYMPTOMS
HAC-95
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
• Insufficient cooling.
• No cool air comes out. (Air flow volume is normal.) • Magnet clutch control system
• Drive belt slipping
• Refrigerant cycle
• ECV (electrical control valve)
• Air leakage from each duct
• A/C auto amp. connection recogni- tion signal circuit
• Temperature setting trimmer (front)HAC-96, "Diagnosis Procedure"
• Insufficient heating.
• No warm air comes out. (Air flow volume is nor- mal.) • Engine cooling system
• Heater hose
• Heater core
• Air leakage from each duct
• Temperature setting trimmer (front)HAC-98, "Diagnosis Procedure"
Noise is heard when front
air conditioning system op-
erates. During compressor
operation Refrigerant cycle
HA-18, "Symptom Table"
During front blower
motor operation • Mixing any foreign object in front
blower motor
• Front blower motor fan breakage
• Front blower motor rotation inferiori-
ty HAC-85, "Component Inspection
(Blower Motor)"
• Memory function does not operate.
• Setting temperature is not memorized. • Battery power supply system of A/C
auto amp.
• A/C auto amp. HAC-78, "A/C AUTO AMP. : Diag-
nosis Procedure"
Symptom Corresponding malfunction part Reference
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-96
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
DescriptionINFOID:0000000009463167
Symptom
• Insufficient cooling
• No cool air comes out. (Air flow volume is normal.)
Diagnosis ProcedureINFOID:0000000009463168
NOTE:
Perform self-diagnoses with CONSULT before performi ng symptom diagnosis. If any DTC is detected, per-
form the corresponding diagnosis.
1.CHECK MAGNET CLUTCH OPERATION
1. Turn ignition switch ON.
2. Operate fan switch.
3. Press A/C switch.
4. Check that A/C indicator turns ON. Check visually and by sound that compressor operates.
5. Press A/C switch again.
6. Check that A/C indicator turns OFF. Check that compressor stops.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform diagnosis of “COMPRESSOR DOES NOT OPERATE” in “SYMPTOM DIAGNOSIS”.
Refer to HAC-99, "Diagnosis Procedure"
.
2.CHECK DRIVE BELT
Check tension of drive belt. Refer to EM-19, "Checking Drive Belts"
(QR25DE) or EM-134, "Checking Drive
Belts" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 3.
NO >> Adjust or replace drive belt depending on the inspection results.
3.CHECK REFRIGERANT CYCLE
Connect recovery/recycling recharging equipment to the vehicle and perform pressure inspection with gauge.
Refer to HA-18, "Symptom Table"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace parts depending on the inspection results.
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of the fr ont air conditioning system for leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK AMBIENT TEMPERATURE DISPLAY
Check that there is not much difference between act ual ambient temperature and indicated temperature on
information display in combination meter.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Perform diagnosis for the A/C auto amp. connection recognition signal circuit. Refer to HAC-60,
"Diagnosis Procedure".
6.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (FRONT)
1. Check setting value of temperature setting trimmer (front). Refer to HAC-50, "Temperature Setting Trim-
mer".
2. Check that temperature setting trimme r (front) is set to “+ direction”.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

INSUFFICIENT COOLINGHAC-97
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
NOTE:
The control temperature can be set with the setti ng of the temperature setting trimmer (front).
3. Set difference between set temperature and control temperature to “0”.
Is inspection result normal?
YES >> Inspection End.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-98
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT HEATING
INSUFFICIENT HEATING
DescriptionINFOID:0000000009463169
Symptom
• Insufficient heating
• No warm air comes out. (Air flow volume is normal.)
Diagnosis ProcedureINFOID:0000000009463170
NOTE:
Perform self-diagnosis with CONSULT before performing symptom diagnosis. If DTC is detected, perform the
corresponding diagnosis.
1.CHECK COOLING SYSTEM
1. Check engine coolant level and check leakage. Refer to CO-11, "System Inspection"
(QR25DE) or CO-
35, "System Inspection" (VQ35DE).
2. Check reservoir tank cap. Refer to CO-11, "System Inspection"
(QR25DE) or CO-35, "System Inspection"
(VQ35DE).
3. Check water flow sounds of the engine coolant. Refer to CO-11, "System Inspection"
(QR25DE) or CO-
35, "System Inspection" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refill engine coolant and repair or repl ace parts depending on the inspection results.
2.CHECK HEATER HOSE
Check installation of heater hose visually or by touching.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace parts depending on the inspection results.
3.CHECK HEATER CORE
1. Check temperature of inlet hose and outlet hose of front heater core.
2. Check that inlet side of heater core is hot and the outle t side is slightly lower than/almost equal to the inlet
side.
CAUTION:
Always perform the temperature in spection in a short period of time because the engine coolant
temperature is very hot.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace heater core. Refer to HA-42, "HEATER CORE : Removal and Installation"
.
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of front air conditioning system for air leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (FRONT)
1. Check setting value of temperature setting trimmer (front). Refer to HAC-50, "Temperature Setting Trim-
mer".
2. Check that temperature setting trimmer (front) is set to “ − direction”.
NOTE:
The control temperature can be set by t he temperature setting trimmer (front).
3. Set difference between the set temperature and control temperature to “0”.
Are the symptoms solved?
YES >> Inspection End.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPRESSOR DOES NOT OPERATEHAC-99
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
COMPRESSOR DOES NOT OPERATE
DescriptionINFOID:0000000009463171
Symptom: Compressor does not operate.
Diagnosis ProcedureINFOID:0000000009463172
NOTE:
• Perform self-diagnoses with CONSULT before perform ing symptom diagnosis. If DTC is detected, perform
the corresponding diagnosis.
• Check that refrigerant system is properly charged. If refrigerant amount is below the proper amount, perform
inspection of refrigerant leakage.
1.CHECK MAGNET CLUTCH OPERATION
Check magnet clutch. Refer to HAC-87, "Component Function Check"
.
Does it operate normally?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK REFRIGERANT PRESSURE SENSOR
Check refrigerant pressure sensor. Refer to EC-523, "Component Function Check"
(QR25DE) or EC-979,
"Component Function Check" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK A/C AUTO AMP. OUTPUT SIGNAL
With CONSULT
Check “COMP REQ SIG” and “FAN REQ SIG” in “D ATA MONITOR” mode of “HVAC” using CONSULT.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
4.CHECK ECM INPUT SIGNAL
With CONSULT
Check “AIR COND SIG” and “HEATER FAN SW” in “DATA MONITOR” mode of “ECM” using CONSULT.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check CAN communication system. Refer to LAN-18, "Trouble Diagnosis Flow Chart"
.
5.CHECK IPDM E/R INPUT SIGNAL
With CONSULT
Monitor item Condition Status
COMP REQ SIG A/C switch ON On
OFF Off
FAN REQ SIG Blower motor ON On
OFF Off
Monitor item Condition Status
AIR COND SIG A/C switch ON On
OFF Off
HEATER FAN SW Blower motor ON On
OFF Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-100
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
COMPRESSOR DOES NOT OPERATE
1. Start engine.
2. Check “AC COMP REQ” in “DATA MONITO R” mode of “IPDM E/R” using CONSULT.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check CAN communication system. Refer to LAN-18, "Trouble Diagnosis Flow Chart"
.
Monitor item Condition Status
AC COMP REQ A/C switch ON On
OFF Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

A/C SWITCH ASSEMBLYHAC-101
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
REMOVAL AND INSTALLATION
A/C SWITCH ASSEMBLY
Removal and InstallationINFOID:0000000009463173
REMOVAL
1. Remove the center stack side finishers. Refer to IP-14, "Exploded View".
2. Remove the A/C switch assembly screws (A).
3. Disconnect the harness connector from the A/C switch assembly and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALIIA0635ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
