NISSAN TEANA 2014 Service Manual

HAC-102
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONER]
A/C AUTO AMP.
A/C AUTO AMP.
Exploded ViewINFOID:0000000009463174
Removal and InstallationINFOID:0000000009463175
REMOVAL
1. Remove the audio unit. Refer to
AV-47, "Removal and Installation" (BASE AUDIO), AV-108, "Removal and
Installation" (DISPLAY AUDIO WITHOUT BOSE) or AV-198, "Removal and Installation" (DISPLAY AUDIO
WITH BOSE).
2. Remove the AV control unit. Refer to AV-298, "Removal and Installation"
( N AV I G AT I O N W I T H O U T
BOSE) or AV-418, "Removal and Installation"
( N AV I G AT I O N W I T H B O S E ) .
3. Remove the audio unit bracket screws and audio unit brackets (LH/RH).
4. Remove the A/C auto amp.
INSTALLATION
Installation is in the reverse order of removal.
1. Audio unit 2. Audio unit bracket (LH) 3. A/C auto amp.
4. Audio unit bracket (RH)
AWNIA2551ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

AMBIENT SENSORHAC-103
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
AMBIENT SENSOR
Removal and InstallationINFOID:0000000009463176
REMOVAL
1. Remove the core support cover clips (A), then remove the core support cover (1).
2. Disconnect the harness connector from the ambient sensor.
3. Release the ambient sensor clip, then remove the ambient sen- sor (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2602ZZ
ALIIA0314ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-104
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONER]
IN-VEHICLE SENSOR
IN-VEHICLE SENSOR
Removal and InstallationINFOID:0000000009463177
REMOVAL
1. Remove the instrument lower panel LH. Refer to
IP-21, "Removal and Installation".
2. Disconnect the harness connector from the in-vehicle sensor.
3. Disconnect the aspirator hose (2) from the in-vehicle sensor.
4. Remove the in-vehicle sensor screw (A) and the in-vehicle sen- sor (1).
INSTALLATION
Installation is in the reverse order of removal.
ALIIA0593ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SUNLOAD SENSORHAC-105
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
SUNLOAD SENSOR
Removal and InstallationINFOID:0000000009463178
REMOVAL
1. Release the front speaker grille (LH). Refer to IP-14, "Exploded View".
2. Disconnect the harness connector from the sunload sensor.
3. Release the sunload sensor pawls and remove. : Pawl
INSTALLATION
Installation is in the reverse order of removal.
ALIIA0592ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-106
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONER]
INTAKE SENSOR
INTAKE SENSOR
Removal and InstallationINFOID:0000000009463179
The intake sensor is not available separately and must be replaced with the heating and cooling unit as an
assembly. Refer to HA-41, "HEATING AND COOLING UNIT ASSEMBLY : Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REFRIGERANT PRESSURE SENSORHAC-107
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
REFRIGERANT PRESSURE SENSOR
Removal and InstallationINFOID:0000000009463180
REMOVAL
1. Discharge the refrigerant. Refer to HA-23, "Recycle Refrigerant".
2. Remove the front bumper fascia. Refer to EXT-17, "Removal and Installation"
.
3. Disconnect the harness connector from the refrigerant pressure sensor.
4. Remove the refrigerant pressure sensor. CAUTION:
Cap or wrap the opening of the refrigerant pressu re sensor with suitable material such as vinyl
tape to avoid the entry of air.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply A/C oil to the O-ri ng of the refrigerant pressu re sensor for installation.
• After charging refrigerant, check for leaks. Refer to HA-21, "Leak Test"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-108
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONER]
DOOR MOTOR
DOOR MOTOR
Exploded ViewINFOID:0000000009463181
1. Front heating and cooling unit assembly 2. Mode door motor 3. Air mix door motor (LH)
4. Air mix door motor (RH) 5. Intake door motor
ALIIA0591ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DOOR MOTORHAC-109
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
INTAKE DOOR MOTOR
INTAKE DOOR MOTOR : Re moval and InstallationINFOID:0000000009463182
REMOVAL
1. Remove the glove box assembly. Refer to IP-22, "Removal and Installation".
2. Disconnect the harness connector from the intake door motor.
3. Remove the intake door motor screws and the intake door motor.
INSTALLATION
Installation is in the reverse order of removal.
MODE DOOR MOTOR
MODE DOOR MOTOR : Re moval and InstallationINFOID:0000000009463183
REMOVAL
1. Remove the instrument lower panel LH. Refer to IP-21, "Removal and Installation".
2. Disconnect the harness connector from the mode door motor.
3. Remove the mode door motor screws and the mode door motor.
INSTALLATION
Installation is in the reverse order of removal.
AIR MIX DOOR MOTOR
AIR MIX DOOR MOTOR : Removal and Inst allation - Air Mix Door Motor (RH)
INFOID:0000000009463184
REMOVAL
1. Remove the glove box assembly. Refer to IP-22, "Removal and Installation".
2. Remove the upper floor connecting duct (RH). Refer to HA-40, "Exploded View"
.
3. Disconnect the harness connector from the air mix door motor (RH).
4. Remove the air mix door motor (RH) screws and the air mix door motor (RH).
INSTALLATION
Installation is in the reverse order of removal.
AIR MIX DOOR MOTOR : Removal and Inst allation - Air Mix Door Motor (LH)
INFOID:0000000009463185
REMOVAL
1. Remove the upper floor connecting duct (LH). Refer to HA-40, "Exploded View".
2. Disconnect the harness connector from the air mix door motor (LH).
3. Remove the air mix door motor (LH) screws and the air mix door motor (LH).
INSTALLATION
Installation is in the reverse order of removal.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-110
< PRECAUTION >[MANUAL AIR CONDITIONER]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951776
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000009463187
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Working with HFC-134a (R-134a)INFOID:0000000009463188
WARNING:
• CFC-12 (R-12) refrigerant and HFC-134a (R-134a) refr igerant are not compatible. If the refrigerants
are mixed compressor failure is likely to occur. Refer to HA-25, "Inspection"
. To determine the purity
of HFC-134a (R-134a) in the vehicle and recovery tank, use Refrigerant Recovery/Recycling Recharg-
ing equipment and Refrigerant Identifier.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PRECAUTIONSHAC-111
< PRECAUTION > [MANUAL AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
• Use only specified oil for the HFC-134a (R-134a) A/C system and HFC-134a (R-134a) components. If
oil other than that specifi ed is used, compressor fa ilure is likely to occur.
• The specified HFC-134a (R-134a) oil rapidly absorb s moisture from the atmosphere. The following
handling precautions must be observed:
- When removing refrigerant components from a vehicle, immediately cap (seal) the component to
minimize the entry of mois ture from the atmosphere.
- When installing refrigerant components to a vehicle, do not remove the caps (unseal) until just
before connecting the co mponents. Connect all refrigerant lo op components as quickly as possible
to minimize the entry of moisture into system.
- Only use the specified oil from a sealed container. Immediately reseal containers of oil. Without
proper sealing, oil will become moisture saturat ed and should not be used.
- Avoid breathing A/C refrigerant and oil vapor or mist. Exposure may irritate eyes, nose and throat.
Remove HFC-134a (R-134a) from the A/C system usi ng certified service equipment meeting require-
ments of SAE J2210 [HFC-134a (R-134a) recycling equipment], or J2209 [HFC-134a (R-134a) recy-
cling equipment], If accidental system discharge occurs, ventila te work area before resuming
service. Additional health and saf ety information may be obtained from refrigerant and oil manufac-
turers.
- Do not allow A/C oil to come in contact with styrofoam parts. Damage may result.
CONTAMINATED REFRIGERANT
If a refrigerant other than pure HFC-134a (R-134a) is identified in a vehicle, your options are:
• Explain to the customer that environmental regulations prohibit the release of contaminated refrigerant into
the atmosphere.
• Explain that recovery of the contaminated refri gerant could damage your service equipment and refrigerant
supply.
• Suggest the customer return the vehicle to the locati on of previous service where the contamination may
have occurred.
• If you choose to perform the repair, recover the refrigerant using only dedicated equipment and contain-
ers. Do not recover contaminated refrig erant into your existing service equipment. If your facility does
not have dedicated recovery equipment, you may contact a local refrigerant product retailer for available ser-
vice. This refrigerant must be disposed of in accordance with all federal and local regulations. In addition,
replacement of all refrigerant system components on the vehicle is recommended.
• If the vehicle is within the warranty period, the air conditioner warranty is void. Please contact NISSAN Cus-
tomer Affairs for further assistance.
Precaution for Service EquipmentINFOID:0000000009463189
MANIFOLD GAUGE SET
Be certain that the gauge face indicates R-134a or 134a. Make sure
the gauge set has 1/2 ″-16 ACME threaded connections for service
hoses. Confirm the set has been used only with refrigerant HFC-
134a (R-134a) along with specified oil.
SERVICE HOSES
SHA533D
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
