< SYSTEM DESCRIPTION >[MANUAL AIR CONDITIONER]
OPERATION
OPERATION
Switch Name and FunctionINFOID:0000000009463202
Front Air Control
Switch Operation
1. A/C switch 2. Blower control dial (with OFF switch) 3. DEF switch
4. Rear DEF switch 5. REC switch 6. Temperature control dial
7. MAX A/C switch 8. D/F switch 9. FOOT switch
10. B/L switch 11. VENT switch
ALIIA0604ZZ
A/C switch Switches the compressor control switch indicator between ON
⇔ OFF with each press while front
blower fan is activated. The circuit used by the BCM to detect an A/C ON request is grounded.
NOTE:
When front blower fan is OFF, the compressor control cannot be activated.
Blower control dial (with
OFF switch) • Blower fan speed is manually controlled with the dial for varying blower speed. When ON, the circuit
used by the BCM to detect a fan ON request signal is grounded.
• Turns air conditioning system OFF.
NOTE:
When blower control dial is turned to any ON position the air conditioning system is activated. (Com-
pressor control state returns to the previous state before air conditioning system was turned OFF.)
DEF switch Switches DEF mode (switch indicator) between ON
⇔ OFF with each press.
• When DEF mode is turned ON, the air conditioning system changes to the following state.
- Air inlet: Fresh air intake
- Air outlet: DEF
- Blower fan: Manual setting.
- Compressor: ON
• When DEF mode is turned OFF, the air conditioning system state returns to the previous state be-
fore DEF mode was selected, but the following state is continued:
- Air inlet: Fresh air intake
- Compressor: ON
NOTE:
When front blower fan is OFF, DEF cannot be activated.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

OPERATIONHAC-123
< SYSTEM DESCRIPTION > [MANUAL AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
MAX A/C switch Switches the MAX A/C and compressor control switch indicators between ON
⇔ OFF with each press
while front blower fan is activated.
• When MAX A/C mode is turned ON, the air conditioning system changes to the following state.
- Air inlet: Recirculation air intake
- Air outlet: Manual setting
- Blower fan: Manual setting.
- Compressor: ON
• When MAX A/C mode is turned OFF, the air conditioning system state returns to the previous state
before MAX A/C mode is selected. But, the following state is changed:
- Air inlet: Fresh air intake
- Compressor: ON
NOTE:
When front blower fan is OFF, the compressor control cannot be activated.
MODE switches Selects air outlet from VENT, B/L, FOOT, and D/F.
NOTE:
When the air conditioning system is OFF, the air outlet can still be selected.
REC switch • Air inlet is selected to fresh air intake (REC) by pressing this switch.
- REC indicator: ON
NOTE:
• When the air conditioning system is OFF, the air inlet can still be selected.
• When D/F mode or DEF is selected, the REC button is disabled.
Temperature control dial • Selects desired temperature between full cold and full hot.
- Clockwise rotation: Temperature increases.
- Counterclockwise rotation: Temperature decreases.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-124
< SYSTEM DESCRIPTION >[MANUAL AIR CONDITIONER]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
CONSULT Function (BCM - COMMON ITEM)INFOID:0000000009958322
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentially causing a di scharged battery and a no-start condition.
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode Description
Ecu Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
Ecu Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN Diag Support Mntr
Door lock DOOR LOCK ××××
Rear window defogger REAR DEFOGGER ×××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ×××
Exterior lamp HEADLAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITIONER ×
Intelligent Key system INTELLIGENT KEY ××××
Combination switch COMB SW ×
BCM BCM × × ×××
Immobilizer IMMU ×××
Interior room lamp battery saver BATTERY SAVER ××
Trunk open TRUNK ×
Vehicle security system THEFT ALM ×××
RAP system RETAINED PWR ×
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM (BCM)HAC-125
< SYSTEM DESCRIPTION > [MANUAL AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
CONSULT Function (BCM - AIR CONDITIONER)INFOID:0000000009958323
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and a no-start condition.
DATA MONITOR
Signal buffer system SIGNAL BUFFER ×
TPMS AIR PRESSURE MONITOR ××××
System Sub System
Direct Diagnostic Mode
Ecu Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN Diag Support Mntr
Monitor Item [Unit] Description
FAN ON SIG [On/Off] Indicates condition of fan switch.
AIR COND SW [On/Off] Indicates condition of A/C switch.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-126
< SYSTEM DESCRIPTION >[MANUAL AIR CONDITIONER]
DIAGNOSIS SYSTEM (IPDM E/R)
DIAGNOSIS SYSTEM (IPDM E/R)
CONSULT Function (IPDM E/R)INFOID:0000000009958324
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentially causing a di scharged battery and a no-start condition.
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with IPDM E/R.
ECU IDENTIFICATION
The IPDM E/R part number is displayed.
SELF DIAGNOSTIC RESULT
Refer to PCS-20, "DTC Index".
DATA MONITOR
Direct Diagnostic Mode Description
Ecu Identification The IPDM E/R part number is displayed.
Self Diagnostic Result The IPDM E/R self diagnostic results are displayed.
Data Monitor The IPDM E/R input/output data is displayed in real time.
Active Test The IPDM E/R activates outputs to test components.
CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed.
Monitor Item [Unit] Main
Signals Description
MOTOR FAN REQ [%] ×Indicates cooling fan speed signal received from ECM on CAN communication
line
AC COMP REQ [On/Off] ×Indicates A/C compressor request signal received from ECM on CAN commu-
nication line
TAIL&CLR REQ [On/Off] ×Indicates position light request signal received from BCM on CAN communica-
tion line
HL LO REQ [On/Off] ×Indicates low beam request signal received from BCM on CAN communication
line
HL HI REQ [On/Off] ×Indicates high beam request signal received from BCM on CAN communication
line
FR FOG REQ [On/Off] ×Indicates front fog light request signal received from BCM on CAN communica-
tion line
FR WIP REQ [Stop/1LOW/Low/Hi] ×Indicates front wiper request signal received from BCM on CAN communication
line
WIP AUTO STOP [STOP P/ACT P] ×Indicates condition of front wiper auto stop signal
WIP PROT [Off/BLOCK] ×Indicates condition of front wiper fail-safe operation
IGN RLY1 -REQ [On/Off] Indicates ignition switch ON signal received from BCM on CAN communication
line
IGN RLY [On/Off] ×Indicates condition of ignition relay
PUSH SW [On/Off] Indicates condition of push-button ignition switch
INTER/NP SW [On/Off] Indicates condition of CVT shift position
ST RLY CONT [On/Off] Indicates starter relay status signal received from BCM on CAN communication
line
IHBT RLY -REQ [On/Off] Indicates starter control relay signal received from BCM on CAN communication
line
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM (IPDM E/R)HAC-127
< SYSTEM DESCRIPTION > [MANUAL AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
ACTIVE TEST
CAN DIAG SUPPORT MNTR
Refer to LAN-15, "CAN Diagnostic Support Monitor".
ST/INHI RLY [Off/ ST /INHI] Indicates condition of starter relay and starter control relay
DETENT SW [On/Off] Indicates condition of CVT shift selector (park position switch)
DTRL REQ [Off] Indicates daytime light request signal received from BCM on CAN communica-
tion line
HOOD SW [On/Off] Indicates condition of hood switch
THFT HRN REQ [On/Off] Indicates theft warning horn request signal received from BCM on CAN commu-
nication line
HORN CHIRP [On/Off] Indicates horn reminder signal received from BCM on CAN communication line
HOOD SW 2 [On/Off] Indicates condition of hood switch 2 Monitor Item [Unit]
Main
Signals Description
Test item Description
HORN This test is able to check horn operation [On].
FRONT WIPER This test is able to check wiper motor operation [Hi/Lo/Off].
MOTOR FAN This test is able to check cooling fan operation [4/3/2/1].
EXTERNAL LAMPS This test is able to check external lamp operation [Fog/Hi/Lo/TAIL/Off].
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-128
< ECU DIAGNOSIS INFORMATION >[MANUAL AIR CONDITIONER]
FRONT AIR CONTROL
ECU DIAGNOSIS INFORMATION
FRONT AIR CONTROL
Reference ValueINFOID:0000000009463206
VALUES ON THE DIAGNOSIS TOOL
Display Item List
TERMINAL LAYOUT
PHYSICAL VALUES
Monitor item name “operation or unit” Contents
HEATER FAN SW “ON/OFF” Displays “O N/OFF” status as judged from blower fan motor switch signal.
AIR COND SW “ON/OFF” Displays “ON/OFF” status as judged from air conditioner switch signal.
ABIIA0520ZZ
Te r m i n a l No. Wire
color ItemIgnition
switch Condition Voltage (V)
(Approx.)
1 SB Power supply for battery — — 12
2 G Power supply for IGN ON — 12
4 P Rear defrost feedback ON Defroster
switch ON 12
OFF 0
5 R Illumination (+) ON Lighting
switch OFF 0
1st position 12
6 GR Illumination (-) — — 0
7 L Compressor ON signal ON Compressor ON 0
OFF 9 - 12
8 Y Blower ON signal ON Fan ON 0
OFF 5
9 B Ground — — 0
10 Y Rear defrost ON signal ON Defroster
switch ON 0
OFF 5
11 P Blower motor feedback ON Fan speed Low 7.0.- 10.0
12 G LIN signal ON — 5.5
13 W VACTR ON — 12
14 B ACTR Ground — — 0
16 BR PD cut ON Compressor ON 4.6
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM, IPDM E/R, BCMHAC-129
< ECU DIAGNOSIS INFORMATION > [MANUAL AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
ECM, IPDM E/R, BCM
List of ECU ReferenceINFOID:0000000009463207
ECU Reference
ECM EC-88, "Reference Value"
(QR25DE)
EC-613, "Reference Value"
(VQ35DE)
EC-101, "Fail Safe"
(QR25DE)
EC-627, "Fail-safe"
(VQ35DE)
EC-104, "DTC Inspection Priority Chart"
(QR25DE)
EC-629, "DTC Inspection Priority Chart"
(VQ35DE)
EC-105, "DTC Index"
(QR25DE)
EC-630, "DTC Index"
(VQ35DE)
IPDM E/R PCS-12, "Reference Value"
PCS-19, "Fail Safe"
PCS-20, "DTC Index"
BCMBCS-31, "Reference Value"BCS-50, "Fail Safe"
BCS-50, "DTC Inspection Priority Chart"
BCS-52, "DTC Index"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-130
< WIRING DIAGRAM >[MANUAL AIR CONDITIONER]
AIR CONDITIONER CONTROL
WIRING DIAGRAM
AIR CONDITIONER CONTROL
Wiring DiagramINFOID:0000000009463208
ABIWA0339GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

AIR CONDITIONER CONTROLHAC-131
< WIRING DIAGRAM > [MANUAL AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
ABIIA1163GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
