NISSAN TEANA 2014 Service Manual

HAC-62
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B257B, B257C AMBIENT SENSOR
3. Check resistance between ambient sensor terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace ambient sensor. Refer to HAC-103, "Removal and Installation"
.
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12
− 15 (5) 12.73
− 10 (14) 9.92
− 5 (23) 7.80
0 (32) 6.19
5 (41) 4.95
10 (50) 3.99
15 (59) 3.24
20 (68) 2.65
25 (77) 2.19
30 (86) 1.81
35 (95) 1.51
40 (104) 1.27 45 (113) 1.07
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

B2581, B2582 INTAKE SENSORHAC-63
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
B2581, B2582 INTAKE SENSOR
DTC LogicINFOID:0000000009463133
DTC DETECTION LOGIC
NOTE:
• If DTC is displayed along with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to HAC-
55, "DTC Logic".
• If DTC is displayed along with DTC U1010, first per form the trouble diagnosis for DTC U1010. Refer to HAC-
56, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON.
2. Using CONSULT, perform “SELF- DIAGNOSIS RESULTS” of HVAC.
3. Check if any DTC No. is displayed in the self-diagnosis results.
Is DTC detected?
YES >> Refer to HAC-63, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463134
Regarding Wiring Diagram information, refer to HAC-34, "Wiring Diagram".
1.CHECK INTAKE SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect intake sensor connector.
3. Turn ignition switch ON.
4. Check voltage between intake sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK INTAKE SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between intake sensor harness connector and ground.
DTC Items
(CONSULT screen terms) DTC detection condition Possible cause
B2581 INTAKE SENSOR The intake sensor recognition temperature is
too high. • Intake sensor
• A/C auto amp.
• Harness or connectors (The sensor circuit is open or short-
ed.)
B2582
The intake sensor recognition temperature is
too low.
+
−Vol tag e
(Approx.)
Intake sensor
Connector Terminal M69 1 Ground 5 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-64
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2581, B2582 IN
TAKE SENSOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Check intake sensor. Refer to HAC-64, "Component Inspection"
.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Replace intake sensor. Refer to HAC-106, "Removal and Installation"
.
4.CHECK INTAKE SENSOR POWER SUPPLY CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between intake sensor har ness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair harness or connector.
5.CHECK INTAKE SENSOR POWER SUPPLY CIRCUIT FOR GROUND SHORT
Check continuity between intake sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK INTAKE SENSOR POWER SUPPLY CIRCUIT FOR POWER SHORT
1. Turn ignition switch ON.
2. Check voltage between intake sensor harness connector and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Repair harness or connector.
Component InspectionINFOID:0000000009463135
1.CHECK INTAKE SENSOR
1. Turn ignition switch OFF.
2. Disconnect intake sensor connector.
Intake sensor —Continuity
Connector Terminal
M69 2 Ground Yes
Intake sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M69 1 M152 28 Yes
Intake sensor —Continuity
Connector Terminal
M69 1 Ground No
+ −Voltage
(Approx.)
Intake sensor
Connector Terminal M69 1 Ground 0 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

B2581, B2582 INTAKE SENSORHAC-65
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
3. Check resistance between intake sensor terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace intake sensor. Refer to HAC-106, "Removal and Installation"
.
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12 −
15 (5) 17.73
− 10 (14) 13.46
− 5 (23) 10.33
0 (32) 8.00
5 (41) 6.25
10 (50) 4.93
15 (59) 3.92
20 (68) 3.14
25 (77) 2.54
30 (86) 2.06
35 (95) 1.69
40 (104) 1.39 45 (113) 1.15
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-66
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2630, B2631 SUNLOAD SENSOR
B2630, B2631 SUNLOAD SENSOR
DTC LogicINFOID:0000000009463136
DTC DETECTION LOGIC
NOTE:
• If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
55, "DTC Logic" or HAC-56, "DTC Logic".
• Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60W or more).
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT
1. Using CONSULT, perform “SELF- DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC No. is displayed in the self-diagnosis results.
NOTE:
• If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
55, "DTC Logic" or HAC-56, "DTC Logic".
• Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60W or more).
Is DTC No.
“B2630” or “B2631” displayed?
YES >> Perform trouble diagnosis for the sunload sensor. Refer to HAC-66, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463137
Regarding Wiring Diagram information, refer to HAC-34, "Wiring Diagram".
1.CHECK SUNLOAD SENSOR POWER SUPPLY
1. Disconnect sunload sensor connector.
2. Turn ignition switch ON.
3. Check voltage between sunload sensor harness connector M56 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK CONTINUITY BETWEEN SUNL OAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
DTC Items
(CONSULT screen terms) Diagnostic item is detected when... Possible cause
B2630 SUNLOAD SEN (SHORT) Detected calorie at sunload sensor 1395 w/m
2
(1200 kcal/m2·h) or more • Sunload sensor
• A/C auto amp.
• Harness and connector
(Sunload sensor circuit is open, or
there is a short in the circuit)
B2631 SUNLOAD SEN (OPEN)
Detected calorie at sunload sensor 0 w/m
2
(0 kcal/m2·h)
+
−Voltage
(Approx.)
Sunload sensor
Connector Terminal M56 1 Ground 5 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

B2630, B2631 SUNLOAD SENSORHAC-67
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
3. Check continuity between sunload sensor harness connector M56 terminal 2 and A/C auto amp. harness
connector M152 terminal 26.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK SUNLOAD SENSOR
1. Reconnect sunload sensor connector and A/C auto amp. connector.
2. Check sunload sensor. Refer to HAC-67, "Component Inspection"
.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Replace sunload sensor. Refer to HAC-105, "Removal and Installation"
.
4.CHECK CONTINUITY BETWEEN SUNLOAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harness connector M56 terminal 1 and A/C auto amp. harness
connector M152 terminal 9.
4. Check continuity between sunload sensor harness connector M56 terminal 1 and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Repair harness or connector.
Component InspectionINFOID:0000000009463138
1.CHECK SUNLOAD SENSOR
1. Turn ignition switch ON.
2. Check voltage between A/C auto amp. harness connector and ground.
Sunload sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M56 2 M152 26 Yes
Sunload sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M56 1 M152 9 Yes
Sunload sensor —Continuity
Connector Terminal
M56 1 Ground No
(+) ( −)
A/C auto amp. —
Connector Terminal
M56 9 Ground
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-68
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2630, B2631 SUNLOAD SENSOR
NOTE:
Select a place in direct sunl ight when checking sunload sensor.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace sunload sensor. Refer to HAC-105, "Removal and Installation"
.
AWIIA1189GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
HAC-69
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
DTC LogicINFOID:0000000009463139
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON.
2. Using CONSULT, perform “SELF- DIAGNOSIS RESULTS” of HVAC.
3. Check if any DTC No. is displayed in the self-diagnosis results.
Is DTC detected?
YES >> Refer to HAC-69, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463140
Regarding Wiring Diagram information, refer to HAC-34, "Wiring Diagram".
1.CHECK AIR MIX DOOR MOTOR LH COMMUNICATION SIGNAL
1. Turn ignition switch ON.
2. Check output waveform between air mix door moto r LH harness connector and ground with the oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK INSTALLATION OF AIR MIX DOOR MOTOR LH
Check air mix door motor LH is properly installed. Refer to HAC-108, "Exploded View"
.
DTCItems
(CONSULT screen terms) DTC detection condition Possible cause
B2632
DR AIR MIX DOOR MOT Air mix door motor LH PBR position
95% or more • Air mix door motor LH
(PBR internal circuit is open or short-
ed)
• Air mix door motor LH installation con-
dition
• A/C auto amp.
• Harness and connector
(LIN communication line is open or
shorted)
B2633
Air mix door motor LH PBR position 5%
or less
+
−Output waveform
Air mix door motor LH
Connector Terminal
M128 3 Ground
SJIA1453J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-70
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2632, B2633 AIR MIX DOOR
MOTOR (DRIVER SIDE)
Is the inspection result normal?
YES >> Replace air mix door motor LH. Refer to HAC-109, "AIR MIX DOOR MOTOR : Removal and
Installation - Air Mix Door Motor (LH)".
NO >> Repair or replace malfunctioning part.
3.CHECK AIR MIX DOOR MOTOR LH COMMUNICATION SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect air mix door motor LH and A/C auto amp. connector.
3. Check continuity between air mix door motor LH harness connector and A/C auto amp. harness connec- tor.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Repair harness or connector.
Air mix door motor LH A/C auto amp. Continuity
Connector Terminal Connector Terminal
M128 3 M152 16 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
HAC-71
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
DTC LogicINFOID:0000000009463141
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON.
2. Using CONSULT, perform “SELF- DIAGNOSIS RESULTS” of HVAC.
3. Check if any DTC No. is displayed in the self-diagnosis results.
Is DTC detected?
YES >> Refer to HAC-71, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463142
Regarding Wiring Diagram information, refer to HAC-34, "Wiring Diagram".
1.CHECK AIR MIX DOOR MOTOR RH COMMUNICATION SIGNAL
1. Turn ignition switch ON.
2. Check output waveform between front air mi x door motor RH harness connector and ground with the
oscilloscope.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK INSTALLATION OF AIR MIX DOOR MOTOR RH
Check air mix door motor RH is properly installed. Refer to HAC-108, "Exploded View"
.
DTCItems
(CONSULT screen terms) DTC detection condition Possible cause
B2634
PASS AIR MIX DOOR MOT Air mix door motor RH PBR position
95% or more • Air mix door motor RH
(PBR internal circuit is open or short-
ed)
• Air mix door motor RH installation con-
dition
• A/C auto amp.
• Harness and connector
(LIN communication line is open or
shorted)
B2635
Air mix door motor RH PBR position
5% or less
+
−Output waveform
Air mix door motor RH
Connector Terminal
M129 3 Ground
SJIA1453J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
