NISSAN TEANA 2014 Service Manual

HAC-52
< BASIC INSPECTION >[AUTOMATIC AIR CONDITIONER]
ADDITIONAL SERVICE WHEN REPLACI
NG CONTROL UNIT (A/C AUTO AMP.)
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (A/C AUTO
AMP.)
DescriptionINFOID:0000000009463116
BEFORE REPLACEMENT
When replacing A/C auto amp., save or print current v ehicle specification with CONSULT configuration before
replacement.
NOTE:
If “Before Replace ECU” cannot be used, use the “After Replace ECU” or “Manual Configuration” after replac-
ing A/C auto amp.
AFTER REPLACEMENT
CAUTION:
• When replacing A/C auto amp., you must perform “After Replace ECU” with CONSULT.
- Complete the procedure of “After Replace ECU” in order.
- If you set incorrect “After Replace ECU”, incidents might occur.
- Configuration is different for each vehicle mode l. Confirm configuration of each vehicle model.
Work ProcedureINFOID:0000000009463117
1.SAVING VEHICLE SPECIFICATION
CONSULT
Enter "Re/Programming, Configuration" and perform “Before Replace ECU” to save or print current vehicle
specification.
NOTE:
If “Before Replace ECU” cannot be used, use the "After Replace ECU" or "Manual Configuration" after replac-
ing A/C auto amp.
>> GO TO 2.
2.REPLACE A/C AUTO AMP.
Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
>> GO TO 3.
3.WRITING VEHICLE SPECIFICATION
CONSULT
1. Enter "Re/Programming, Configuration".
2. If “Before Replace ECU” operation was performed, automatically an "Operation Log Selection" screen will
be displayed. Select the applicable file from the "S aved Data List" and press “Confirm” to write vehicle
specification. Refer to HAC-53, "Work Procedure"
.
3. If “Before Replace ECU” operation was not performed, select "After Replace ECU" or "Manual Configura-
tion" to write vehicle specification. Refer to HAC-53, "Work Procedure"
.
>> GO TO 4.
4.OPERATION CHECK
Check that the operation of the A/C auto amp. is normal.
>> Work End.
