NISSAN TEANA 2014 Service Manual

WATER PUMPCO-21
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
3. Remove fender protector side cover (RH). Refer to
EXT-26, "FENDER PROTECTOR : Removal and
Installation".
4. Remove engine under cover. Refer to EXT-17, "Removal and Installation"
.
5. Remove engine room cover. Refer to EXT-17, "Removal and Installation"
.
6. Remove front air duct. Refer to EM-84, "Removal and Installation"
.
7. Remove generator. Refer to CHG-32, "Removal and Installation"
.
8. Remove water pump bolts.
9. Remove the water pump and gasket, as necessary. CAUTION:
• Handle the water pump vane so that it does not contact any other parts.
• Water pump cannot be disassembled an d should be replaced as an assembly.
10. Remove water pipe, O-rings, water pump housing, and gasket.
INSPECTION AFTER REMOVAL
• Visually check that there is no significant dirt or rusting on the water pump body and vane.
• Check that there is no looseness in the vane shaft, and that it turns
smoothly when rotated by hand.
• If the water pump does not perform properly, replace the water pump assembly.
INSTALLATION
Installation is in the reverse order of removal.
• When inserting water pipe end to cylinder block, apply a mild soap to O-ring. Then insert it immediately.
CAUTION:
Do not reuse O-rings.
Do not reuse gasket.
INSPECTION AFTER INSTALLATION
• After installation refill engine coolant and check for leaks. Refer to CO-12, "Changing Engine Coolant" and
CO-11, "System Inspection"
.
ALBIA0939ZZ
Revision: November 20132014 Altima NAM

CO-22
< REMOVAL AND INSTALLATION >[QR25DE]
THERMOSTAT AND THERMOSTAT HOUSING
THERMOSTAT AND THERMOSTAT HOUSING
Exploded ViewINFOID:0000000009460399
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping from the radiator. Wrap a th ick cloth around the cap. Slowly push down and
turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down
and turning it all the way.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
Removal and InstallationINFOID:0000000009460400
REMOVAL
1. Drain engine coolant from the radiator. Refer to CO-12, "Changing Engine Coolant".
CAUTION:
Perform when the engine is cold.
2. Remove the core support cover clips (A), then remove the core support cover (1).
3. Remove the front air duct. Refer to EM-29, "Removal and Installation"
.
4. Remove engine under cover. Refer to EXT-17, "Removal and Installation"
.
5. Remove radiator hose (lower) from the water inlet side.
6. Remove exhaust manifold heat shield.
7. Remove water inlet and thermostat.
INSPECTION AFTER REMOVAL
1. Water inlet 2. Thermostat 3. Rubber ring
ALBIA0824GB
ALKIA2602ZZ
Revision: November 20132014 Altima NAM

THERMOSTAT AND THERMOSTAT HOUSINGCO-23
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
• Place a thread so that it is caught
in the valves of the thermostat.
Immerse fully in a container filled with water. Heat while stirring.
• The valve opening temperature is the temperature at which the
valve opens and the thermostat falls from the thread.
• Continue heating. Check the full-open lift amount. NOTE:
The full-open lift amount standard temperature for the thermostat is
the reference value.
• After checking the full-open lift amount, lower the water tempera-
ture and check the valve closing temperature.
• If valve setting at measured values are out of standard range, replace thermostat.
INSTALLATION
Installation is in the reverse order of removal.
• Install the thermostat with the whole circumference of the flange fit-
ting securely inside the rubber ring.
• Install the thermostat with the jiggle valve facing upwards. The
position deviation may be within the range of ±10 °.
• After installation, refill coolant and check for leaks. Refer to CO-
12, "Changing Engine Coolant" and CO-11, "System Inspection".
SLC252B
Thermostat Standard Values
Valve opening temperature Refer to CO-26, "Thermostat"
Full-open lift amount Refer to CO-26, "Thermostat"
Valve closing temperature Refer to CO-26, "Thermostat"
PBIC0157E
Revision: November 20132014 Altima NAM

CO-24
< REMOVAL AND INSTALLATION >[QR25DE]
WATER OUTLET AND WATER PIPING
WATER OUTLET AND WATER PIPING
Exploded ViewINFOID:0000000009460401
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping from the radiator. Wrap a th ick cloth around the cap. Slowly push down and
turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down
and turning it all the way.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
Removal and InstallationINFOID:0000000009460402
REMOVAL
1. Drain engine coolant from the radiator. Refer to CO-12, "Changing Engine Coolant".
CAUTION:
Perform when the engine cold.
1. Heater pipe 2. O-ring 3. Clamp
4. Water hose 5-9. Tightening order 10. Water outlet
11. O-ring 12. Water temp sensor
ALBIA0848GB
Revision: November 20132014 Altima NAM

WATER OUTLET AND WATER PIPINGCO-25
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
2. Remove the core support cover clips (A), then remove the core
support cover (1).
3. Remove air cleaner assembly and front air duct. Refer to EM-84, "Removal and Installation"
.
4. Remove the engine room cover. Refer to EM-28, "Removal and Installation"
.
5. Remove the upper radiator hose, heater pipe, electric throttle control actuator inlet hose, water hose, and
water temperature sensor.
6. Remove the water outlet, O-ring and gasket. CAUTION:
• Do not reuse O-ring.
• Do not reuse gasket.
• Do not reuse water outlet.
INSTALLATION
Installation is in the reverse order of removal.
• Install the engine coolant temperature sensor. Use Genuine RTV Silicone Seal ant or equivalent. Refer to GI-21, "Recommended Chemical Products
and Sealants".
• Install the heater pipe, first apply a mild soap to t he O-ring and quickly insert the heater pipe into the hous-
ing.
CAUTION:
• Do not reuse O-ring.
• Do not reuse gasket.
• Do not reuse water outlet.
• After installation, refill coolant and check for leaks. Refer to CO-12, "Changing Engine Coolant"
and CO-11,
"System Inspection".
CAUTION:
Do not spill coolant in engi ne compartment. Use a shop cloth to absorb coolant.
ALKIA2602ZZ
Revision: November 20132014 Altima NAM

CO-26
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
CapacityINFOID:0000000009460403
(US qt, Imp qt)
*Includes MAX-line quantity (0.75 L) of reservoir tank.
ThermostatINFOID:0000000009460404
RadiatorINFOID:0000000009460405
Unit: kPa (kg/cm2, psi)
Coolant capacity (With reservoir tank at MAX level) 7.9 (8-3/8, 7)*
Valve opening temperature 80.5 - 83.5
°C (177 - 182 °F)
Full-open lift amount More than 8 mm / 95 °C (0.315 in / 203 °F)
Valve closing temperature 77 °C (171 °F) or higher
Cap relief pressure Standard 127 ± 9.8 (1.30 ± 0.10, 18.4 ± 1.42)
Testing pressure 156 (1.6, 23)
Revision: November 20132014 Altima NAM

PRECAUTIONSCO-27
< PRECAUTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951690
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service t he system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Precaution for Liquid GasketINFOID:0000000009460407
REMOVAL OF LIQUID GASKET
• After removing the bolts and nuts, separate the mating surface and
remove the liquid gasket using Tool (A).
CAUTION:
Be careful not to damage the mating surfaces.
• In areas where the cutter is difficult to use, use a plastic hammer to lightly tap (1) the cutter where the liquid gasket is applied. Use a
plastic hammer to slide (2) the cutter by tapping on the side.
CAUTION:
Do not damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Using a scraper, remove the old liquid gasket adhering to the gasket application surface and the mating surface.
• Remove the liquid gasket completely from the groove of the
gasket application surface, mounting bolts, and bolt holes.
2. Thoroughly clean the gasket application surface and the mating surface and remove adhering moisture, grease and foreign
materials.
3. Attach the liquid gasket tube to the tube presser. Use Genuine Silicone RTV Seal ant or equivalent. Refer to
GI-21, "Recommended Chemical Products and Sealants"
.
Tool Number (A): KV10111100 (J-37228)
AWBIA1249GB
PBIC0003E
Revision: November 20132014 Altima NAM

CO-28
< PRECAUTION >[VQ35DE]
PRECAUTIONS
4. Apply the liquid gasket using suitable tool without breaks to the
specified location.
• If there is a groove for the liquid gasket application, apply the
liquid gasket to the groove.
• As for the bolt holes, normally apply the liquid gasket inside the holes. If specified, it should be applied outside the holes.
Make sure to read the text of this manual.
• Within five minutes of the liquid gasket application, install the mating component.
• If the liquid gasket protrudes, wipe it off immediately.
• Do not retighten after the installation.
• After 30 minutes or more have passed from the installation, fill the engine with the specified oil and coolant. Refer to MA-11,
"FOR USA AND CANADA : Fluids and Lubricants".
CAUTION:
If there are more specific instruct ions in the procedures contained in this manual concerning liquid
gasket applicatio n, observe them.
EMA0622D
SEM159F
Revision: November 20132014 Altima NAM

PREPARATIONCO-29
< PREPARATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009460408
The actual shapes of the tools may
differ from those illustrated here.
Commercial Service ToolINFOID:0000000009460409
Tool number
(TechMate No.)
Tool name Description
EG17650301
(J-33984-A)
Radiator cap tester adapter Adapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
K V 1 0 1111 0 0
(J-37228)
Seal cutter Removing chain tensioner cover and water
pump cover
KV991J0070
(J-45695)
Coolant Refill Tool Refilling engine cooling system
—
(J-23688)
Engine coolant refractometer Checking concentration of ethylene glycol in
engine coolant
S-NT564
NT046
LMA053
WBIA0539E
Revision: November 20132014 Altima NAM

CO-30
< PREPARATION >[VQ35DE]
PREPARATION
Tool name
Description
Power tool Loosening nuts, screws and bolts
Radiator cap tester Testing radiator cap
Tube pressure Pressing the tube of liquid gasket
PIIB1407E
PBIC1982E
S-NT052
Revision: November 20132014 Altima NAM
