< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0711 TRANSMISSION FLUID
TEMPERATURE SENSOR A
P0711 TRANSMISSION FLUID TEMPERATURE SENSOR A
DTC LogicINFOID:0000000009464045
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for atle-
ast 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch OFF and cool the engine.
2. Turn ignition switch ON. CAUTION:
Never start the engine.
3. Select “Data Monitor” in “TRANSMISSION”.
4. Select “FLUID TEMP”.
5. Record CVT fluid temperature.
6. Start the engine and wait for at least 2 minutes.
7. Drive the vehicle for the total minutes specified in the Driving time column below with the following condi-
tions satisfied.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0711 FLUID TEMP SENSOR A
(Transmission Fluid Tempera-
ture Sensor A Circuit Range/
Performance) When any of 1 or 2 is satisfied:
1. Under the following diagnosis conditions, CVT fluid temperature does not rise to 10 °C (50 °F)
after driving for a certain period of time with the
TCM-received fluid temperature sensor value
between − 40 °C ( −40 °F) and 9 °C (48.2 °F).
- TCM power supply voltage: More than 11 V
- CAN communication is normal
- Engine speed: 450 rpm or more
- Accelerator pedal position: 3 deg. or more
- Vehicle speed: 10 km/h (7 MPH) or more
- U0100, P0705 and P0706 are not detected.
- Selector lever: “D” position
2. When the condition of the final judgment is satisfied after satisfying that of the provisional
judgment:
- Provisional judgment: All of the following con- ditions are satisfied within 2 seconds after the
ignition switch is turned ON.
• U0073, U0100, P0712 and P0713 are not de-
tected.
• CAN communication is normal.
• TCM power supply voltage: More than 11 V
• The difference between CVT fluid temperature and engine coolant temperature is 55 °C
(131 °F) or more, or −27 °C ( −16 °F) or less.
- Final judgment: When all of the following con- ditions are satisfied and this state is main-
tained for 300 seconds:
•ECM is normal.
• Provisional judgment is satisfied. CVT fluid temperature sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0711 TRANSMISSION FLUID TEMPERATURE SENSOR A
TM-107
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
8. Stop the vehicle.
9. Check the first trip DTC.
With GST
1. Turn ignition switch OFF and cool the engine.
2. Start the engine and wait for at least 2 minutes.
3. Drive the vehicle and maintain the following conditions for 20 minutes or more.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0711” detected?
YES >> Go to TM-107, "Diagnosis Procedure".
NO >> GO TO 3.
3.CHECK CVT FLUID TEMPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check resistance between CVT unit connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperat ure sensor. Replace transaxle assembly. Refer to
TM-206, "Removal and Installation"
.
Diagnosis ProcedureINFOID:0000000009464047
1.CHECK CVT FLUID TEMPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check resistance between CVT unit connector terminals.
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
CVT fluid temperature before engine start Driving time
− 40 °C ( −40 °F) – −31 °C ( −23.8 °F) 20 minutes or more
− 30 °C ( −22 °F) – −21 °C ( −5.8 °F) 18 minutes or more
− 20 °C ( −4°F) – −11 °C ( −12.2 °F) 14 minutes or more
− 10 °C (14 °F) – −1 °C (30.2 °F) 10 minutes or more
0 °C (32 °F) – 9 °C (48.2 °F) 7 minutes or more
Other than the above —
(Go to 3.)
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
CVT unit Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °F) 6.5 k Ω
CVT fluid temperature: 50 °C (122 °F) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °F) 0.87 k Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

TM-108
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0711 TRANSMISSION FLUID
TEMPERATURE SENSOR A
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2. CHECK CIRCUIT BETWEEN TCM AND CVT UNIT (C VT FLUID TEMPERATURE SENSOR) (PART 1)
1. Disconnect the TCM connector.
2. Check continuity between TCM harness connector terminals and CVT unit harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3. CHECK CIRCUIT BETWEEN TCM AND CVT UNIT (C VT FLUID TEMPERATURE SENSOR) (PART 2)
Check continuity between TCM harness connector terminals and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace damaged parts.
4.CHECK TERMINAL CORD ASSEMBLY (PART 1)
1. Remove terminal cord assembly. Refer to TM-186, "Exploded View"
.
2. Check continuity between CVT unit harness connector terminals and control valve harness connector ter-
minals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK TERMINAL CORD ASSEMBLY (PART 2)
Check terminal cord assembly harness cladding for damage.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
CVT unit CVT unit ConditionResistance
(Approx.)
Connector Terminal
F209 16 – 17 CVT fluid temperature: 20
°C (68 °F) 6.5 k Ω
CVT fluid temperature: 50 °C (122 °F) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °F) 0.87 k Ω
TCM CVT unit
Continuity
Connector Terminal Connector Terminal
F16 11
F46 16
Existed
12 17
TCM Ground Continuity
Connector Terminal
F16 11
Ground Not existed
12
CVT unit Control valve Continuity
Connector Terminal Connector Terminal
F209 16
F207 13
Existed
17 5
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0711 TRANSMISSION FLUID TEMPERATURE SENSOR A
TM-109
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
6. CHECK DTC (TCM)
With CONSULT
1. Perform “DTC CONFIRMATION PROCEDURE”. Refer to TM-106, "DTC Logic"
.
2. Select “Self Diagnostic Results” in “TRANSMISSION”.
Is
“P0710” detected?
YES >> There is a malfunction of the CVT fluid tem perature sensor. Replace the transaxle assembly.
Refer to TM-206, "Removal and Installation"
.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
