NISSAN TERRANO 2002 Service Repair Manual

Wiring Diagram Ð TAIL/L Ð
LHD MODELS
YEL071D
EXTERIOR LAMP
EL-45

RHD MODELS
YEL072D
EXTERIOR LAMP
Wiring Diagram Ð TAIL/L Ð (Cont'd)
EL-46

YEL073D
EXTERIOR LAMP
Wiring Diagram Ð TAIL/L Ð (Cont'd)
EL-47

Wiring Diagram Ð STOP/L Ð
YEL074D
EXTERIOR LAMP
EL-48

Wiring Diagram Ð BACK/L Ð
LHD MODELS
YEL075D
EXTERIOR LAMP
EL-49

RHD MODELS
YEL076D
EXTERIOR LAMP
Wiring Diagram Ð BACK/L Ð (Cont'd)
EL-50

Wiring Diagram Ð F/FOG Ð
LHD MODELS
YEL077D
EXTERIOR LAMP
EL-51

RHD MODELS
YEL078D
EXTERIOR LAMP
Wiring Diagram Ð F/FOG Ð (Cont'd)
EL-52

Front Fog Lamp Aiming Adjustment
When performing fog lamp aiming adjustment, use an aiming
machine, aiming wall screen or headlamp tester. The aimer should
be in good operational condition, calibrated and used according to
the relevant operation manuals supplied with the unit.
If an aimer is not available, aiming adjustment can be done as fol-
lows:
For details, refer to the regulations in your own country.
CAUTION:
IKeep all tires inflated to correct pressures.
IPlace vehicle and tester on one and the same flat surface.
IEnsure that there is no-load in the vehicle other than
coolant, engine oil (filled up to correct level), full fuel tank
and the driver (or equivalent weight placed in driver's posi-
tion).
For details of front fog lamp aiming adjustment, refer to ªAiming
Adjustmentº, EL-43.
Check the distance between the vehicle and the ground illumina-
tion point of the main axis of the fog lamp beam. Keep the distance
to approximately 40 m (131 ft).
NEL331
EXTERIOR LAMP
EL-53

Wiring Diagram Ð R/FOG Ð
YEL079D
EXTERIOR LAMP
EL-54
