NISSAN TIIDA 2007 Service Repair Manual

AV-126
< ON-VEHICLE REPAIR >[AUDIO WITH NAVIGATION]
STEERING SWITCH
STEERING SWITCH
Removal and InstallationINFOID:0000000001724705
For removal and installation, refer to AV-27, "Removal and Installation".

AV
GPS ANTENNA
AV-127
< ON-VEHICLE REPAIR >[AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
GPS ANTENNA
Removal and InstallationINFOID:0000000001724706
AUDIO UNIT
Removal
1. Remove cluster lid C. Refer to IP-11, "Removal and Installation".
2. Remove the GPS antenna screw (A), detach the GPS antenna
harness clip.
3. Remove the center console. Refer to IP-11, "
Removal and Installation".
4. Disconnect the GPS antenna connector (A) and remove the
GPS antenna.
Installation
Installation is in the reverse order of removal.
ALNIA0864ZZ
ALNIA0865ZZ

AV-128
< ON-VEHICLE REPAIR >[AUDIO WITH NAVIGATION]
DISPLAY UNIT
DISPLAY UNIT
Removal and InstallationINFOID:0000000001724707
AUDIO UNIT
Removal
1. Remove the AV (NAVI) control unit. Refer to AV-23, "Removal
and Installation".
2. Remove the AV (NAVI) control unit bracket screws (A), remove
the display unit screws (B), then remove the display unit brack-
ets (2) and remove the display unit (1).
Installation
Installation is in the reverse order of removal.
ALNIA0866ZZ

AV
MICROPHONE
AV-129
< ON-VEHICLE REPAIR >[AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
MICROPHONE
Removal and InstallationINFOID:0000000001724710
BLUETOOTH MICROPHONE
Removal
1. Remove over-head console assembly, roof finisher. Refer to INL-25, "Removal and Installation".
2. Remove the Bluetooth microphone Screw (A), then release the
Bluetooth microphone tabs and remove the Bluetooth micro-
phone (1).
Installation
Installation is in the reverse order of removal.
ALNIA0867ZZ

AV-130
< ON-VEHICLE REPAIR >[AUDIO WITH NAVIGATION]
NAVI CONTROL UNIT
NAVI CONTROL UNIT
Removal and InstallationINFOID:0000000001724711
NAVI CONTROL UNIT
Removal
CAUTION:
To avoid damage, eject map DVD-ROM before removing the NAVI control unit.
1. Disconnect the negative battery terminal.
2. Remove the front seat RH. Refer to SE-14, "
Removal and Installation".
3. Remove the NAVI control unit kick shield clips (A), then remove
the NAVI control unit kick shield (1).
4. Disconnect the NAVI control unit connectors (A) and the Blue-
tooth connector (B).
5. Remove the NAVI control unit bolts (C), then remove the NAVI
control unit (1).
6. Remove the NAVI control unit bracket screws and remove the
NAVI control unit brackets.
Installation
Installation is in the reverse order of removal.
ALNIA0873ZZ
ALNIA0874ZZ

BCS
BCS-1
ELECTRICAL & POWER CONTROL
C
D
E
F
G
H
I
J
K
L B
SECTION BCS
A
O
P N
CONTENTS
BODY CONTROL SYSTEM
BASIC INSPECTION ....................................3
INSPECTION AND ADJUSTMENT .....................3
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT ..........................................................
3
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Description ..................................
3
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Special Repair Requirement .......
3
CONFIGURATION .......................................................3
CONFIGURATION : Description ...............................3
CONFIGURATION : Special Repair Requirement ......4
FUNCTION DIAGNOSIS ...............................7
BODY CONTROL SYSTEM ................................7
System Description ...................................................7
Component Parts Location ........................................8
COMBINATION SWITCH READING SYSTEM
.....
9
System Diagram ........................................................9
System Description ...................................................9
Component Parts Location ......................................12
SIGNAL BUFFER SYSTEM ...............................13
System Diagram ......................................................13
System Description .................................................13
POWER CONSUMPTION CONTROL SYS-
TEM ....................................................................
14
System Diagram ......................................................14
System Description .................................................14
Component Parts Location ......................................15
DIAGNOSIS SYSTEM (BCM) ............................16
COMMON ITEM .........................................................16
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .....................................................
16
BCM ...........................................................................16
BCM : CONSULT-III Function (BCM - BCM) ...........17
DOOR LOCK ..............................................................17
DOOR LOCK : CONSULT-III Function (BCM -
DOOR LOCK) ..........................................................
17
REAR WINDOW DEFOGGER ...................................18
REAR WINDOW DEFOGGER : CONSULT-III
Function (BCM - REAR DEFOGGER) .....................
18
BUZZER .....................................................................18
BUZZER : CONSULT-III Function (BCM - BUZZ-
ER) ..........................................................................
18
INT LAMP ...................................................................19
INT LAMP : CONSULT-III Function (BCM - INT
LAMP) ......................................................................
19
MULTIREMOTE ENT .................................................19
MULTIREMOTE ENT : CONSULT-III Function
(BCM - MULTIREMOTE ENT) .................................
19
HEADLAMP ...............................................................20
HEADLAMP : CONSULT-III Function (BCM -
HEAD LAMP) ...........................................................
20
WIPER ........................................................................21
WIPER : CONSULT-III Function (BCM - WIPER) ....21
FLASHER ...................................................................22
FLASHER : CONSULT-III Function (BCM -
FLASHER) ...............................................................
22
AIR CONDITIONER ...................................................23
AIR CONDITIONER : CONSULT-III Function
(BCM - AUTO AIR CONDITIONER) ........................
23
INTELLIGENT KEY ....................................................23
INTELLIGENT KEY : CONSULT-III Function
(BCM - INTELLIGENT KEY) ....................................
23
COMB SW ..................................................................24

BCS-2
COMB SW : CONSULT-III Function (BCM -
COMB SW) .............................................................
24
IMMU .........................................................................24
IMMU : CONSULT-III Function (BCM - IMMU) .......24
BATTERY SAVER ....................................................25
BATTERY SAVER : CONSULT-III Function (BCM
- BATTERY SAVER) ..............................................
25
THEFT ALM ..............................................................26
THEFT ALM : CONSULT-III Function (BCM -
THEFT ALM) ..........................................................
26
SIGNAL BUFFER ......................................................26
SIGNAL BUFFER : CONSULT-III Function (BCM
- SIGNAL BUFFER) ................................................
26
PTC HEATER ............................................................26
PTC HEATER : CONSULT-III Function (BCM -
PTC HEATER) ........................................................
26
COMPONENT DIAGNOSIS ........................28
U1000 CAN COMM CIRCUIT ............................28
Description ..............................................................28
DTC Logic ...............................................................28
Diagnosis Procedure ..............................................28
U1010 CONTROL UNIT (CAN) .........................29
DTC Logic ...............................................................29
Diagnosis Procedure ..............................................29
Special Repair Requirement ...................................29
POWER SUPPLY AND GROUND CIRCUIT .....30
Diagnosis Procedure ..............................................30
COMBINATION SWITCH INPUT CIRCUIT .......31
Diagnosis Procedure ..............................................31
Special Repair Requirement ...................................32
COMBINATION SWITCH OUTPUT CIRCUIT ...33
Diagnosis Procedure ...............................................33
Special Repair Requirement ...................................33
COMBINATION SWITCH ..................................34
Description ..............................................................34
Diagnosis Procedure ...............................................34
ECU DIAGNOSIS .......................................35
BCM (BODY CONTROL MODULE) ..................35
Reference Value .....................................................35
Terminal Layout ......................................................38
Physical Values .......................................................39
Wiring Diagram .......................................................50
DTC Inspection Priority Chart ...............................53
DTC Index ..............................................................54
SYMPTOM DIAGNOSIS ............................55
COMBINATION SWITCH SYSTEM SYMP-
TOMS .................................................................
55
Symptom Table .......................................................55
PRECAUTION ............................................56
PRECAUTIONS .................................................56
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................
56
ON-VEHICLE REPAIR ...............................57
BCM (BODY CONTROL MODULE) ..................57
Removal and Installation of BCM ............................57

BCS
INSPECTION AND ADJUSTMENT
BCS-3
< BASIC INSPECTION >
C
D
E
F
G
H
I
J
K
L B A
O
P N
BASIC INSPECTION
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description
INFOID:0000000001451449
When replacing BCM, save or print current vehicle specification with CONSULT-III configuration before
replacement.
Configuration has three functions as follows
• READ CONFIGURATION is the function to read (extract) vehicle configuration of current BCM.
 WRITE CONFIGURATION - Manual selection is the function to select and write vehicle configuration on
BCM manually.
 WRITE CONFIGURATION - Config file is the function to write vehicle configuration with the data extracted
from current BCM.
CAUTION:
• When replacing BCM, you must perform WRITE CONFIGURATION with CONSULT-III.
 Complete the procedure of WRITE CONFIGURATION in order.
 If you set incorrect WRITE CONFIGURATION, incidents will occur.
 Configuration is different for each vehicle model. Confirm configuration of each vehicle model.
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Re-
quirement
INFOID:0000000001451450
1. SAVING VEHICLE SPECIFICATION
Perform “READ CONFIGURATION” with CONSULT-III to save or print current vehicle specification.
>> GO TO 2
2. REPLACE BCM
Replace BCM. Refer to BCS-57, "
Removal and Installation of BCM".
>> GO TO 3
3. WRITING VEHICLE SPECIFICATION
Perform “WRITE CONFIGURATION - Config file” or “WRITE CONFIGURATION - Manual selection” with
CONSULT-III to write vehicle specification. Refer to BCS-4, "
CONFIGURATION : Special Repair Require-
ment".
>> GO TO 4
4. INITIALIZE BCM (NATS)
Perform BCM initialization. (NATS)
>> WORK END
CONFIGURATION
CONFIGURATION : DescriptionINFOID:0000000001451451
Vehicle specification needs to be written with CONSULT-III because it is not written after replacing BCM.
Configuration has three functions as follows
 READ CONFIGURATION is the function to read (extract) vehicle configuration of current BCM.
 WRITE CONFIGURATION - Manual selection is the function to select and write vehicle configuration on
BCM manually.
 WRITE CONFIGURATION - Config file is the function to write vehicle configuration with the data extracted
from current BCM.
CAUTION:

BCS-4
< BASIC INSPECTION >
INSPECTION AND ADJUSTMENT
 When replacing BCM, you must perform WRITE CONFIGURATION with CONSULT-III.
 Complete the procedure of WRITE CONFIGURATION in order.
 If you set incorrect WRITE CONFIGURATION, incidents will occur.
 Configuration is different for each vehicle model. Confirm configuration of each vehicle model.
CONFIGURATION : Special Repair RequirementINFOID:0000000001451452
1. WRITING VEHICLE SPECIFICATION
Perform “WRITE CONFIGURATION” with CONSULT-III.
When writing saved data>>GO TO 2
When writing manually>>GO TO 3
2. PERFORM “WRITE CONFIGURATION - CONFIG FILE”
Perform “WRITE CONFIGURATION - Config file” with CONSULT-III.
>> WORK END
3. PERFORM “WRITE CONFIGURATION - MANUAL SELECTION”
For “WRITE CONFIGURATION - Manual selection”, using the following flow chart, identify the correct model
and configuration list.
Confirm and/or change setting value for each item according to the configuration list.
Depending on CONSULT-III software version being used, some or all of the write configuration items shown in
the following configuration lists may be displayed. If an item does not display on the CONSULT-III “WRITE
CONFIGURATION - Manual selection” screen, then it is an auto setting item and it cannot be manually set or
changed.
 Gasoline engine models (RHD)
 Gasoline engine models (LHD)
MANUAL SETTING ITEM
Items Setting value
HANDLE RHD
PTC HEATER WITHOUT
AUTO LIGHT WITH⇔WITHOUT
KEYLESS ENTRY WITH⇔WITHOUT
DTRL WITHOUT
THEFT ALARM WITH⇔WITHOUT
AUTO SETTING ITEM
RAIN SENSOR WITH or WITHOUT
H/L WSR SWTRG FR WSR SW
H/L_BULB H4 HALOGEN or DEFAULT
FR FOG LAMP WITH or WITHOUT
DONGLE WITH or WITHOUT
SUPER LOCK WITH
I-KEY WITH or WITHOUT
DOOR/L SPEED WITH
H/L BAT SAVER WITH
KEY WARNING MODE1
R LAMP LOGIC MODE2

BCS
INSPECTION AND ADJUSTMENT
BCS-5
< BASIC INSPECTION >
C
D
E
F
G
H
I
J
K
L B A
O
P N
 Diesel engine models (RHD)
 Diesel engine models (LHD)
MANUAL SETTING ITEM
Items Setting value
HANDLE LHD
PTC HEATER WITHOUT
AUTO LIGHT WITH⇔WITHOUT
KEYLESS ENTRY WITH⇔WITHOUT
DTRL WITH⇔WITHOUT
THEFT ALARM WITHOUT
AUTO SETTING ITEM
RAIN SENSOR WITH or WITHOUT
H/L WSR SWTRG FR WSR SW
H/L_BULB H4 HALOGEN or DEFAULT
FR FOG LAMP WITH or WITHOUT
DONGLE WITH or WITHOUT
SUPER LOCK WITHOUT
I-KEY WITH or WITHOUT
DOOR/L SPEED WITH
H/L BAT SAVER WITH
KEY WARNING MODE1
R LAMP LOGIC MODE2
MANUAL SETTING ITEM
Items Setting value
HANDLE RHD
PTC HEATER WITHOUT
AUTO LIGHT WITH⇔WITHOUT
KEYLESS ENTRY WITH⇔WITHOUT
DTRL WITHOUT
THEFT ALARM WITH⇔WITHOUT
AUTO SETTING ITEM
RAIN SENSOR WITH or WITHOUT
H/L WSR SWTRG FR WSR SW
H/L_BULB H4 HALOGEN or DEFAULT
FR FOG LAMP WITH or WITHOUT
DONGLE WITH or WITHOUT
SUPER LOCK WITH
I-KEY WITH or WITHOUT
DOOR/L SPEED WITH
H/L BAT SAVER WITH
KEY WARNING MODE1
R LAMP LOGIC MODE2
