NISSAN TIIDA 2007 Service Repair Manual

DLK-62
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector (A) M18 terminals 6,
25 and door lock and unlock switch connector (B) D7 terminal 6,
connector (C) D8 terminal 18.
4. Check continuity between BCM connector (A) M18 terminals 6, 25 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
3.CHECK DOOR LOCK AND UNLOCK SWITCH GROUND
Check continuity between main power window and door lock/unlock
switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
ALKIA0738ZZ
BCM connector TerminalDoor lock and unlock
switch connectorTerminal Continuity
M186D8 18
Ye s
25 D7 6
BCM connector Terminal
GroundContinuity
M186
No
25
LIIA0392E
Main power window and door lock/unlock
switch connectorTe r m i n a l
GroundContinuity
D8 17 Yes

DOOR LOCK AND UNLOCK SWITCH
DLK-63
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check signal between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHECK DOOR LOCK AND UNLOCK SWITCH
Check door lock and unlock switch
Refer to DLK-63, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace door lock and unlock switch. Refer to XX-XX, "*****"
.
6.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Component InspectionINFOID:0000000001396523
1.CHECK DOOR LOCK AND UNLOCK SWITCH
Check continuity between main power window and door lock/unlock
switch terminals.
ALKIA0739ZZ
Te r m i n a l
Signal
(Reference value) (+)
(–)
BCM connector Terminal
M186
Ground
25
JPMIA0154GB
ALKIA0740ZZ

DLK-64
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Replace main power window and door lock/unlock switch. Refer to XX-XX, "*****"
.
Door lock and unlock switch Terminals Condition Continuity
D7, D86
17UNLOCK Yes
NEUTRAL/LOCK No
18LOCK Yes
NEUTRAL/UNLOCK No

DOOR SWITCH
DLK-65
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001396536
Detects door open/closed condition.
DRIVER SIDE : Component Function CheckINFOID:0000000001396537
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-DR” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-65, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000001396538
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
Monitor item Condition
DOOR SW-DR OPEN :ON
CLOSE :OFF
ALKIA0745ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M18 29 GroundOPEN 0
CLOSE
JPMIA0011GB

DLK-66
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
DOOR SWITCH
1. Disconnect BCM and driver door switch connectors.
2. Check continuity between BCM connector (A) M18 terminal 29
and door switch connector (B) B34 terminal 2.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-66, "
DRIVER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front door switch (driver side). Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
DRIVER SIDE : Component InspectionINFOID:0000000001396539
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check door switch.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace front door switch (driver side). Refer to XX-XX, "*****"
.
PASSENGER SIDE
BCM connector TerminalDoor switch
connectorTerminal Continuity
M18 29 B34 2 Yes
BCM connector Terminal
GroundContinuity
M18 29 No
ALKIA0746ZZ
ALKIA0747ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
2 Ground part of door switchPressed Yes
Released No

DOOR SWITCH
DLK-67
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
PASSENGER SIDE : DescriptionINFOID:0000000001396540
Detects door open/closed condition.
PASSENGER SIDE : Component Function CheckINFOID:0000000001396541
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-AS” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-67, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000001396542
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM and passenger door switch connectors.
Monitor item Condition
DOOR SW-ASOPEN : ON
CLOSE : OFF
ALKIA0749ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M18 30 GroundOPEN 0
CLOSE
JPMIA0011GB

DLK-68
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
DOOR SWITCH
2. Check continuity between BCM connector (A) M18 terminal 30
and passenger door switch connector (B) B27 terminal 2.
3. Check continuity between BCM connector (A) M18 terminal 30
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-68, "
PASSENGER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
PASSENGER SIDE : Component InspectionINFOID:0000000001396543
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check passenger door switch.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****"
.
REAR LH
BCM connector TerminalDoor switch
connectorTerminal Continuity
M18 30 B27 2 Yes
BCM connector Terminal
GroundContinuity
M18 30 No
ALKIA0748ZZ
ALKIA0747ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
2 Ground part of door switchPressed Yes
Released No

DOOR SWITCH
DLK-69
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR LH : DescriptionINFOID:0000000001396544
Detects door open/closed condition.
REAR LH : Component Function CheckINFOID:0000000001396545
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-RL” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-69, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000001396546
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector and rear door switch LH.
Monitor item Condition
DOOR SW-RLOPEN :ON
CLOSE :OFF
ALKIA0750ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M19 59 GroundOPEN 0
CLOSE
JPMIA0011GB

DLK-70
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
DOOR SWITCH
2. Check continuity between BCM connector (A) M19 terminal 59
and rear door switch LH connector (B) B71 terminal 1.
3. Check continuity between BCM connector (A) M19 terminal 59
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and rear door switch LH.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-70, "
REAR LH : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear door switch LH. Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
REAR LH : Component InspectionINFOID:0000000001396547
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check rear door switch LH.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace rear door switch LH. Refer to XX-XX, "*****"
.
REAR RH
BCM connector TerminalRear door switch LH
connectorTerminal Continuity
M19 59 B71 1 Yes
BCM connector Terminal
GroundContinuity
M19 59 No
ALKIA0751ZZ
ALKIA0752ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
1Ground part of door
switchPressed Yes
Released No

DOOR SWITCH
DLK-71
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR RH : DescriptionINFOID:0000000001396548
Detects door open/close condition.
REAR RH : Component Function CheckINFOID:0000000001396549
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-RR” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-71, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000001396550
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
Monitor item Condition
DOOR SW-RROPEN :ON
CLOSE :OFF
ALKIA0754ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M19 60 GroundOPEN 0
CLOSE
JPMIA0011GB
