Page 81 of 128
YOUR 206 CC IN DETAIL77
Windscreen wash Pull the wipers stalk towards you.
The windscreen wash, then the wind- screen wipers, operate for a fixed period.
Operation In position
1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, then resumesits initial speed when the vehicle startsagain. In the Intermittent position, the wiping
speed is proportional to the speed of the vehicle.
In the AUTO position, the wiping
speed is proportional to the heaviness of the rain fall.
When the ignition has been switched off for more than oneminute with the stalk in the wipeposition, it is necesary to reactivatethis function. To do this, move the
stalk to any position, then move it backto the required position.
WINDSCREEN WIPER
STALK Stalk with intermittent wipe Front windscreen wiper
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
I Intermittent wipe.
0 Off.
Single wipe (press down- wards). Stalk with automatic wipe Front windscreen wiper
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.
Single wipe (press down- wards).
07-10-2002
Page 82 of 128
YOUR 206 CC IN DETAIL
78
07-10-2002
Automatic timed windscreen wipers In the
AUTO position, the windscreen
wipers operate automatically and adapt their speed to the intensity ofthe rainfall. Operating checkActivation When the function is activated, the message "Automatic windscreen
wiping active" appears on the multi-
function display. In the event of malfunction , the dri-
ver is informed by an audible signal and the message "Auto windscreen
wiper faulty" on the multifunction
display. In the event of malfunction in the
AUTO position, the windscreen wiper
will operate in intermittent mode.
Contact a PEUGEOT dealer to have the system checked. When using an automaticcar wash, switch off theignition or check that thewiper stalk is not in theautomatic position.
In winter it is advisable to wait for thewindscreen to completely clear ofice before operating the automaticwipe.
Page 83 of 128
YOUR 206 CC IN DETAIL79
TRIP COMPUTER
Pressing the button on the end of the wash/wipe stalkenables the following data to be
displayed:
Display B
Ð the range
Ð the distance travelled
Ð the average consumption
Ð the current consumption
Ð the average speed Zero reset Press the stalk for more than two seconds. Display C
Ð the current consumption and the range,
Ð the average consumption, the distance travelled and the
average speed calculated over a period "1",
Ð the average consumption, the distance travelled and the average speed calculated over a period "2".
Periods "1"and "2"are defined by the frequency of the
zero reset. They allow, for instance, daily calculations over period "1"and monthly calculations over period "2".
Zero reset When the required period is displayed, press the stalk for more than two seconds.
07-10-2002
Page 84 of 128
YOUR 206 CC IN DETAIL
80
Range The display shows the distance that can still be covered with the fuelremaining in the tank. Note:
this figure may rise if there is
a change in driving style or road sur- face, causing a significant drop incurrent fuel consumption. If there are less than 3 litres of fuel in the tank, only three segments willbe displayed.
Current fuel consumption This gives the fuel consumption recorded during the last two sec-
onds. This function is only dislpayedwhen the vehicle is travelling atmore than 12 m.p.h. (20 km/h). Average consumption This is the ratio between the amount of fuel consumed and the distancetravelled since the computer waslast reset to zero.
Average speed This is obtained by dividing the dis- tance travelled by the period of timethe vehicle has been in use (with theignition on), since the computer waslast reset to zero. Distance travelled This shows the distance travelled since the computer was last reset tozero. After the trip computer has been reset to zero, the range data becomesmeaningful only after the vehicle hasbeen in use for a certain period. If horizontal segments are displayed instead of figures when driving, contact
a PEUGEOT dealer.
07-10-2002
Page 85 of 128
YOUR 206 CC IN DETAIL81
ELECTRIC WINDOWS
1. DriverÕs electric window switch.
2. PassengerÕs electric window
switch.
Each switch controls, on its own side, the front window and the rear quarter
panel window. Manual operation Press the switch (to open) or pull it (to close) without going beyond thepoint of resistance. The window stops when the switch is released. The rear quarter panel window can only be opened when the front win-dow is completely open, after aninactive period of one second. Automatic operation
Opening
The windows open automatically(when the ignition key is in the ÔonÕposition, with the engine running orthe vehicle moving).
Press the switch past the point ofresistance:
Ð Press briefly to completely open the front window; press brieflyagain to completely open the
rear quarter panel window,
Ð Sustained pressure opens the front window, then the rear
quarter panel, completely.
Closing
Only the front window on the driverÕsside closes automatically (enginerunning or vehicle moving), whenthe rear quarter panel is closed.
Briefly pull the switch past thepoint of resistance to completely
close the driverÕs front window.
Note: the window switches do not func-
tion while the roof is being operated.
07-10-2002
Page 86 of 128
07-10-2002
YOUR 206 CC IN DETAIL
82
Manual interior mirror The interior mirror has two positions:
Ð day (normal),
Ð night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower edge of
the mirror. ELECTRIC EXTERIOR MIRRORS
Turn knob
1to the right or to the left to
select the corresponding mirror. Move knob 1in all four directions to
adjust. Fold-back electric mirrors With the ignition on, turn knob 1to
position A.
The outside of the mirror on the driver's side is con-vex (area at edge definedby dotted line) in order to
eliminate the 'blind spot'. Furthermore, objects in the driver's and passenger's mirrors are in
reality closer than they appear. This must be taken into account to judge correctly the distance ofvehicles approaching from behind.
Page 87 of 128
07-10-2002
YOUR 206 CC IN DETAIL83
Headlamp adjustment
Depending on the load in your vehicle, adjusting the beam of the headlamps isrecommended as follows.
0.
1 or 2 people in the front seats.
Ð. 3 people.
1. 4 people.
2. 4 people + maximum authorisedload.
3. Driver + maximum authorised load.
Initial setting is position 0. STEERING WHEEL HEIGHTADJUSTMENT
When stationary, lower the handle to unlock the steering wheel. Adjust to the desired height and lift the handle to lock the steering wheel.
HORN
Press one of the spokes orthe centre of the steeringwheel.
Page 88 of 128
YOUR 206 CC IN DETAIL
84
AREAS FOR TOLL
CARDS/CAR PARK TICKETS The athermic windscreen has two non-reflective zones located either
side of the base of the interior mirror.
They are intended for affixing toll cards and/or car park tickets.
COURTESY LIGHT
Lights when one of the doorsis opened. In this position thecourtesy light flashes whenthe vehicle is moving, if a dooris not correctly closed.
Off Permanently on when the igni- tion key is in the accessoriesposition or the ignition is on. SUN VISOR The sun visors are fitted with a vanity
mirror, with a concealing flap on thedriver's side. FRONT ASHTRAY
To empty, close the cover. Pull the lug and release the ashtray upwards.
LIGHTER Press and wait a few minutes until it
springs out automatically. It is supplied with power with the igni- tion key in the accessories position(1 st
notch).
07-10-2002
Page 89 of 128
YOUR 206 CC IN DETAIL85
GLOVE COMPARTMENT The glove compartment is fitted with a lock.
To open the glove compartment, lift the handle. The light comes on when the lid is opened. 1.
Vehicle document folder storage
2. Can holder
3. Pen holder
4. Spectacles storage
5. Map storage
6. Coin storage BOTTLE HOLDER
A bottle holder is fitted between the two rear seat backs.
To open it, pull the top of the cover.LASHING RINGS Use the 4 lashing rings on the lug- gage compartment floor to secureyour luggage.
LUGGAGE RETAINING NET Hooked onto the lashing rings, this enables you to secure your luggage.
07-10-2002
Page 90 of 128
07-10-2002
YOUR 206 CC IN DETAIL
86
AUTOMATIC AUTOADAPTIVE GEARBOX Moving Off
To move off, move the selector lever to position
Nor P. Press the brake to exit
position P. Stopped or parked Always leave the lever in position Pwhen you get out of your vehicle.
If not, a buzzer will sound when you open the driver's door. Positions of the selector lever These positions are displayed on the instrument panel. P. Park: use with the handbrake.
R. Reverse: this must only be engaged when the vehicle is stationary, engine at idle.
N. Neutral: if Nis engaged by mistake while the car is moving, allow the engine
to return to idle before engaging a new forward gear.
D. Drive: in this position, the four gears change automatically. The gear change
points vary depending on the programme selected.
3. Automatic changing of the first three gears only. Select this position when you notice frequent changes between third and fourth gear (town driving or on winding roads).
2. Automatic changing of the first two gears only. This position is particularly suitable for mountain roads, when going uphill (to make the best use of the engine's power) and downhill (engine braking).
