PEUGEOT 206 CC DAG 2002 Owners Manual

PRACTICAL ASPECTS OF YOUR VEHICLE99
Refitting the wheel
After positioning the wheel, pre-tighten the bolts using the wheelbrace 1.
 Compress the jack 3and release it.
 Fully tighten the bolts using the wheelbrace 1.
 Replace the wheel trim, starting at the valve passage hole, and press on it using the palm of the hand.
Replace the shim and the jack in their bag, then store the tools in the boot.For your safety, always change the wheel:
Ð on level, stable and non- slippery ground,
Ð with the handbrake applied and the ignition switched off,
Ð with the first or reverse gear engaged (position Pfor the auto-
matic gearbox),
Ð with the vehicle chocked using a shim.
Never go underneath a vehicle which is supported only by a jack(use an axle stand) .
After changing the wheel:
Ð As soon as possible contact a PEUGEOT dealer to check that the wheel bolts are tight.
07-10-2002

PRACTICAL ASPECTS OF YOUR VEHICLE
100
SPECIAL FEATURES OF ALLOY WHEELS Bolt covers The bolts on the alloy wheels are cov- ered with chrome-plated trim caps. Remove them using the yellow tool
4
before slackening the bolts. Refitting the spare wheel* If your vehicle is fitted with a metal spare wheel, when fitting the wheel itis
normal to notice that the bolt wash-
ers do not come into contact with the
wheel. The spare wheel is held inplace by the conical support of eachbolt. Fitting snow tyres If your vehicle has tyres fitted to steel wheels, it is essentialto use special
bolts available from a PEUGEOT
dealer. Wheel anti-theft bolts* If your wheels are fitted with anti-theft bolts (one per wheel), the chrome-plated trim cap and then the plasticcover on the wheel must be removed,using tool
4, before slackening the bolt
using one of the anti-theft sockets(handed to you along with the dupli-cate keys and the confidential card ondelivery of your vehicle) and thewheelbrace 1.
Note: take a careful note of the code
number engraved on the top of the
anti-theft socket. This will enable youto obtain a duplicate anti-theft socket
from a PEUGEOT dealer.
* According to model and destination.
07-10-2002

07-10-2002
PRACTICAL INFORMATION101
Ð Pull tab
Aupwards and remove the protective cover.
Ð Disconnect the connector.
Ð Press the end of the securing clip to remove it. Change the faulty bulb.
Ð On fitting, ensure that the direction notches are in the cor- rect position and that the clip is secured correctly.
Ð Reconnect the connector.
Ð Replace the protective cover.
CHANGING A BULB Dipped/main headlamps H7 55 WSide lights W 5 W
Turn the pin connector Ba quarter turn and remove it.
Change the bulb.
Remarks
Ð Only touch the bulbs with a dry cloth.
Ð To replace the bulbs on the right side, remove the wash-wipe reservoir filler pipe first.
Ð Condensation may form inside the headlamps. It will disappear when they are used.

07-10-2002
PRACTICAL INFORMATION
102
Amber direction indicators
PY 21 W
Turn the pin connector
Ca quarter turn
and remove it. Change the bulb. Amber direction indicator side
repeater WY 5 W Push the repeater forwards or back-
wards and release the assembly. Hold the connector and turn the trans- parent cover a quarter turn. Change the bulb.
Use only H7 bulbs of brands:
Ð GE/TUNGSRAM,
Ð PHILIPS,
Ð OSRAM,
to avoid damaging the headlamps.These comply with the anti-UV (ultraviolet) specifications neces-sary for the correct operation andreliability of the headlamps. The headlamps are fitted with polycarbon glass with a protective
coating. We strongly adviseagainst cleaning them using a dryor abrasive cloth or using deter-gents or solvents. Use a soft, damp cloth.

07-10-2002
PRACTICAL INFORMATION103
Rear lights Release the top of the boot side trim. Unscrew the wing bolt inside the boot
using the wheelbrace if necessary. Disconnect the connector
A.
Release the light unit.Release spanner B from the bulb holder.
Unscrew nut Cusing spanner B and
removet the bulb holder. Change the faulty bulb.When refitting, stow spanner B on
support D and refit the light.
1. Amber direction indicators
PY 21 W.
2. Reversing lights P 21 W.
3. Brake lights/side lights P 21/5 W.Front fog lamps H1 55 W Press underneath the access flap to release it. Open the flap.
Turn the cover to remove it.Disconnect the bulb.Pinch both ends of the securing clip to release the bulb.
The "amber" bulbs must bereplaced by bulbs of identi-
cal specification and colour.

07-10-2002
PRACTICAL INFORMATION
104
Rear fog lamp P 21 W Unclip the lamp and release the
assembly.
Turn the pin connector a quarter turn and remove it. Change the bulb. Number plate lights W 5 W Insert a thin screwdriver into one of the
exterior holes of the transparent cover. Push it outwards to unclip it.
Remove the transparent cover.Change the faulty bulb.

07-10-2002
PRACTICAL INFORMATION105
Fascia fuse box Unscrew the catch a quarter turn using a coin, then remove the cover to gainaccess to the fuses. The spare fuses and the pliers
Aare
secured on the inside of the fascia
fuse box cover. Removing and refitting a fuse
Before changing a fuse, the cause of the fault must be found and remedied. The fuse numbers are indicated on the fuse box. Use the pliers
A.
Always replace a faulty fuse (fault registered depending on fuse) with a fuse of the same rating.
CHANGING A FUSE
The fuse boxes are located under the instrument panel and in the enginecompartment.
CorrectIncorrect
Pliers A

07-10-2002
PRACTICAL INFORMATION105
Fascia fuse box Unscrew the catch a quarter turn using a coin, then remove the cover to gainaccess to the fuses. The spare fuses and the pliers
Aare
secured on the inside of the fascia
fuse box cover. Removing and refitting a fuse
Before changing a fuse, the cause of the fault must be found and remedied. The fuse numbers are indicated on the fuse box. Use the pliers
A.
Always replace a faulty fuse (fault registered depending on fuse) with a fuse of the same rating.
CHANGING A FUSE
The fuse boxes are located under the instrument panel and in the enginecompartment.
CorrectIncorrect
Pliers A

07-10-2002
Fuse RatingFunctions
1 15 A Heated seat - Alarm
4 20 A Mulltifunction screen - Navigation control unit - Boot lighting - Audio system - Retractable roof control unit
5 15 A Automatic gearbox diagnostics
6 10 A Coolant level - Automatic gearbox - Audio system - Steering wheel angle sensor (ESP)
7 15 A Driving school accessories - Alarm fitted as an accessory - Rain detector
9 30 A Hydraulic pump
10 40 A Driving mirror demisting 11 15 A Windscreen wiper
12 30 A Front windows
14 10 A Engine module - Air bags - Steering wheel stalk
15 15 A Instrument panel - Multifunction screen - Navigation control unit - Air conditioning - Audio system
16 30 A Locking/unlocking of doors
20 10 A Right-hand brake light
21 15 A Left-hand brake light - 3rd brake light
22 30 A Front courtesy light - Glove box lighting - Lighter
S1 Shunt PARC shunt PRACTICAL INFORMATION
106

07-10-2002
PRACTICAL INFORMATION107
Fuse no. Rating Functions
1* 20 A Fan unit
2* 60 A ABS/ESP
3* 30 A ABS/ESP
4* 70 A Supply to built-in systems interface
5* 70 A Supply to built-in systems interface
6* Ð Not used
7* 30 A Ignition lock supply
8* Ð Not used Engine compartment fuse box
To access the fuse box located in the engine compartment (next to the bat-
tery), unclip the cover. After changing the fuse, close the
cover very carefully.
Your vehicle's electrical circuit is designed to ope-rate with standard oroptional equipment.
Before installing additional electri-cal equipment or accessories, con-
sult a PEUGEOT dealer. Some electrical accessories, or the way in which they are fitted,may adversely affect the operationof your vehicle (the electronic con-trol circuits, the radio circuit andthe electrical charging circuit).
PEUGEOT does not accept anyresponsibility for expenses incurredby repairs or for any faults resultingfrom the installation of additionalaccessories which are not suppliedor recommended by PEUGEOT andwhich were not installed in accor-dance with the manufacturer'sinstructions, in particular equipmentwith a consumption greater than
10 milliamps.
* The maxi fuses provide additional protection for the electrical systems. Any work must be carried out by a PEUGEOT dealer.
