PEUGEOT 206 CC DAG 2002 Manual Online

07-10-2002
YOUR 206 CC IN DETAIL81
ELECTRIC WINDOWS
1. DriverÕs electric window switch.
2. PassengerÕs electric window
switch.
Each switch controls, on its own side, the front window and the rear quarter
panel window. Manual operation  Press the switch (to open) or pull it (to close) without going beyond thepoint of resistance. The window stops when the switch is released. The rear quarter panel window can only be opened when the front win-dow is completely open, after aninactive period of one second. Automatic operation
Opening
The windows open automatically (when the ignition key is in the ÔonÕposition, with the engine running orthe vehicle moving).  Press the switch past the point of resistance:
Ð Press briefly to completely open the front window; press brieflyagain to completely open the
rear quarter panel window,
Ð Sustained pressure opens the front window, then the rear
quarter panel, completely.
Closing
Only the front window on the driverÕs side closes automatically (enginerunning or vehicle moving), when therear quarter panel is closed.  Briefly pull the switch past the point of resistance to completely
close the driverÕs front window.
Note: the window switches do not func-
tion while the roof is being operated.

07-10-2002
YOUR 206 CC IN DETAIL
82
Manual interior mirror The interior mirror has two positions:
Ð day (normal),
Ð night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower edge of
the mirror. ELECTRIC EXTERIOR MIRRORS
Turn knob
1to the right or to the left to
select the corresponding mirror. Move knob 1in all four directions to
adjust. Fold-back electric mirrors With the ignition on, turn knob 1to
position A.
The outside of the mirror on the driver's side is con-vex (area at edge definedby dotted line) in order to
eliminate the 'blind spot'. Furthermore, objects in the driver's and passenger's mirrors are in
reality closer than they appear. This must be taken into account to judge correctly the distance ofvehicles approaching from behind.

07-10-2002
YOUR 206 CC IN DETAIL83
Headlamp adjustment
Depending on the load in your vehicle, adjusting the beam of the headlamps isrecommended as follows.
0.
1 or 2 people in the front seats.
Ð. 3 people.
1. 4 people.
2. 4 people + maximum authorisedload.
3. Driver + maximum authorised load.
Initial setting is position 0. STEERING WHEEL HEIGHTADJUSTMENT
When stationary, lower the handle to unlock the steering wheel. Adjust to the desired height and lift the handle to lock the steering wheel.
Horn
Press one of the spokes orthe centre of the steeringwheel.

07-10-2002
YOUR 206 CC IN DETAIL
84
AREAS FOR TOLL
CARDS/CAR PARK TICKETS The athermic windscreen has two non- reflective zones located either side of
the base of the interior mirror.
They are intended for affixing toll cards and/or car park tickets.
COURTESY LIGHT
Lights when one of the doorsis opened. In this position thecourtesy light flashes whenthe vehicle is moving, if a dooris not correctly closed.
Off Permanently on when the igni- tion key is in the accessoriesposition or the ignition is on. SUN VISOR The sun visors are fitted with a vanity
mirror, with a concealing flap on thedriver's side. FRONT ASHTRAY
To empty, close the cover. Pull the lug and release the ashtray upwards.
LIGHTER Press and wait a few minutes until it
springs out automatically. It is supplied with power with the igni- tion key in the accessories position (1 st
notch).

07-10-2002
YOUR 206 CC IN DETAIL85
GLOVE COMPARTMENT The glove compartment is fitted with a lock.
To open the glove compartment, lift the handle. The light comes on when the lid is opened. 1.
Vehicle document folder storage
2. Can holder
3. Pen holder
4. Spectacles storage
5. Map storage
6. Coin storage BOTTLE HOLDER
A bottle holder is fitted between the two rear seat backs.
To open it, pull the top of the cover.
LASHING RINGS Use the 4 lashing rings on the luggage compartment floor to secure your lug-gage.
LUGGAGE RETAINING NET Hooked onto the lashing rings, this enables you to secure your luggage.

07-10-2002
YOUR 206 CC IN DETAIL
86
AUTOMATIC AUTOADAPTIVE GEARBOX Moving Off
To move off, move the selector lever to position
Nor P. Press the brake to exit
position P. Stopped or parked Always leave the lever in position Pwhen you get out of your vehicle.
If not, a buzzer will sound when you open the driver's door. Positions of the selector lever These positions are displayed on the instrument panel. P. Park: use with the handbrake.
R. Reverse: this must only be engaged when the vehicle is stationary, engine at idle.
N. Neutral: if Nis engaged by mistake while the car is moving, allow the engine to
return to idle before engaging a new forward gear.
D. Drive: in this position, the four gears change automatically. The gear change
points vary depending on the programme selected.
3. Automatic changing of the first three gears only. Select this position when you notice frequent changes between third and fourth gear (town driving or on winding roads).
2. Automatic changing of the first two gears only. This position is particularly suitable for mountain roads, when going uphill (to make the best use of the engine's power) and downhill (engine braking).

07-10-2002
YOUR 206 CC IN DETAIL87
Operating programmes
You have a choice of three operating pro- grammes:
Ð Autoadaptive (normal).
Ð Sport.
Ð Snow.One press on button
Aor Bwill select
Sport or Snow respectively. The selec- tion is displayed on the instrumentpanel. Pressing the button a secondtime will return to the autoadaptive(normal) programme. Autoadaptive programme (normal) Gear changes are carried out on the basis of various parameters, such as:
Ð driving style,
Ð road characteristics,
Ð vehicle load.The gearbox selects the most suitable programme from those in the memoryfor the current driving conditions. Sport programme The Sport programme automatically favours more dynamic driving. Snow Programme In position
D, the Snow programme
provides smooth driving suited to slip- pery roads in order to improve traction
and stability. Starting is in 2nd gear
and changing down is at low enginespeeds. Special operating features
Ð During prolonged braking, the gear- box changes down automatically, so
as to provide efficient engine braking.
Ð If you take your foot off the acceler- ator suddenly (when you are takenby surprise, for example), the gear-box will not change up, so as to
improve safety.
Ð When the engine is cold, the gearbox automatically selects a special pro-gramme that enables the engine toreach its ideal temperature morequickly in order to decrease pollution.
Kickdown For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as it
will go. The gearbox will change downautomatically or stay in the gearselected, up to maximum enginespeed.Any disruption of the system is signalled by the simultane-ous flashing of the Sport andSnow lights on the instrument
panel. In such a case, the gearbox will
operate in downgrade mode. You mayfeel a substantial knock when reverseis selected from Pto Ror Nto R(with-
out any risk of damage to the gear-box). Do not exceed 100km/h.Contact a PEUGEOT dealer without
delay. When the engine is idling with the car
in gear, the car will move even withoutyou accelerating. Do not accelerate while a gear is being selected, when the vehicle is
stationary.
When stationary, have your foot on the
brake pedal when selecting a gear. Do not accelerate in gear with the brakes on. If work needs to be done with the engine running, apply the handbrakeand select position P.
Do not change down to brake on slip-pery roads. Never select position Nwhen the
vehicle is moving.Never engage Por Rif the vehicle is
not stationary.Do not leave children inside the vehicle unsupervised when theengine is running.

07-10-2002
YOUR 206 CC IN DETAIL
88
The normal operation of the ABS may make itself felt by slight vibra-tions of the brake pedal. In emergency braking, press very firmly without releasing thepressure.
THE ABS ANTI-LOCK BRAKING SYSTEM
The ABS system with Electronic Brake Force Distribution (EBFD) increasesthe stability and manoeuvrabilty ofyour vehicle, particularly on poor orslippery road surfaces. Note:
when replacing wheels (tyres
and rims), ensure that they are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
Lighting of this warninglamp, accompanied by anaudible signal and the mes-sage "Braking fault" on the
multifunction display, indicates a mal-function of the electronic brake forcedistribution which could result in loss ofcontrol of the vehicle when braking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Applying When parking, pull the handbrake to immobilise your vehicle. Releasing Pull the handle and press the button to release the handbrake.
Illumination of this warninglight and of the STOPwarning
light, accompanied by anaudible signal (at 10 km/h)
and the message "handbrake on"on
the multifunction display, indicates thatthe handbrake is still applied or has
not been released fully. EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pressure to be
reached more quickly, thus reducingthe stopping distance. It is triggered by the speed at which
the brake pedal is activated. The effectof this is a reduction in the resistanceof the pedal and an increase in braking
efficiency.

07-10-2002
YOUR 206 CC IN DETAIL89
TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY CON-
TROL (ESP) These systems are linked and comple-
ment the ABS.
The ASR system optimises drive to prevent the wheels skidding, by actingon the brakes of the drive wheels andon the engine. It also allows the direc-tional stability of the vehicle to beimproved on acceleration. If there is a variation between the tra- jectory followed by the vehicle and that
required by the driver, the ESP systemautomatically acts on the engine andthe brake of one or more wheels, inorder to put the vehicle back oncourse.Disarming the ASR/ESP systems In exceptional conditions (starting a vehicle which is bogged down, stuck in
snow, on soft ground), it may be advis-
able to disarm the ASR and ESP sys-tems, so that the wheels can movefreely and regain grip.
Press the "ESP OFF" switch, locat-
ed under the steering wheel to the left.
The switch lights up and thewarning light comes on: the
ASR and ESP systems no
longer have any effect on theengine operation.
These are triggered again:  automatically if the ignition is
switched off,
 automatically above 50 km/h,
 manually by pressing the switchagain.
Operation of the ASR and ESPsystems
When one of these two sys-tems is operating, this lightflashes. Operating check
When a malfunction of the sys-tems occurs, the switch lightflashes and the warning lightcomes on, accompanied by anaudible signal and the mes-
sage "ESP/ASR system not opera-
tional" on the multifunction display.
Contact a PEUGEOT dealer to havethe system checked.
The ESP system offersexceptional safety in normaldriving, but this should notencourage the driver to takeextra risks or drive at high
speed. The correct functioning of this sys- tem depends on observation of themanufacturer's recommendationsregarding wheels (tyres and rims),the braking components and theelectronic components, as well asthe PEUGEOT assembly and opera-tion procedures. After an impact, have the system
checked by a PEUGEOT dealer.

YOUR 206 CC IN DETAIL
90
FRONT AIR BAGS
These are folded in the centre of the steering wheel for the driver and in the
fascia for the front passenger. They are
deployed simultaneously, except in caseswhere the passenger air bag is disarmed.
Front air bag fault If this warning light comes on, accompanied by an audiblesignal and the message
"Air
bag fault" on the multifunction dis-
play, contact a PEUGEOT dealer tohave the system checked.
AIR BAGS The air bags have been designed to maximise the safety of the occupantsin the event of serious collisions.They work in conjunction with theforce-limiting seat belts. The electronic detectors register and analyse any abrupt deceleration ofthe vehicle: if the triggering thresholdis reached, the air bags inflate instant-ly and protect the occupants of thevehicle. Immediately after the impact, the air bags deflate rapidly so that they do nothinder the visibility of the occupantsnor their exit if necessary from thevehicle. The air bags are not deployed in the case of collisions which are not seri-
ous, for which the seat belt is sufficient
to ensure maximum protection. Theseriousness of a collision depends onthe nature of the obstacle and thespeed of the vehicle at the moment ofthe collision. Air bags only operate when the ignition is switched on. Note:
the gas escaping from the air
bags can be a minor irritant. Disarming the passenger air bag*
To ensure the safety of your child, it is essential to disarm the passengerair bag when you install a rear-facingchild seat on the front passengerseat.
With the ignition switched off, insert the key into the passenger air bagdisarming switch 1, turn it to the
"OFF" position, then remove the
key keeping the slot in this position.
The air bag warning light on
the instrument panel is litthroughout the disarmingprocess.
* According to destination.
