Page 39 of 131
62
YOUR 306 IN DETAIL
Traffic information programmes Press the " TA" button to switch the function on or off.
Any traffic information flash will be given priority, whatever source you are listening to (radio, cassette or CD). If you wish to interrupt a message, press the " TA" button; this switches off the function.
Note : the volume of the traffic information announcements is independent of the volume of normal radio
listening. You can adjust it using the volume button. The setting will be stored and will be used when thenext messages are broadcast.
While traffic information is being broadcast, the display will alternately show Ò TRAFFICÓ and the name of the
station.
When the station selected cannot broadcast traffic information, the display shows Ò NO TAÓ.
Regional following mode (REG) When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme.
To do this press the ÒRDSÓbutton for more than two seconds to switch this function on or off.
Page 45 of 131
68
YOUR 306 IN DETAIL
GENERAL FUNCTIONS On / off
With the ignition key in the ACCESSORIES or IGNITION position, press the "M"button to switch the set on or off.
The set can operate for 30 minutes without switching the ignition on. ANTI-THEFT SYSTEM
The first time you use the set following disconnection of the set or the battery, you must enter the confidential code which was given to you on handover of your vehicle. Entering the code Switch the set on. The display shows " CODE IN" then the set changes over to code request mode and " - - - -" is displayed.
Enter your four-digitcode number using buttons " 1" to " 6".
For example: if your code is 5345 press buttons " 5", " 3", " 4" and " 5" in turn.
When the fourth number has been entered correctly, the radio starts automatically.
Error in entering the code
If an error is made when entering one of the first three digits, do not continue the operation and switch off the radio to prevent blocking it. Each incorrect code entry will result in the set being blocked for a period of from 5 seconds to 30 minutes, after
the 7th incorrect entry.
To unblock the set, leave it switched on during the waiting period. When " - - - -" is displayed, you can enter the
code again.
If the set is switched off during the waiting period, this waiting period will restart when the set is switched on again.After 14 incorrectly input codes, the radio will be permanently locked and will display ÒENDÓ.
ADJUSTING THE SOUND Adjusting the volume
Turn the "ON/VOL" button Mto increase or decrease the volume of the set.
In the event of the radio overheating, the volume level decreases. Note If you have a telephone fitted with a Ò muteÓ signal output connected to the set, the set will automatically change
to Ò mute Ó when the telephone is used.
Page 46 of 131
69
YOUR 306 IN DETAIL
AUDIO SETTINGS Press the ÒAUDIOÒbutton several times to select bass (BASS), treble (TREB), loudness (LOUD), fader(FAD)
and balance (BAL).
Exit from audio mode is automatic after a few seconds, without pressing any button or by pressing the Ò AUDIOÓ
button after adjusting the balance. Note: the bass and treble settings are specific to each source. It is possible to set the radio, CD, or CD multi-changer
differently.
Bass setting When ÒBASSÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
ÑÒ BASS Ñ9 Ó for a minimum bass setting,
ÑÒ BASS 0 Ó for a normal position,
ÑÒ BASS +9 Ó for a maximum bass setting.
Treble settingWhen Ò TREBÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
ÑÒ TREB Ñ9 Ó for a minimum treble setting,
ÑÒ TREB 0 Ó for a normal position,
ÑÒ TREB +9 Ó for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low. Press the ÒDÓor ÒEÓ buttons to switch this function on or off.
Setting the front/rear sound distribution (Fader) When Ò FA DÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
The Ò DÓ button increases the volume at the front.
The Ò EÓ button increases the volume at the rear.
This function may be switched off by simultaneously pressing buttons ÒMÓand ÒFÓ.
Setting the right/left sound distribution (Balance)When Ò BALÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
The ÒDÓbutton increases the volume on the right-hand side.
The ÒEÓbutton increases the volume on the left-hand side.
Page 49 of 131
72
YOUR 306 IN DETAIL
Traffic information programme Press the Ò TAÓ button to switch the function on or off.
Any traffic information flash will be broadcast as a priority, whether you are using the radio, CD, CD multi-
changer. If you wish to interrupt a message, press the ÒTAÓbutton; this switches off the function.
Note : the volume of the traffic information announcements is independent of the volume of normal radio
listening. You can adjust it using the volume button. The setting will be stored and will be used when thenext messages are broadcast.
While traffic information is being broadcast, the display will alternately show Ò TRAFFICÓ and the name of the
station.
When the station selected cannot broadcast traffic information, the display shows Ò NO TAÓ.
Regional following mode (REG) When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme.
To do this press the ÒRDSÓbutton for more than two seconds to switch this function on or off.
PTY function This allows you to listen to stations broadcasting a specific type of programme (news, culture, sport, rock etc.). With FM selected, press the Ò TAÓ button for two seconds to switch this function on or off.
To find a PTY programme:
- switch on the PTYfunction,
- briefly press button ÒGÓor ÒHÓ to scroll down the list of the various types of programmes offered,
- when the programme of your choice is displayed, keep button ÒGÓ orÒHÓ pressed for more than two seconds
to carry out an automatic search (after an automatic search the PTY function is switched off).
In PTY mode the different types of programmes can be stored in memory. To do this, press down the preselec-
tion buttons Ò1Óto Ò6Ó for more than two seconds. Recalling the type of programme stored in the memory is by
a brief press on the corresponding button.
Page 60 of 131
543 - Adjusting the air distribution
To direct the hot or cold air, turn the knob 3to the desired position.
This provides optimum comfort as well as dehumidifying the air inside the vehicle.
In particular, it allows the temperature to be lowered in summer and the effective-
ness of the demisting to be increased in winter. 1 - Switching onPress the switch 1, the operating light will come on.
2 - Adjusting the temperature:
Turn the knob 2to the blue zone (cold) or to the red zone (hot).
On positioning the knob in the white zone the system automatically controls the
operation of the air conditioning. This ensures a comfortable temperature whatever the climatic conditions may be.
Temperature selection in auto mode requires 12 to 15 seconds before the required temperature is reached. Windscreen and side windows. Windscreen, side windows and footwells.
Footwells only. Side and central vents.
23
4
1
5
YOUR 306 IN DETAIL
AUTOMATIC AIR CONDITIONING
Page 63 of 131
84
YOUR 306 IN DETAIL
Heated seat controls* Press the switch.The temperature is controlled auto-
matically. Pressing a second time stops opera- tion.Isofix mounting** The Isofix mountings available on the two rear seats allow for the ins-tallation of
special child seats** ,
approved by UTAC for Peugeotvehicles and marketed within the
network. The fixings are available asan accessory and must be fitted by
an approved PEUGEOT dealer. The locks incorporated in the child seat fit onto the mounting and ensu-re quick, reliable and safe installation
of the seats. The combined use ofthe seat belt is compulsoryfor a for-
ward-facing child seat. In the front, it is compulsoryto fit
the child seat in the rear-facing posi- tion*** (in this instance it is imperati-ve to disarm the passenger airbag if
your vehicle is fitted with one). Theforward-facing position is permitted
in the rear.
* According to specification.
** During the model year.
*** According to current legislation.
For maximum safety, it is essential
to adjust the corresponding front seat to the intermediate longitudinalposition, seat back upright. Follow the instructions for fitting the child seat in the leaflet provi-ded when the child seat is purcha-sed.
Page 67 of 131
84
YOUR 306 IN DETAIL
Heated seat controls* Press the switch.The temperature is controlled auto-
matically. Pressing a second time stops opera- tion.Isofix mounting** The Isofix mountings available on the two rear seats allow for the ins-tallation of
special child seats** ,
approved by UTAC for Peugeotvehicles and marketed within the
network. The fixings are available asan accessory and must be fitted by
an approved PEUGEOT dealer. The locks incorporated in the child seat fit onto the mounting and ensu-re quick, reliable and safe installation
of the seats. The combined use ofthe seat belt is compulsoryfor a for-
ward-facing child seat. In the front, it is compulsoryto fit
the child seat in the rear-facing posi- tion*** (in this instance it is imperati-ve to disarm the passenger airbag if
your vehicle is fitted with one). Theforward-facing position is permitted
in the rear.
* According to specification.
** During the model year.
*** According to current legislation.
For maximum safety, it is essential
to adjust the corresponding front seat to the intermediate longitudinalposition, seat back upright. Follow the instructions for fitting the child seat in the leaflet provi-ded when the child seat is purcha-sed.
Page 87 of 131
DRIVING YOUR 306
106
Any disruption of the system is signalled by thesimultaneous flashing of theSport and Snow lights onthe instrument panel. In
such a case, the gearbox will operate
in downgraded mode. You may feela substantial knock when reverse isselected from Por N(without any risk
of damage to the gearbox). Do not exceed 60 m.p.h. (100km/h). Contact a PEUGEOT dealer
without delay. When the engine is idling with the
car in gear, the car will move evenwithout you accelerating. Do not accelerate while a gear is being selected, when the vehicle is
stationary.
When stationary, have your foot on the brake pedal when selecting a
gear. Do not accelerate in gear with the brakes on. If work needs to be done with the engine running, apply the hand-brake and select position P.
Do not change down to brake onslippery roads. Never select position Nwhen the
vehicle is moving. Never engage Por Rif the vehicle
is not stationary. Do not allow children inside the vehicle unsupervised when theengine is running.Operating programmes
You have a choice of three operating programmes:
- Auto-adaptive (normal).
- Sport.
- Snow.One press on button Aor Bwill select
Sport or Snow respectively. The selection is displayed on the instru-ment panel. Pressing the button asecond time will return to the auto-adaptive (normal) programme. Auto-adaptive programme (normal) Gear changes are carried out on the basis of various parameters, such as:
- driving style,
- road characteristics,
- the vehicleÕs load.The gearbox continuously scans the
different programmes in the memoryand selects the one most suitable forthe driving conditions at any givenmoment. Sport programme The Sport programme favours perfor- mance for sporty driving and moredynamic acceleration. Snow Programme In position
Dthe Snow programme
provides smooth driving suited to slip- pery roads in order to improve trac-
tion and stability. Starting is in 2ndgear and changing down is at lowengine speeds. Special operating features During prolonged braking, the
gearbox changes down automatically,
so as to provide efficient enginebraking.
- If you take your foot off the accel- erator suddenly (when you are taken by surprise, for example), thegearbox will not change up, so as to
improve safety.
-When the engine is cold, thegearbox automatically selects aspecial programme which enablesthe engine to reach its ideal tem-perature more quickly to decrease pollution.
Kickdown For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as
it will go. The gearbox will changedown automatically or stay in the gearselected, up to maximum enginespeed.
Page 91 of 131
110
SIDE AIRBAGS*
DRIVING YOUR 306This is indicated by one of the lights on the instrument panel. It comes on for 6 seconds, each time the ignition is switched on.
Operating check If one of the switches:
Ð does not light up when the ignition
is switched on, or,
Ð does not go out after 6 seconds or,
Ð flashes for 5 minutes then stays on,
contact a PEUGEOT dealer.
* According to specification.
** During model year and depending on model.
These are incorporated into the front seat back frame on the door side. They are deployed independently of each other depending on which sidethe collision occurs, in collisions whichcould cause injury to the chest, theabdomen or the head.
* *
Page 93 of 131
110
SIDE AIRBAGS*
DRIVING YOUR 306This is indicated by one of the lights on the instrument panel. It comes on for 6 seconds, each time the ignition is switched on.
Operating check If one of the switches:
Ð does not light up when the ignition
is switched on, or,
Ð does not go out after 6 seconds or,
Ð flashes for 5 minutes then stays on,
contact a PEUGEOT dealer.
* According to specification.
** During model year and depending on model.
These are incorporated into the front seat back frame on the door side. They are deployed independently of each other depending on which sidethe collision occurs, in collisions whichcould cause injury to the chest, theabdomen or the head.
* *
