Peugeot 406 2002 Owner's Guide

Door open warning light
When the engine is running, the warning light indicates that a door has not beenclosed properly or that the
boot is open.
Electronic immobiliser warning light This indicates a malfunction of the electronic immobilis-
er. Contact a PEUGEOT dealer.
Low fuel level warning light. When the warning light comes on, you have
enough fuel to drive at least 30 miles
(50 km). The tank capacity is approx-imately 70 litres (15.4 gallons). Coolant temperature indicator When the needle is in zone
A,the
temperature is correct. When the needle is in zone B, the
temperature is too high. The central
(STOP) warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light With the engine running, the indicator light comes onwhen the driver's seat belt isnot fastened.
YOUR 406 IN DETAIL
133

Lighting rheostat
With the lights on, press the button to vary the intensity of the lighting of theinstruments and controls. When thelighting reaches the minimum (ormaximum) setting, release the but-ton then press it again to increase (orreduce) the brightness. As soon as the lighting is of the required brightness, release the button.
Trip recorder zero reset With the ignition on, press the button. Instrument panel display After switching on the ignition, three functions are shown in succession:
- engine oil level indicator,
- service indicator,
- total distance recorder. Engine oil level
When the ignition is switched on, the engine oil level indicator is displayed for approximately five seconds, then the service indicator is displayed for five seconds.
Maximum Use the dipstick to confirm the level on the indicator; a surplus of oil can cause damage to the engine.
Contact a PEUGEOT dealer as soon as possible. Minimum
Check the level with the dipstick and top it up. The figure shown is only correct if the vehicle has been on stable, level ground, withthe engine stopped, for 10 minutes. No oil It is essential to top up the oil to the correct level, otherwise the engine will be damaged.
YOUR 406 IN DETAIL
134

Display BThis enables the following information to be displayed:
– the time,
– the date,
– the outside temperature (the °C symbol flashes when there is a risk of ice),
– the radio displays,
– the status of the doors. The display shows you whether a door, the boot or thebonnet is open and if the fuel filler cap is missing.
– the warning messages (e.g. ''battery low'') or information messages (e.g. "top up fuel tank''), displayed temporarily, can be cleared by pressing button 1or 2,
– the trip computer. Setting the parameters Press button 1for two seconds to access the settings. The information flashes
to show it is ready to be modified.Then, individual presses on button 1 allow you to scroll through the various data
in the following sequence:
– language in which the information is displayed,
– hour,
– unit of distance (kms or miles),
– unit of temperature (Celsius or Fahrenheit),
– time format (12 then 24 hour mode)
– minutes,
– year,
– month,
– day, Pressing button 2allows you to change the information selected. Maintain the
pressure for rapid scrolling.After ten seconds without moving, the display returns to the main screen and the modified data is recorded.
YOUR 406 IN DETAIL 137

Display CThis enables the following information to be displayed:
– the time,
– the date,
– the outside temperature (the °C symbol flashes when there is a risk of ice),
– the radio displays,
– the status of the doors. The display shows you whether a door, the boot or the
bonnet is open,
– the warning messages are displayed temporarily (e.g. "top up fuel tank'') and can be cleared using the remote control,
– the trip computer (see following page),
– the satellite navigation system (see corresponding section). Setting the parameters
The remote control allows you to access the settings. Accessing the different menus is described in the section on the Satellite Navigation System.
YOUR 406 IN DETAIL
138

YOUR 406 IN DETAIL
64
AUDIO RB2
Angle your aerial, following the line of the windscreen.
1– Press (behind)
2
– Press (behind)
Recommended angle for the aerial (saloon)
Function
Increase volume Decrease volume
1+2
– Simultaneous press
3
– Press Cutting off the sound (mute); restoring the sound by pressing any button Automatic search of higher frequencies (radio) Selection of next track (CD and cassette)
4
– Press Automatic search of lower frequencies (radio) Selection of previous track (CD and cassette)
5
– Press the end Source selection (radio, cassette, CD changer)
6
– Rotation (clockwise) Selection of higher frequency station stored in memory (radio)- Selection of next CD - Reversal of direction of play (cassette)
7 – Rotation (anti-clockwise)Selection of lower frequency station stored in memory(radio) - Selection of previous CD - Reversal of direction ofplay (cassette)
Movement

YOUR 406 IN DETAIL65
Button Function
A ON VOL Radio on/off. Adjustment of volume.
B RDS RDS function on/off.
Press for more than 2 seconds: regional following mode on/off.
CTATraffic information priority on/off.
D Press fully: cassette rewind.
EPress fully: cassette fast forward
D + E
B APress half-way: reversal of direction of play of the cassette.
BB AAPress fully: ejection of the cassette.
F  Increasing the bass/treble setting.
GDecreasing the bass/treble setting.
H AUDIO Adjustment of bass, treble, loudness and sound distribution.
I SRC Source selection: radio, cassette or CD changer.
Press for more than 2 seconds: CD shuffle.
J A Automatic search of higher frequency
Selection of next CD track.
K B Automatic search of lower frequency
Selection of previous CD track.
L MAN
Manual/automatic operation of buttons Iand Jin radio mode.
M BNDSelection of FM1, FM2, FMast and AM wavebands.
ASTPress for more than 2 seconds: storing of a station in the memory (autostore).
1 to 6 12 34 56 Selection of station stored in the memory.
Press for more than 2 seconds: storing of a station in the memory.Selection of a CD.

GENERAL FUNCTIONS On / offWith the ignition key in the ACCESSORIES or IGNITION position, press button Ato switch the set on or off.
The set can operate for 30 minutes without the vehicle ignition being switched on.
Anti-theft systemThe set is coded in such a way that it can operate only on your vehicle. It would not function if fitted to another vehicle.The anti-theft system is automatic and requires no action on your part. VOLUME SETTING Adjusting the volume Turn button Ato increase or reduce the volume.
AUDIO SETTINGS Press the "AUDIO" button several times to access the bass (BASS), treble (TREB), loudness (LOUD), fader
(FAD) and balance (BAL).
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing the "AUDIO" button after adjusting the balance.
Note: bass and treble settings are specific to each source. It is possible to set them differently for radio, cas-
sette or CD changer.
YOUR 406 IN DETAIL
66

YOUR 406 IN DETAIL67
Adjusting the bass When "BASS" is displayed, press button For Gto vary the setting.
- "BASS -9" for a minimum bass setting,
- "BASS 0"for a normal setting,
- "BASS +9" for a maximum bass setting.
Adjusting the treble When " TREB" is displayed, press button For Gto vary the setting.
- "TREB -9" for a minimum treble setting,
- "TREB 0"for a normal setting,
- "TREB +9" for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low.Press button For Gto switch the function on or off.
Setting the front/rear sound distribution (Fader)When "FAD" is displayed, press button For G.
Button Fincreases the volume at the front.
Button Gincreases the volume at the rear.
Setting the right/left sound distribution (Balance)When "BAL" is displayed, press button For G.
Button Fincreases the volume on the right-hand side.
Button Gincreases the volume on the left-hand side.

YOUR 406 IN DETAIL
68
RADIO Notes on radio reception
Car radio receivers are subject to phenomena which do not affect domestic radio sets. Both MW/LW and FM reception are
subject to various forms of interference. This is no reflection on the quality of the equipment, but is due to the nature of th e
signals and the way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of increasing distance from the transmitter, deflection of the signals by obstacles
(mountains, hills, buildings etc), or of being in an area which is not covered by a transmitter. Selecting radio mode
Press the "SRC"button until the radio is selected.
Selecting a waveband Briefly press the "BAND/AST"button to select the FM1, FM2, FMast and AM wavebands.
Automatic station search Briefly press button Jor Kto search for the station immediately above or below.
By continuing to press the button in the direction selected, you will obtain contin-
uous scrolling of the frequency. The scrolling stops at the first station found as soon as the button is released.
If the TAtraffic programme is selected, only stations broadcasting this type of programme are selected.
Searching for a station occurs first in "LO"sensitivity (selection of the most powerful transmitters) during scanning of the
waveband, then in "DX"sensitivity (selection of the weakest and most distant transmitters).

YOUR 406 IN DETAIL69
Manual station search Press the "MAN"button.
Briefly press button Jor Kto increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency. The scrolling stops at the first station found as soon as the button is released.Pressing the "MAN"button again returns you to automatic station search.
Manual storing of stations in the memory Select the station required.Press one of the buttons "1"to "6" for more than two seconds.
The sound stops then becomes audible again, confirming that the
station has been stored in the memory. Automatic storing of FM stations in the memory (autostore)
Press button "BND/AST"for more than two seconds, to automatically store the 6 stations with the strongest
signal in FM. These stations are stored in the FMast waveband.
-If it is not possible to find 6 stations, the remaining memories are empty.
Recalling stations stored in the memory For each waveband, briefly press buttons "1"to "6" to recall the corresponding station.
