Peugeot 406 2002 Service Manual

YOUR 406 IN DETAIL
70
RDS Using the RDS (Radio Data System) function on FM Radio Data System allows you to continue listening to the same station, whatever frequency it is using for the region you are going through. Briefly press the "RDS"button to switch the function on or off.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.
Traffic information programme Press the "TA"button to switch the function on or off.
Any traffic information flash will be given priority, whatever source you are listening to (radio, cassette or CD changer).
If you wish to interrupt a message, press the "TA"button; this switches the function off.
Note: the volume of traffic information announcements is independent of the volume of normal radio listening. Youcan adjust it using the volume button. The setting will be stored and will be used when the next messages arebroadcast. Regional following mode When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode, you can keep listening to the same programme. Press the "RDS"button for more than two seconds to switch the function on or off.

YOUR 406 IN DETAIL71
CASSETTE Selecting cassette mode When a cassette is inserted, the cassette player will start automatically.If a cassette is already inserted, press the "SRC"button until cassette mode is selected.
Ejecting the cassetteFully press buttons Dand Eto eject the cassette from the player.
Direction of play The player will play sides 1 and 2 of the cassette alternately, by automatically reversing the direction of play at the end of a side.
To manually reverse the direction of play, press buttons Dand Ehalf-way.
Fast forward/rewindFully press button Dor Eto fast forward or rewind the cassette. At the end of the fast forward/rewind, the set plays the cur-
rent side. Recommendations regarding the use of cassettes
-Use good quality cassettes.
-Do not use cassettes which play for more than 90 minutes.
-Never expose the cassettes to heat or direct sunlight.
-Re-tension the tape if necessary before inserting the cassette in the player.
-Regularly clean the playing heads with a humid type cleaning cassette.

YOUR 406 IN DETAIL
72
CD CHANGER Selecting CD changer mode Press the "SRC"button until the CD changer is selected.
Selecting a disc Press buttons "1"to "6" to select the corresponding disc.
Selecting a track Press button Jto select the next track.
Press button Kto return to the start of the current track or to select the previous
track.
Accelerated playPress the "MAN"button.
Press and hold button Jor Kfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.Buttons Jand Kresume the "track selection" function when the "MAN"button is pressed again.
Shuffle When the CD changer is selected, keep the "SRC"button pressed for two seconds. The tracks will be played
in random sequence. Pressing the "SRC"button again for two seconds returns you to normal play.

This is located inside the boot on the left hand side. It holds up to 6 discs.
To insert a disc into the changer:
-open sliding panel A,
-press button Bto eject the cartridge C,
-open one of the six compartments of the cartridge by pulling tab D,
-insert the disc with the printed face upwards and close the compartment,
-insert the cartridge into the changer,
-close the sliding panel A.
CD CHANGER
YOUR 406 IN DETAIL
73
The use of blank compact discs can cause malfunctions.

YOUR 406 IN DETAIL
74
Angle your aerial, following the line of the windscreen. Recommended angle for
the aerial (saloon)
AUDIO RM2
1–Press (behind)
2
–Press (behind)
Function
Increase volume Decrease volume
1+2
–Simultaneous press
3
–Press Cutting off the sound (mute); restoring the sound by pressing any button Automatic search of higher frequencies (radio) Selection of next track (CD and cassette)
4
–Press Automatic search of lower frequencies (radio) Selection of previous track (CD and cassette)
5
–Press the end Source selection (radio/cassette/CD changer)
6
–Rotation (anti-clockwise) Selection of higher frequency station stored in memory (radio) -Selection of next CD - Reversal of direction of play (cassette)
7
–Rotation (anti-clockwise) Selection of lower frequency station stored in memory (radio)- Selection of previous CD - Reversal of direction of play (cassette)
Movement

ButtonFunction
A ON/VOL Radio on/off. Adjustment of volume.
B Radio selection. Selection of FM1, FM2, FMast and AM wavebands.
Press for more than 2 seconds: automatic storing of stations in the memory (autostore).
C Cassette selection. Reversal of the direction of play of the cassette.
Press for more than 2 seconds: noise reduction.
D CD changer selection.
Press for more than 2 seconds: shuffle.
EEjection of the cassette.
FT ATraffic information priority on/off.
Press for more than 2 seconds: PTY function on/off.
G RDS RDS function on/off.
Press for more than 2 seconds: regional following mode on/off.
H Increase bass/treble setting.
I Decrease bass/treble setting.
J AUDIO Adjustment of bass, treble, loudness ,sound distribution and automatic
volume correction.
K
AAAutomatic search of higher frequency.
Selection of next track - cassette and CD.
L
BBAutomatic search of lower frequency.
Selection of previous track - cassette and CD.
M MAN Manual/automatic operation of buttons Kand Lin radio mode.
1 to 6 12 34 56 Selection of station stored in the memory.
Press for more than 2 seconds: storing of a station in the memory.Selection of a CD.
YOUR 406 IN DETAIL 75

GENERAL FUNCTIONS On/offWith the ignition key in the ACCESSORIES or IGNITION position, press button Ato switch the set on or off.
The set can operate for 30 minutes without the vehicle ignition being switched on.
Anti-theft systemThe audio system is coded in such a way that it can operate only on your vehicle. It would not function if fitted to another vehicle. The anti-theft system is automatic and requires no action on your part. VOLUME SETTING Adjusting the volume Turn button Ato increase or decrease the volume.
AUDIO SETTINGS Press the "AUDIO" button several times to access the bass ( BASS), treble(TREB), loudness (LOUD), fader
(FAD) , balance ( BAL)and automatic volume correction (CAV).
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing the " AUDIO " button after configuration of the automatic volume correction.
Note : bass and treble settings are specific to each source. It is possible to set them differently for radio, cas-
sette or CD changer.
YOUR 406 IN DETAIL
76

Adjusting the bassWhen "BASS" is displayed, press button Hor Ito vary the setting.
-"BASS –9" for a minimum bass setting,
-"BASS 0" for a normal setting,
-"BASS +9" for a maximum bass setting.
Adjusting the treble When " TREB" is displayed, press button Hor Ito vary the setting.
-"TREB -9" for a minimum treble setting,
-"TREB 0"for a normal setting,
-"TREB +9" for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low. Press button Hor Ito switch the function on or off.
Adjusting the front/rear sound distribution (Fader) When " FA D" is displayed, press button H or I.
Button Hincreases the volume at the front.
Button Iincreases the volume at the rear.
Adjusting the right/left sound distribution (Balance)When "BAL" is displayed, press button Hor I.
Button Hincreases the volume on the right-hand side.
Button Iincreases the volume on the left-hand side.
Automatic volume correction 'CAV'
This function enables the volume to be automatically adapted depending on the level of noise produced by the speed of the vehic le.
Press buttons Hor I to switch the function on or off.
YOUR 406 IN DETAIL 77

RADIO Notes on radio reception
Car radio receivers are subject to phenomena which do not affect domestic radio sets. Both MW/LW and FM reception are
subject to various forms of interference. This is no reflection on the quality of the equipment, but is due to the nature of the
signals and the way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of increasing distance from the transmitter, deflection of the signals by obstacles
(mountains, hills, buildings etc), or of being in an area which is not covered by a transmitter. Selecting radio mode
Press button B.
Selecting a waveband Briefly press button Bto select the FM1, FM2, Fmast and AM wavebands.
Automatic station search Briefly press button K or Lto search for the station immediately above or below.
By continuing to press the button in the direction selected, you will obtain contin-
uous scrolling of the frequency. The scrolling stops at the first station found as soon as the button is released.
If the TAtraffic programme is selected, only stations broadcasting this type of programme are selected.
Searching for a station occurs first in " LO" sensitivity (selection of the most powerful transmitters) during scanning of the
waveband, then in " DX" sensitivity (selection of the weakest and most distant transmitters).
To make a direct search in " DX" sensitivity, press button Kor Ltwice.
YOUR 406 IN DETAIL
78

Manual station searchPress the "MAN" button.
Briefly press button Kor Lto increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency. The scrolling stops at the first station found as soon as the button is released.Pressing the " MAN" button again returns you to automatic station search.
Manual storing of stations in the memory Select the station required.Press one of the buttons "1" to " 6" for more than two seconds.
The sound stops then becomes audible again, confirming that the station has been stored in the memory. Automatic storing of FM stations in the memory (autostore) Press button B for more than two seconds, to automatically store the 6 stations with the strongest signal in
FM. These stations are stored in the FMast waveband.
-If it is not possible to find 6 stations, the remaining memories are empty.
Recalling stations stored in the memory For each waveband, briefly press buttons " 1" to " 6" to recall the corresponding station.
The list of the 6 stations stored in memory on the waveband is displayed each time one of the buttons " 1" to " 6" is pressed.
YOUR 406 IN DETAIL 79
