Peugeot 406 Break Dag 2003 Owner's Manual

17-02-2003
Front fog lamps and rear fog lamp (2nd for-wards turn of the ring)
Note: to switch off the rear fog lamp
and the front fog lamps, turn the ringtwice backwards.
Direction indicators(flashers) Left:downwards.
Right: upwards.
THE LIGHTS STALK Front and rear lightsSelection is by turning ring A.
Lights off Side lights on Dipped/main beam headlamps Automatic switching on of lights Dipped/Main beam change Pull the stalk towards you.Note:
with the ignition off, if the dri-
ver's door is open, a buzzer sounds if you have left your lights on. Front fog lamps and rear fog lamp Rotate the ring Bforwards to switch
on and backwards to switch off. The status is confirmed by the light on theinstrument panel.
Front fog lamps (1st for-wards turn of the ring)
YOUR 406 IN DETAIL
124
In good or rainy weather, both day and night, thefront fog lamps and therear fog lamp are daz-
zling and are prohibited.Do not forget to switch them offwhen they are no longer need-ed.

17-02-2003
AUTOMATIC SWITCHING ON OF THE LIGHTS Side lights and dipped beam head- lamps switch on automatically if the
light is poor, or during continuousoperation of the windscreen wipers.
They switch off as soon as the lightbecomes bright enough or the wind-screen wipers stop. This function is active when the vehicle
is supplied to the customer.
To disarm or activate the function: Place the key in the accessories position (1st notch),
 Press the end of the lights stalkfor more than two seconds.
Note: In foggy weather, the bright-
ness sensor can detect sufficientlight. Because of this, the lights do
not come on automatically. Do not cover the brightness sen-
sor connected to the rain sensor,located in the windscreen behind
the mirror. It is used for automaticswitching on of the lights. Operating check Activation Activation of this function is accom- panied by an audible signal and themessage
"Automatic lighting of
the headlamps activated" on the
multifunction display. Note: Always operate the lighting
controls manually where this is pos- sible. Disarming Disarming of the function is accom- panied by an audible signal and themessage "Automatic lighting of
the headlamps deactivated" on the
multifunction display. When driving, if this function is
switched off when the headlampswould switch on in automatic mode,the lights remain on. It is however possible to disarm this
function and switch off the lights by:
Ð manually switching off the lights using the lights stalk,
Ð switching off the engine.
YOUR 406 IN DETAIL 125
If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come on).The driver is alerted by the flashing ofthe ''dipped beam'' warning light on theinstrument panel.
Contact a PEUGEOT dealer to have the system checked. Follow me Home When there is a low level of bright- ness or at night, if you leave yourvehicle, the side lights and thedipped beam lights may remain onfor approximately one minute.
To do this: place the lights stalk in the AUTO
position,
 place the key in the accessories position (first notch),
 press the end of the lights stalk for
more than two seconds,
 place the lights stalk in the 0posi-
tion,
 flash the headlamps,
 get out of the car and lock it.

17-02-2003
Rear screen wiper (estate)
Turn ring Ato the first notch,
for intermittent wiping. Rear screen wash (estate)
Turn ring Abeyond the first
notch; the windscreen wash then the windscreen wiperoperate for a fixed period.
WINDSCREEN WIPER STALK Front windscreen wipers2 Rapid wipe (heavy rain)
1 Normal wipe (moderate rain).
AUTO Automatic wipe
0 Off.

Single wipe (press downwards).
Operation In position 1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, thenresumes its initial speed when thevehicle starts again. When the ignition has been switched off for more than a
minute with the stalk in the AUTOposition, it is necesary to reacti-vate this function. To do this, move
the stalk to any position, then move itback to the AUTOposition. Automatic windscreen wiper In the
AUTO position, the wipers
operate automatically and adjust
their speed to the intensity of the rainfall .
Operating check Switching on Activation of the function is accom- panied by the message "Automatic
windscreen wiper actuated" on the
multifunction display. In the event of malfunction in the
AUTO position, the windscreen
wiper will operate in downgrademode.
Contact a PEUGEOT dealer to have the system checked.
YOUR 406 IN DETAIL
126
Do not mask the rain detector located on thewindscreen behind the
interior mirror.
If you take the vehicle to anautomatic car wash, switch off theignition or check that the windscreenwiper stalk is not in the automaticposition.
In Winter, it is advisable to wait for complete de-icing of the wind-screen before switching on theautomatic wipe.
Windscreen and headlamp wash Pull the windscreen wiper stalk
towards you. The windscreen washthen the windscreen wipers operatefor a fixed period. The windscreen wash and head- lamp wash operate simultaneouslyfor two seconds, only if the head-
lamps are on .

17-02-2003
TRIP COMPUTERDisplay B Display C
Ð the range
Ð the distance travelled
Ð the average consumption
Ð the current consumption
Ð the average speed Zero reset Press the stalk for more than two seconds. Pressing the button on the end of the
wash/wipe stalkenables the following data
to be displayed:
Ð the current consumption and the range,
Ð the average consumption, the distance travelled and theaverage speed calculated over a period "1",
Ð the average consumption, the distance travelled and the average speed calculated over a period "2".
Periods "1"and "2"are defined by the frequency of the zero
reset. They allow, for instance, daily calculations over period "1" and monthly calculations over period "2".
Zero reset When the required period is displayed, press the stalk for more than two seconds.
YOUR 406 IN DETAIL 139

17-02-2003
Range The display shows the distance that can still be covered with the fuelremaining in the tank. Note:this figure may rise if there is a
change in driving style or road sur- face, causing a significant drop incurrent fuel consumption. If there are less than 3 litres of fuel in the tank, only three segments will bedisplayed. Average consumption This is the ratio between the amount of fuel consumed and the distancetravelled since the computer was lastreset to zero.
Current fuel consumption This gives the fuel consumption recorded during the last two sec-
onds. This function is only displayedwhen the vehicle is travelling at morethan 12 m.p.h. (20 km/h). Average speed This is obtained by dividing the dis- tance travelled by the period of timethe vehicle has been in use (with theignition on), since the computer waslast reset to zero.Distance travelled This shows the distance travelled since the computer was last reset tozero. After the trip computer has been reset to zero, the range databecomes meaningful only after thevehicle has been in use for a certainperiod. If horizontal segments are displayed instead of figures when driving, con-
tact a PEUGEOT dealer.
YOUR 406 IN DETAIL
140

17-02-2003
ELECTRIC WINDOWS
1 - Driver's electric window switch.You have two options:
Ð Manual operation:Press or pull switch 1gently.
The window stops as soon as the switch is released.
Ð Automatic operation: Press or pull switch 1fully. The
window opens or closes com-pletely when the switch isreleased. Pressing the switchagain stops the movement of
the window.
YOUR 406 IN DETAIL 141
Safety auto-reverse When the window on the driver's side rises and meets an obstacle,it stops and partialy lowers again. Notes: In the case of unwanted opening of the window on closing (forexample, in the case of frost) ifthe window will not rise and goesinto safety auto-reverse mode,lower it completely and raise it
again immediately, by pulling theswitch until the window closes
completely. Continue to press theswitch for approximately one sec-ond after closing. Following reconnection of the
battery, in the event of a malfunc-tion, you must reinitialise thesafety auto-reverse function:
Ð open the window completely,
then close it, it will rise in stages of a few centimetreswith each press, repeat theoperation until the window iscompletely closed,
Ð continue to press the switch for at least one second afterreaching this position.
The safety auto-reverse func-tion is not operational duringthese operations. 2 - Passenger's electric window
switch.
3 - Rear right electric window switch.
4 - Rear left electric window switch.
5 - Disarming the rear window switches (child safety). For the safety of your children, press switch 5 to prevent opera-tion of the rear windows irrespec-tive of their position. The 1st press activates the switch and the 2nd press deacti-vates it.
Always remove the key from the ignition whenleaving the vehicle, evenfor a short time.
In the event of contact when oper-ating the windows, you mustreverse the movement of the win-
dow. To do this, press the switchconcerned. When the driver operates the pas- senger window switches, he mustensure that no one is preventing
correct closing of the window. The driver must ensure that pas- sengers use the electric windows
correctly. Be aware of children when operating the windows.

17-02-2003
EXTERIOR MIRRORS Electric rear view mirrors
Turn knob 6to the right or to the left
to select the corresponding mirror.Move knob 6in all four directions to
adjust.When parked, the mirrors can be
folded back manually. Fold-back electric mirrors With the ignition on, turn knob 6to
position A.
The outside of the mirror on the driver's side is con-vex (area at edge definedby dotted line) in order toeliminate the "blind spot".
Objects observed in the driver'sand passenger's mirrors are in
reality closer than they appear. This must be taken into account to judge correctly the distance ofvehicles approaching from behind.
YOUR 406 IN DETAIL
142

17-02-2003
Automatic day/night interior mirror This automatically and gradually changes between the day and night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending onthe intensity of the light from behind. It clears as the light (headlamps of follow-
ing vehicles, sunlight) decreases, ensuring maximum visibility. Operation Switch on the ignition and press switch 1:
Ð Indicator light 2lit (switch pressed): automatic operation.
Ð Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
To ensure maximum visibility during manoeuvres, the mirror clears automatical- ly when reverse gear is engaged.
YOUR 406 IN DETAIL 143
AREAS FOR TOLL
CARDS/CAR PARK TICKETS The athermic windscreen has two non-reflective zones located either
side of the base of the interior mirror.
They are intended for affixing tollcards and/or car park tickets.
Manual interior mirror The interior mirror has two positions:
Ð day (normal),
Ð night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower
edge of the mirror.

17-02-2003
HORN Press one of the spokes or the centre of the steeringwheel.
HEADLAMP ADJUSTMENT Depending on the load in your vehi- cle, it is recommended that the head-lamp beam is adjusted.0 1 or 2 people in the front seats.
Ð 3 people.
1 5 people.
2 5 people + maximum authorised load.
3 Driver + maximum authorised load.
Initial setting is position 0. Hazard warning lights Press the button, the direction indi- cators flash. They can operate with the ignition
off.
STEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT
When the vehicle is stationary, unlock the steering wheel by pullinghandle
A.
Adjust the height and depth of thesteering wheel, then lock it by pushinghandle Adown fully.
YOUR 406 IN DETAIL
144
Automatic lighting of hazard warning lights*
When braking in an emergency, depending on the force of decelera-tion, the hazard warning lights come
on automatically. They switch offautomatically the first time youaccelerate.
It is also possible to switch them off by pressing the button.* According to destination.

17-02-2003
Sun visor with illuminated courtesy mirror With the ignition on, the mirror is automatically lit up when the flap isopened.COURTESY LIGHTSOff. On when one of the doors is opened. Permanently on when the ignition key is in the accessories position or the ignition is on.
1 - Front courtesy light
2 - Rear courtesy light
3 - Map-reading lights With the key in the accessories position or the ignition on, operate the relevant switch. YOUR 406 IN DETAIL
