Peugeot 406 Break Dag 2003 Owner's Manual

17-02-2003
CENTRE CONSOLERear shelf compartment This is provided for the storage of a first aid kit. The catch on the lid is designed to withstand a weight of 9lbs (4 kg) onimpact.
Rear screen sun blind Pull the blind by the central tab, and then position the hooks in the slots A.
1. Front ashtray Press the cover to open the ashtray.
To empty it, after opening, push the cover forwards.
2. Lighter Push in and wait a few moments until it springs out automatically.
3. Coin storage
4. Cup holder
5. Rear ashtray Release to empty, by pulling it sharply towards you.
To refit the ashtray, push it into its housing. YOUR 406 IN DETAIL
146

17-02-2003
Luggage cover (estate) Pull the luggage cover towards you with both hands and position it in the notches A.
Guide the luggage cover back when closing it. Storage compartmentsThere are two storage compartments located behind the boot side trim.
To gain access to a compartment, pull the handle towards you and freethe panel by moving it upwards.
Rear parcel shelf
To remove:
turn control B, raise the rear of the shelf and remove it by pulling it
towards you.
To refit: insert the front part in the notches Cthen fold down the rear part.
LightThe boot light works when the boot is opened. Luggage net
The stowing rings allow the net to be placed in different positions. YOUR 406 IN DETAIL
147

DRIVING Y0UR 406
148
THE AUTOMATIC AUTOADAPTIVE GEARBOX The 4-gear
automaticgearbox provides the comfort of integral automatic
regulation, enhanced by a sport programme (switchA) and a snow
programme (switchB).
Gear selection gate
Ð Move the lever in the gate to select one of the functions. Once the position has been selected, the indicator light for that function is displayed on the instrument panel.
P ark (parking): for immobilisingthe vehicle and for startingthe engine, with the
handbrake on or off. R everse: to drive in reverse gear(select this position when the vehicle is sta-
tionary, engine at idle).N eutral: for starting the engine and forparking , with the handbrake on.
D rive: to drive in auto-adaptive mode (with automatic changing of the four
gears).3: for urban driving or for driving on winding roads(automatic changing of the
first three gears only).
2: for mountain roads or for towing a trailer (automatic changing of the first two
gears only).
1: or tackling steep gradients (selection of first gear only).
Special feature of the gearbox (1.8 and 2 litre petrol engines, 2 litre turbo diesel HDI engine) Selection of first gear is by pressing switch C, with the lever in position 2.
To change out of first gear, press switch Cagain or move the selector lever.
V6 Engine 1.8 litre and 2 litre petrol engines, 2 litre turbo diesel
HDIengine
17-02-2003

17-02-2003
Automatic operation Automatic changing of thefour
gears :
 Select function Din the gate.
The gearbox always selects the most suitable gear on the basis of the fol-lowing parameters:
Ð driving style,
Ð road characteristics,
Ð the vehicle's load.The gearbox operates in auto-
adaptive mode without any action
on your part.
Moving off
With the engine running, to move off with the selector lever in position
P:
 It is essential to press the brakepedal to exit position P (shift
lock),
 Select the required function ( R, D,
3 , 2 or 1) then gradually release
the pressure on the brake pedal;the vehicle will move offimme-
diately.
You can also move off with the se-lector lever in position N:
 Release the handbrake with yourfoot on the brake,
 Select the required function ( R,D ,
3 , 2 or 1) then gradually release
the pressure on the brake pedal;the vehicle will move offimme-
diately.
DRIVING Y0UR 406 149
When the engine is idling, with the brakes not ap-plied, if function R,D, 3, 2
or 1is selected, the ve-
hicle will move even if you are notaccelerating. For this reason, do not leave
children unsupervised inside the vehicle, when the engine isrunning. When maintenance operations need to be carried out with theengine running, apply the hand-brake and select function P.
Never select function Nwhen the
vehicle is moving. Never select functions Por R
unless the vehicle is stationary.Do not change from one position to another to improve braking effi-ciency on a slippery surface.
With the selector lever in position P , it will be impossible to change
to another position if your batteryis flat.
Remarks:
To obtain maximum acceleration
without touching the gear lever,press the accelerator pedal down as
far as it will go (kickdown). The gear-box will change down automaticallyor stay in the gear selected, up tomaximum engine speed. When braking, the gearbox changes down automatically so as to provide
efficient engine braking.
If you take your foot off the accele-
rator suddenly, the gearbox will not
change up, so as to improve safety.

17-02-2003
DRIVING Y0UR 406
150
Sport and Snow programmes In addition to the auto-adaptive pro- gramme, you have a choice of two
specific programmes. The pro-gramme selected is displayed on theinstrument panel. Sport Programme Press button S, once the vehicle
has started and function D has
been selected.
The gearbox automatically favours dynamic driving. Snow programme This programme favours starting operations and drive to improvetraction.  Press button , once the vehicle
has started and function Dhas
been selected.
The gearbox adapts to driving on slippery roads. Note:
You can return to the auto-adaptive programme at any time.  Press button Sor again to can-
cel the programme selected. Difficulties in operationAny disruption of the system is sig- nalled by the alternate flashing of theSport and Snow lights on the instru-ment panel. In this case, the gearbox will operate in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when reverse is selected fromP
to Ror from Nto R (without any
risk of damage to the gearbox). Do not exceed 60 m.p.h. (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer without
delay.
MANUAL GEARBOX Reverse*
To change to reverse gear, lift the ring under the gear lever knob andpush the gear lever to the left then tothe front. Reverse gear can only be engaged when the vehicle is stationary withthe engine idling.
* According to engine.

17-02-2003
DRIVING Y0UR 406
150
Sport and Snow programmes In addition to the auto-adaptive pro- gramme, you have a choice of two
specific programmes. The pro-gramme selected is displayed on theinstrument panel. Sport Programme Press button S, once the vehicle
has started and function D has
been selected.
The gearbox automatically favours dynamic driving. Snow programme This programme favours starting operations and drive to improvetraction.  Press button , once the vehicle
has started and function Dhas
been selected.
The gearbox adapts to driving on slippery roads. Note:
You can return to the auto-adaptive programme at any time.  Press button Sor again to can-
cel the programme selected. Difficulties in operationAny disruption of the system is sig- nalled by the alternate flashing of theSport and Snow lights on the instru-ment panel. In this case, the gearbox will operate in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when reverse is selected fromP
to Ror from Nto R (without any
risk of damage to the gearbox). Do not exceed 60 m.p.h. (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer without
delay.
MANUAL GEARBOX Reverse*
To change to reverse gear, lift the ring under the gear lever knob andpush the gear lever to the left then tothe front. Reverse gear can only be engaged when the vehicle is stationary withthe engine idling.
* According to engine.

17-02-2003
The ESP system offers increased safety duringnormal driving, but shouldnot incite the driver to take
risks or to drive at high speed. The operation of the system is assured to the extent to which therecommendations of the manufac-turer regarding the wheels (tyresand wheel rims), the braking com-ponents, the electronic compo-nents and the assembly and repairprocedures within the PEUGEOTnetwork are respected. After an accident or impact, have the system checked by a
PEUGEOT dealer.
DRIVING Y0UR 406
152
TRACTION CONTROL (ASR) AND
DYNAMIC STABILITY CONTROL
CONTROL (ESP) These systems are linked and com-
plement the ABS.
The ASR system optimises drive to prevent the wheels skidding, byacting on the brakes of the drivewheels and on the engine. It alsoallows the directional stability ofthe vehicle to be improved onacceleration. If there is a variation between the tra- jectory followed by the vehicle and
that required by the driver, the ESPsystem automatically acts on theengine and the brake of one or morewheels, in order to put the vehicleback on course.
Operation of the ASR and ESP systems
When one of these two sys-tems is operating, this lightflashes. Handbrake Applying When parking, pull the handbrake toimmobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and apply the handbrake. Releasing Pull the handle and press the buttonto release the handbrake.
Disarming the ESP/ASR systems In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),it could prove useful to disarm theASR system to make the wheelsspin and regain grip.
Press the switch "ESP OFF", si-
tuated to the left of the steering wheel.
The switch lights up and the indicatorlights come on, accompanied by themessage '' ASR/ESP de-activated''
on the multi-function display: the
ESP and ASR systems no longer
affect the operation of the engine orthe brakes. They engage again: automatically when the ignition is
switched off,
 manually by pressing the switchagain.
Operating check When a system malfunctionoccurs, the switch lightflashes and the indicatorlight comes on.
Contact a PEUGEOT dealer tocheck the system.

17-02-2003
CRUISE CONTROL Cruise control enables the vehicle to maintain a steady speed pro-
grammed by the driver, regardless ofthe road characteristics and withoutthe driver having to touch the acce-lerator or brake pedals. In order for it to be memorised, the vehicle speed must be greater than40 km/h or 60 km/h , depending onthe engine, and fourth gear at leastmust be engaged (second gear forthe automatic gearbox). Operation Place switch 1in the ONposition.
A speed can be memorised. Place switch 1in the OFFposition
to cancel.
Memorising a speedAs soon as you reach the chosen speed, press button 2or 3. This
memorises the speed, which will be
maintained automatically. Note: It is possible to accelerate and drive momentarily at a speed greater than the memorised speed. When theaccelerator pedal is released, the vehi-cle will return to the memorised speed. Cancelling the memorised speed If you wish to cancel the memorised speed:
press button 4or the brake or
clutch pedal.
Recalling the memorised speed After cancellation, press button 4.
Your vehicle will return to the last memorised speed. Changing a memorised speed
To memorise a speed higher than the previous one:  press button 3;
 release it when you have reached the required speed.
To memorise a speed lower than theprevious one:  press button 2;
 release it when you have reached the required speed.
Cancelling the cruise control  Place switch 1in the OFFposition
or switch off the ignition.
DRIVING Y0UR 406 151
Do not use cruise control on slippery roads or inheavy traffic.
THE ABS ANTI-LOCK BRAKING SYSTEM
When used with approved tyres in
good condition, the ABS increasesthe stability and manoeuvrability ofyour vehicle, particularly on poor orslippery road surfaces. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pres-
sure to be reached more quickly,thus reducing the stopping distance. It is triggered by the speed at which
the brake pedal is activated. The
effect of this is a reduction in theresistance of the pedal and an
increase in braking efficiency. The normal operation of the ABSmay make itself felt by slightvibrations of the brake pedal. In emergency braking, press very firmly without releasingthe pressure.

17-02-2003
FRONT AIR BAGS These are folded in the centre of the steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,except in cases where the air bag isdisarmed. Front air bag malfunctionIf this warning light comes on, accompanied by a buz-zer and the message "Air
bag fault" on the multi-
function display, contact a
PEUGEOT dealer to have the sys-tem checked.
AIR BAGS The air bags have been designed to maximise the safety of the occupantsin the event of serious collisions;they work in conjunction with theforce limiting seat belts. In the event of a serious collision, the electronic detectors record andanalyse any abrupt deceleration ofthe vehicle: if the triggering thresholdis reached, the air bags inflateinstantly and protect the occupantsof the vehicle. Immediately after the impact, the air
bags deflate rapidly, so that they donot hinder the visibility of the occu-pants nor their possible exit from thevehicle. The air bags will not be deployed in collisions which are not serious, for
which the seat belt is sufficient to
provide maximum protection. Theseriousness of the collision dependson the nature of the obstacle and thespeed of the vehicle at the momentof impact. Air bags only operate when the ignition is switched on. Note: the gas escaping from the air
bags can be a minor irritant.
DRIVING Y0UR 406 153
Passenger air bag precautions For a vehicle fitted with a passenger air bag disarming switch: Ð disarm the airbag if you ins-tall a rear-facingchild seat on thefront passengerseat,
Ð arm the air bag for an adult
pas-senger.
For a vehicle not fitted with a pas-senger air bag disarming switch: Ð do not install a rear-facing child seat onthe front passengerseat.
Never place your feet or
any object on the fascia.

17-02-2003
Operating check This is confirmed by an indi- cator light, accompanied by an audible signal and a
message on the multi-function dis-
play. With the ignition on (2nd notch), illu- mination of this warning light accom-panied by an audible signal and themessage "Passenger air bag dis-
armed" on the multi-function display,
indicates that the passenger air bagis disarmed (switch in the "OFF"
position).
DRIVING Y0UR 406
154
Disarming the passenger air bag*
To ensure the safety of your child, it is essential to disarm the pas-senger air bag when you install arear-facing child seat on the frontpassenger seat. With the ignition switched off, insert the key into the passenger air bagdisarming switch 1, turn it to the
"OFF" position, then remove the
key keeping the slot in this position.
The air bag warning light on theinstrument panel is lit throughout thedisarming process. In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is removed, turn the air bag slot to the "ON"posi-
tion to re-activate the air bag andthus ensure the safety of your pas-senger in the event of an impact.
* According to destination. SIDE AIR BAGS The side air bags are incorporated into the backs of the front seats, onthe door side. They are deployed independently of
each other, on whichever side thecollision occurs. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comeson, accompanied by anaudible signal and the mes-sage "Air bag fault" on
the multifunction display,
contact a PEUGEOT dealer to havethe system checked.
