Peugeot Expert 2003 User Guide

22-04-2003
FUEL QUALITY*I-5
14
A label on the inside of the fuel filler flap indicates the approved fuel quality type.
Petrol engines are designed to operate on 95-octane fuel; however, for improved driving (petrol engines only) we recom- mend 98-octane.
* According to model or country UNLEADED PETROL
DIESEL

22-04-2003
FRONT SEATS* (Driver)15I-6Reach Lift the control bar and adjust to the desired position.
Head restraint
To remove, pull upwards.
Armrest
Backrest angle
Turn the handwheel to adjust to the desired position. Driver's seat height
* According to model or country

22-04-2003
TILTING REAR SEATCombi 8/9-seater version16I-7
Tilting the seat Access to the rear seats Lift the lever Ato unlock and tilt the
seat. Location: see combi 8/9-Seater page 20.
A
A

22-04-2003
REAR BENCH-SEATCombi 8/9-seater versionI-9
18
AA
BB
B
When carrying out seat
removal and refitting opera- tions, be careful not to trap your hands.
Tilting the seat back Lift lever
Aand tilt the seat back for-
wards.
To make it easier to manoeuvre lever A, the exertion of slight pres-
sure on the top of the seat backbefore tilting is recommended. Removing the rear seat After tilting the seat back, lift lever
B.
Incline the seat forwards and remo- ve it from its fixing points. Refitting the rear seat Position the front feet in the fixing points.
Tilt the folded seat rearwards and straighten out the seat back. Check the assembly is locked
into place properly.

CHILD RESTRAINTS116
In certain instances* a child may be transported in the "forwards-
facing"** position on the front passenger seat. In this case, slide the front passenger seat as far back as possible.
Peugeot greatly recommend that your children be transported in the rear of your vehicle, even when in a Òrear-facingÓ child seat.
Young children should not be consi- dered as small adults; until the ageof 7 or 8 the ratio of head weight to
body weight is different to that ofadults. During violent deceleration or an impact, the weight of the head andthe relative weakness of the neckmuscles can cause serious spinal
injury. It is only from the age of approxi-
mately 10 or a height of 4Õ 6Ó (1.35m) that children can use the samemeans of restraint as an adult. This is why most countries legislate on the means of transporting chil-dren, and the sale and use of safe-ty equipment suitable for theirweight. On the advice of specialists in acci-
dentology, Peugeot recommendsthe following systems*.
* Contact your dealer for a list of
specially recommended child seats.
** According to current legislation in the country.
22-04-2003
From birth to 1 year (up to 13 kg):
a Òrear-facingÓ seat installed using a 3 point seat belt. From 9 months to 3 years
(from 9 to 18 kg):
a Òforwards-facingÓ seat installed inthe rear using a 2 or 3 point seatbelt.

22-04-2003
CHILD RESTRAINTS117
From 3 to 6 years
(from 15 to 25kg):
A restraining cushion, which enables the child to sit in the rear in the Òforwards-facingÓ position, securedusing a 2 or 3 point seat belt.
By law a child can only be transported in the front of the vehicle in the following cases: ¥ When the rear seats do not allow for installation of such a seat (because they are missing or folded down).
¥ When the number of children is such that they cannot all be transported in the rear.
So that your children travel in complete safety whatever their age ,
Peugeot has tested and selected a range of approved restraining equipment,
designed to offer maximum protection in the event of an impact. This is avai-lable within the Peugeot network. From 6 to 10 years
(from 22 to 36kg):
A booster more adapted to large children installed in the Òforwards-facingÓ position on rear seats fitted witha 3 point seat belt. ÒISOFIXÓ MOUNTINGS
Available on the side rear seat cushions (2nd row), on the indivi-dual front passenger seat and theside passenger seat (2-seaterbench seat), the Isofix mountingsallow the fitting of a
special child
seat , sold within the PEUGEOT
network. The locks incorporated in the child seat fit onto the Isofix mountings and ensure safe, reliable and fast
assembly.
Never leave a child or an animal in a vehicle which is exposed to the sun, with the windows closed. In order to protect your young children from the suns rays: fit sun blinds to the rear windows.Never leave the keys within reach if children inside the vehicle.Strap children into their child seats, even on short journeys.Observe closely the installation and fitting recommendations as indicated in the child seat instructions.

22-04-2003
CHILD RESTRAINTS118
Summary of options for the installation of child restraining systems, according to the weight of the child and their posi- tion in the vehicle (in accordance with Directive 2000/3):
U : Universal category Òrear-facingÓ and Òforwards-facingÓ.
X : No child restraintAccording to destination:
L1 : BRITAX Babysure E11 0344117 Universal (birth to 13kg)
L2 : R…MER Prince E1 03301058 Universal (9 to 18kg)
L3 : R…MER Vario E1 03301120 Universal (15 to 25kg)
L4 : RECARO Start E1 03301108 Universal (15 to 36kg)
L5 : KLIPPAN Optima E17 030007 Universal (15 to 36kg)
L6 : KIDDY Isofix Rear-facing E1 03301123 and Universal (birth to 13kg)
L7 : KIDDY Isofix Forwards-facing E2 030011 Universal (9 to 18kg)
* Vehicle seat in intermediate longitudinal position.** Child seats installed with a 2 point seat belt.
Weight
Position < 13 kg 9 - 18 kg 15 - 25 kg 22 - 36 kg
Passenger UUU *U
Individual seat L1, L6 L7 L3, L4*, L5* L4*, L5*
Side UUUU
2-seater bench seat L1, L6 L7 L3, L5 L5
Centre** XX L3X
2-seater bench seat
Side UUUU
Tilting individual seat L1
L2, L7 (sitting position)L3, L4, L5 L4, L5
Side L1, L6 L2, L7 L3, L4, L5 L4, L5
2-seater bench seat
(lying down position) (sitting position)
Centre**
2-seater bench seat XL2 L3 X
Side
3-seater bench seat L1 L2, L7 L4, L5 L4, L5
Centre**
3-seater bench seat XL2XX
Side
3-seater bench seat L1 L2 L3, L4, L5 L4, L5
Centre
3-seater bench seat XL2 L3 X
1st
row
2 nd
row
3 th
row

22-04-2003
STEERING WHEEL ADJUSTMENTI-817
IMPORTANT
As a safety measure,
these manoeuvres must not be carried out when driving.
The height of the steering wheel can be adjusted.
When stationary, first adjust your seat to the most suitable position.
Unlock the steering wheel by pushing the adjustment control.Adjust the height of the steering wheel then lock it by pulling the adjustment control fully towards you. Make sure that you can see all the displays on the fascia panel.

22-04-2003
COMBI 5/6-SEATER19I-10
These models are fitted with two individual front seats as standard.
FIVE SEATER
The basic version offers a three-
seater bench in second row. The bench can be removed. SIX SEATER
The 6-seater version offers a two- seater bench instead of the indivi-dual front passenger seat.

22-04-2003
COMBI 8/9-SEATERI-10
20
EIGHT SEATER
This version offers a three-seater bench for the third row.
In this case, in order to provide access to the third row, the second row offers a two-seater bench on the left and a single seat on the right.
