Peugeot Expert 2003 Owner's Guide

22-04-2003
WARNING LAMPS*29I-13LH direction indicator See Ç Signalling È Dipped beam See Ç Signalling È
All the direction indicators flash simultaneously when the hazard war- ning lamps are switched on.
Anti-lock Braking System On switching on the igni-
tion, the ABS lamp will
light for approximately 2 seconds. If it stays on there may be a fault in the system. See Chapter II Ç Brakes È RH direction indicatorSee Ç Signalling È Main beam See Ç Signalling È Front brake pad wear If it lights when pressing the brake pedal, have thebrake pads checked and
replaced if necessary.
Diesel Preheater See the instructions for starting the engine. Refer to section II - Driving
- Ç Starting È. Rear screen demister
See Ç Visibility È Foglamp See Ç Signalling È Engine auto-diagnosis If it flashes or comes on while you are driving, thisindicates a fault in either
the injection, ignition or emissionsystems. Contact the dealer network as soon as possible.
Water-in-fuel Drain the fuel filter as soon as possible.
Front airbag warninglamp Refer to the section
Ç Airbag È
* According to model or country

22-04-2003
WARNING LAMPS*I-13
30
Immediate STOP command Lights simultaneous- ly with another war-
ning lamp.
Handbrake and lowbrake fluid level war-ning With the engine running,
the warning lamp indicates that the handbrake is on, or is not fullyreleased, or that the brake fluid
level is too low. See Chapter II - Ç Brakes È and Chapter IV Ç Levels È.
Battery charge Must not light when the engine is running. If it
lights continuously, con-
tact your nearest dealer. Low coolant level If the warning lamp comes on: stop the vehicle.
Check the level (see chapter IV -Maintenance - Ç Levels È).
Engine oil pressure If it comes on while driving, stop the engine and checkthe level (refer to section IV
Ð Maintenance Ç Levels È). If it remains on, despite the level being correct, contact the nearest
dealer.
Low level fuel warning
When it comes on conti-
nuously, there areapproximately 6 litres offuel left in the tank. Coolant temperaturewarning lamp If the warning lamp
comes on, stop immediately, switch
off the engine - the cooling fan maycontinue to operate for a period
after switching off - and allow tocool before checking the coolantlevel, taking the necessary precau-tions (refer to section IV ÐMaintenance - Ç Levels È). Engine overheating can have various causes. Contact your nea-
rest dealer.
On TURBO DIESEL versions:
¥ Orange lamp on = warning.
Reduce speed, the lamp should go out.
¥ STOP and orange warning lamps
on = Danger (stop immediately).
* According to model or country

22-04-2003
SIGNALLING*31I-14Horn Press the end of the stalk. Headlamp flash Pull the stalk towards you to flash headlamps.
The headlamp flash operates even with the ignition off. Direction indicators Left: move the stalk downwards.Right: move the stalk upwards.
Movement of the steering wheel returns the stalk to the off position automati-
cally. Hazard warning lamps
Operates the direction indicators simultaneously.
Use only in case of danger, emergency stop or in hazardous conditions.
Also operates with the ignition off.The direction indicators will not work when the hazard warning lamps are in use.
* According to model or country
Protection fuses under the dashboardF7 - F26 - F30Protection fuses under the dashboardF4 - F9 - F18 - F19
(under the bonnet)
F3 - F4 - F7 - F8 (with ABS)
F2 - F3 - F12 - F13 (without ABS)

22-04-2003
SIGNALLING*I-14
32
Vehicles fitted with front fog lamps and a rear fog lamp (ring C)
Front fog lamps.
These function with the side lightsand the dipped beam headlamps.
Front fog lampsand rear fog lamp
These function with the side lightsand the dipped and main beamheadlamps.
Fog lamps off.
Vehicles fitted with a rear foglamp (ring B) Rear fog lamp.
This operates with the dipped/mainbeam headlamps.
THE LIGHTS STALK Front and rear lights Selection is by turning ring
A.
Lights off Side lights on
Dipped/main beam headlamps
Dipped/ main beam change Pull the stalk fully towards you. Note: with the ignition off, an
audible signal will sound upon ope-
ning the driverÕs door, if you haveleft your lights on. Front fog lamps* and rear fog lamp Rotate the ring forwards to switch
on and backwards to switch off. Thestatus is confirmed by the light onthe instrument panel.
BA
In good or rainy weather, both day and night, the rear foglamp is dazzling and is prohi-bited. Do not forget to switch it off as soon as it is no longer needed.
C
* According to model or country

22-04-2003
SIGNALLING*33I-14Adjusting the headlamps
You are advised to adjust the beam of the headlamps in accor- dance with vehicle load. Electrically operated adjustments* In the dashboard on the right hand side of the steering column.0 Empty
1 Lightly laden
2 Half laden
3 Fully laden
Manual adjustments*Using the controls located in the engine compartment behind eachheadlamp.
* According to model or country
Protection fuses under the dashboardF4

22-04-2003
VISIBILITYI-15
34
Windscreen wiper
3 High speed
2 Normal speed
1 Intermittent wipe
0 Stop
4 Single wipe - Press the stalk down
By pulling the stalk towards you:
Windscreen wash And headlamp washers if the dipped beams are on*.
Two headlamp wash operations at an interval of less than 10 seconds will pro-
vide effective cleaning of the headlamps.
BEWARE: When washing the vehicle, with the ignition on (for example when using an automatic car wash):
- ensure that the stalk is returned to position 0-Off.
* According to model or country
Protection fuses under the dashboardF9 - F24
(under the bonnet)
F10 - F12 (with ABS)
F4 (without ABS)
1
2
3
4
0

22-04-2003
VISIBILITY35I-15Rear screen demister* Can only be operated with the engine running.
Press the button to switch on the rear screen (and door mirrors) electric demister.
The demister switches off automatically after approximately twelve minutes of operation to avoid excessive current consumption. Press the button to cancel the demisting function.Press the button again to re-activate the demisting function for another twelve minutes.
* According to model or country
Protection fuses under the dashboardF6 - F27

22-04-2003
REAR VIEW MIRRORS*I-16
36
Interior rear view mirror
A lever on the underside of the mir- ror allows you to choose betweentwo positions:
1 - Day position: the lever is not
visible.
2 - Night position (anti-dazzle):
the lever is visible. Door mirrors Manual operation The mirror can be adjusted, from inside the vehicle, in four directionsusing the control on the door panel. When parking, the mirror heads
may be folded manually. If the mirror housing is out of posi- tion it should be manually repositio-ned (with the vehicle at standstill).Zones for toll cards / car park tickets* The athermic windscreen has two non-reflective zones located eitherside of the base of the interior rear-
view mirror.
They are designed for affixing toll cards and/or ca r park tickets.
* According to model or country
21

22-04-2003
REAR VIEW MIRRORS*37I-17
A
Electrically - controlled door mirrors If your vehicle is fitted with two electrically controlled rear view mirrors, turn lever Ato select the desired rear view mirror:
- to the right for the right hand rear view mirror,
- to the left for the left hand rear view mirror. Adjust the rear view mirror using lever A.
* According to model or country
Protection fuses under the dashboardF30

22-04-2003
WINDOWS*I-17
38
AB
Electric control The switches mounted in the roof
console control the vehicleÕs frontwindows. Sequential control* One touch on the switch to its first
position offers partial opening of the
driverÕs window. Pressing the switch to its second position fully opens or closes the
window. Glazed or Combi versions Sliding side window in second row
To open, pull
Aand slide the win-
dow towards the front.
To close, slide the window towards
the rear, then press Bto lock it.
* According to model or country
Always remove the key from the ignition when leaving thevehicle, even for a short time. In the event of contact when operating the windows, youmust reverse the movement of
the window. To do this, pressthe switch concerned. When the driver operates the passenger window switches, hemust ensure that no one is pre-venting correct closing of the
window. The driver must ensure that passengers use the electric win-
dows correctly. Be aware of children when ope- rating the windows.
