Lateraladjustmentoftheheadlightsshouldbecarriedoutataspecialistworkshopwithanopticaladjustmentunit.
Distance
Visualaimshallbeperformedatnotlessthan7.5m(thisvalueisaroundeddownconversionfromthe25-footdistancetypicaloffieldaimusingascreen).The7.5m(24.6ft.)distanceismeasuredfromtheheadlamplenstotheviewingscreen.
Floor
Thesurfaceuponwhichthevehiclerestsisflatandapproximatelylevel.
Screen
Thescreenuponwhichheadlampbeamsareprojectedisperpendiculartothefloorandthevehicle’slongitudinalaxis,flat,uniformlylightincolor,unobstructed,andwideandhighenoughtoaccommodatethevehiclebeampatternstobeaimed.
Thescreenshouldbewideenoughtoprovideatleast1m(3.3ft.)ofspaceoutboardofthevehicle’sheadlampspacing.
Adjustmentscrews
Detachsidecarpetinginluggagecompart-ment.UnscrewplasticnutA.Openthecoveroftheappropriateadjustmentscrew.Theset-tingisadjustedbyturningthehexagonsocketscrewsrightorleft,asappropriate.
PracticalTips,EmergencyService319

B-Headlightverticaladjustment
Verticaladjustment(screwB)
turnclockwise=beammovesdownturncounter-clockwise=beammovesup
Note
Donotalterthelateraladjustment.
320PracticalTips,EmergencyService

Towing
Generalinformation
Certainstatestatutesandlocalordinancesprohibittowingwithachain,ropeorevenatowbar.Inaddition,damagetoyourvehiclemayresultfromimproperprocedures.ConsultyourauthorizedPorschedealerfordetails.
Vehicletowing
FlatbedtowingisthepreferredtypeoftowingtobeusedonPorschevehicles.Undercertaincircumstances,wheelliftsmaybeusedwhenthevehiclewillnotroll.Thevehiclemustbetowedwithallfourwheelsofftheground,otherwisedamagetothevehiclemayresult.
Towinghook
ThetowinghookAisstoredinthetoolboxintheluggagecompartment.
Caution!
Riskofdamagetothevehicle.
Usethetowinghookonlyforanemergencytoremovethevehicleofftheroad.Thetowinghookistobeusedonlytopullthevehicleontotheflatbed,tractorortowingapparatusifthevehiclewillrollfreely.Undernocircumstancesisthevehicletobesecuredusingthetowinghook.
Neverusethetowinghooktotowthisoranyothervehicle.
Bearinmindthelimitedgroundclearanceofyourcaronunevensurfaces.
PracticalTips,EmergencyService321

Fittingtowinghook
Whenfittingontherearofthevehicle,thelicenseplatemustberemoved.
1.Presstheloweredgeoftheappropriateplasticcoverintothebumperuntilthecoverdisengages.
2.Pullcoveroutofthebumperandletithangbyitsthread.
3.CompletelyscrewinthetowinghookA.
Removingtowinghook
1.UnscrewthetowinghookA.
2.Insertplasticcoverattheloweredgeoftheopening.
3.Foldthecoverupandpressonitsupperedgetoengageitinthebumper.
Whenremovingontherearofthevehicle,thelicenseplatemustbemounted.
Pullingvehicleontoatbed
1.Positionwoodenrampsatthebaseoftheflatbedtoreducetheangleofthepull.
2.Reelinthehoistcableandchecktheundersideofthevehicleforanyinterference.
322PracticalTips,EmergencyService

Tyingdownvehicleonatbed
1.Carefullyfeedtowingstrapsthroughtheopeningintherearwheels.Makesuremetalpartsofstrapsdonotdamagerim.Makesurethestrapisflatovertherimbead.Makesurebrakebackingplateisnotdamaged.
2.Securestrapstorearofflatbed.
3.Reelinhoistcableonlyfarenoughtotensiontie-downstraps.
4.Carefullyfeedtowingstrapsthroughtheopeninginthefrontwheels.Makesuremetalpartsofstrapsdonotdamagerim.Makesurethestrapisflatovertherimbead.Makesurebrakebackingplateisnotdamaged.
5.Securestrapstofrontofflatbed.
6.Releasetensiononhoistcable,butdonotdisconnect.Usehoistcableasasafetycable.
PracticalTips,EmergencyService323

324PracticalTips,EmergencyService

VehicleIdentication,TechnicalData
VehicleIdentification....................................326TechnicalData............................................328
VehicleIdentification,TechnicalData325

VehicleIdentication
Orderingspareparts
Whenorderingsparepartsormakinginquiries,pleasealwaysquotethevehicleidentificationnumber.
Vehicledatabank
Thevehicledatabankisattachedtotheinsideofthe“Maintenance”booklet.Itcontainsallimportantdataaboutyourvehicle.
Note
Thisdatabankcannotbere-orderedifitislostordamaged.
Thislabelcontainsthefollowinginformation:
1.VehicleIdentificationNo.
2.Type/Typedescription
3.Enginecode/Transmissioncode
4.PaintNo./Interior
5.Optionalequipment
Vehicleidenticationnumber
Position
InaccordancewithFederalSafetyRegulations,thevehicleidentificationnumberofyourcarislocatedatthebottomleftofthewindshieldframeandcanbeseenfromtheoutside.
Thevehicleidentificationnumberisintheluggagecompartmentunderthebatterycoverandatthebottomleftbehindthewindshield.
Removingthebatterycover
Pleaseobservethechapter”BATTERY”onpage295.
Safetycompliancesticker
ThesafetycompliancestickerisyourassurancethatyournewPorschecomplieswithallapplica-bleFederalMotorVehicleSafetyStandardswhichwereineffectatthetimethevehiclewasmanufac-tured.
Thestickeralsoshowsthemonthandyearofproductionandthevehicleidentificationnumberofyourcar(perforations)aswellastheGrossVehicleWeightRatingandtheGrossAxleWeightRating.
326VehicleIdentification,TechnicalData

Tirepressureplate
Thetirepressureplateisattachedtotheleft-handdooraperture.
Enginenumber
Theenginenumberisstampedontheundersideofthecrankcase.
VehicleIdentification,TechnicalData327

TechnicalData
Enginedata
911Carrera,911Carrera4,911Targa4911CarreraS,911Carrera4S,911Targa4S911CarreraS,911Carrera4S,911Targa4S(increasedperformanceversion)
TypeM96/05Horizontallyopposedengine,liquidcooled
M97/01Horizontallyopposedengine,liquidcooled
M97/01SHorizontallyopposedengine,liquidcooled
Numberofcylinders666
Bore3.78in./96mm3.90in./99mm3.90in./99mm
Stroke3.26in./82.8mm3.26in./82.8mm3.26in./82.8mm
Cubiccapacity219.4cu.in./3596cm³233.3cu.in./3824cm³233.3cu.in./3824cm³
Net-horsepower,SAEJ1349325hp/239kW355hp/261kW381hp/280kW
atcrankshaftspeed6800rpm6600rpm7200rpm
Nettorque,SAEJ1349273ft.lb./370Nm295ft.lb./400Nm307ft.lb./415Nm
atcrankshaftspeed4250rpm4600rpm5500rpm
Engineoilconsumptionupto1.5liters/1000km(1.6quarts/622miles)upto1.5liters/1000km(1.6quarts/622miles)upto1.5liters/1000km(1.6quarts/622miles)
EnginecontrolStationaryhigh-voltagedistribution,sequentialinjection,cylinder-selectiveknock-control,stereooxygensensorclosed-loopcontrol,diagnosticsystem,4overheadcamshafts,PorscheVarioCamPlus,hydraulicvalveclearancecompensa-tion
