Forinformationonthespacers:
Pleaseobservethechapter”SPACERS”onpage286.
Removingthespacers
1.Unscrewbothcountersunkscrews(M6x16)onthewheelhub.
2.Removethespacer.
3.FastenthebrakediscwiththeshortM6x12countersunkscrews,partNo.:900.269.047.09.Tighteningtorque10Nm(7.5ftlb.).
4.Forwheelmountingwithoutaspacer,5mmshorterwheelbolts(partNo.:996.361.203.02)mustbeused.Tighten-ingtorque:130Nm(96ftlb.).
Pleaseobservethechapter”CHANGINGAWHEEL”onpage287.
Mountingthespacers
1.Removewheel.
2.Unscrewbothcountersunkscrews(M6x12)onthebreakdisc.
3.FastenthespacerwiththelongM6x16countersunkscrews.Tighteningtorque10Nm(7.5ftlb.).
4.Fitwheel.Todothisusethelongerwheelboltsforfasteningthewheels.Tighteningtorque:130Nm(96ftlb.).
Pleaseobservethechapter”CHANGINGAWHEEL”onpage287.
Longwheelbolt
-X:Boltlengthapprox.50mm-Arrows:marks
Wheelboltidentifyingfeatures
ThelongwheelboltsareidentifiedonthefacesurfaceoftheboltheadwithGTorinred,orthemoveablesphericalcapringisgalvanisedinred.Thelongwheelboltsmustonlybeusedtogetherwith5mmspacersfitted.
Theshortwheelboltsarenotmarkedincolour.Theshortwheelboltsmustonlybeusedwithout5mmspacersfitted.
PracticalTips,EmergencyService289

Tighteningtorqueforbothwheelbolts:130Nm(96ftlb.).911Carrera4,911Carrera4S,
911Targa4,911Targa4S
17mmspacers
Danger!
Riskofaccident.17mmspacersmustonlybemountedontherearaxletogetherwith11.5Jx19(67mmrimoffset)wheels.
Alwaysremove17mmspacersbeforemountingotherwheelsizesoranemergencysparewheelbecausethewheelcannotbemountedcorrectly.
Forinformationonthespacers:
Pleaseobservethechapter”SPACERS”onpage286.
Removingthespacers
1.UnscrewthewheelboltsAwithwhichthespacerisfastened.
2.Removethespacer.
3.Screwin1or2assemblyaidsinsteadofthewheelbolts.
4.Fitwheel.
5.InsertwheelboltsAandtightenbyhand.Removeassemblyaids,screwinremainingwheelbolts.Initiallytightenboltsslightlyindiagonallyoppositesequencesothatthewheeliscentred.
Pleaseobservethechapter”WHEELBOLTS”onpage285.
6.Lowerthecarcompletely.
7.Tightenwheelboltsindiagonallyoppositesequence.
Immediatelyafterchangingawheel,useatorquewrenchtocheckthepre-scribedtighteningtorqueofthewheelbolts(130Nm/96ftlb.).
290PracticalTips,EmergencyService

Storespacerandwheelnutstogether.
Mountingthespacers
1.Removewheel.
2.FitthespacerwiththewheelboltsAusedtofastenthewheel.Initiallytightenthewheelboltsslightlyindiagonallyoppositesequence.
3.Tightenwheelboltsindiagonallyoppo-sitesequence.Tighteningtorque:130Nm(96ftlb.).
4.Fitwheel.Todothisusetheoriginalwheelnutsforfasteningthewheels.Tighteningtorque:130Nm(96ftlb.).
Pleaseobservethechapter”CHANGINGAWHEEL”onpage287.
Onrequest,separateanti-theftprotectionforthewheelnutscanbemounted.
PleaseconsultanauthorizedPorschedealer.
PracticalTips,EmergencyService291

ElectricalSystem
Generalinformation
Inordertoavoiddamageandfaultsinelectricalorelectronicsystems,electricalaccessoriesshouldbeinstalledatyourauthorizedPorschedealer.
OnlyuseaccessoriesauthorizedbyPorsche.
Warning!
Riskofshortcircuitandre,resultinginseriouspersonalinjuryordeath.Replacingfusesorrelayswiththeenginerunningortheignitiononcouldcauseelectricalshock.
Disconnectthebatteryduringallworkontheelectricalsystem.
Pleaseobservethechapter”BATTERY”onpage295.
Relays
Defectiverelaysshouldbechangedonlybyanauthorizedworkshop.
Instoragetraybetweenthefrontseats
Sockets
Electricalaccessoriesshouldpreferablybeconnectedtothe12Vsockets.
Pleaseobservethemaximumpowerconsump-tion.
Noteonoperation
Thetirefillingcompressormustbeconnectedtothecigarettelighter.
Inthepassenger’sfootwell
Noteonoperation
Thesocketsandthustheconnectedelectricalaccessorieswillfunctioneveniftheignitionisswitchedoffortheignitionkeyiswithdrawn.
Iftheengineisnotrunningandtheaccessoriesareswitchedon,thevehiclebatterywillbedischarged.Donotoperateadditionalaccessoriesformorethan5minuteswhenengineisoff.Continuingtodosomaydrainthebatterysuchthatitmaygocompletelydead.
Maximumpowerconsumptionforbothsocketstogether:70W.
292PracticalTips,EmergencyService

Pleaseobservethepowerspecificationsfromtheaccessorymanufacturer.
Alarmsystem,centrallocking
Thestatusofthecentrallockingandalarmsystemisnotchangedbydisconnectingthebattery.Whenthebatteryisdisconnected,thealarmsystemceasestofunction.
Overloadprotection
Ifthecentrallockingsystemisoperatedmorethantentimeswithinaminute,furtheroperationisblockedfor30seconds.
Loadswitch-offafter2hoursor7days
Iftheignitionkeyisremoved,loadswhichareswitchedonorareinstandbymode(suchastheluggagecompartmentlight,interiorlightandradio)areautomaticallyswitchedoffafterapprox.2hours.
Ifthevehicleisnotstartedorunlockedwiththeremotecontrolwithin7days,theremotecontrolstandbyfunctionisswitchedoff(tosavethevehiclebattery).
1.Inthiscase,unlockthedriver’sdoorwiththekeyatthedoorlock.Leavethedoorclosedinordertopreventthealarmsystemfrombeingtriggered.
2.Pressbutton1ontheremotecontrol.
Theremotecontrolisnowactivatedagain.
A-Diagnosticsocket
Replacingfuses
Inordertopreventdamagetotheelectricalsystemduetoshortcircuitsandoverloads,theindividualcircuitsareprotectedbyfuses.Thefuseboxislocatedinthedriver’sfootwell.
A-PlasticgripperB-Sparefuses
1.Switchofftheloadwiththedefectivefuse.
2.Pulloffplasticcoveratthefingerhole(arrow).Thefuseplanandinstructionsforemer-gencyunlockingoftheluggagecompart-mentlidcanbefoundontheinnersideofthecover.
3.RemovethecorrespondingfusefromitsslotusingtheplasticgripperAinordertocheckit.Ablownfusecanbeidentifiedbythemeltedmetalstrip.
4.Replaceonlywithfusesofthesamerating.
PracticalTips,EmergencyService293

Note
Ifafuseblowsrepeatedlyconsultanauthor-izedPorschedealer.
Nevertryto“repair”fuses:youmaycauseseriousdamagetootherpartsoftheelectricalsystem.
Emergencyunlockingoftheluggage
compartmentlid
Ifthebatteryisdischarged,thelidcanbeopenedonlywiththeaidofadonorbattery.
Unlockinglid
1.Usethekeytounlockthevehicleatthedoorlock.
2.Removeplasticcoveroverthefusebox.
3.PulloutpositiveterminalAinthefusebox.
4.UseajumpercabletoconnectthepositiveterminalofthedonorbatterywithpositiveterminalAinthefusebox.
Note
Ifthevehiclewaslocked,thealarmhornwillsoundwhenthenegativecableisconnected.
5.UsethesecondjumpercabletoconnectthenegativeterminalofthedonorbatterywithlatchstrikerB.
6.Unlocktheluggagecompartmentlidwiththeremotecontrol.Thealarmsystemisswitchedoff.
7.Disconnectthenegativecablefirst,thenthepositivecable.
8.PushthepositiveterminalAintothefuseboxandpushontheplasticfuseboxcover.
Note
Theenginecannotbestartedwiththismethod.
Pleaseobservethechapter”EMERGENCYSTARTINGWITHJUMPERCABLES”onpage300.
294PracticalTips,EmergencyService

Battery
Generalinformation
Warning!
Riskofshortcircuitandre,resultinginseriouspersonalinjuryordeath.
Observeallwarningnotesonthebattery.
Disconnectthebatteryduringallworkontheelectricalsystem.
Donotlaytoolsorothermetalobjectsonthebatteryastheycouldcauseashortcircuitacrossthebatteryterminal.
Warning!
Hydrogengasgeneratedbythebatterycouldcauseanexplosion,resultinginseriouspersonalinjuryordeath.
Donotexposethebatterytoanopenflame,electricalsparkoralitcigarette.
Donotwipebatterywithadrycloth.
Warning!
Riskofseriouspersonalinjuryordeathanddamagetothefabric,metalorpaint.
Weareyeprotection.
Donotallowbatteryacidtocomeincontactwithyourskin,eyes,fabricorpaintedsurfac-es.
Ifyougetelectrolyte,whichisanacid,inyoureyesoronyourskin,immediatelyrinsewithcoldwaterforseveralminutesandcalladoctor.
Spilledelectrolytemustberinsedoffatoncewithasolutionofbakingsodaandwatertoneutralizetheacid.
Warning!
Batteryposts,terminalsandrelatedacces-soriescontainleadandleadcompounds,chemicalsknowntotheStateofCaliforniatocausecancerandreproductiveharm.
Alwaysprotectyourskinbywashingthorough-lywithsoapandwater.
Warning!
Riskofexplosionasaresultofstaticcharge,resultinginseriouspersonalinjuryordeath.
Donotwipethebatterywithadrycloth.
Eliminatepotentialelectrostaticchargebytouchingthevehiclebeforetouchingthebattery.
Chargestate
Awellchargedbatterywillnotonlypreventstartingproblemsbutwillalsolastlonger.
Inordertoavoiddischargingthebatteryunintentionally:
Switchoffunnecessaryelectricalloadsincitytraffic,onshorttripsorinalineortraffic.
Alwaysremovetheignitionkeyfromtheignitionswitchwhenleavingthecar.
AvoidfrequentoperationoftheconvertibletopandoperationofthePorscheCommunicationManagementsystemwhentheengineisnotrunning.
PracticalTips,EmergencyService295

Batterycare
Ensurethatbatteryissecurelymounted.
Keepterminalsandconnectionscleanandproperlytightened.Corrosioncanbepreventedbycoatingtheterminalsandconnectionswithpetroleumjellyorsiliconespray.
Ensurethatventcapsaresecurelytightenedtopreventspillage.
Checkingtheelectrolyteuidlevel
Generally,theelectrolytelevelmustbecheckedmoreofteninsummerthaninthewinter,andmoreoftenwhendrivinglongdistances.
Whenaddingwater,useonlycleancontainers.Innocasemayalcohol(e.g.windowcleanerresidues)bepermittedtoenterthebattery.
Unscrewandopenthefillerventcapsofeachcell.
Withthecaronalevelsurface,thefluidlevelshouldmeettheindicatormarkineachcell.
Ifnecessary,topupwithdistilledwater.Donotuseacid.Onlyfilluptothemark,otherwisetheelectrolytewilloverflowwhenthebatteryisbeingchargedandcausedamage.
Batterycharging
Automotivebatteriesloosetheirefficiencywhennotinuse.Thechargeavailableinyourbatterycanbemeasuredwithabatteryhydrometer.WerecommendthatthebatteryvoltagebetestedbyyourPorschedealerwhohastheappropriateequipment.
Ifthecarisnotdrivenforprolongedperiods,thebatterymustbechargedatleastevery6weeks.Adischargedbatteryallowsrapidformationofsulfates,leadingtoprematuredeteriorationoftheplates.
Danger!
Hydrogengasgeneratedbythebatterycouldcauseanexplosion,resultinginseriouspersonalinjuryordeath.
Chargebatteryinawellventilatedarea.
Neverchargeafrozenbattery.Itmayexplodebecauseofgastrappedintheice.Allowafrozenbatterytothawoutfirst.
Ifyougetelectrolyte,whichisanacid,inyoureyesoronyourskin,immediatelyrinsewithcoldwaterforseveralminutesandcalladoctor.
Slowbatterycharging
1.Payattentiontoallwarningsandfollowinstructionsthatcomewithyourbatterycharger.
2.Whencharging,ensureadequateventilation.
3.Removebattery.
Pleaseobservethechapter”REMOVINGTHEBATTERY”onpage297.
4.Allventcapsshouldbeopen.Thefluidlevelshouldmeettheindicatormarkineachcell.
5.Ensurethatchargerisswitchedoff-dangerofshortcircuit!
6.Connectchargercables.ChargercablesmustbeconnectedPOSITIVE(+)toPOSI-TIVE(+)andNEGATIVE(-)toNEGATIVE(-).
7.Switchoncharger.Normally,abatteryshouldbechargedatnomorethan10percentofitsratedcapacity.Ratedcapacityofthebatteryinyourvehicleislistedonthebatteryhousing.
8.Aftercharging,turnoffchargeranddisconnectchargercables.
9.Tightentheventcapsandreinstallbattery.
Pleaseobservethechapter”INSTALLINGTHEBATTERY”onpage298.
Winteroperation
Thecapacityandabilityofthebatterytostorepowerdecreasesatlowoutsidetemperatures.
296PracticalTips,EmergencyService

Additionally,morepowerisconsumedwhilestarting,andtheheadlights,heater,rearwindowdefogger,etc.,areusedmorefrequently.
LetyourPorschedealertestthebattery’scapacitybeforewintersetsin.
Thebatterywilldischargemorequicklyifyourvehicleisnotdrivenonadailybasisoveradistanceofseveralmiles.Themoreoftenyoudriveyourvehicle,andthelongerthedistancedrivenoneachtrip,themoreopportunitythevehicle’schargingsystemwillhavetorechargethebatteries.
Replacingbattery
Theservicelifeofthebatteryissubjecttonormalwear;itdependsgreatlyoncare,climaticcondi-tions,anddrivingconditions(distances,loads).
OnlyuseanoriginalPorschebattery,withthecorrectpartnumber,asareplacement.
Pleaseobservethedisposalinstructionsforbatteries.
Puttingvehicleintooperation
Afterthebatteryisconnectedorafterancom-pletelydischargedbatteryischarged,themul-tifunctionalPSMlightlightsupontheinstrumentpanelandamessageappearsontheon-boardcomputertoindicateafault.
Thisfaultcanberemediedwithafewsimplesteps:
1.Starttheengine.
2.Withthevehiclestationary,performafewsteeringmovementstotheleftandrightandthendriveashortdistanceinastraightlineuntilthemultifunctinalPSMlightgoesoutandthemessageontheon-boardcomputerdisappears.
3.Ifthewarningsdonotdisappear,then:DrivecarefullytothenearestauthorizedPorschedealer.Havethefaultremedied.
4.Afterthewarningsdisappear:Stopthevehicleinasuitableplace.
5.Performadaptationofthepowerwindows:
Pleaseobservethechapter”STORINGENDPOSITIONOFTHEWINDOWS”onpage33.
Ignitionkey/ignitionlock
Donotinserttheignitionkeyintotheignitionlockifthevehiclebatteryisdischarged.Theignitionkeycannolongerberemoved.
Thekeycannotberemoveduntilthevehicleelectricalsystemissuppliedwithpoweragain.
Pleaseobservethechapter”EMERGENCYUNLOCKINGOFTHELUGGAGECOMPART-MENTLID”onpage294.
Pleaseobservethechapter”EMERGENCYSTARTINGWITHJUMPERCABLES”onpage300.
Removingthebattery
Therequiredtoolisinthetoolkit.
Thebatteryislocatedintheluggagecompartmentunderablackplasticlid.
Warning!
Riskofdamagetoalternatorandelectroniccontrolunits.
Donotdisconnectthebatterywhiletheengineisrunning.Thisalsoappliestocarsequippedwithabatterymainswitch.
Neverdrivethecarwithadisconnectedbattery.
Warning!
Riskofcausticburnsfromescapingacid.
Keepventcapsontoavoidspillage.
Donottiltthebatterywhenremovingandinstallingit.
PracticalTips,EmergencyService297

1.Switchoffengineandallelectricalloads.
2.Openturn-locksA.Removeplasticlid.
3.PulloffcentralventhoseC.
Danger!
Riskofshortcircuitandexplosion,resultinginseriouspersonalinjuryordeath.
Important:disconnectthenegative(-)groundwirefirst,andthenthepositive(+)cable.
4.Important:disconnectthenegative(-)groundwirefirst,andthenthepositive(+)cable–dangerofshortcircuit!
5.UnscrewfasteningscrewB.
6.Removebattery.
Installingthebattery
1.Putbatteryinandpushitallthewaytothestop.
2.ScrewinfasteningscrewB.
Danger!
Riskofshortcircuitandexplosion,resultinginseriouspersonalinjuryordeath.
Important:connectthepositive(+)cablefirst,andthenthenegative(-)groundwire.
3.Important:connectthepositive(+)cablefirst,andthenthenegative(-)groundwire–riskofshortcircuit!
4.PushoncentralventhoseC.
5.Fitplasticlid.Lockturn-locksA.
