RENAULT SCENIC 2007 J84 / 2.G Automatic Transmission Siemens TA2005 User Guide
Manufacturer: RENAULT, Model Year: 2007, Model line: SCENIC, Model: RENAULT SCENIC 2007 J84 / 2.GPages: 139, PDF Size: 0.43 MB
Page 11 of 139

AUTOMATIC TRANSMISSION
Fault finding - System operation
23A
23A - 11V5 MR-372-J84-23A100$116.mif
SIEMENS TA2005
Vdiag No.: 14-18
COMPUTER INPUTS AND OUTPUTS
INPUTS OUTPUTS
Diagnostic socket
Automatic
transmission
computer
Solenoid valve control
+ battery feed
+ after ignition feed + warning lights display
Intersystem signals + diagnostic
socketIntersystem signal + diagnostic
socket
Driver actions (brake light switch,
gear selector, multifunction
switch)Gear lever lock
AUTO sensors (turbine speed, oil
pressure, oil temperature)Reversing lights
Earth
Wire connection
Multiplex connection
Page 12 of 139

Fault finding - Replacement of components23A
23A - 12V5 MR-372-J84-23A100$174.mif
SIEMENS TA2005
Vdiag No.: 14-18AUTOMATIC TRANSMISSION
Fault finding - Replacement of components
REPLACING THE COMPUTER
If Techline approves the computer replacement, proceed as follows:
–Note the gearbox oil condition meter code in the Identification menu: ID018 Oil condition meter and the
date of the last gearbox oil service ID017 Gearbox oil service date.
–Switch off the ignition.
–Replace the computer.
–If necessary, change the computer configuration in the Enter configuration menu.
–Enter the VIN into the computer with diagnostic tool command VP001 Enter VIN.
–Enter the oil condition meter code from the old automatic transmission computer (found in the Identification
menu) using command VP015 Transfer oil condition meter.
–Enter the gearbox oil service date with command VP016 Enter gearbox oil service date.
–Enter the After-Sales service date with diagnostic tool command VP009 Enter last After-Sales service
date.
–Carry out a check with the diagnostic tool, on the Identification screen.
–Switch off the ignition.
REPLACING AN AUTOMATIC TRANSMISSION COMPONENT
To replace other components of the automatic transmission, (see MR 364 Mechanical, 23A, Automatic
transmission (for MEGANE II) and see MR 370 Mechanical, 23A, Automatic transmission (for SCENIC II)).
After replacing one or more automatic transmission components, or after reprogramming, auto-program the solenoid
valves using command RZ005 "Auto-adaptives" (see Dealing with command modes).IT IS ESSENTIAL TO CONTACT YOUR TECHLINE BEFORE REPLACING AN AUTOMATIC TRANSMISSION
COMPUTER.
MR-372-J84-23A100$174.mif
Page 13 of 139

Fault finding - Configurations and programming23A
23A - 13V5 MR-372-J84-23A100$232.mif
SIEMENS TA2005
Vdiag No.: 14-18AUTOMATIC TRANSMISSION
Fault finding - Configurations and programming
PROGRAMMING
●VP001 Enter VIN:
As it is necessary to enter the VIN each time dialogue is established with the diagnostic tool, it must be
programmed into each vehicle computer whenever a computer is replaced.
Programming procedure:
–Connect the diagnostic tool.
–Consult the fault finding procedure for the automatic transmission.
–Select configuration VP001 Enter VIN.
–Enter the VIN.
–Exit fault finding mode.
–Switch off the ignition.
–Wait for the end of Power-latch: over 10 seconds.
●VP009 Enter last After-Sales operation date:
Every time work is carried out on the automatic transmission in the workshop, enter the date of the
operation.
Select command VP009 Enter last After-Sales operation date on the diagnostic tool, then use the tool's
keypad to enter the date of the operation.
●VP015 Transfer oil condition meter:
Transfer the oil wear counter code from the old computer.
Select command VP015 Transfer oil wear counter on the diagnostic tool, then use the keypad to enter
the code found on the replaced computer.
●VP016 Enter gearbox oil service date:
Select command VP016 Enter gearbox oil service date on the diagnostic tool, then use the keypad to
enter the date found on the replaced computer.
* The immobiliser warning light will flash a few seconds after the ignition is switched off.
MR-372-J84-23A100$232.mif
Page 14 of 139

Fault finding - Fault summary table23A
23A - 14V5 MR-372-J84-23A100$290.mif
SIEMENS TA2005
Vdiag No.: 14-18AUTOMATIC TRANSMISSION
Fault finding - Fault summary table
* All Mégane vehicles except ScénicTool faultAssociated
DTCDiagnostic tool title
DF003 0641Analogue sensor power supply
DF005 0840Oil pressure sensor circuit
DF009 0705Multifunction switch prohibited position
DF012 0657Solenoid valve supply
DF016 0795Lock-up solenoid valve circuit
DF017 2753Exchanger flow rate solenoid valve circuit
DF023 0710Gearbox oil temperature sensor circuit
DF029 0709Multifunction switch in unstable position
DF036 0775Pressure modulating solenoid valve circuit
*DF064 0814Display circuit
DF084 C001Multiplex network
DF085 0753EVS1 sequence solenoid valve circuit
DF086 0758EVS2 sequence solenoid valve circuit
DF087 0763EVS3 sequence solenoid valve circuit
DF088 0773EVS5 sequence solenoid valve circuit
DF089 0768EVS4 sequence solenoid valve circuit
DF093 0819Manual sequential controls circuit
DF095 1928Gear lever lock electromagnet circuit
DF105 0741Declutching function when stopping
DF109 D123Engine torque multiplex signal
DF112 2709EVS6 sequence solenoid valve circuit
DF113 0740Converter lockup servo control
DF131 0730Slippage
DF145 D12FInvalid pedal position multiplex signal
MR-372-J84-23A100$290.mif
Page 15 of 139

AUTOMATIC TRANSMISSION
Fault finding - Fault summary table23A
23A - 15V5 MR-372-J84-23A100$290.mif
SIEMENS TA2005
Vdiag No.: 14-18
Tool faultAssociated
DTCDiagnostic tool title
DF147 D122Invalid anticipated torque multiplex signal
DF177 0218Automatic transmission overheating
DF183 C140No UCH multiplex signal
DF185 C121No ABS/ESP multiplex signal
DF186 C100No injection multiplex signal
DF226 0841Automatic transmission internal pressure
DF227 D403Invalid UCH brake pedal multiplex signal
DF228 D22BInvalid ABS transverse acceleration multiplex signal
DF229 D208Invalid ABS brake multiplex signal
DF230 0720Invalid vehicle speed multiplex signal
DF231 D200Absent vehicle speed multiplex signal
DF232 0603Computer
DF233 0604Computer
DF234 0605Computer
DF235 D121Invalid pedal position multiplex signal
DF236 D11FInvalid engine speed multiplex signal
DF237 D100Invalid coolant temperature signal
DF238 D12BInvalid raw engine torque multiplex signal
DF239 D120Invalid actual engine torque multiplex signal
DF240 D220Invalid front right-hand wheel speed multiplex signal
DF241 D221Invalid front left-hand wheel speed multiplex signal
DF242 D225Invalid rear right-hand wheel speed multiplex signal
DF243 D226Invalid rear left-hand wheel speed multiplex signal
DF244 0715Turbine speed sensor signal
DF263 D12DInstantaneous maximum torque multiplex signal
Page 16 of 139

Fault finding - Interpretation of faults23A
23A-16V5 MR-372-J84-23A100$348.mif
SIEMENS TA2005
Vdiag No.: 14-18AUTOMATIC TRANSMISSION
Fault finding - Interpretation of faults
DF003
PRESENT
OR
STOREDANALOGUE SENSOR SUPPLY
1.DEF: Voltage outside permitted range of values
NOTESSpecial notes:
Use bornier Elé. 1681 for all operations on the computer connectors.
Customer complaint: deterioration in gear shift strategies.
Deal first with faults: DF005 Oil pressure sensor circuit and DF023 Gearbox oil temperature sensor circuit.
Disconnect the battery.
Check the condition and cleanliness of the modular connector connections.
Disconnect the computer. Check the cleanliness and condition of the connections.
Repair if necessary.
Check the insulation, continuity and the absence of interference resistance to earth, to + 12 V of the following
connections:
●connection code 5U, between components 119 and 781,
●connection code 5V, between components 119 and 781,
●connection code 5BC, between components 119 and 754,
●connection code 5BB, between components 119 and 754.
Check the supply of the analogue sensors = 5 V.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring. Otherwise replace the wiring.
If the problem is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
DP0TA2005_V14_DF003/DP0TA2005_V18_DF003
MR-372-J84-23A100$348.mif
Page 17 of 139

AUTOMATIC TRANSMISSION
Fault finding - Interpretation of faults
23A
23A-17V5 MR-372-J84-23A100$348.mif
SIEMENS TA2005
Vdiag No.: 14-18
DF005
PRESENT
OR
STOREDOIL PRESSURE SENSOR CIRCUIT
CO.0: Open circuit or short circuit to earth
NOTESConditions for applying the fault finding procedure to stored faults:
The fault appears after a timed period of 10 seconds with the engine running
at 2000 rpm.
Special notes:
Use bornier Elé. 1681 for all operations on the computer connectors.
Disconnect the battery.
Disconnect the modular connector, and check the cleanliness and condition of the connections.
Disconnect the computer. Check the cleanliness and condition of the connections.
Repair if necessary.
Check the insulation, continuity and the absence of interference resistance to earth, to + 12 V of the following
connection:
●connection code 5U, between components 119 and 781.
With the ignition on, check for + 5 V on connection 5U of the oil pressure sensor connector.
If the connection is faulty and there is a repair procedure (see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring. Otherwise replace the wiring.
●connection code 5W, between components 119 and 781,
●connection code 5V, between components 119 and 781.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring. Otherwise replace the wiring.
The voltage on connection 5U of the modular connector must be + 5 V, otherwise check the computer supply.
If the connection is faulty and there is a repair procedure (see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring. Otherwise replace the wiring.
Reconnect the modular connector.
Measure the resistance of component 781 between connections 5V and 5W on the computer connector (female
connector).
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring. Otherwise replace the wiring.
Replace the sensor if the resistance is not approximately 20 kΩ.
If the problem is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
DP0TA2005_V14_DF005/DP0TA2005_V18_DF005
Page 18 of 139

AUTOMATIC TRANSMISSION
Fault finding - Interpretation of faults
23A
23A-18V5 MR-372-J84-23A100$348.mif
SIEMENS TA2005
Vdiag No.: 14-18
* CMF: Multifunction switch DF009
PRESENT
OR
STORED
MULTIFUNCTION SWITCH IN PROHIBITED POSITION
NOTESConditions for applying the fault finding procedure to stored faults:
The fault appears when the selector lever is moved from position P to position D with
a stop at each lever position.
Special notes:
Use bornier Elé. 1681 for all operations on the computer connectors.
Use the Mégane II or Scénic II wiring diagram Technical Note.
ACheck the consistency between: ET012 Gear lever position, the instrument panel display and the gear lever
position while shifting the lever into all the possible positions.
BTo check that there is no clearance between the gearbox output lever and the multifunction switch shaft, see
test 1 Checking the gearbox output lever clearance
–If there is clearance, check the tightness of the retaining nut. If this has no effect, replace the lever.
–If there is no clearance, move on to the next step.
CAdjust the control (see MR 370 Mechanical, 23A Automatic transmission, Automatic transmission control
unit (for Mégane II and Scénic II)).
–If the adjustment is correct, then the procedure is complete.
–If the adjustment is incorrect, move on to the next step.
DCheck the cleanliness, condition and mounting of the multifunction switch.
Check the adjustment of the CMF* in neutral (see MR 364 Mechanical, 23A Automatic transmission,
Multifunction switch, Removal - Refitting (for Mégane II) and MR 370 Mechanical, 23A Automatic
transmission, Multifunction switch, Adjustment (for Scénic II)).
–If the adjustment is incorrect, adjust the multifunction switch.
–If the adjustment is correct, move on to the next step.
ECheck the adjustment of the ball detent blade on the gearbox output lever at the unclipped external control
(see Technical Note 4194A: Automatic transmission indicator strip flashing):
–If the adjustment is incorrect, adjust the ball detent blade.
–If the check is correct, move on to the electrical check.
Repair if necessary.
Check the condition and cleanliness of the connector A connections.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
DP0TA2005_V14_DF009/DP0TA2005_V18_DF009
Page 19 of 139

AUTOMATIC TRANSMISSION
Fault finding - Interpretation of faults
23A
23A-19V5 MR-372-J84-23A100$348.mif
SIEMENS TA2005
Vdiag No.: 14-18
DF009
CONTINUED 1
Check for continuity on component 485 between the following connections:
Lever in position P
–Connection codes 5DG and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Lever in position R
–Connection codes 5DG and 5DK between components 119 and 485.
–Connection codes 5DH and 5DK between components 119 and 485.
–Connection codes 5DJ and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Lever in position N
–Connection codes 5DH and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Lever in position D
–Connection codes 5DJ and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the continuity is faulty, change the multifunction switch.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
Page 20 of 139

AUTOMATIC TRANSMISSION
Fault finding - Interpretation of faults
23A
23A-20V5 MR-372-J84-23A100$348.mif
SIEMENS TA2005
Vdiag No.: 14-18
DF009
CONTINUED 2
Check the insulation of component 485 on the following connections:
Lever in position P
●Connection codes 5DH and 5DK between components 119 and 485.
●Connection codes 5DJ and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Lever in position N
●Connection codes 5DG and 5DK between components 119 and 485.
●Connection codes 5DJ and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Lever in position D
●Connection codes 5DG and 5DK between components 119 and 485.
●Connection codes 5DH and 5DK between components 119 and 485.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the insulation is faulty, replace the multifunction switch.
Check the cleanliness and condition of the connections.
Check the insulation, continuity and the absence of interference resistance to earth, to + 12 V of the following
connections:
●Connection code 5DG between components 119 and 485.
●Connection code 5DH between components 119 and 485.
●Connection code 5DJ between components 119 and 485.
●Connection code 5DK between components 119 and 485.
●If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A,
Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the problem is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
