RENAULT SCENIC 2011 J95 / 3.G Engine And Peripherals Workshop Manual

13B-131
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET415 CRUISE CONTROL/SPEED LIMITER DEACTIVATION
NOTESNone.
Note:
Cruise control can be activated when the vehicle speed exceeds 18 mph (30 km/h).
Status ET415 shows various reasons for deactivation of the cruise control / speed limiter function, due to a driver
request or the external environment (e.g. STATUS 1).
IMPORTANT:
Clear the fault memory by running command RZ001 Fault memory, to reset this status to NONE.
NONEThis status is present on the diagnostic tool if:
the computer has been reinitialised,
the computer has been reprogrammed.
STATUS 1Traction control request
If the vehicle is fitted with a traction control system, the cruise control function is
deactivated every time the ABS computer calls for traction control.
Status ET415 becomes STATUS 1 when driving with the cruise control active
(ET042 Cruise control/Speed limiter: CRUISE CONTROL) and traction control is
requested.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 1 without traction control requested (see 38C,
ABS).
DDCR_V44_ET415/DDCR_V48_ET415

13B-132
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET415
CONTINUED 1
STATUS 2
Brake pedal depressed
The cruise control function is deactivated when the brake pedal is depressed.
Status ET415 becomes STATUS 2 when driving with cruise control active
(ET042 Cruise control - speed limiter: CRUISE CONTROL) and the brake pedal is
depressed.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 2 without pressing the brake pedal, consult
the interpretation of statuses ET704 and ET705 Brake contact No. 1 and No. 2.
STATUS 3Clutch pedal depressed
Manual gearbox ONLY
The cruise control function is deactivated when the gearbox is not coupled to
the engine (clutch pedal depressed).
Status ET415 becomes STATUS 3 when driving with the cruise control active
(ET042 Cruise control - speed limiter: CRUISE CONTROL) and the clutch pedal
is depressed.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 3 without the clutch pedal being depressed,
consult the interpretation of status ET405 Clutch pedal.
If the vehicle is fitted with automatic transmission:
Test the multiplex network: check the configuration of the multiplex network in relation
to the vehicle's technical specification, especially the configuration of the automatic
transmission computer (see 88B, MULTIPLEXING).

13B-133
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET415
CONTINUED 2
STATUS 4
Cancel button pressed
The cruise control/speed limiter function is deactivated each time the suspend button
is pressed.
Status ET415 becomes STATUS 4, when driving when:
– Either the cruise control is active, or
– the speed limiter is active,
– and the driver presses the 0 button.
This action deactivates the Cruise control/Speed limiter.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 4 without pressing the 0 button, consult the
interpretation of status ET703 Cruise control - speed limiter buttons and run fault
finding on the R/0 control button located on the right-hand side of the steering wheel.

13B-134
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET415
CONTINUED 3
STATUS 5
Cruise control or speed limiter monitoring
This status appears when the vehicle brakes or decelerates sharply without
the injection computer receiving a signal that the brake pedal switch has been
pressed.
If status ET415 is STATUS 5, consult the interpretation:
– of status ET042 Cruise control/Speed limiter,
– of status ET703 Cruise control - speed limiter buttons,
– of status ET704 Brake switch no. 1,
– and status ET705 Brake switch no. 2,
to test the cruise control/speed limiter system components and locate the faulty
component.
Also, check the operation of the accelerator pedal, and use the diagnostic tool to
check the presence of a fault connected with this component. Deal with them if
necessary.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 5, deal with the present faults or those stored in
the injection computer.
If the fault is still present, contact the Techline.

13B-135
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET415
CONTINUED 4
STATUS 6
Gear lever in neutral (manual gearbox) or the neutral position
(automatic gearbox)
Status ET415 becomes STATUS 6 when driving with cruise control active
(ET042 Cruise control - speed limiter: CRUISE CONTROL) and:
– if the driver puts the gear lever in neutral position on a manual gearbox without
declutching or,
– if the gear lever is put in neutral on an automatic transmission.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 6 without shifting the gear lever into neutral on
a manual gearbox without declutching, or into the neutral position on an automatic
transmission, run fault finding on the ABS computer and check the configuration of
the tyre size stored in the computer. If the configuration is correct, contact the
Techline.
STATUS 7Inconsistency between the request and the vehicle speed
Status ET415 becomes STATUS 7 if the computer detects too great a difference
between the speed requested by the driver and the vehicle speed.
This could occur when driving with cruise control active (ET042 Cruise control/
speed limiter: CRUISE CONTROL) and when there is a significant difference in
speed.
This inconsistency deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If status ET415 becomes STATUS 7 on relatively flat terrain, contact the Techline.

13B-136
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET415
CONTINUED 5
STATUS 8
Automatic transmission in defect mode.
NOT AVAILABLE ON THIS SOFTWARE
STATUS 9Vehicle speed monitoring
Status ET415 becomes STATUS 9 if the vehicle speed received by the computer is
invalid or absent.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the ABS computer.
Deal with the present or stored faults (see 38C, ABS).
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If the specification STATUS 9 is still present, contact Techline.
STATUS 10Monitoring by injection computer
Status ET415 becomes STATUS 10 when driving with cruise control active
(ET042 Cruise control - speed limiter: CRUISE CONTROL) and if the injection
computer detects a fault anywhere in the engine management system, or an engine
speed that is too high or too low.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then Perform fault finding on the injection
computer.
Deal with any present or stored faults (see 13B, Diesel injection).
Reinitialise status ET415 on the injection computer by running command
RZ001 Fault memory.
If STATUS 10 is still present, contact the Techline.

13B-137
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET703 CRUISE CONTROL/SPEED LIMITER BUTTONS
NOTESSpecial notes:
Only perform these tests if the statuses do not correspond with the system programming
functions.
INACTIVEStatus ET703 becomes INACTIVE when none of the cruise control - speed limiter
buttons are pressed. These buttons are located on the steering wheel.
To remove the driver's airbag to perform the checks in complete safety.
(see 88C, Airbag and pretensioners)
If status ET703 does not display INACTIVE,
• check the condition of the cruise control/speed limiter +/- button and the condition
of its connector.
• check the condition of the cruise control/speed limiter R/0 button and the condition
of its connector.
Repair if necessary.
DDCR_V44_ET703/DDCR_V48_ET703

13B-138
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET703
CONTINUED 1
INCREASE
Status ET703 becomes PLUS when the cruise control / speed limiter + button is
pressed. This button is on the steering wheel, on the left-hand side.
To remove the driver's airbag to perform the checks in complete safety.
(see 88C, Airbag and pretensioners)
If status ET703 does not display INCREASE, check the condition of the cruise control
- speed limiter +/- button and the condition of its connector. Repair if necessary.
Measure the resistance on the following connections while pressing
the + button (on the button tracks):
• Connection code 86G of component 331.
• Connection code 86M of component 331.
If the resistance is not approximately 300 Ωcheck the continuity of the connection
when the button is not pressed. If there is continuity, replace the +/- control button.
(see MR 364 (Mégane II), MR 370 (Scénic II), Mechanical, 83D, Cruise control,
Steering wheel switch: Removal - Refitting).
DECREASEStatus ET703 becomes DECREASE when the - button of the cruise control/speed
limiter is pressed. This button is on the steering wheel, on the left-hand side.
To remove the driver's airbag to perform the checks in complete safety.
(see 88C, Airbag and pretensioners)
If status ET703 does not change to MINUS, check the condition of the cruise control
/ speed limiter +/- button, and the condition of its connector. Repair if necessary.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Measure the resistance of the following connections while pressing the "-"
button (on the button tracks):
• Connection code 86G of component 331.
• Connection code 86M of component 331.
If the resistance is not approximately 100 Ωcheck the continuity of the connection
when the button is not pressed. If there is continuity, replace the +/- control button.
(see MR 364 (Mégane II), MR 370 (Scénic II), Mechanical, 83D, Cruise control,
Steering wheel switch: Removal - Refitting).

13B-139
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET703
CONTINUED 2
SUSPEND
Status ET703 becomes SUSPEND when the cruise control / speed limiter 0 button is
pressed. This button is located on the steering wheel, to the right.
To remove the driver's airbag to perform the checks in complete safety.
(see 88C, Airbag and pretensioners)
If status ET703 does not become SUSPEND, check the condition of the cruise control
- speed limiter R/0 button and the condition of its connector.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Measure the resistance of the following connection whilst pressing the 0 button
(on the button tracks):
• Connection code 86G of component 331.
• Connection code 86M of component 331.
If the resistance is not approximately 0 Ω, replace the R/0 control button.
If there is continuity, replace the R/0 control button (see MR 364 (Mégane II), MR 370
(Scénic II), Mechanical, 83D, Cruise control, Steering wheel switch: Removal -
Refitting).

13B-140
AFTER REPAIRCarry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$090.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
DDCR INJECTION
Vdiag No.: 44, 48
ET703
CONTINUED 3
RESUME
Status ET703 becomes RESUME when the R button of the cruise control/speed
limiter is pressed. This button is located on the steering wheel, to the right.
To remove the driver's airbag to perform the checks in complete safety.
(see 88C, Airbag and pretensioners)
If status ET703 does not change to RESUME, check the condition of the cruise
control / speed limiter R/0 button, and the condition of its connector. Repair if
necessary.
If there is a repair procedure (see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
Measure the resistance on the following connection while pressing
the R button (on the button tracks):
• Connection code 86G of component 331.
• Connection code 86M of component 331.
If the resistance is not approximately 900 Ω, check the continuity of the connection
when the button is not pressed. If there is continuity, replace the R/0 control button
(see MR 364 (Mégane II), MR 370 (Scénic II), Mechanical, 83D, Cruise control,
Steering wheel switch: Removal - Refitting).
