Seat Ibiza 2020 Directive 2014/53/EU Bluetooth

Page 61 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
Bibliograph
y Add the following standards:
Add the following notes for the standards indicated:
IEC 60130 - 9 NOTE Harmonized as EN 60130 - 9.
IEC 60269 - 2 NOTE Harmonized as HD 60269 - 2.
IEC 60309 - 1 NOTE Harmo nized as EN 60309 - 1.
IEC 60364 NOTE some parts harmonized in HD 384/HD 60364 series.
IEC 60601 - 2 - 4 NOTE Harmonized as EN 60601 - 2 - 4.
IEC 60664 - 5 NOTE Harmonized as EN 60664 - 5.
IEC 61032:1997 NOTE Harmonized as EN 61032:199 8 (not modified).
IEC 61508 - 1 NOTE Harmonized as EN 61508 - 1.
IEC 61558 - 2 - 1 NOTE Harmonized as EN 61558 - 2 - 1.
IEC 61558 - 2 - 4 NOTE Harmonized as EN 61558 - 2 - 4.
IEC 61558 - 2 - 6 NOTE Harmonized as EN 61558 - 2 - 6.
IEC 61643 - 1 N OTE Harmonized as EN 61643 - 1.
IEC 61643 - 21 NOTE Harmonized as EN 61643 - 21.
IEC 61643 - 311 NOTE Harmonized as EN 61643 - 311.
IEC 61643 - 321 NOTE Harmonized as EN 61643 - 321.
IEC 61643 - 331 NOTE Harmonized as EN 61643 - 331. P

Page 62 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C

ZB ANN EX ZB, SPECIAL NATIONAL CONDITIONS (EN)
N/A
4.1.15 Denmark, Finland, Norway and Sweden
To the end of the subclause the following is added:
Class I pluggable equipment type A intended for
connection to other equipment or a network shall, if
safety relies o n connection to reliable earthing or if
surge suppressors are connected between the network
terminals and accessible parts, have a marking stating
that the equipment shall be connected to an earthed
mains socket - outlet.
The marking text in the applicable c ountries shall be as
follows:
In Denmark : “Apparatets stikprop skal tilsluttes en
stikkontakt med jord som giver forbindelse til
stikproppens jord.”
In Finland : "Laite on liitettä vä suojakoskettimilla
varustettuun pistorasiaan"
In Norway : “Apparatet må til koples jordet stikkontakt”
In Sweden : “Apparaten skall anslutas till jordat uttag” N/A
4.7.3 United Kingdom
To the end of the subclause the following is added:
The torque test is performed using a socket - outlet
complying with BS 1363, and the plug part s hall be
assessed to the relevant clauses of BS 1363. Also see
Annex G.4.2 of this annex N/A
5.2.2.2 Denmark
After the 2nd paragraph add the following:
A warning (marking safeguard ) for high touch current
is required if the touch current exceeds the limit s of 3,5
mA a.c. or 10 mA d.c. N/A

Page 63 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.4.11.1
and Annex
G Finland and Sweden
To the end of the subclause the following is added:
For separation of the telecommunication network from
earth the following is applicable:
If this insulation is solid, including insulation forming part
of a component, it shall at least consist of either
• two layers of thin sheet material, each of which shall
pass the electric strength test below, or
• one layer having a distance through insulation of at
least 0,4 mm, which shall pass the electric strength test
below.
If this insulation forms part of a semiconductor
component (e.g. an optocoupler), there is no distance
through insulation requirement for the insulation
consisting of an insulating compound completely filling
the casi ng, so that clearances and creepage distances
do not exist, if the component passes the electric
strength test in accordance with the compliance clause
below and in addition
• passes the tests and inspection criteria of 5.4.8 with an
electric strength tes t of 1,5 kV multiplied by 1,6 (the
electric strength test of 5.4.9 shall be performed using
1,5 kV), and
• is subject to routine testing for electric strength during
manufacturing, using a test voltage of 1,5kV.
It is permitted to bridge this insulation wi th a capacitor
complying with EN 60384 - 14:2005, subclass Y2.
A capacitor classified Y3 according to EN 60384 -
14:2005, may bridge this insulation under the following
conditions:
• the insulation requirements are satisfied by having a
capacitor classified Y3 as defined by EN 60384 - 14,
which in addition to the Y3 testing, is tested with an
impulse test of 2,5 kV defined in 5.4.11;
• the additional testing shall be performed on all the test
specimens as described in EN 60384 - 14;
the impulse test of 2,5 kV is to be performed before the
endurance test in EN 60384 - 14, in the sequence of
tests as described in EN 60384 - 14. N/A
5.5.2.1 Norway
After the 3rd paragraph the following is added:
Due to the IT power system used, capacitors are
required to be rated for the applicable line - to - line
voltage (230 V). N/A

Page 64 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.5.6 Finland, Norway and Sweden
To the end of the subclause the following is added:
Resistors used as basic safeguard or bridging basic
insulation in class I pluggable equipment type A
shall comply with G.10. 1 and the test of G.10.2. N/A
5.6.1 Denmark
Add to the end of the subclause
Due to many existing installations where the socket -
outlets can be protected with fuses with higher rating
than the rating of the socket - outlets the protection for
pluggable equi pment type A shall be an integral part of
the equipment.
Justification:
In Denmark an existing 13 A socket outlet can be
protected by a 20 A fuse. N/A
5.6.4.2.1 Ireland and United Kingdom
After the indent for pluggable equipment type A , the
following is added:
– the protective current rating is taken to be 13 A, this
being the largest rating of fuse used in the mains plug. N/A
5.6.5.1 To the second paragraph the following is added:
The range of conductor sizes of flexible cords to be
accepted by termina ls for equipment with a rated
current over 10 A and up to and including 13 A is:
1,25 mm 2
to 1,5 mm 2
in cross - sectional area. N/A
5.7.5 Denmark
To the end of the subclause the following is added:
The installation instruction shall be affixed to the
equip ment if the protective conductor current
exceeds the limits of 3,5 mA a.c. or 10 mA d.c. N/A

Page 65 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.7.6.1 Norway and Sweden
To the end of the subclause the following is added:
The screen of the television distribution system is
normally not earthed at the ent rance of the building and
there is normally no equipotential bonding system within
the building. Therefore the protective earthing of the
building installation needs to be isolated from the screen
of a cable distribution system.
It is however accepted to p rovide the insulation external
to the equipment by an adapter or an interconnection
cable with galvanic isolator, which may be provided by a
retailer, for example.
The user manual shall then have the following or similar
information in Norwegian and Swedis h language
respectively, depending on in what country the
equipment is intended to be used in:
“Apparatus connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protect ive
earthing – and to a television distribution system using
coaxial cable, may in some circumstances create a fire
hazard. Connection to a television distribution system
therefore has to be provided through a device providing
electrical isolation below a certain frequency range
(galvanic isolator, see EN 60728 - 11)”
NOTE In Norway, due to regulation for CATV - installations, and in
Sweden, a galvanic isolator shall provide electrical insulation below 5
MHz. The insulation shall withstand a dielectric strength of 1,5 kV
r.m.s., 50 Hz or 60 Hz, for 1 min.

Translation to Norwegian (the Swedish text will also be
accepted in Norway):
“Apparater som er koplet til beskyttelsesjord via
nettplugg og/eller via annet jordtilkoplet utstyr – og er
tilkoplet et koaksialbas ert kabel - TV nett, kan forårsake
brannfare. For å unngå dette skal det ved tilkopling av
apparater til kabel - TV nett installeres en galvanisk
isolator mellom apparatet og kabel - TV nettet.”
Translation to Swedish:
”Apparater som är kopplad till skyddsjord via jordat
vä gguttag och/eller via annan utrustning och samtidigt
är kopplad till kabel - TV nät kan i viss a fall medfőra risk
főr brand. Főr att undvika detta skall vid anslutning av
apparaten till kabel - TV nät galvanisk isolator finnas
mellan apparaten och kabel - TV nätet.”. N/A

Page 66 of 8 9 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.7.6.2 Denmark
To the end of the subclause the following is added:
The warning (marking safeguard) for high touch current
is required if the touch current or the protective current
exceed the limits of 3,5 mA . N/A
B.3.1 and
B.4 Ireland and United Kingdom
The following is applicable:
To protect against excessive currents and short - circuits
in the primary circuit of direct plug - in equipment , tests
according to Annexes B.3.1 and B.4 shall be conducted
using an external miniature circuit breaker complying
with EN 60898 - 1, Type B, rated 32A. If the equipment
does not pass these tests, s uitable protective devices
shall be included as an integral part of the direct plug -
in equipment , until the requirements of Annexes B.3.1
and B.4 are met N/A
G.4.2 Denmark
To the end of the subclause the following is added:
Supply cords of single phase a ppliances having a rated
current not exceeding 13 A shall be provided with a plug
according to DS 60884 - 2 - D1:2011.
CLASS I EQUIPMENT provided with socket - outlets with earth
contacts or which are intended to be used in locations where
protection against ind irect contact is required according to the
wiring rules shall be provided with a plug in accordance with
standard sheet DK 2 - 1a or DK 2 - 5a.
If a single - phase equipment having a RATED CURRENT
exceeding 13 A or if a poly - phase equipment is provided with
a su pply cord with a plug, this plug shall be in accordance with
the standard sheets DK 6 - 1a in DS 60884 - 2 - D1 or EN 60309 -
2.
Mains socket outlets intended for providing power to
Class II apparatus with a rated current of 2,5 A shall be
in accordance DS 60884 - 2 - D1:2011 standard sheet
DKA 1 - 4a.
Other current rating socket outlets shall be in
compliance with Standard Sheet DKA 1 - 3a or DKA 1 -
1c.
Mains socket - outlets with earth shall be in compliance
with DS 60884 - 2 - D1:2011 Standard Sheet DK 1 - 3a, DK
1 - 1c, DK1 - 1d, D K 1 - 5a or DK 1 - 7a
Justification:
Heavy Current Regulations, Section 6c N/A

Page 67 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
G.4.2 United Kingdom
To the end of the subclause the following is added:
The plug part of direct plug - in equipment shall be
assessed to BS 1363: Part 1, 12.1, 12.2, 12.3, 12.9,
12 .11, 12.12, 12.13, 12.16, and 12.17, except that the
test of 12.17 is performed at not less than 125 °C.
Where the metal earth pin is replaced by an Insulated
Shutter Opening Device (ISOD), the requirements of
clauses 22.2 and 23 also apply. N/A
G.7.1 Un ited Kingdom
To the first paragraph the following is added:
Equipment which is fitted with a flexible cable or cord
and is designed to be connected to a mains socket
conforming to BS 1363 by means of that flexible cable
or cord shall be fitted with a ‘stan dard plug’ in
accordance with the Plugs and Sockets etc (Safety)
Regulations 1994, Statutory Instrument 1994 No. 1768,
unless exempted by those regulations.
NOTE "Standard plug" is defined in SI 1768:1994 and essentially
means an approved plug conforming t o BS 1363 or an approved
conversion plug. N/A
G.7.1 Ireland
To the first paragraph the following is added:
Apparatus which is fitted with a flexible cable or cord
shall be provided with a plug in accordance with
Statutory Instrument 525: 1997, “13 A Plug s and
Conversion Adapters for Domestic Use Regulations:
1997. S.I. 525 provides for the recognition of a standard
of another Member State which is equivalent to the
relevant Irish Standard N/A
G.7.2 Ireland and United Kingdom
To the first paragraph the f ollowing is added:
A power supply cord with a conductor of 1,25 mm 2
is
allowed for equipment which is rated over 10 A and up
to and including 13 A. N/A

Page 68 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
ZC ANNEX ZC, NATIONAL DEVIATIONS (EN)
N/A
10.5.2 Germany
The following requirement applies:
For the o peration of any cathode ray tube intended for
the display of visual images operating at an acceleration
voltage exceeding 40 kV, authorization is required, or
application of type approval (Bauartzulassung) and
marking.
Justification:
German ministerial dec ree against ionizing radiation
(Röntgenverordnung), in force since 2002 - 07 - 01,
implementing the European Directive 96/29/EURATOM.
NOTE Contact address:
Physikalisch - Technische Bundesanstalt, Bundesallee 100,
D - 38116 Braunschweig,
Tel.: Int +49 - 531 - 592 - 63 20,
Internet: http://www.ptb.de N/A

Page 69 of 89 Report No. : 60404488 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
ATTACHMENT TO TEST R EPORT
IEC 62368 - 1
EUROPEAN GROUP DIFFE RENCES AND NATIONAL DIFFERENCES
(AUDIO/VIDEO, INFORM ATION AND COMMUNICAT ION TECHNOLOGY EQUIP MENT - PART 1: SAFET Y
REQUIREMENTS)
Differences according to ............... :
EN IEC 62368 - 1:2020+A11:2020
Attachment Form No . ..................... :
EU_GD_IEC62368_1C
Attachment Originator ................... :
UL(Demko)
Master Attachment ......................... :
2020 - 03 - 10
Copyright © 2020 IEC System for Conformity Testing and Certification of Electrical Equipment
(IECEE), Geneva, Switzerland . All rights reserved.
CENELEC COMMON MODIFICATIONS (EN)
P
Clause numbers in the cells that are shaded light grey are clause references in EN
IEC 62368 - 1:2020+A11:2020. All other clause numbers in that column, except for
those in the paragraph below, r efers to IEC 62368 - 1:2018.

Clauses, subclauses, notes, tables, figures and annexes which are additional to
those in IEC 62368 - 1:2018 are prefixed “Z”. P
Add the following annexes:
Annex ZA (normative) Normative references to international publications
with their corresponding European publications
Annex ZB (normative) Special national conditions
Annex ZC (informative) A - deviations
Annex ZD (informative) IEC and CENELEC code designations for flexible
cords P
1 Modification to Clause 3 .
N/A
3.3.19 Sound exposure
Replace 3.3.19 of IEC 62368 - 1 with the following definitions: N/A
3.3.19.1
momentary exposure level, MEL
metric for estimating 1 s sound exposure level from
the HD 483 - 1 S2 test signal applied to both channels,
based on EN 50332 - 1: 2013, 4.2.

Note 1 to entry: MEL is measured as A - weighted levels in dB.
Note 2 to entry: See B.3 of EN 50332 - 3:2017 for additional
information. N/A

Page 70 of 89 Report No. : 60404488 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
3.3.19.3
sound exposure, E

A - weighted sound pressure ( p ) squared and
integrated over a stated period of time, T

Note 1 to entry: The SI unit is Pa 2
s.
N/A
3.3.19.4
sound exposure level, SEL

logarithmic measure of sound exposure relative to a
reference value, E 0 , typically the 1 kHz
threshold of hearing in humans.

Note 1 to entry: SEL is measured as A - weighted levels in dB.

dB

Note 2 to entry: See B.4 of EN 50332 - 3:2017 for additional
information. N/A
3.3.19.5
digital signal level relative to full scale, dBFS

levels reported in dBFS are always r.m.s. Full scale
level, 0 dBFS, is the level of a dc - free 997 -
Hz sine wave whose undithered positive peak value
is positive digital full scale, leaving the code
corresponding to negative digital full scale unused

Note 1 to entry: It is invalid to use dBFS for non - r.m.s. levels.
Because the definition of full scale is based on a sine wave, the
level of signals with a crest factor lower than that of a sine wave
may exceed 0 dBFS. In particular, square wave signals may
reach +3,01 dBFS. N/A
2 Modification to Clause 10
N/A
10.6 Safeguards against acoustic energy sources
Replace 10.6 of IEC 62368 - 1 with the following: N/A
10.6.1.1 Introduction

Safeguard requirements for protection against long -
term exposure to excessive sound pressure
levels from personal music players closely coupled
to the ear are speci fied below. Requirements
for earphones and headphones intended for use
with personal music players are also covered.
A personal music player is a portable equipment
intended for use by an ordinary person , that:

– is designed to allow the user to listen t o audio or
audiovisual content / material; and N/A
