TRANSFER CASE
RODIUS 2005.07
3410-01
Ring, snap
Ring, snap
Ring, snap
Bearing
Hub, circular
Asm. -shaft, input
Plate, thrust
Gear, sun
Snap ring
Asm. -carrier (complete)
Hub reduction
Asm. -shaft, main
Clamp hose
Hose
Filter
Asm. -coil, electric
Asm. -cam/coil hsg.
Ring, snap
Armature
Hub, lockup
Spring, sleeve return
Collar, lockup
Sprocket, driving
Spring, return
Rail, shift
Fork, shift
Asm. -fork, shift
Cam, electric shift
Spring, torsion
Spacer
Shaft, shift
Ring, retaining
Asm. -case, transfer
Barb, breather 1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.Decal
Shaft, output
Deflector, dust
Magnet
Ring snap
Sprocket lower
Spacer
Chain
Ring retaining
Bearing
Bearing
Cover
Bendable clip
Bolt, Metric
Seal, oil
Washer
Nut, Metric
Flange, companion
Seal, oil
Spacer
Tone wheel (upper)
Nut, Metric
Clip, “J”
Bolt, hex head
Bracket, relay mounting
Locking clip
Connector
Bolt, hex head
Capscrew, hex head
Asm. -motor, electric
Seal, oil
Plug, pipe
Sealing Compound 35.
36.
37.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
48.
49.
50.
51.
52.
53.
54.
55.
56.
57.
58.
59.
60.
61.
62.
63.
64.
65.
66.
0-16
RODIUS 2005.07
3410-01
TRANSFER CASE
8. SYSTEM OPERATION
1) Transfer Case Control Unit (Tccu)
(1) 4WD Operation
TCCU is located under the front left seat and
permits the vehicle to shift from two-wheel
drive to four-wheel drive (and back shift)
according to drivers switch operation during
driving (For the shifting between 4WD HIGH
and 4WD LOW, stop the vehicle).
2H → 4H ▶
Change the 4WD switch in instrument panel from 2H to 4H.
This shift is available during driving.
“4WD HIGH” indicator in meter cluster comes on. -
-
-
When the system is defective
“4WD CHECK” warning lamp comes
on -
Change the 4WD switch in instrument panel from 4H to 2H.
This shift is available during driving.
“4WD HIGH” indicator in meter cluster goes out.
“4WD CHECK” warning lamp comes on when the system is defective. -
-
-
- 4H → 2H ▶
0-17
TRANSFER CASE
RODIUS 2005.07
0000-00
This function is only available when the speed signal from speed sensor is about to stop
(below 2 km/h).
This function is only available when clutch pedal is depressed (manual transmission) o
r
selector lever is selected to “N” position (automatic transmission).
(TCCU must recognize the clutch pedal signal or “N” signal.)
Change the 4WD switch in instrument panel from 4H to 4L.
“4WD LOW” warning lamp in meter cluster blinks during this process, then remains
when the shift is completed.
“4WD CHECK” warning lamp comes on when the system is defective. -
-
-
-
- 4H → 4L ▶
