1314-2. Opening, closing and locking the doors
4
Operation of each component
■Security feature
P. 120
■ Conditions affecting operation
P. 125
■ If the wireless remote cont rol does not operate properly
Locking and unlocking the doors: Use the mechanical key. ( P. 384)
■ Electronic key battery depletion
P. 128
■ When the electronic key battery is fully depleted
P. 299
■ Customization
Settings (e.g. door unlocking function) can be changed.
(Customizable features: P. 414)

1324-2. Opening, closing and locking the doors
Side doors
The vehicle can be locked and unlocked using the entry function,
wireless remote control or door lock switches.
■Entry function
 P. 1 2 0
■Wireless remote control
P. 1 3 0
■Door lock switches
For driver’s use
Locks all the doors
Unlocks all the doors
For front passenger’s use
Locks all the doors
Unlocks all the doors
Unlocking and locking the side doors
1
2
1
2

1334-2. Opening, closing and locking the doors
4
Operation of each component
■Inside door lock buttonsLocks the door
Unlocks the door
The side doors can be opened
by pulling the inside handle
even if the lock buttons are in
the lock position.
Move the inside door lock button to the lock position.
Close the door.
The door cannot be locked if the pow er switch is in ACCESSORY or
ON mode, or the electronic key is left inside the vehicle.
The key may not be detected correctly and the door may be locked.
■ Using the mechanical key
The doors can also be locked and unlocked with the mechanical key.
(P. 384)
■ Customization
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features: P. 414)
1
2
Locking the side doors from the outside without a key
CAUTION
■To prevent an accident
Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant throwing out
of the vehicle, resulting in death or serious injury.
● Always use a seat belt.
● Ensure that all doors are properly closed and locked.
● Do not pull the inside handle of the doors while driving.
Be especially careful for the side doors, as the doors may be opened even
if the inside door lock buttons are in locked position.
1
2

1344-2. Opening, closing and locking the doors
Back door
■Entry function
P. 1 2 0
■Wireless remote control
P. 1 3 0
■Door lock switches
P. 1 3 2
Raise the back door while pushing
up the back door opener switch.
The back door cannot be closed
immediately after the back door
opener switch is pushed.
Lower the back door using the
back door handle, and make sure
to push the back door down from
the outside to close it.
Locking and unlocking the back door
Opening the back door from outside the vehicle
When closing the back door

1354-2. Opening, closing and locking the doors
4
Operation of each component
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
■Before driving
● Make sure that the back door is fully closed. If the back door is not fully
closed, it may open unexpectedly while driving and hit near-by objects or
luggage in the luggage compartment may be thrown out, causing an acci-
dent.
● Do not allow children to enter the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could
have heat exhaustion or suffocate.
● Do not allow a child to open or close the back door.
Doing so may cause the back door to move unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door.
■ Important points while driving
● Keep the back door closed while driving.
If the back door is left open, it may hit near-by objects or luggage in the
luggage compartment may be thrown out, causing an accident.
● Never let anyone sit in the luggage compartment. In the event of sudden
braking or a collision, they are susceptible to death or serious injury.

1364-2. Opening, closing and locking the doors
CAUTION
■Operating the back door
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in death
or serious injury.
● Remove any heavy loads, such as snow and ice, from the back door
before opening it. Failure to do so may cause the back door to suddenly
shut again after it is opened.
● When opening or closing the back door, thoroughly check to make sure
the surrounding area is safe.
● If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.
● Use caution when opening or closing the back door in windy weather as it
may move abruptly in strong wind.
● Do not pull on the back door damper stay to close the back door, and do
not hang on the back door damper stay.
Doing so may cause hands to be caught or the back door damper stay to
break, causing an accident.
● If a bicycle carrier or similar heavy object is attached to the back door, it
may suddenly shut again after being opened, causing someone’s hands,
head or neck to be caught and injured. When installing an accessory part
to the back door, using a genuine Scion part is recommended.
●The back door may suddenly shut if it is
not opened fully. It is more difficult to
open or close the back door on an
incline than on a level surface, so
beware of the back door unexpectedly
opening or closing by itself. Make sure
that the back door is fully open and
secure before using the luggage com-
partment.
● When closing the back door, take extra
care to prevent your fingers etc. from
being caught.
● When closing the back door, make sure
to press it lightly on its outer surface. If
the back door handle is used to fully
close the back door, it may result in
hands or arms being caught.

1374-2. Opening, closing and locking the doors
4
Operation of each component
NOTICE
■Back door damper stays
The back door is equipped with damper stays that hold the back door in
place.
Observe the following precautions.
Failure to do so may cause damage to the back door damper stay, resulting
in malfunction.
● Do not attach any foreign objects, such
as stickers, plastic sheets, or adhesives
to the damper stay rod.
● Do not touch the damper stay rod with
gloves or other fabric items.
● Do not attach any heavy accessory to
the back door. Scion recommends gen-
uine Scion parts.
● Do not place your hand on the damper
stay or apply lateral forces to it.
Damper stay

1384-3. Adjusting the seats
Front seats
Seat position adjustment lever
Seatback angle adjustment
lever
Seatback angle adjustment
lever (passenger’s seat only)
Lift up the seatback angle adjustment lever.
When the seatback is folded to the forward limit, the seat can slide back
and forth.
Slide the seat to the front-most position.
After rear passengers are in, lift up the seatback and return the seat until it
locks.
By raising the seatback, the seat locks at the upright position.
■ Head restraints
Head restraints are provided for all front seats.
The head restraints do not have adjustment function.
Adjustment procedure
1
2
3
Moving the front passenger’s seat for rear seat entry
1
2

1394-3. Adjusting the seats
4
Operation of each component
CAUTION
■When adjusting the seat position
● Take care that seat does not strike passengers or luggage. Especially
when lowering the seatback, take care as to not squash the legs of the
rear passenger.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● After adjusting the seat, make sure that the seat is locked in position.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● When returning the seatback upright, be careful not to be hit by the seat-
back which will rebound with considerable spring force.
● After adjusting the seat, make sure that the seat is locked in position.
■ Caution while driving
● Never operate the seat position adjustment lever and the seatback angle
adjustment lever while driving.
● Do not place anything under the front seats.
The items may fly out and interrupt pedal operation in events such as sud-
den braking, and may cause an accident.
■ When sitting down or getting up off the rear seat
● Take care as not get hand or feet caught in between movable and joining
parts.
● When sitting down or getting up off the rear seat, make sure not to trip
over the seat rail grooves.
● Be sure to fix the front seat after sitting down or getting up off the rear seat.
■ Operating the front seats from the rear seat
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not operate when there is a passenger in the front seat.
● Never operate the front seats while driving.

1404-3. Adjusting the seats
Rear seats
Stow the seat belt buckles as
shown.
Press the seatback lock release
button and fold the seatback
down until it reaches the posi-
tion where the head restraints
can be removed.
Remove the head restraints.
Pull the head restraint up while
pushing the lock release button.
Fold down the seatbacks.
Stow the head restraints between
seatbacks and seat cushion as
shown.
Folding down procedure
1
2
3
4
