TOYOTA LAND CRUISER 2007 J200 Navigation Manual

li
— Route guidance screen
When starting route guidance, the following
screen is displayed.
This screen displays the route that guides
the driver to the destination.
The route to the destination is indicated by
a highlighted line. Drive along the guided
route.
When the vehicle approaches a guidance
point such as an intersection or a freeway,
the screen automatically divides in two to
display the guidance screen. (For details,
see page lxiii.)
The current street name will be displayed at
the bottom of the screen.
In some areas, the roads have not been
completely digitized in our database yet. For
this reason, the route guidance may guide
the road that is not allowed to pass.
— Typical voice guidance
prompts
The voice guidance provides various mes-
sages as you approach an intersection, or
other point where you need to maneuver the
vehicle.
1“Proceed about 5 miles.”
2“In a quarter of a mile, right turn.”
3“Right turn.”
4(Beep sound only)
INFORMATION
On freeways, interstates or other high-
ways with higher speed limits, the
voice guidance will be made at earlier
points than on city streets in order to al-
low time to maneuver.

lii
4.2 miles
0.25 miles
1“Proceed about 4 miles to the
traffic circle.”
2“In a quarter of a mile, traffic circle
ahead, and then 3rd exit ahead.”
3“The 3rd exit ahead.”
4“The exit ahead.”
5(Beep sound only)
One−way road
One−way road
∗: The system indicates a U−turn if the dis-
tance between two one−way roads (of oppo-
site directions) is less than 50 feet (15 m) in
residential areas or 164 feet (50 m) in non−
residential areas.
1“In half of a mile, make a legal U−
turn.”
2“Make a legal U−turn ahead.”
3(Beep sound only)
The system announces your approach to
the final destination.
1“Your destination is ahead.”
2“You have arrived at your des-
tination. The route guidance is
now finished.”

liii
INFORMATION
If the system cannot determine the
current vehicle position correctly (in
cases of poor GPS signal reception),
the voice guidance may be made
early or delayed.
If you did not hear the voice guid-
ance command, touch the
“MAP/
VOICE” button to hear it again.
To adjust the voice guidance vol-
ume, see page lxxiv.
Setting and deleting
destination
(a) Adding destinations
You can add destinations and search
again for the routes.
1. Touch the “Route” switch.
2. Touch the “Add” switch of “Destina-
tion”.3. Input an additional destination in the
same way as the destination input. (See
page xxx.)
4. Touch the desired “Add” switch to
determine the arrival order of the addi-
tional destination.

liv
(b) Reordering destinations
When more than one destination is set,
you can change the arrival order of the
destinations.
1. Touch the
“Route” switch.
2. Touch the “Reorder” switch of
“Destination”.
3. Select the destination in the order of
arrival by touching the switch of destina-
tions.
Reordered number of arrival is displayed on
the right side of the screen.
When you finish selecting the destinations,
touch the
“OK” switch. The system
searches for the guidance route again, and
displays the entire route. Even if you do not
touch the
“OK” switch, the entire route is
displayed automatically within a few sec-
onds when order is fixed.
(c) Deleting destination
You can delete a set destination.
1. Touch the
“Route” switch.
2. Touch the “Delete” switch of “Des-
tination”.
3. When more than one destination is
set, a list will appear on the screen.
Touch the destination on the screen you
wish to delete.

lv “Delete All”: To delete all destinations on
the list.
4. A message appears to confirm your
request to delete. To delete the destina-
tion(s), touch the
“Yes” switch.
If you touch the
“Yes” switch, the data can-
not be recovered.
If you touch the
“No” switch, the previous
screen will return.
5. If more than one destination is set,
touch the
“OK” switch after deleting the
destinations. The system searches for
the guidance route again, and displays
the entire route.
Setting and deleting route
(a) Adding preferred road
You can add points you wish to pass
through.
1. Touch the “Route” switch.
2. Touch the “Add” switch of “Pre-
ferred road”.
3. Select the preferred road which you
wish to modify and touch the “Enter ”switch.
4. A message appears to confirm your
request. To add the preferred road, touch
the
“OK” switch.
Touch the
“Next” switch to use another
road.

lvi
5. If more than one destination is set, the
“Add Preferred Road” screen appears.
Touch the
“Add” switch where you wish
to add a preferred road.
(b) Deleting preferred road
You can delete a set preferred road.
1. Touch the
“Route” switch.
2. Touch the “Delete” switch of “Pre-
ferred road”.
3. When more than one preferred road is
set, a list will appear on the screen.
Touch the switch of the preferred road to
be deleted.“Delete All”: To delete all the listed pre-
ferred road.
4. A message appears to confirm your
request to delete. To delete the preferred
road, touch the
“Yes” switch.
If you touch the
“Yes” switch, the data can-
not be recovered.
If you want to try again or cancel deletion,
touch the
“No” switch. The previous
screen will return.
5. If more than one preferred road is set,
touch the
“OK” switch after deleting the
preferred road. The system searches for
the guidance route again, and displays
entire route.

lvii
(c) Search condition
You can designate the route conditions
of the route to the destination.
1. Touch the
“Route” switch.v
2. Touch the “Search Condition”switch. The “Search Condition” screen
appears.
3. Touch the “Quick”, “Quick1”,“Quick2” or “Short” switch and
touch the “OK” switch.
The entire route from the starting point to the
destination is displayed.
“Guide”: To start guidance.
“Route”: To add or change a route. (For de-
tails, see pages liii and lv.)
(d) Detour setting
While the route guidance is operating,
you can change the route to detour
around a section of the route where a
delay is caused by road repairs, an acci-
dent, etc.
1. Touch the
“Route” switch.
2. Touch the “Detour” switch.

lviii
3. Select the switch below to select the
desired detour distance.
“1 mile (km)”, “3 miles (km)” or “5 miles
(km)”: Touch one of these switches to start
the detour process. After detouring, the sys-
tem returns to the original guidance route.
“Whole Route”: If you touch this switch, the
system will calculate an entire new route to
the destination.
This picture shows an example of how the
system would guide you around a delay
caused by a traffic jam.
1This position indicates the location of a
traffic jam caused by road repairs or an
accident.
2This route indicates the detour sug-
gested by the system.
INFORMATION
When your vehicle is on a freeway,
the detour distance selections are 5,
15, and 25 miles (km).
The system may not be able to calcu-
late a detour route depending on the
selected distance and surrounding
road conditions.
(e) Route preference
You are given a number of choices on the
conditions which the system uses to de-
termine the route to your destination.
1. Touch the
“Route” switch.
2. Touch the “Route Preference”switch to change the conditions which
are to determine the route to your des-
tination.

lix
3. You can turn the indicator on or off by
touching the switch.
When searching for a route, the system
avoids routes where the indicator is dimmed
as much as possible.
After choosing the conditions, touch the
“OK” switch.
(f) Starting route from adjacent
road
You can start the route guidance from the
adjacent road.
(ex. When the route guidance guides the
route on the freeway, but you drive on the
parallel way along a freeway.)
1. Touch the
“Route” switch.
2. Touch the “Start from Adjacent
Road” switch.
When there is no adjacent road, this switch
will not appear.
Show POI icons
Points of Interest such as gas stations
and restaurants can be displayed on the
map screen. You can also set their loca-
tion as a destination and use them for
route guidance.
1. Touch the “Map View” switch.

lx
2. Touch the “Show POI Icon” switch
to display a particular type of Point of In-
terest on the screen.
A screen with a limited choice of Points of In-
terest will be displayed. (To change the dis-
played POI, see page ci.) When you touch
the desired Point of Interest category, sym-
bols will appear on the map screen indicat-
ing where the POI addresses are located.
To turn off the symbols of the Points of In-
terest on the map screen, touch the
“POI Off” switch.
“More”: If you cannot find your desired
Point of Interest on the limited choice
screen, touch this switch. The screen then
displays the complete POI listing screen.
You can display up to 5 categories of icons
on the screen.
When you select a Point of Interest type from
either the limited list or the complete list, the
screen will display symbols at those loca-
tions on the map screen.
Touching the
“Delete” switch will delete
the last selected icon.
“Local POI List”: If you want to search for
the nearest Point of Interest, touch this
switch. Then choose one of the categories.
The system will list the points within 20 miles
(30 km).
