TOYOTA MIRAI 2023 Owners Manual

912-1. Fuel cell electric vehicle
Owners Manual_USA_M62064_en
2
Fuel cell systemMaintaining the Fuel cell System
Indicator to Eco area on the
multi-information display can
extend your driving range.
( P.103, 108)
Drive your vehicle smoothly.
Avoid abrupt acceleration and
deceleration.
Mild acceleration and decelera-
tion can help curb wasteful fuel
consumption.
If the brakes are operated gently
and in a timely manner, a
greater amount of electrical
energy can be regenerated
when slowing down.
Repeated acceleration and
deceleration, as well as long
waits at traffic lights, will lead to decreased fuel economy. Check
traffic reports before leaving and
avoid delays as much as possi-
ble. When driving in a con-
gested traffic situations, gently
release the brake pedal to allow
the vehicle to move forward
slightly while avoiding overuse
of the accelerator pedal. Doing
so can help control excessive
fuel consumption.
Similar to an electric vehicle, a
fuel cell electric vehicle uses the
most fuel in high output driving
such as driving on a steep uphill
or at high speeds. Moderate the
vehicle speed and maintain a
steady speed.
When using Eco drive mode, the
torque corresponding to the
accelerator pedal depression
amount can be generated more
smoothly than it is in normal
conditions. In addition, the oper-
ation of the air conditioning sys-
tem (heating/cooling) will be
minimized, improving the fuel
economy. (
P.320)
 Use the air conditioning only
when necessary. Doing so
Fuel cell electric vehi-
cle driving tips
To maximize fuel economy
and range, pay attention to
the following:
Use of Fuel cell System
Indicator
Accelerator pedal/brake
pedal operation
When braking
Delays
Driving with high power
output
Using Eco drive mode
Air conditioning

922-1. Fuel cell electric vehicle
Owners Manual_USA_M62064_en
can help reduce excessive
fuel consumption.
In summer: When the ambient
temperature is high, use the
recirculated air mode. Doing
so will help to reduce the bur-
den on the air conditioning
system and reduce fuel con-
sumption as well.
In winter: Avoid excess heat-
ing. Use the seat heater (if
equipped) or steering heater
(if equipped) to minimize the
need for cabin heating
(P.351).
 Using eco air conditioning
mode, this helps curb fuel
consumption even with the air
conditioning system turned
on. ( P.334, 341)
Make sure to check the tire infla-
tion pressure frequently.
Improper tire inflation pressure
can cause poor fuel economy.
Also, as snow tires can cause
large amounts of friction, their
use on dry roads can lead to
poor fuel economy. Use tires
that are appropriate for the sea-
son.
Carrying heavy luggage will lead
to reduced fuel economy. Install-
ing a large roof rack will also reduce fuel economy.
Checking tire inflation
pressure
Luggage

93
Owners Manual_USA_M62064_en
3
3
Vehicle status information and indicators
Vehicle status informa-tion and indicators
3-1. Instrument cluster
Warning lights and indica-tors ............................... 94
Gauges and meters (with 8- inch multi-information dis-
play) ............................. 99
Gauges and meters (With 12.3-inch multi-information
display) ...................... 102
Multi-information display .................................. 105
Head-up display .......... 114
Energy monitor/consump- tion screen/air purification
screen ....................... 119

943-1. Instrument cluster
Owners Manual_USA_M62064_en
3-1.Instrument cluster
For the purpose of explanation, the following illustrations display all
warning lights and indicators illuminated.
■With 8-inch multi-information display
The units used on the meters and some indicators may differ dep ending on
the target region.
■With 12.3-inch multi-information display
War ning lights and indicators
The warning lights and indicators on the instrument cluster,
center panel and outside rear view mirrors inform the driver
of the status of the vehicle’s various systems.
Instrument cluster

953-1. Instrument cluster
Owners Manual_USA_M62064_en
3
Vehicle status information and indicators
The units used on the meters and some indicators may differ dep ending on
the target region.
Warning lights inform the driver
of malfunctions in the indicated
vehicle’s systems.
Warning lights
Hydrogen leak warn-
ing light
*1 (  P.454)
(U.S.A.)
Brake system warn-
ing light
*1 ( P.454)
(Canada)
(Red)
Brake system warn-
ing light
*1 ( P.454)
(Yellow)
Brake system warn-
ing light
*1 ( P.454)
(Red)
High coolant tempera-
ture warning light
( P.455)
Fuel cell system over-
heat warning light
*2
(  P.455)
Charging system
warning light
*2
(  P.455)
SRS warning light
*1
(  P.455)
Pop Up Hood warning
light
*1 (  P.455)
(U.S.A.)
ABS warning light*1
(  P.456)
(Canada)
ABS warning light*1
(  P.456)
(Red)
Electric power steer-
ing system warning
light
*1 ( P.456)
(Yellow)
Electric power steer-
ing system warning
light
*1 ( P.456)
(Flashes or
illuminates)
PCS warning light*1
(  P.456)
(Orange)
LTA i n d i c a t o r
( P.457)
Intuitive parking assist
OFF indicator
*3 (if
equipped) ( P.457)
PKSB OFF indica-
tor
*1 (if equipped)
(  P.457)
(Flashes)
RCTA OFF indicator*1
(if equipped) ( P.458)
(Flashes or
illuminates)
RCD OFF indicator (if
equipped) ( P.458)
Slip indicator light
*1
(  P.458)
Inappropriate pedal
operation warning
light
*2 (  P.459)
(Flashes)
Brake hold operated
indicator
*1 ( P.459)
(U.S.A.)
(Flashes)
Parking brake indica-
tor ( P.459)

963-1. Instrument cluster
Owners Manual_USA_M62064_en
*1: These lights turn on when the power switch is turned to ON to
indicate that a system check is
being performed. They will turn
off after the fuel cell system is
on, or after a few seconds. There
may be a malfunction in a sys-
tem if the light does not come on,
or turn off. Have the vehicle
inspected by your Toyota dealer.
*2: This light illuminates on the multi-informatio n display with a
message.
*3: Intuitive parking assist OFF indi- cator turns on when the power
switch is turned to ON while the
Intuitive parking assist function is
on. It will turn off after a few sec-
onds.
*4: Refer to “Toyota Teammate Advanced Drive OWNER’S
MANUAL” at Toyota.com.
(Canada)
(Flashes)
Parking brake indica-
tor ( P.459)
Tire pressure warning
light
*1 (  P.460)
Low fuel level warn-
ing light ( P.460)
Driver’s and front pas-
senger’s seat belt
reminder light
(  P.460)
Rear passengers’ seat
belt reminder lights
(  P.461)
Advanced Drive warn-
ing light (if
equipped)
*1, 4
WARNING
■If a safety system warning
light does not come on
Should a safety system light such
as the ABS and SRS warning light
not come on when you start the
fuel cell system, this could mean
that these system s are not avail-
able to help protect you in an acci-
dent, which could result in death
or serious injury. Have the vehicle
inspected by you r Toyota dealer
immediately if this occurs.
NOTICE
■To prevent damage to the fuel
cell system and its compo-
nents
This vehicle is equipped with high
coolant temperature warning light
(  P.490), instead of, coolant tem-
perature gauge.
The fuel cell sys tem may be over-
heating if the high coolant tem-
perature warning light flashes or
comes on. In this case, immedi-
ately stop the vehicle in a safe
place, and check the fuel cell sys-
tem after it has cooled completely.

973-1. Instrument cluster
Owners Manual_USA_M62064_en
3
Vehicle status information and indicators
The indicators inform the driver
of the operating state of the
vehicle’s various systems.
Indicators
Turn signal indicator
(  P.190)
(U.S.A.)
Headlight indicator
( P.198)
(Canada)
Tail light indicator
( P.198)
Headlight high beam indi-
cator ( P.200)
AHB indicator ( P.200)
(Blue)
Low coolant temperature
indicator
*1
Smart key system indica-
tor
*2 ( P.180)
Cruise control indicator
(  P.244)
Dynamic radar cruise
control indicator
(  P.244)
Cruise control “SET” indi-
cator ( P.244)
(*3)
LTA indicator ( P.220,
236)
Intuitive parking assist
OFF indicator
*4, 5 (if
equipped) ( P.262)
PKSB OFF indicator
*4, 6
(if equipped) ( P.283)
(Flashes)
Slip indicator light*6
(  P.323)
VSC OFF indicator
*4, 6
(  P.323)
PCS warning light
*4, 6
(  P.222)
BSM outside rear view
mirror indicators
*6, 7 (if
equipped) ( P.257, 272)
BSM OFF indicator
*4, 6 (if
equipped) ( P.257)
RCTA OFF indicator
*4, 6
(if equipped) ( P.273)
RCD OFF indicator
*4 (if
equipped) ( P.278)
Brake hold standby indi-
cator
*6 (  P.194)
Brake hold operated indi-
cator
*6 (  P.194)
Security indicator
*8
(  P.70, 71)
“READY” indicator
(  P.180)
Low outside temperature
indicator
*9 (  P.100)
(U.S.A.)
Parking brake indicator
( P.191)
(Canada)
Parking brake indicator
( P.191)
Br mode indicator
(  P.185)
Eco drive mode indicator
(  P.320)

983-1. Instrument cluster
Owners Manual_USA_M62064_en
*1: Indicates the coolant tempera-ture is cool.
*2: This light illuminates on the multi-informatio n display with a
message.
*3: Depending on the operating con- ditions of the system, the color
and state (illuminated/blinking) of
the indicator change.
*4: The light comes on when the system is turned off.
*5: Intuitive parking assist OFF indi-cator turns on when the power
switch is turned to ON while the
Intuitive parking assist function is
on. It will turn off a fter a few sec-
onds.
*6: These lights turn on when the power switch is turned to ON to
indicate that a system check is
being performed. They will turn
off after the fuel cell system is
on, or after a few seconds. There
may be a malfunction in a sys-
tem if the lights do not turn on, or
turn off. Have the vehicle
inspected by your Toyota dealer.
*7: This light illumi nates on the out-
side rear view mirrors.
*8: This light illumi nates on the cen-
ter panel.
*9: When the outside temperature is approximately 37°F (3°C) or
lower, the indicator will flash for
approximately 10 seconds, then
stay on.
*10: Refer to “Toyota Teammate Advanced Drive OWNER’S
MANUAL” at Toyota.com.
Sport mode indicator
(
 P.320)
Snow mode indicator
(  P.321)
“AIRBAG ON/OFF” indi-
cator
*6, 8 (  P. 4 6 )
Advanced Drive indica-
tor
*10 (if equipped)

993-1. Instrument cluster
Owners Manual_USA_M62064_en
3
Vehicle status information and indicators
The units used on the meter and display may differ depending on the target
region.
Fuel gauge/Driving range ( P.101)
Multi-information display
Presents the driver with a variety of driving-related data ( P.105)
Displays warning messages if a malfunction occurs (P.464)
Speedometer
Displays the vehicle speed
Clock ( P.100)
Time displayed is linked to the multimedia system. For details, refer to
“MULTIMEDIA OWNER’S MANUAL”.
Shift position indicator
Displays the selected shift position ( P.185)
Odometer and trip meter ( P.100)
Outside temperature ( P.100)
Gauges and meters (with 8-inch multi-infor mation
display)
The meters display various drive information.
Meter display

1003-1. Instrument cluster
Owners Manual_USA_M62064_en
■The meters and display illumi-
nate when
The power swit ch is in ON.
■When changing driving mode
Background color of the multi-infor-
mation display is changed following
the selected driving mode. ( P.320,
321)
■Clock settings screen
If “Clock :00” is displayed when
is selected on the multi-information
display, the system may be malfunc-
tioning. Have the vehicle inspected
by your Toyota dealer.
■Outside temperature display
●In the following si tuations, the cor-
rect outside tempe rature may not
be displayed, or the display may
take longer than normal to
change.
• When stopped, or driving at low speeds (less than 12 mph [20
km/h])
• When the outside temperature has changed su ddenly (at the
entrance/exit of a garage, tunnel,
etc.)
●When “--” or “E” is displayed, the
system may be malfunctioning.
Take your vehicle to your Toyota
dealer.
●Displays the outside temperature
within the range of -40°F (-40°C)
to 122°F (50°C).
●When the outside temperature is
approximately 37°F (3°C) or
lower, the indicator will flash
for approximately 10 seconds,
then stay on.
■Liquid crystal display
 P. 1 0 6
■Customization
Settings (e. g. meter display) can be
changed on screen of the multi- information display. (
P.512)
■Display items
 Odometer
Displays the total distance the vehi-
cle has been driven.
 Trip meter A/Trip meter B
Displays the distance the vehicle
has been driven since the meter
was last reset. Trip meters A and B
can be used to record and display
different distances independently.
■Changing the display
Each time the “ODO/TRIP”
switch is pressed, the displayed
item will be changed. When the
trip meter is displayed, pressing
and holding the switch will reset
the trip meter.
The brightness of the instrument
panel lights can be adjusted.
Odometer and trip meter
display
Instrument panel light
control
