TOYOTA SEQUOIA 2001 Service Repair Manual

05_SEQUOIA_U (L/O 0408)
212
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station. (See ªTUNEº or
ªSEEK/TRACKº.) Push and hold down the
button until you hear a beepÐthis will set
the station to the button. The button num-
ber will appear on the display.
To recall a preset station: Push the button
for the station you want. The button num-
ber and station frequency will appear on
the display.
These systems can store one AM and two
FM stations for each button. (The display
will show ªAMº, ªFM1º or ªFM2º when you
push ªAMº or ªFMº button.)
(Eject button)
Push the cassette tape eject button to
eject a cassette. Push the compact disc
eject button to eject a compact disc.
(Program)
Push ª
º (preset button 4) to select
the other side of a cassette tape. The
display indicates which side is currently
selected (ª
º indicates the top side, ªº
indicates the bottom side).
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
(Reverse/Fast forward button)
Cassette player
Push ª
º (preset button 6) to fast for-
ward a cassette tape. ªFFº will appear on
the display. Push ª
º (preset button 5)
to rewind a tape. ªREWº will appear on
the display.
To stop the tape while it is fast forward-
ing, push ª
º or ªTAPEº button. To stop
the tape while it is rewinding, push ª
º
or ªTAPEº button.
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast forwards completely,
the cassette will play the other side of the
tape using the auto±reverse feature.Compact disc player
Push and hold ª
º (preset button 6) or
ª
º (preset button 5) to fast forward or
reverse within a compact disc. When you
release the button, the compact disc play-
er will resume playing.
AM
Push the ªAMº button to turn on the radio
and select the AM band. ªAMº will appear
on the display.
AUDIO CONTROL (Tone and sound bal-
ance adjustment function)
Each time you push the ªAUDIO
CONTROLº knob, the mode changes. To
adjust the tone and balance, turn the
knob.
BAS: Adjusts low±pitched tones. The dis-
play ranges from ±5 to 5.
MID (on some models): Adjusts mid±
pitched tones. The display ranges from ±5
to 5.
TRE: Adjusts high±pitched tones. The dis-
play ranges from ±5 to 5.
FAD: Adjusts the sound balance between
the front and rear speakers. The display
ranges from F7 to R7.

05_SEQUOIA_U (L/O 0408)
213
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
DISC (Compact disc)
Push the ªDISCº button to play a compact
disc.
When the audio system is set into com-
pact disc operation, the display shows the
track, or track and disc number currently
being played.
Vehicles with rear seat entertainment sys-
temÐ
The ªDISCº button may also be used to
operate a DVD player when a disc is
loaded in the DVD player. Pressing the
ªDISCº button changes between the CD
player and DVD player. When the DVD
player is in operation, ªAUXº appears on
the display.
Error messages
If the player malfunctions, your audio sys-
tem will display one of the four following
error messages.
ªWAITº: The compact disc player unit
may be too hot. Allow the player to cool
down.
ªERROR 1º: The disc may be dirty, dam-
aged or inserted incorrectly (up±side
down). Clean the disc and re±insert it.ªERROR 3º: There is a problem inside
the system. Eject the disc or magazine.
Set the disc or magazine again.
ªERROR 4º: Over±current. Ask your
Toyota dealer to inspect.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
Dolby
B NR*
If you are listening to a tape that was
recorded with Dolby B Noise Reduction,
push ª
º (preset button 3). ªº will
appear on the display. Push the button
again to turn off Dolby B NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on
or off according to the mode used to re-
cord the tape.
*: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. ªDOLBYº and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
FM
Push the ªFMº button to turn on the radio
and select the FM band. ªFM1º or ªFM2º
will appear on the display. This system
allows you to set twelve FM stations, two
for each of the preset button.PWR´VOL (Power and Volume)
Push ªPWR´VOLº to turn the audio system
on and off. Turn ªPWR´VOLº to adjust the
volume.
RAND (Random)
Push ª
º to listen the tracks on the
disc in random order. ª
º will ap-
pear on the display. The disc you are
listening to will play in random order. To
turn off the random feature, push this but-
ton again.
RPT (Repeat)
Cassette player
Push ªRPTº (preset button 2) while the
track is playing. ª
º will appear on
the display. When the track ends, it will
automatically rewind and replay. To turn
off the repeat feature, push this button
again.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly.

05_SEQUOIA_U (L/O 0408)
214
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Compact disc player
Push ª
º while the track is playing.
ª
º will appear on the display. When
the track ends, it will automatically be
replayed. This process will be continued
until you push the button again to turn off
the repeat feature.SCAN
Radio
You can either scan all the frequencies on
a band or scan only the preset stations
for that band.
To scan the preset stations:
Push and hold the ªSCANº button until
you hear a beep. The radio will tune in
the next preset station up the band, stay
there for 5 seconds, and then move to the
next preset station. To stop scanning,
push this button again.
To scan all the frequencies:
Quickly push and release the ªSCANº but-
ton. The radio will find the next station up
the station band, stay there for 5 seconds,
and then scan again to the next station.
To stop scanning, push this button again.
Compact disc player
Push ª
º to scan the tracks on a spe-
cific disc. ª
º will appear on the dis-
play and the player will scan all the tracks
on the disc you are listening to. To select
a track, push ªSCANº again. If the player
scanned all the tracks on the disc, it will
stop scanning.SEEK/TRACK (Seeking/Track up/down)
Radio
In the seek mode, the radio finds and
plays the next station up or down the
station band.
To seek the next station, quickly push and
release ª
º or ªº side of the ªSEEK/
TRACKº button. Do this again to find the
station after that.
Cassette Player
Use this button to skip up or down to
locate a song or recording.
You can select up to nine recordings (in-
cluding current one).
A blank space of at least 3 seconds is
considered to be a start of a recording.
When the beginning of a tape is reached,
the player automatically resumes play.
When the end of the tape is reached, the
player automatically reverses sides and
resumes normal play.
In addition, the feature may not work well
with some spoken word, live, or classical
recordings.

05_SEQUOIA_U (L/O 0408)
215
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Compact disc player
Use this button to skip up or down to a
different track.
Push ª
º or ªº side of the ªSEEK/
TRACKº button until the number of the
track you want to listen to appears on the
display. If you want to return to the begin-
ning of the current track, quickly push the
down side of the button one time.
Vehicles with rear seat entertainment sys-
temÐ
While the DVD player is in operation, the
chapter or track can be changed by push-
ing the ª
º or ªº side of the ªSEEK/
TRACKº button.
ST (Stereo reception) display
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. ªSTº appears on the display. If the
signal becomes weak, the radio reduces
the amount of channel separation to prev-
ent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion.
TA P E
Push the ªTAPEº button to play a cassette
tape.TEXT
This button is used to change the display
for the compact disc that contains text
data.
To change the display, quickly push and
release the ªTEXTº button while the com-
pact disc is playing. The display changes
in the order from the elapsed time to disc
title to track title, then back to the
elapsed time.
If this button is pushed while a compact
disc that does not contain text data is
playing, ªNO TITLEº will appear on the
display.
If the entire disc or track title does not
appear on the display, push and hold the
button until you hear a beep. The rest of
the title will appear.
TUNE (Tuning)
Turn the ªTUNEº knob clockwise to step
up the frequency. Turn the knob counter-
clockwise to step down the frequency.

05_SEQUOIA_U (L/O 0408)
216
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Details of specific buttons, controls, and
features are described in the alphabetical
list that follows.
Ty p e 2

05_SEQUOIA_U (L/O 0408)
217
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station. (See ªTUNEº or
ªSEEK/TRACKº.) Push and hold down the
button until you hear a beepÐthis will set
the station to the button. The preset but-
ton number will appear on the display.
RDS stations will be preset to the buttons
when you turn on the RDS (see ªRDSº
button).
To recall a preset station: Push the button
for the station you want. The preset but-
ton number and station frequency will ap-
pear on the display.
This radio can store one AM, two FM and
RDS stations for each button. (The display
will show ªAMº, ªFM1º, ªFM2º or ªFM
TYPEº when you push ªAMº or ªFMº but-
ton.) (Eject button)
Cassette player
This button is used to eject a cassette.
Compact disc player
This button is used to eject one or all
compact discs.
To eject the current compact disc, push
and release the compact disc eject button.
To eject a specific disc, push ªº (preset
button 3) or ª
º (preset button 4) until the
number of the disc you want to eject is
displayed. Push and release the eject but-
ton.
To eject all discs at a time, press and
hold the eject button until you hear a
beep. The last compact disc played before
pushing the button will be ejected first. If
the ejected disc is not removed for a long
time, the eject function will be cancelled. (Program)
Push ª
º (preset button 4) to select
the other side of a cassette tape. The
display indicates which side is currently
selected (ª
º indicates the top side, ªº
indicates the bottom side).
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
(Reverse/Fast forward button)
Cassette player
Push ª
º (preset button 6) to fast for-
ward a cassette tape. ªFFº will appear on
the display. Push ª
º (preset button 5)
to rewind a tape. ªREWº will appear on
the display.
To stop the tape while it is fast forward-
ing, push ª
º or ªTAPEº button. To stop
the tape while it is rewinding, push ª
º
or ªTAPEº button.
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast forwards completely,
the cassette will play the other side of the
tape using the auto±reverse feature.

05_SEQUOIA_U (L/O 0408)
218
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Compact disc player
Push and hold ª
º (preset button 6) or
ª
º (preset button 5) to fast forward or
reverse within a compact disc. When you
release the button, the compact disc play-
er will resume playing.
AM
Push the ªAMº button to turn on the radio
and select the AM band. ªAMº will appear
on the display.
AUDIO CONTROL (Tone and sound bal-
ance adjustment function)
Each time you push the ªAUDIO
CONTROLº knob, the mode changes. To
adjust the tone and balance, turn the
knob.
BAS: Adjusts low±pitched tones. The dis-
play ranges from ±5 to 5.
MID: Adjusts mid±pitched tones. The dis-
play ranges from ±5 to 5.
TRE: Adjusts high±pitched tones. The dis-
play ranges from ±5 to 5.
FAD: Adjusts the sound balance between
the front and rear speakers. The display
ranges from F7 to R7.BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
DISC (Compact disc)
Push the ªDISCº button to play a compact
disc.
When the audio system is set into com-
pact disc operation, the display shows the
track, or track and disc number currently
being played.
Vehicles with rear seat entertainment sys-
temÐ
The ªDISCº button may also be used to
operate a DVD player when a disc is
loaded in the DVD player. Pressing the
ªDISCº button changes between the CD
player and DVD player. When the DVD
player is in operation, ªAUXº appears on
the display.
Error messages
If the player malfunctions, your audio sys-
tem will display one of the four following
error messages.
ªWAITº: The compact disc player unit
may be too hot. Allow the player to cool
down.
ªERROR 1º: The disc may be dirty, dam-
aged or inserted incorrectly (up±side
down). Clean the disc and re±insert it.ªERROR 3º: There is a problem inside
the system. Eject the disc or magazine.
Set the disc or magazine again.
ªERROR 4º: Over±current. Ask your
Toyota dealer to inspect.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
 DISC

Use these buttons to select a disc you
want to listen to.
Push ªº (preset button 3) or ª
º (preset
button 4) until the number of the disc you
want to listen appears on the display.
Dolby
B NR*
If you are listening to a tape that was
recorded with Dolby B Noise Reduction,
push ª
º (preset button 3). ªº will
appear on the display. Push the button
again to turn off Dolby B NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on
or off according to the mode used to re-
cord the tape.
*: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. ªDOLBYº and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.

05_SEQUOIA_U (L/O 0408)
219
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
FM
Push the ªFMº button to turn on the radio
and select the FM band. ªFM1º, ªFM2º or
ªFM TYPEº will appear on the display.
This system allows you to set twelve FM
and six RDS stations, three for each of
the preset button. If the RDS is off or
RDS stations are not preset to the preset
buttons, ªFM TYPEº will not appear on the
display.
LOAD
This button is used to load the compact
discs in the compact disc player. This
player can store up to six discs.
To load one compact disc only, quickly
push and release the button, then insert
a compact disc. After the disc is loaded,
the shutter of the slot will close.
If no compact disc is inserted, the shutter
will close after 15 seconds.To load multiple compact discs, push and
hold the button (until you hear a beep
when the audio system is on), then insert
the first compact disc. After the disc is
loaded, the shutter of the slot will close.
After a few seconds, the shutter will auto-
matically open again so the next disc can
be inserted. The same process can be
applied for loading the rest of the discs.
If the player is full of discs, ªDISC FULLº
will appear on the display.
If no compact disc is inserted, the shutter
will close after 15 seconds.
PWR´VOL (Power and Volume)
Push ªPWR´VOLº to turn the audio system
on and off. Turn ªPWR´VOLº to adjust the
volume.RAND (Random)
There are two random featuresÐyou can
either listen to the tracks on one compact
disc in random order, or listen to the
tracks on all the compact discs in the
magazine in random order.
To play the tracks on one disc in random
order:
Quickly push and release ªRANDº (preset
button 1). ª
º will appear on the
display and the player will perform the
tracks on the disc you are listening to in
random order. To turn off the random fea-
ture, push this button again.
To play all the tracks in the magazine in
random order:
Push and hold ªRANDº (preset button 1)
until you hear a beep. ª
º will ap-
pear on the display and the player will
perform all the tracks on all the discs in
the magazine in random order. To turn off
the random feature, push this button
again.

05_SEQUOIA_U (L/O 0408)
220
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
RDS (Radio Data System)
Your audio system is equipped with Radio
Data System (RDS). RDS station providing
good reception is automatically selected if
current reception worsens.
The ªRDSº button turns the RDS on and
off. This button is operational except in
AM mode.
To turn on the RDS, push and hold this
button until you hear a beep and ªRDSº
will appear on the display. At this time,
the radio starts to search the RDS sta-
tions and ªRDS SEARCHº will flash on the
display.
Quickly push and release this button when
the RDS turns on, the radio starts to
search the RDS stations and ªRDS
SEARCHº will flash on the display.
When the RDS stations are found,
ªFOUNDº and the number of the RDS sta-
tions will appear on the display, and you
will hear two beeps. The stations will be
preset to the preset buttons.
If the RDS stations can not be found, ªNO
RDS STº will appear on the display and
you will hear a beep, and the display
returns to the previous mode.
To turn the RDS off, push the button until
you hear a beep again.RPT (Repeat)
Cassette player
Push ªRPTº (preset button 2) while the
track is playing. ª
º will appear on
the display. When the track ends, it will
automatically rewind and replay. To turn
off the repeat feature, push this button
again.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly.
Compact disc player
There are two repeat featuresÐYou can
either replay a disc track or a whole com-
pact disc.
Repeating a track:
Quickly push and release ªRPTº (preset
button 2) while the track is playing.
ª
º will appear on the display. When
the track ends, it will automatically replay.
To turn off the repeat feature, push this
button again.Repeating a disc:
Push and hold ªRPTº (preset button 2)
until you hear a beep. ª
º will ap-
pear on the display. The player will repeat
all the tracks on the disc you are listening
to. When the disc ends, the player will
automatically go back to the first track on
the disc and replay. To turn off the repeat
feature, push this button again.
SCAN
Radio
You can either scan all the frequencies on
a band or scan only the preset stations
for that band.
To scan the preset stations:
Push and hold the ªSCANº button until
you hear a beep. The radio will tune in
the next preset station up the band, stay
there for 5 seconds, and then move to the
next preset station. To stop scanning,
push this button again.
To scan all the frequencies:
Quickly push and release the ªSCANº but-
ton. The radio will find the next station up
the station band, stay there for 5 seconds,
and then scan again to the next station.
To stop scanning, push this button again.

05_SEQUOIA_U (L/O 0408)
221
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Compact disc player
There are two scan featuresÐyou can ei-
ther scan the tracks on a specific disc or
scan the first tracks of all the discs in the
magazine.
Scanning the tracks on a disc:
Quickly push and release the ªSCANº but-
ton. ªSCANº will appear on the display
and the player will scan all the tracks on
the disc you are listening to. To stop
scanning, push this button again. If the
player has scanned all the tracks on the
disc, it will stop scanning.
Scanning the first tracks of all the discs
in the magazine:
Push the ªSCANº button until you hear a
beep. ª
´SCANº will appear on the dis-
play and the player will scan the first
track of the next disc. To stop scanning,
push this button again. If the player has
scanned all the discs, it will stop scan-
ning.SEEK/TRACK (Seeking/Track up/down)
Radio
In the seek mode, the radio finds and
plays the next station up or down the
station band.
To seek the next station, quickly push and
release ª
º or ªº side of the ªSEEK/
TRACKº button. Do this again to find the
station after that.
Cassette Player
Use this button to skip up or down to
locate a song or recording.
You can select up to nine recordings (in-
cluding current one).
A blank space of at least 3 seconds is
considered to be a start of a recording.
When the beginning of a tape is reached,
the player automatically resumes play.
When the end of the tape is reached, the
player automatically reverses sides and
resumes normal play.
In addition, the feature may not work well
with some spoken word, live, or classical
recordings.Compact disc player
Use this button to skip up or down to a
different track.
Push ª
º or ªº side of the ªSEEK/
TRACKº button until the number of the
track you want to listen to appears on the
display. If you want to return to the begin-
ning of the current track, quickly push the
down side of the button one time.
Vehicles with rear seat entertainment sys-
temÐ
While the DVD player is in operation, the
chapter or track can be changed by push-
ing the ª
º or ªº side of the ªSEEK/
TRACKº button.
ST (Stereo reception) display
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. ªSTº appears on the display. If the
signal becomes weak, the radio reduces
the amount of channel separation to prev-
ent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion.
TA P E
Push the ªTAPEº button to play a cassette
tape.
